FORD RANGER 1997 2.G Owners Manual

Maintenance and Care
281
%*
[MC26500(R)01/96]
Tire Rotation
*
[MC26600(R)01/96]
Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them as indicated in the following
diagram.
*
[MC26700(R)05/96]
For tire rotation intervals, see theMaintenance Schedulebooklet.
If you notice that the tires wear unevenly, have them checked.
*
[MC26750(R)03/96]
In situations where the tires differ from front to rear
(snow/traction), simply rotate using a side to side pattern.
[MC26800(R)01/96]
17-1/2 pica
art:0021191-A
Tire rotation pattern
*
[MC26900(R)03/96]
After each rotation, adjust individual tire pressure as specified
on the Safety Compliance Certification Label. Tighten wheel lug
nuts to the required torque specification and retighten again
after 500 miles (800 km).
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997

282
*
[MC27000(R)03/96]
If your vehicle has aluminum wheels, you may demount the full
size, non-temporary spare tire (if so equipped) and remount on
an aluminum wheel to rotate the spare tire into your vehicle's
rotation pattern. Rebalance the wheel.
%*
[MC27300(R)01/96]
Replacing the Tires
*
[MC27400(R)01/96]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
*
[MC27500(R)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
*
[MC27600(R)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC27700(R)03/96]
Your wheels and tires are match-mounted for improved ride.
Before you begin to repair a tire, mark the wheel and tire so
that they are properly aligned when remounted. This will
ensure that the tires will continue to give you the same ride
level.
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997

Maintenancean dCare
283
WARNING
Whe nreplacin gful lsiz etires ,neve rmi xradial,
WARNING
Mak esur etha tal lreplacemen ttire sar e of th esam esize,
WARNING
Do no treplac eyou r4x 2tire swit hªhig hperformanceº

284
WARNING
Do no tus eP235/75R1 5ªAl lSeason ºtires .Fo rRange r4x4
WARNING
D o no tus eP265/75R15S Ltire son theRange r4x 4108
*WARNING
Failur eto follo wthes eprecaution sma yadversel yaffect

Maintenancean dCare
285
*WARNING
Us eof aftermarke twhee lassemblie sma ydamag eyour

286
WARNING
Snowtire smus tbe th esam esiz ean dgrad eas th etires

Maintenance and Care
287
*
[MC31600(R)01/96]
n
Put the chains on tightly with the ends held down securely.
Verify that no chain touches any wiring, brake lines, or fuel
lines. Follow the chain manufacturer's instructions.
*
[MC31700(R)01/96]
n
Drive slowly. If you can hear the chains rub or bang against
your vehicle, stop the vehicle and tighten the chains. If you
continue to hear the chains rub or bang against your vehicle,
remove the chains to prevent damage to your vehicle.
*
[MC31800(R)01/96]
n
Avoid fully loading your vehicle if possible.
*
[MC31850(R)01/96]
n
Tire chains may affect vehicle handling. Drive carefully and
avoid hard braking.
[MC31900(R)01/96]
Remove tire chains at the first opportunity after using them on
snow and ice. Do not use the chains on dry roads.
*
[MC31950(R)01/96]
n
Make sure your suspension insulation and bumpers are not
missing or worn to avoid damage to your vehicle.
%*
[MC31960(R)03/96]
Cleaning the Wheels
*
[MC31970(R)03/96]
Wash the wheels with the same detergent you use to wash your
vehicle's body. Do not use acid-based wheel cleaners, steel wool,
abrasives, fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil remover to
remove grease and tar.
*
[MC31975(R)03/96]
NOTE: Before going to a car wash, find out if the brushes are
abrasive.
[MC31980(R)01/96]
If you have raised white letter tires that are difficult to clean
with regular detergent, use whitewall tire cleaner. Follow the
directions on the container and rinse the tires with plenty of
clean water.
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997

288
%
WARNING
Do no toverfil lth efue ltank .Th epressur ein an

Maintenancean dCare
289
WARNING
If yo udo no tus eth eprope rfue lcap ,th epressur ein the
WARNING
Th efue lsyste mma ybe unde rpressure .If th efue lca p is

290
*
[MC32510(R)01/96]
A venting fuel tank is not an abnormal condition. It may be
caused by:
[MC32520(R)01/96]
n
Too volatile a fuel for the weather conditions. The service
stations sometimes sell winter grade fuel in the spring.
*
[MC32530(R)01/96]
n
Pulling a heavy load on hot days, or at high altitudes.
*
[MC32540(R)01/96]
n
Extended periods of idling with the engine RPM increased
above the normal idle range.
*
[MC32550(R)01/96]
n
Parking vehicle in full sunlight for extended periods on
extremely hot days.
%*
[MC32580(R)01/96]
Choosing the Right Fuel
*
[MC32592(R)05/96]
Use only UNLEADED FUEL. The use of leaded fuel is
prohibited by law and could damage your vehicle. The damage
may not be covered by your warranty.
*
[MC32600(R)05/96]
Your vehicle was not designed to use fuel containing
manganese-based additives such as MMT. Additionally, vehicles
certified to California emission standards (indicated on the
underhood Vehicle Emissions Control Information label) are
designed to operate on California reformulated gasolines. If
California reformulated gasoline is not available when you
refuel, your vehicle can be operated on non-California fuels.
However, even though your engine will perform adequately on
other gasolines, the performance of the emission control devices
and systems may be adversely affected. Repair of damage
caused by using a fuel that your vehicle was not designed for
may not be covered by your warranty.
[MC32620(R)05/96]
Octane Recommendations
*
[MC32640(R)05/96]
Your vehicle is designed to use regular gasoline with an
(R+M)/2 octane rating of 87.We do not recommend gasolines
labeled as ªregularº in high altitude areas that are sold with
octane ratings of 86 or even less.
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997
