Page 1108 of 4462
BR-8
BRAKE PEDAL
Revision: 2006 December 2006 FX35/FX45
INSPECTION AFTER REMOVAL
Make sure the rivets in the upper part of brake pedal are not
deformed.
Make sure that joint length “L” of sub-bracket and sliding plate is
5.5 mm (0.217 in) or more.
Replace brake pedal assembly if any non-standard condition is
detected.
Check clevis pin and plastic stopper for damage and deforma-
tion. Replace clevis pin if there are.
INSTALLATION
Installation in the reverse order of removal.
After installing brake pedal assembly to the vehicle, adjust brake pedal height. Refer to BR-6, "Inspection
and Adjustment" .
SFIA2487E
SBR997
Page 1116 of 4462
BR-16
BRAKE BOOSTER
Revision: 2006 December 2006 FX35/FX45
Removal and InstallationNFS000M6
REMOVAL
CAUTION:
Be careful not to splash brake fluid on painted areas; it may cause paint damage. If brake fluid is
splashed on painted surfaces of body, immediately wipe it off and them wash it away with water
immediately.
Be careful not to deform or bend brake tube while removing and installing brake booster.
Replace clevis pin if it is damaged.
Be careful not to damage brake booster stud bolt threads. If brake booster is tilted or inclined dur-
ing installation, dash panel may damage the threads.
Install the check valve in the correct direction.
1. Remove vacuum hose from brake booster. Refer to BR-17, "
VACUUM LINES" .
2. Remove brake master cylinder. Refer to BR-13, "
Removal and Installation" .
3. Disconnect harness connector from brake booster assembly. (ICC model)
4. Remove snap pin and clevis pin from inside the vehicle. Refer to BR-7, "
Components" .
5. Remove nuts from brake booster and brake pedal bracket.
6. Remove brake booster assembly from engine room.
INSPECTION AFTER REMOVAL
Output Rod Length Inspection
1. Using a handy vacuum pump, apply a vacuum of –66.7 kPa (– 500 mmHg, –19.69 inHg) to brake booster.
2. Check output rod length.
INSTALLATION
1. Loosen lock nut to adjust input rod length so that the length “B” (shown in the figure) satisfies the specified value.
2. After adjusting “B”, temporarily tighten lock nut to install brake booster assembly to the vehicle. At this time, make sure to
install a gasket between brake booster assembly and the engine
room.
3. Connect brake pedal with clevis of input rod.
4. Install brake pedal bracket mounting nuts and bolt and tighten them to the specified torque. BR-7, "
Components" .
5. Install brake tube from brake master cylinder to ABS actuator. Refer to BR-11, "
Hydraulic Circuit" .
6. Install master cylinder to booster assembly. Refer to BR-13, "
Removal and Installation" .
7. Adjust the height and play of brake pedal. BR-6, "
Inspection and Adjustment" .
8. Tighten lock nut of input rod to the specified torque. Refer to BR-15, "
Components" .
9. Bleed air. Refer to BR-10, "
Bleeding Brake System" .
