change language INFINITI EX 2013 Navigation Manual

Black plate (37,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. After the tone sounds and the icon onthe screen changes from [
] to [],
speak a command.
4. Continue to follow the voice menu
prompts and speak after the tone
sounds until the operation is com-
pleted.
Operating tips
.Speak a command after the tone.
. Commands that are available are al-
ways shown on the display and spoken
through voice menu prompts. Com-
mands other than those that are dis-
played are not accepted. Please follow
the prompts given by the system.
. If the command is not recognized, the
system announces, “Please say again”.
Repeat the command in a clear voice.
. Push once to return to the
previous screen.
. Push and hold >to cancel the
command. The message, “Voice recog-
nition is canceled” will be announced.
. Push >to stop the voice
prompt and give the command at once.
Remember to wait for the tone before speaking.
. To adjust the volume of the system
feedback, push the volume control
buttons <+>or<−> on the steering
wheel or use the audio system volume
control knob while the system is mak-
ing an announcement.
VOICE COMMAND EXAMPLES
To use the voice recognition system,
speaking one command is sometimes
sufficient, but at other times it is necessary
to speak two or more commands. As
examples, some additional basic opera-
tions that can be performed by voice
commands are described here.
Example 1: Placing call to phone number
800-662-6200
1. Push >located on the steering
wheel.
IGT0135
2. The system announces, “Would you like
to access Phone, Navigation, Informa-
tion, Audio or Help?”.
3. Speak “Phone”.
JVH0493X4. Speak“Dial Number”.
IGT01375. Speak“800”.
2. Getting started
2-29
Condition: Language=NAM_English/

Black plate (38,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-30
IGT01386.The system announces, “Please say
next three digits or dial, or say change
number”. Speak “662”.
IGT01397.The system announces, “Please say
last four digits or say change number”.
Speak “6200”.
IGT01408. The system announces, “Dial or Change
Number?”. Speak “Dial”.
IGT01419. The system makes a call to 800-662-
6200.
INFO:
.
Speaking “800-662-6200” (10 continuous
digits) or “662-6200” (7 continuous digits)
is acceptable, if the area code is not
necessary. However the 3-3-4 digit grouping
is recommended for improved recognition.
“How to speak numbers” (page 9-14)
.The INFINITI voice recognition system is not
limited to recognizing phone numbers of
only 7 or 10 digits. To dial a number in a
format other than the 3-3-4 digit grouping,
use the“International Call” command.
.If“Change Number” is spoken during phone
number entry, the system will automatically
request that the number be repeated using
the 3-3-4 format. In this case, speak the
area code first and then follow the prompts.
.Do not add a “1”in front of the area code
when speaking phone numbers.
.If the system does not recognize a spoken
voice command, try repeating the command
using a natural voice. Speaking too slowly
or too loudly may further reduce recognition
accuracy.
Example 2: Placing international call to
phone number 011-81-111-222-333
1. Push >located on the steering
wheel.
Condition: Language=NAM_English/

Black plate (40,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-32
JNB0276X4. Speak“Address”.
IGT01285. Speak the name of the state, “Califor-
nia”.
IGT0130
6. Speak the name of the city, “Gardena”.
IGT01317. Voice feedback will be provided when
the command is accepted, and the list
of city names is displayed.
8. After the tone sounds and the icon on the screen changes again, speak
“Four”.
IGT01299. Speak the name of the street, “South
Figueroa Street”.
INFO:
Only the official street names stored in the
map database can be recognized by the
system. To improve accuracy, speak the
street name precisely and include boule-
vard, way, north, south, etc. If the full name
is not known, speaking only part of the
street name such as “Figueroa”is accepta-
ble, but recognition accuracy may be
reduced.
IGT013210. Voice feedback will be provided when
the command is accepted, and the list
of street names appears.
11. After the tone sounds and the icon on the screen changes again, speak
“One”.
Condition: Language=NAM_English/

