2. Getting started
2-2
CONTROL BUTTONS AND FUNCTIONS
Designs and button layout may vary
depending on the specifications and the
model.
CONTROL PANEL (Type A)
JNB0275X
*1
Push to enter a destination. Various
methods for entering a destination are
available.
“4. Setting destination”
*2:
Push to access the guidance control
functions (guidance cancellation, route
priority, waypoint setting on the route,
etc.).
“5. Route guidance”
*3INFINITI controller:
Turn to highlight an item on the
screen, and pushto select
the highlighted item.
On the map screen, turn to adjust the
map scale.
To scroll the map, push the controller
in the direction you want to scroll.
“INFINITI controller” (page 2-6)
*4:
Push to display the vehicle, traffic,
weather or voice recognition informa-
tion.
“7. Viewing technical informa-
tion”
*5:
Push multiple times to display audio
information with either the air condi-
tioner status, fuel economy or naviga-
tion directions.
*6:
Push to switch between the day screen
(bright) and the night screen (dark).
Push and hold to turn off the display.
Push again to turn on the display.
Condition: Language=NAM_English/

Black plate (12,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-4
*3INFINITI controller:
Slide or rotate to highlight an item on
the screen, and pushto select
the highlighted item.
On the map screen, turn to adjust the
map scale.
To scroll the map, slide the controller
in the direction you want to scroll.
“INFINITI controller” (page 2-6)
*4:
Push to display the vehicle, traffic,
weather or voice recognition informa-
tion.
“7. Viewing technical informa-
tion”
*5:
Push to access the system settings.
“8. Other settings”
*6:
Push to access the guidance control
functions (guidance cancellation, route
priority, waypoint setting on the route,
etc.).
“5. Route guidance”
*7

Black plate (13,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
CONTROL PANEL (Type C)
IGT0228
*1:
Push to enter a destination. Various
methods for entering a destination are
available.
“4. Setting destination”
*2INFINITI controller:
Slide or rotate to highlight an item on
the screen, and pushto select
the highlighted item.
On the map screen, turn to adjust the
map scale. To scroll the map, slide the INFINITI
controller in the direction you want to
scroll.
“INFINITI controller”
(page 2-6)
*3:
Push to display the vehicle, traffic,
weather or voice recognition informa-
tion.
“7. Viewing technical informa-
tion”
*4:
Push to access the system settings.
“8. Other settings”
*5:
Push to access the guidance control
functions (guidance cancellation, route
priority, waypoint setting on the route,
etc.).
“5. Route guidance”
*6

Black plate (16,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-8
displayed.
“Map menu screen”(page 2-18)
Push and hold while a map or status
screen is shown to display the Start
Menu.
“Start menu” (page 2-13)
If this button is tilted up while the
audio function is activated and the
map or status screen is displayed, the
audio system can be operated.
*2<−+>:
Use to adjust the volume. These
buttons have the same function as
that of the volume control knob. Refer
to the vehicle Owner’s Manual.
*3:
Push this button during a setting
operation to return to the previous
screen. In a settings screen, this
button can also be used to apply the
setting.
*4:
Push to start the voice recognition
system. If the voice recognition system
is already activated, pushing this
button cancels the voice guidance
and a voice command can be spoken immediately.
*5:
Use to switch the audio mode (source).
Refer to the vehicle Owner’s Manual.
*6<>:
Push to display the phone mode
screen.
Refer to the vehicle Owner’s Manual.
*7<>:
Push to change what is shown on the
vehicle information display.
Refer to the vehicle Owner’s Manual.
STARTING SYSTEM
The navigation system starts when the
ignition switch is turned to the ACC or ON
position.
NOTE:
Do not keep the navigation system on with the
engine or the hybrid system stopped. Doing so
may discharge the vehicle battery (12V bat-
tery). When you use the navigation system,
always keep the engine or the hybrid system
running.
Condition: Language=NAM_English/

Black plate (17,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
NAVIGATION SYSTEM STATUS SCREEN
By pushingat any time, a split
screen with audio information that is
always at the top can be displayed.
Each time is pushed, the bottom
part of the screen changes between air
conditioner, fuel economy and navigation
directions.
INFO:
There are different status screens displayed
depending on various factors, such as the
currently active mode, whether a destination
has been set or not, etc.
JNB0195MWhen a route to the destination is set and the
audio system is on, a screen similar to the one above appears.
*1Turning direction at the next intersec-
tion
*2Name of the next street
*3Distance to the next intersection
*4Distance remaining to the destination
*5Remaining time to the destination
JNB0196MWhen a route to the destination is not set
and the audio system is off, a screen
similar to the one above appears.
2. Getting started
2-9
Condition: Language=NAM_English/

Black plate (34,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-26
IGT01191. Push.
2. Highlight [Guidance Settings] and push .
IGT01223. Highlight [Guidance Volume] and push.
IGT01234. Adjust the volume of voice guidance byusing the INFINITI controller.
Other settings
The volume of voice guidance can also be
adjusted by performing the following
procedure.
IGT01241. Push .
2. Highlight [Volume & Beeps] and push . 3. Highlight [Guidance Volume] and push
.
4. Adjust the volume of voice guidance by using the INFINITI controller.
INFO:
The guidance volume can also be adjusted by
turning the audio system volume control knob
or pushing <+>/<−> on the steering wheel while
voice guidance is being announced.
“Steering wheel switches” (page 2-7)
Condition: Language=NAM_English/

