engine HYUNDAI I20 2022 Owners Manual

10-14
Maintenance
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
Tyre Pressure,condition & rotation - I,TR I,TR I,TR I,TR I,TR I,TR I,TR I,TR
Fuel lines, hoses and connections IIIIIIII
iMT system clutch tube and line - I IIIIIII
Driveshafts & bootsIIIIIIIII
Fluid leakages IIIIIIIII
Front and rear wheel bearings & bushes Inspect if reqd.
Parking brake (disc/drum ,shoe & operation) - CCCCCCCC
Wheel Alignment & Balancing - Inspect if reqd.
FINAL CHECKS
Bolt and nuts on chasis and body I I IIIIIII
Lubricate locks & hinges ILLLLLLLL
Check all electrical systems (Drive belts ,alterna-
tor)*
9
IIIIIIIII
Warning lights operation & GDS system check I IIIIIIII
Ext & int. lights, horn & gaugesIIIIIIIII
NORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.)
I : Inspect and if necessary adjust,top-up, clean or replace
R : ReplaceC : Clean and Replace if necessary
TR : Tyre Rotation L : Lubricate

10-15
10
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
Power window / Sunroof operation (if equipped) I I IIIIIII
All seat belt operationIIIIIIIII
Road test - - - I - - - - INORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.)I : Inspect and if necessary adjust,top-up, clean or replace
R : ReplaceC : Clean and Replace if necessary

10-16
Maintenance
MAINTENANCE UNDER SEVERE USAGE CONDITIONS - PETROL ENGINEThe following items must be serviced more frequently on cars mainly used under severe driving conditions.
Refer to the chart below for the appropriate maintenance intervals.I : Inspect and if necessary, adjust, correct, clean or replace R:Replace or change
Maintenance itemMaintenance
operationMaintenance intervalsDriving
condition
Engine oil and engine oil filter R1.0 T-GDi every 5,000km (3,000miles) or 6 months
A, B, C, D, E, F,
G, H, I, J , K, L
Smartstream
G1.2every 7,500km (5,000miles) or 6 months
Air cleaner filter R Replace more frequently depending on the condition C, E
Spark plugs R Replace more frequently depending on the condition B, H
Manual transmission fluid
(Intelligent manual transmission fluid)
(if equipped)R Every 120,000 km (80,000 miles)C, D, E, F, G,
H, I, J
Dual clutch transmission fluid
(if equipped)R Every 120,000 km (80,000miles)C, D, E, F, G,
H, I, J
Steering gear rack, linkage and boots I Inspect more frequently depending on the condition C, D, E, F, G

10-17
10
Maintenance itemMaintenance
operationMaintenance intervalsDriving
condition
Front suspension ball joints I Inspect more frequently depending on the condition C, D, E, F, G
Disc brakes and pads, calipers and rotors I Inspect more frequently depending on the condition C, D, E, G, H
Drum brakes and linings I Inspect more frequently depending on the condition C, D, E, G, H
Parking brake I Inspect more frequently depending on the condition C, D, G, H
Driveshaft and boots I Inspect more frequently depending on the conditionC, D, E, F, G,
H, I, J
Climate control air filter R Replace more frequently depending on the condition C, ESevere driving conditionsA : Repeated short distance driving
B : Extensive idling
C : Driving in dusty, rough roads
D : Driving in areas using salt or other corrosive materials or in very
cold weather
E : Driving in the condition of inflowing sand or dust into engineF : Driving in heavy traffic area
G : Driving in mountainous areas
H : Towing a trailer
I : Driving for patrol car, taxi, commercial car or vehicle towing
J : Driving with high speed and rapid accelation
K : Frequently driving in stop-and-go condition
L : Engine oil usage which is not recommended (Mineral type, Semi-
synthetic, Lower grade spec, etc.)

10-18
Maintenance
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
ENGINE BAY
Engine oil & filter *
1 *2 *3
I RRRRRRRR
Drive beltAt first, inspect every 80,000km (50,000miles) or 48months :
after that, inspect every 20,000km (12,500miles) or 12months
Air cleaner filter - C R C R C R C
Battery condition & specific gravityIIIIIIIII
Valve clearance*
4
Inspect at every 90,000 kms or 108 months
Hoses (Vaccum/ EGR / VGT/ WGT) -IIIIIIII
Idler / damper pulley/Adj. Bolt Inspect when replacing the drive belt or timing belt/chain
Brake/Clutch fluid Inspect @ Every service ; Replace @ every 45,000 km or 3 years
Engine Coolant (topup & specify gravity) *
5
Inspect at every service;
Replace first at 120,000 Km or 120 months ; then at every 30,000 Km or 24 months
Manual transaxle fluid *
6
------ I - I
Dual Transmission fluid (if equipped) *
6
No Check ; No Service reqd.
NORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE
C : Clean and Replace if necessary I : Inspect and if necessary adjust,top-up, clean or replace
R : Replace