Black plate (46,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. Map settings
3-2
MAP TYPES
Two types of map views are available: 2D
map and BirdviewTM(3D) map.
2D MAP
The 2D map displays the map in a 2-
dimensional environment similar to a road
map.
Screen information
JNC0199X
*1Vehicle icon:
Indicates the current vehicle location
and the direction of travel.
*2Guide point:
Indicates a guide point on the route.
*3Remaining time and distance to
the destination:
Indicates the approximate remaining
time and distance to the destination or
waypoint. This indicator will appear
when a destination or waypoint is set
and route guidance is started.
When the vehicle is not driven on the
suggested route, the screen displays
the direction to the destination and the
distance to the destination from the
current vehicle position.
“Switching estimated arrival time
display” (page 5-29)
*4Suggested route:
Appears in bold yellow during route
guidance.
*5/Direction indicator:
Indicates the directional setting of the
map. Touch the icon to change the
setting.
: North always pointing up.
Condition: Language=NAM_English/

Black plate (47,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
: Direction of the vehicle always
pointing up.
“Setting map orientation”
(page 3-14)
*6Scale indicator:
Indicates the scale of the map. Touch
the icon to display the scale bar.
The map scale can be adjusted using
the scale bar.
“Operating with touch panel op-
eration” (page 3-10)
*7Arrow:
Indicates the distance to the next
guide point and the turning direction
at that guide point.
*8Stored location (orange):
Displays the locations that are stored
in the Address Book. Icons can be
changed according to personal prefer-
ences.
“Storing location” (page 6-2)
*9Avoid Area (green or blue):
Displays the areas to avoid that are
stored in the Address Book with green
or blue icons. During the route search,
the route guidance is performed by
searching for a route that avoids those areas.
“Storing avoid area”
(page 6-7)
*10Street name:
Displays the name of the street the
vehicle is currently driving on.
*11Traffic indicator:
Displays the reception condition of the
traffic information transmitted from
the provider.
Green: Reception condition is good.
Gray: Reception condition is not good.
No mark: Subscription to NavTraffic
service is not detected.
BirdviewTM(3D) MAP
BirdviewTMdisplays the map from an
elevated perspective. In BirdviewTM, it is
easy to recognize an image of the route
because it provides a panoramic view over
a long distance.
IMA0073
INFO:
Note the following items about the BirdviewTM
display.
.“BirdviewTM” is a registered trademark of
Clarion Co., Ltd.
.The map in BirdviewTMalways appears with
the current forward direction facing up.
BUILDING GRAPHICS
In an area where the building graphics are
stored in the map data, the building
graphics are displayed when the map is
zoomed in. On the 2D map display, these
are called “Building footprint graphics”,
and on the Birdview
TMdisplay, these are
called “3D building graphics”.
The method to look at the map is the same
for the 2D and Birdview
TMmaps.
3. Map settings
3-3
Condition: Language=NAM_English/

Black plate (52,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. Map settings
3-8
IMA00863.Touch [] or [] to change the
direction of the map.
: Rotates the map clockwise.
: Rotates the map counterclockwise.
INFO:
While driving, one touch continuous scrolling is
disabled. Touch the screen again to scroll
further.
CHANGING SCALE OF MAP
OPERATING WITH ZOOM BUTTONS (if so equipped)
IMA0087
Condition: Language=NAM_English/

Black plate (53,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
Push or. A scale
appears on the right side of the screen.
To view the map in detail, push .
To view a wider area, push .
The scale will automatically disappear
when neither nor OUT> has been pushed for several sec-
onds.
If the scaling operation is not performed
for a specified period of time, the scale
display disappears.
INFO:
Free zoom:
The scale can be changed in smaller steps when
or is pushed and held
than when the button is pushed briefly. When
the button is pushed briefly, the scale can be
changed in large steps.
“Other navigation settings” (page 8-7)
OPERATING WITH CENTER DIAL
IMA0173
1. Turn the center dial when the map
screen is displayed. The map scale is
displayed at the right side of the
screen.
2. Use the center dial to adjust the map scale.
*1Clockwise: Zoom in
*2Counterclockwise: Zoom out
INFO:
Free zoom:
Depending on the setting, using the center dial
to change the map scale may adjust the scale
normally, or it may engage the free zoom (finer
scale adjustment in smaller steps).
“Other navigation settings” (page 8-7)
3. Map settings
3-9
Condition: Language=NAM_English/