Black plate (35,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
INFINITI VOICE RECOGNITION
INFINITI Voice Recognition allows hands-
free operation of the navigation system
and other systems equipped on this
vehicle, such as the phone, vehicle infor-
mation and audio.
INFINITI Voice Recognition can be used in
one of two selectable modes, Standard
Mode or Alternate Command Mode.
In Standard Mode, the commands that are
available are always shown on the display
and announced by the system. To perform
operations, simply follow the prompts
given by the system.
For advanced operations, change to Alter-
nate Command Mode. When this mode is
active, an expanded list of commands can
be spoken after pushing >on the
steering wheel, and the voice command
menu prompts are turned off. Note that in
this mode the recognition success rate may
decrease because there are more com-
mands available and more ways of speak-
ing each command. Otherwise, it is
recommended that Alternate Command
Mode be turned off and Standard Mode
be used for the best recognition perfor-
mance.
INFO:
.
For U.S. customers, Standard Mode is
selected by default. For Canadian custo-
mers, Alternate Command Mode is the
default mode.
.For voice recognition system operations
related to the phone, audio or vehicle
information systems, refer to the vehicle
Owner’s Manual.
.When the system language is set to
“Français” (French) or “Español”(Spanish),
the available commands and functions may
differ from those that are available when
using the system in English.
USING VOICE RECOGNITION SYS-
TEM
Initialization
When the ignition switch is pushed to the
ON position, INFINITI Voice Recognition is
initialized, which may take up to one
minute. When completed, the system is
ready to accept voice commands. If >is pushed before the initialization
completes, the display will show the
message: “System not ready.”
BEFORE STARTING
To get the best recognition performance
from INFINITI Voice Recognition, observe
the following points.
. The interior of the vehicle should be as
quiet as possible. Close the windows to
eliminate the surrounding noises (traf-
fic noise, vibration sounds, etc.), which
may prevent the system from correctly
recognizing the voice commands.
. The voice recognition system cannot be
operated when the retractable hard top
is not closed (for G37 Convertible only).
. Wait until the tone sounds before
speaking a command.
. Speak in a natural conversational voice
without pausing between words.
. If the air conditioner is set to “AUTO”,
the fan speed is automatically lowered
so that commands can be recognized
more easily.
2. Getting started
2-27
Condition: Language=NAM_English/

Black plate (36,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
2. Getting started
2-28
GIVING VOICE COMMANDS
The method of giving a voice command in
Standard Mode is described here.
INI0267Type A
INI0376Type B
IGT0208Type C
IGT0233Type D
JNB0288XType E
1. Pushlocated on the steering
wheel.
IGT01252. A list of commands appears on the screen, and the system provides the
voice menu prompt, “Would you like to
access Phone, Navigation, Information,
Audio or Help?”.
Condition: Language=NAM_English/

Black plate (37,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
3. After the tone sounds and the icon onthe screen changes from [
] to [],
speak a command.
4. Continue to follow the voice menu
prompts and speak after the tone
sounds until the operation is com-
pleted.
Operating tips
.Speak a command after the tone.
. Commands that are available are al-
ways shown on the display and spoken
through voice menu prompts. Com-
mands other than those that are dis-
played are not accepted. Please follow
the prompts given by the system.
. If the command is not recognized, the
system announces, “Please say again”.
Repeat the command in a clear voice.
. Push once to return to the
previous screen.
. Push and hold >to cancel the
command. The message, “Voice recog-
nition is canceled” will be announced.
. Push >to stop the voice
prompt and give the command at once.
Remember to wait for the tone before speaking.
. To adjust the volume of the system
feedback, push the volume control
buttons <+>or<−> on the steering
wheel or use the audio system volume
control knob while the system is mak-
ing an announcement.
VOICE COMMAND EXAMPLES
To use the voice recognition system,
speaking one command is sometimes
sufficient, but at other times it is necessary
to speak two or more commands. As
examples, some additional basic opera-
tions that can be performed by voice
commands are described here.
Example 1: Placing call to phone number
800-662-6200
1. Push >located on the steering
wheel.
IGT0135
2. The system announces, “Would you like
to access Phone, Navigation, Informa-
tion, Audio or Help?”.
3. Speak “Phone”.
JVH0493X4. Speak“Dial Number”.
IGT01375. Speak“800”.
2. Getting started
2-29
Condition: Language=NAM_English/

Black plate (39,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
IGT01422. The system announces,“Would you like
to access Phone, Navigation, Informa-
tion, Audio or Help?”.
3. Speak “Phone”.
JVH0493X4. Speak“International Call ”.
IGT01445. Speak“01181111222333”.
IGT01456. Speak“Dial”.
IGT0146
7. The system makes a call to 011-81-
111-222-333.
INFO:
Any digit input format is available in the
international number input process.
Example 3: Setting destination by street
address
1. Push >located on the steering
wheel.
IGT01262. The system announces, “Would you like
to access Phone, Navigation, Informa-
tion, Audio or Help?”.
3. Speak “Navigation”.
2. Getting started
2-31
Condition: Language=NAM_English/