Standard dimension when applying a vacuum of
− 66.7 kPa ( −500 mmHg, −19.69 inHg):
15.6 − 15.9 mm (0.614 − 0.626 in)
SFIA2146E
Length “B” : 126.5 mm (4.98 in)
SGIA0060E
Page 1252 of 4462
DI-2Revision: 2006 December 2006 FX35/FX45 Oil Pressure Warning Lamp Does Not Turn Off (Oil
Pressure Is Normal) ............................................. ... 49
Component Inspection ......................................... ... 51
OIL PRESSURE SWITCH ................................ ... 51
A/T INDICATOR ..................................................... ... 52
System Description .............................................. ... 52
MANUAL MODE ............................................... ... 52
NOT MANUAL MODE ...................................... ... 52
Wiring Diagram — AT/IND — .............................. ... 53
A/T Indicator Is Malfunction ................................. ... 55
WARNING CHIME .................................................. ... 56
System Description .............................................. ... 56
POWER SUPPLY AND CIRCUIT ..................... ... 56
IGNITION KEY WARNING CHIME (WITHOUT
INTELLIGENT KEY) ......................................... ... 57
IGNITION KEY WARNING CHIME (WITH INTEL-
LIGENT KEY) ................................................... ... 57
LIGHT WARNING CHIME ................................ ... 58
SEAT BELT WARNING CHIME ........................ ... 58
Component Parts and Harness Connector Location ... 59
Schematic ............................................................ ... 60
Wiring Diagram — CHIME — .............................. ... 61
Terminals and Reference Value for BCM ............. ... 64
Terminals and Reference Value for Unified Meter
and A/C Amp. ...................................................... ... 68
Terminals and Reference Value for Combination
Meter ................................................................... ... 69
CONSULT-II Function (METER A/C AMP) .......... ... 69
CONSULT-II Function (BCM) ............................... ... 69
DIAGNOSIS ITEMS DESCRIPTION ................ ... 69
CONSULT-II BASIC OPERATION .................... ... 69
DATA MONITOR ............................................... ... 69
ACTIVE TEST .................................................. ... 70
SELF-DIAG RESULTS ..................................... ... 70
Trouble Diagnosis ................................................ ... 70
HOW TO PERFORM TROUBLE DIAGNOSIS . ... 70
PRELIMINARY INSPECTION .......................... ... 71
Symptom Chart .................................................... ... 71
Power Supply and Ground Circuit Inspection ...... ... 71
Combination Meter Buzzer Circuit Inspection ...... ... 72
Front Door Switch (Driver Side) Signal Inspection ... 74
Key Switch Signal Inspection (Without Intelligent
Key) ..................................................................... ... 75
Key Switch and Ignition Knob Switch Signal Inspec-
tion (With Intelligent Key, When Mechanical Key Is
Used) ................................................................... ... 76
Lighting Switch Signal Inspection ........................ ... 77
Seat Belt Buckle Switch (Driver Side) Signal Inspec-
tion ....................................................................... ... 78
Component Inspection ......................................... ... 79
FRONT DOOR SWITCH (DRIVER SIDE) ........ ... 79
KEY SWITCH ................................................... ... 79
KEY SWITCH AND IGNITION KNOB SWITCH ... 79
SEAT BELT BUCKLE SWITCH (DRIVER SIDE) ... 79
LANE DEPARTURE WARNING SYSTEM ............. ... 80
Precautions for Lane Departure Warning (LDW)
system ................................................................. ... 80
System Description .............................................. ... 80 LDW SYSTEM OPERATION ............................
... 80
POWER SUPPLY AND GROUND CIRCUIT .... ... 82
Action Test ........................................................... ... 83
LDW SYSTEM RUNNING TEST ...................... ... 83
Camera Aiming Adjustment ................................. ... 83
OUTLINE .......................................................... ... 83
PREPARATION ................................................. ... 83
TARGET SETTING ........................................... ... 83
VEHICLE HEIGHT CHECK .............................. ... 86
AIMING ADJUSTMENT .................................... ... 86
Component Parts and Harness Connector Location ... 90
Schematic ............................................................ ... 91
Wiring Diagram — LDW — .................................. ... 92
Terminals and Reference Value for LDW Camera
Unit ....................................................................... ... 95
CONSULT-II Function (LDW) ............................... ... 95
DESCRIPTION ................................................. ... 95
CONSULT-II BASIC OPERATION .................... ... 95