Black plate (54,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. Map settings
3-10
OPERATING WITH TOUCH PANEL
OPERATION
IMA00891. Touch [].
The scale is displayed.
IMA00902. Touch [ZOOM IN] or [ZOOM OUT] to change the scale.
INFO:
Free zoom:
Once the [Small Step Zoom by Dial] is set to ON
in the setting screen, the scale can be changed
in smaller steps when [ZOOM IN] or [ZOOM OUT]
is pushed and held than when either button is
briefly pushed. If briefly pushed, the operation
returns to normal.
Voice command
1. Push >located on the steering
wheel.
2. After the tone sounds, speak a com- mand.
To change the map scale:
“Zoom In
<1 to 13>”(Alternate Com-
mand Mode)
“Zoom Out
<1 to 13>” (Alternate Com-
mand Mode)
MAP SCALE
Any required map scale (map coverage)
between 320 miles (640 km) and 1/64 of a
mile (25 m) can be selected.
Scale level for 2D map and Bird-
view
TMmap (3D) display
Normal Map US Units Metric Units
320 miles 640 km 80 miles 160 km
32 miles 64 km8 miles 16 km
5 miles 10 km
2 miles 4 km1 mile 2 km
1/2 mile 1 km
1/4 mile 500 m
1/8 mile 200 m
1/16 mile 100 m
1/32 mile 50 m
Shows build- ing footprint
graphics 1/32 mile 50 m
1/64 mile 25 m
Condition: Language=NAM_English/

Black plate (55,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
IMA0091Example: The most detailed level (2D map)
IMA0092Example: The widest level (2D map)
IMA0093Example: The most detailed level (Bird-viewTMmap)
IMA0094Example: The widest level (BirdviewTMmap)
INFO:
The traffic information icons are not displayed
on the map screen when the map scale is set to
32 miles (64 km) or higher.
“Traffic information display and scale
levels”(page 7-19)
CHANGING MAP VIEW
The map view can be changed between the
2D and BirdviewTMmaps. The map can also
be displayed in the split screen mode.
IMA00951. Push while the current location
map screen is displayed.
IMA00972. Highlight [Map View] and push
.
3. Map settings
3-11
Condition: Language=NAM_English/

Black plate (56,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. Map settings
3-12
IMA00973. Highlight [Change View] and push theright button of the directional buttons
or push the slide switch to the right.
4. Highlight the preferred map view and push . The indicator of the
selected map view illuminates.
5. The display automatically returns to the map screen.
Available views . [2D Map]:
Switches to the 2D map.
. [Birdview (3D)]:
Switches to the Birdview
TMmap.
. [Split: 2D Map]:
Changes to the split screen mode and
both halves display maps in 2D.
. [Split: Birdview Map]:
Changes to the split screen mode and the left half displays the map in 2D and
the right half displays the map in
Birdview
TM.
INFO:
.
When the split screen mode is selected, the
map settings for the left screen can be
changed independently.
“Setting left screen display”
(page 3-17)
.If the split screen mode is selected, the
normal map scrolling and scale adjustment
are set in the right screen.
.The map direction or scale for each screen
can be adjusted independently by touching
an icon on the map.
IMA0098Split: 2D Map
IMA0099Split: BirdviewTMMap
OTHER SETTINGS
The map view can also be set by perform-
ing the following procedure.
IMA01001. Push .
2. Highlight [Navigation] and push
.
3. Highlight [Map View] and push
.
4. Highlight [Change View] and push
.
Condition: Language=NAM_English/