10-19
10
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
VEHICLE ON FLOOR
Wiper (wiper blade , washer fluid)IIIIIIIII
Brake/Clutch (Pedal free play/Pipes/Hoses/
Connectors)IIIIIIIII
Fuel filler cap - I IIIIIII
Climate control air filter I C R C R C R C R
Check AC system (refrigerant/Compressor)IIIIIIIII
Cooling system (water pump,hoses) & leakage IIIIIIIII
VEHICLE ON LIFT
Steering gear rack, linkage and boots I I IIIIIII
Exhaust system (leakages & damages)IIIIIIIII
Fuel filter*8IIIIIIIII
Fuel tank air filter (If equipped) - -R-R-R
-R
Front & rear suspension (linkages & ball joints)IIIIIIIII
I : Inspect and if necessary adjust,top-up, clean or replace
R : ReplaceC : Clean and Replace if necessary
NORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE (CONT.)

10-20
Maintenance
NORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE (CONT.)
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
Tyre Pressure,condition & rotation - I,TR I,TR I,TR I,TR I,TR I,TR I,TR I,TR
Fuel lines, hoses and connectionsIIIIIIIII
Driveshafts & bootsIIIIIIIII
Fluid leakages I IIIIIIII
Front and rear wheel bearings & bushes Inspect if reqd.
Parking brake (disc/drum ,shoe & operation) - C CCCCCCC
Wheel Alignment & Balancing - Inspect if reqd.
FINAL CHECKS
Bolt and nuts on chasis and body I I IIIIIII
Lubricate locks & hinges ILLLLLLLL
Check all electrical systems (Drive belts ,alterna-
tor)*
9
IIIIIIIII
Warning lights operation & GDS system check I IIIIIIII
Ext & int. lights, horn & gaugesIIIIIIIII
C : Clean and Replace if necessary
TR : Tyre Rotation L : Lubraicate I : Inspect and if necessary adjust,top-up, clean or replace
R : Replace

10-21
10
MAINTENANCE
INTERVALS
MAINTENANCE ITEMNumber of months or driving distance, whichever comes first
Kmsx1,000
1.51020304050607080
Months
2 1224364860728496
Years
- 12345678
Power window / Sunroof operation (if equipped) I I IIIIIII
All seat belt operation IIIIIIIII
Road test - - - I---- INORMAL MAINTENANCE SCHEDULE - DIESEL ENGINEI : Inspect and if necessary adjust,top-up, clean or replace
R : Replace

10-22
Maintenance
Maintenance itemMaintenance
operationMaintenance intervals Driving condition
Engine oil and engine oil filter R Every 5,000 km (3,000 miles) or 6 monthsA, B, C, D, E,
F, G, H, I, J, K, L
Air cleaner filter R Replace more frequently depending on the condition C, E
Manual transmission fluid R Every 120,000 km (80,000 miles)C, D, E, F,
G, H, I, J, K
Steering gear rack, linkage and boots I Inspect more frequently depending on the condition C, D, E, F, G
Front suspension ball joints I Inspect more frequently depending on the condition C, D, E, F, G
Disc brakes and pads, calipers and rotors I Inspect more frequently depending on the condition C, D, E, G, H
Intelligent variable transmission fluid
(if equipped)R Every 100,000 km (60,000 miles)A, C, D, E, F,
G, H, I, K,JMAINTENANCE UNDER SEVERE USAGE CONDITIONS - DIESEL ENGINEThe following items must be serviced more frequently on cars mainly used under severe driving conditions.
Refer to the chart below for the appropriate maintenance intervals.I : Inspect and if necessary, adjust, correct, clean or replace R : Replace or change

10-23
10
Maintenance itemMaintenance
operationMaintenance intervals Driving condition
Parking brake I Inspect more frequently depending on the condition C, D, G, H
Driveshaft and boots I Inspect more frequently depending on the conditionC, D, E, F,
G, H, I, K
Climate control air filter R Replace more frequently depending on the condition C, ESevere driving conditionsA :Repeated short distance driving
B : Extensive idling
C : Driving in dusty, rough roads
D : Driving in areas using salt or other corrosive materials or in very
cold weather
E : Driving in the condition of inflowing sand or dust into engine
F : Driving in heavy traffic areaG : Driving in mountainous areas
H : Using for towing or camping, and driving with loading on the roof
I : Driving for patrol car, taxi, commercial car or vehicle towing
J : Driving in very cold weather
K : Frequently driving under high speed or rapid acceleration
L : Frequently driving in stop-and-go conditions