WORK SUPPORT ............................................ ... 95
SELF-DIAG RESULTS ...................................... ... 95
DATA MONITOR ............................................... ... 96
ACTIVE TEST ................................................... ... 97
Trouble Diagnosis ................................................ ... 98
HOW TO PERFORM TROUBLE DIAGNOSIS . ... 98
SYMPTOM CHART ........................................... ... 98
Preliminary Inspection .......................................... ... 98
Power Supply and Ground Circuit Inspection ...... ... 99
DTC [C1B00] CAMERA UNIT MALF ................... .100
DTC [C1B01] CAM AIMING INCMP .................... .100
DTC [C1B02] VHCL SPD DATA MALF ................ .100
DTC [C1B03] ABNRML TEMP DETECT ............. .101
DTC [U1000] CAN COMM CIRCUIT ................... .101
DTC [U1010] CONTROL UNIT (CAN) ................. .101
LDW Chime Circuit Inspection ............................. .101
LDW Switch Circuit Inspection ............................. .102
LDW Indicator Lamp Circuit Inspection ................ .105
Turn Signal Input Inspection ................................ .106
Electrical Component Inspection ......................... .106
LDW SWITCH ................................................... .106
Removal and Installation for LDW Camera Unit .. .107
REMOVAL ......................................................... .107
INSTALLATION ................................................. .107
Removal and Installation for LDW Chime ............ .107
REMOVAL ......................................................... .107
INSTALLATION ................................................. .107
Removal and Installation for LDW Switch ............ .107
CAN COMMUNICATION ........................................ .108
System Description .............................................. .108
CAN Communication Unit .................................... .108
COMPASS .............................................................. .109
Precautions for Compass ..................................... .109
System Description .............................................. .109
Troubleshooting ................................................... .110
Zone Variation Setting Procedure ........................ . 111
Calibration Procedure .......................................... . 111
Wiring Diagram — COMPAS — ........................... .112
Removal and Installation of Compass .................. .113
CLOCK ................................................................... .114
Page 1336 of 4462
DI-86
LANE DEPARTURE WARNING SYSTEM
Revision: 2006 December 2006 FX35/FX45
7. Mark point at the center of the point “E” and “F”, on the line “FW”.
CAUTION:
Make sure that “E” through “X” is equal to “F” through “X”.
8. Position the center of the right target to the point of “X”.
VEHICLE HEIGHT CHECK
Measure the wheel arch height. And calculate “Dh”.
NOTE:
“Dh” may be calculated as a minus value.
AIMING ADJUSTMENT
Operation Procedure
CAUTION:
Perform the adjustment under unloaded vehicle condition.
LDW indicator is turned off after the removal/installation, and blinks after replacement.
1. With the ignition switch OFF, connect CONSULT-II and CON- SULT-II CONVERTER to the data link connector, and then turn
ignition switch ON.
2. Start the engine, wait for at least 10 seconds, and touch “START (NISSAN BASED VHCL)”.
PKIB5331E
Dh [mm] = (Hfl + Hfr) ÷ 2 − 840
where, Hfl: Front left wheel arch height [mm]
Hfr: Front right wheel arch height [mm]
SKIB3164E
PBIB1503E
BCIA0029E
Page 1998 of 4462
![INFINITI FX35 2006 User Guide EC-614
[VQ35DE]
DTC P2A00, P2A03 A/F SENSOR 1
Revision: 2006 December 2006 FX35/FX45
10. CHECK INTERMITTENT INCIDENT
Perform EC-148, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
OK or NG
OK >>](/img/42/57019/w960_57019-1997.png "INFINITI FX35 2006 User Guide EC-614
[VQ35DE]
DTC P2A00, P2A03 A/F SENSOR 1
Revision: 2006 December 2006 FX35/FX45
10. CHECK INTERMITTENT INCIDENT
Perform EC-148, \"
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT\" .
OK or NG
OK >>")
EC-614
[VQ35DE]
DTC P2A00, P2A03 A/F SENSOR 1
Revision: 2006 December 2006 FX35/FX45
10. CHECK INTERMITTENT INCIDENT
Perform EC-148, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
OK or NG
OK >> GO TO 11.
NG >> Repair or replace.
11 . REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) sensor 1.
CAUTION:
Discard any air fuel ratio (A/F) sensor which has been dropped from a height of more than 0.5 m
(19.7 in) onto a hard surface such as a concrete floor; use a new one.
Before installing new air fuel ratio (A/F) sensor, clean exhaust system threads using Heated Oxy-
gen Sensor Thread Cleaner tool J-43897-18 or J-43897-12 and approved anti-seize lubricant.
>> GO TO 12.
12. CONFIRM A/F ADJUSTMENT DATA
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-II.
3. Make sure that “0.000” is displayed on CONSULT-II screen.
OK or NG
OK >> INSPECTION END
NG >> GO TO 13.
PBIB3202E
Page 2677 of 4462
![INFINITI FX35 2006 User Guide DTC P2A00, P2A03 A/F SENSOR 1 EC-1293
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
11 . REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) s](/img/42/57019/w960_57019-2676.png "INFINITI FX35 2006 User Guide DTC P2A00, P2A03 A/F SENSOR 1 EC-1293
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
11 . REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) s")
DTC P2A00, P2A03 A/F SENSOR 1 EC-1293
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
11 . REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) sensor 1.
CAUTION:
Discard any A/F sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; use a new one.
Before installing new A/F sensor, clean exhaust system threads using Oxygen Sensor Thread
Cleaner tool J-43897-18 or J-43897-12 and approved anti-seize lubricant.
>> GO TO 12.
12. CONFIRM A/F ADJUSTMENT DATA
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-II.
3. Make sure that “0.000” is displayed on CONSULT-II screen.
OK or NG
OK >> INSPECTION END
NG >> GO TO 13.
13. CLEAR THE SELF-LEARNING DATA.
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Select “SELF-LEARNING CONT” in “WORK SUPPORT” mode with CONSULT-II.
3. Clear the self-learning control coefficient by touching “CLEAR”.
Without CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF.
3. Disconnect mass air flow sensor (1) harness connector.
4. Restart engine and let it idle for at least 5 seconds.
5. Stop engine and reconnect mass air flow sensor harness con- nector.
6. Make sure DTC P0102 is displayed.
7. Erase the DTC memory. Refer to EC-727, "
HOW TO ERASE
EMISSION-RELATED DIAGNOSTIC INFORMATION" .
8. Make sure DTC P0000 is displayed.
>> GO TO 14.
PBIB3202E
SEF968Y
PBIB3230E
Page 2797 of 4462
EM-3
C
D E
F
G H
I
J
K L
M
EM A
Revision: 2006 December 2006 FX35/FX45 ANCE ...............................................................
. 147
MAIN BEARING OIL CLEARANCE ................. . 148
MAIN BEARING CRUSH HEIGHT ................... . 149
CONNECTING ROD BEARING CRUSH
HEIGHT ............................................................ . 149
MAIN BEARING CAP BOLT OUTER DIAMETER . 149
CONNECTING ROD BOLT OUTER DIAMETER . 150
DRIVE PLATE .................................................. . 150
OIL JET ............................................................ . 150
OIL JET RELIEF VALVE .................................. . 150
SERVICE DATA AND SPECIFICATIONS (SDS) ... . 151
Standard and Limit .............................................. . 151
GENERAL SPECIFICATIONS ......................... . 151
DRIVE BELT .................................................... . 152
INTAKE MANIFOLD COLLECTOR, INTAKE
MANIFOLD AND EXHAUST MANIFOLD ........ . 152
SPARK PLUG .................................................. . 152
CAMSHAFT AND CAMSHAFT BEARING ....... . 153
CYLINDER HEAD ............................................ . 155
CYLINDER BLOCK .......................................... . 158
PISTON, PISTON RING AND PISTON PIN ..... . 159
CONNECTING ROD ........................................ . 160
CRANKSHAFT ................................................. . 161
MAIN BEARING ............................................... . 162
CONNECTING ROD BEARING ....................... . 163
VK45DE
PRECAUTIONS ..................................................... . 164
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect ..................................... . 164
OPERATION PROCEDURE ............................ . 164
Precautions for Drain Engine Coolant and Engine
Oil ........................................................................ . 164
Precautions for Disconnecting Fuel Piping ......... . 164
Precautions for Removal and Disassembly ........ . 164
Precautions for Inspection, Repair and Replace-
ment .................................................................... . 164
Precautions for Assembly and Installation .......... . 164
Parts Requiring Angle Tightening ........................ . 165
Precautions for Liquid Gasket ............................. . 165
REMOVAL OF LIQUID GASKET SEALING ..... . 165
LIQUID GASKET APPLICATION PROCEDURE . 165
PREPARATION ...................................................... . 167
Special Service Tools .......................................... . 167
Commercial Service Tools ................................... . 169
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... . 171
NVH Troubleshooting — Engine Noise ............... . 171
Use the Chart Below to Help You Find the Cause
of the Symptom. .................................................. . 172
ENGINE ROOM COVER ....................................... . 173
Components ........................................................ . 173
Removal and Installation ..................................... . 173
REMOVAL ........................................................ . 173
INSTALLATION ................................................ . 173
DRIVE BELTS ........................................................ . 174
Components ........................................................ . 174 Checking Drive Belts ...........................................
.174
Tension Adjustment ............................................. .174
Removal and Installation ..................................... .174
REMOVAL ........................................................ .174
INSTALLATION ................................................ .175
Components ........................................................ .176
Drive Belt Auto Tensioner and Idler Pulley .......... .176
REMOVAL ........................................................ .176
INSTALLATION ................................................ .176
AIR CLEANER AND AIR DUCT ............................ .177
Components ........................................................ .177
Removal and Installation ..................................... .177
REMOVAL ........................................................ .177
INSPECTION AFTER REMOVAL .................... .178
INSTALLATION ................................................ .178
Changing Air Cleaner Filter ................................. .178
REMOVAL ........................................................ .178
INSTALLATION ................................................ .178
INTAKE MANIFOLD .............................................. .179
Components ........................................................ .179
Removal and Installation ..................................... .180
REMOVAL ........................................................ .180
INSPECTION AFTER REMOVAL .................... .182
INSTALLATION ................................................ .182
INSPECTION AFTER INSTALLATION ............. .182
EXHAUST MANIFOLD AND THREE WAY CATA-
LYST ....................................................................... .183
Components ........................................................ .183
Removal and Installation ..................................... .183
REMOVAL ........................................................ .183
INSPECTION AFTER REMOVAL .................... .185
INSTALLATION ................................................ .185
OIL PAN AND OIL STRAINER .............................. .187
Components ........................................................ .187
Removal and Installation ..................................... .187
REMOVAL ........................................................ .187
INSPECTION AFTER REMOVAL .................... .189
INSTALLATION ................................................ .189
INSPECTION AFTER INSTALLATION ............. .190
IGNITION COIL ...................................................... .191
Components ........................................................ .191
Removal and Installation ..................................... .191
REMOVAL ........................................................ .191
INSTALLATION ................................................ .191
SPARK PLUG (PLATINUM-TIPPED TYPE) .......... .192
Components ........................................................ .192
Removal and Installation ..................................... .192
REMOVAL ........................................................ .192
INSPECTION AFTER REMOVAL .................... .192
INSTALLATION ................................................ .193
FUEL INJECTOR AND FUEL TUBE ..................... .194
Components ........................................................ .194
Removal and Installation ..................................... .194
REMOVAL ........................................................ .194
INSTALLATION ................................................ .196
INSPECTION AFTER INSTALLATION ............. .198
Page 2798 of 4462
EM-4Revision: 2006 December 2006 FX35/FX45
ROCKER COVER ..................................................
.200
Components ........................................................ .200
Removal and Installation ..................................... .200
REMOVAL ........................................................ .200
INSTALLATION ................................................. .202
TIMING CHAIN ....................................................... .203
Components ........................................................ .203
Removal and Installation ..................................... .204
REMOVAL ........................................................ .204
INSPECTION AFTER REMOVAL ..................... .208
INSTALLATION ................................................. .208
INSPECTION AFTER INSTALLATION ............. .214
CAMSHAFT ............................................................ .215
Components ........................................................ .215
Removal and Installation ..................................... .215
REMOVAL ........................................................ .215
INSPECTION AFTER REMOVAL ..................... .216
INSTALLATION ................................................. .219
INSPECTION AFTER INSTALLATION ............. .221
Valve Clearance ................................................... .222
INSPECTION .................................................... .222
ADJUSTMENT ................................................. .224
OIL SEAL ............................................................... .228
Removal and Installation of Valve Oil Seal .......... .228
REMOVAL ........................................................ .228
INSTALLATION ................................................. .228
Removal and Installation of Front Oil Seal .......... .229
REMOVAL ........................................................ .229
INSTALLATION ................................................. .229
Removal and Installation of Rear Oil Seal ........... .230
REMOVAL ........................................................ .230
INSTALLATION ................................................. .230
CYLINDER HEAD .................................................. .232
On-Vehicle Service .............................................. .232
CHECKING COMPRESSION PRESSURE ...... .232
Components ........................................................ .233
Removal and Installation ..................................... .233
REMOVAL ........................................................ .233
INSPECTION AFTER REMOVAL ..................... .234
INSTALLATION ................................................. .234
Disassembly and Assembly ................................. .236
COMPONENTS ................................................ .236
DISASSEMBLY ................................................ .236
ASSEMBLY ...................................................... .237
Inspection After Disassembly .............................. .238
VALVE DIMENSIONS ....................................... .238
VALVE GUIDE CLEARANCE ........................... .239
VALVE GUIDE REPLACEMENT ...................... .239
VALVE SEAT CONTACT .................................. .241
VALVE SEAT REPLACEMENT ........................ .241
VALVE SPRING SQUARENESS ...................... .242
VALVE SPRING DIMENSIONS AND VALVE
SPRING PRESSURE LOAD ............................ .242 ENGINE ASSEMBLY ..............................................
.243
Components ......................................................... .243
Removal and Installation ...................................... .243
REMOVAL ......................................................... .243
INSTALLATION ................................................. .246
INSPECTION AFTER INSTALLATION ............. .246
CYLINDER BLOCK ................................................ .248
Components ......................................................... .248
Disassembly and Assembly ................................. .249
DISASSEMBLY ................................................. .249
ASSEMBLY ....................................................... .253
How to Select Piston and Bearing ....................... .258
DESCRIPTION ................................................. .258
HOW TO SELECT PISTON .............................. .259
HOW TO SELECT CONNECTING ROD BEAR-
ING .................................................................... .260
HOW TO SELECT MAIN BEARING ................. .261
Inspection After Disassembly ............................... .265
CRANKSHAFT END PLAY ............................... .265
CONNECTING ROD SIDE CLEARANCE ........ .265
PISTON TO PISTON PIN OIL CLEARANCE .... .265
PISTON RING SIDE CLEARANCE .................. .266
PISTON RING END GAP ................................. .266
CONNECTING ROD BEND AND TORSION .... .267
CONNECTING ROD BIG END DIAMETER ..... .267
CONNECTING ROD BUSHING OIL CLEAR-
ANCE ................................................................ .267
CYLINDER BLOCK DISTORTION ................... .268
MAIN BEARING HOUSING INNER DIAMETER .269
PISTON TO CYLINDER BORE CLEARANCE . .269
CRANKSHAFT MAIN JOURNAL DIAMETER .. .270
CRANKSHAFT PIN JOURNAL DIAMETER ..... .271
CRANKSHAFT OUT-OF-ROUND AND TAPER .271
CRANKSHAFT RUNOUT ................................. .271
CONNECTING ROD BEARING OIL CLEAR-
ANCE ................................................................ .272
MAIN BEARING OIL CLEARANCE .................. .273
CRUSH HEIGHT OF MAIN BEARING ............. .274
CRUSH HEIGHT OF CONNECTING ROD
BEARING .......................................................... .274
DRIVE PLATE ................................................... .274
SERVICE DATA AND SPECIFICATIONS (SDS) ... .275
Standard and Limit ............................................... .275
GENERAL SPECIFICATIONS .......................... .275
DRIVE BELTS ................................................... .275
INTAKE MANIFOLD AND EXHAUST MANI-
FOLD ................................................................ .275
SPARK PLUG ................................................... .276
CAMSHAFT AND CAMSHAFT BEARING ........ .276
CYLINDER HEAD ............................................. .278
CYLINDER BLOCK ........................................... .281
PISTON, PISTON RING AND PISTON PIN ..... .282
CONNECTING ROD ......................................... .283
CRANKSHAFT .................................................. .284
MAIN BEARING ................................................ .286
CONNECTING ROD BEARING ........................ .287
Page 3650 of 4462
LT-88
FRONT FOG LAMP
Revision: 2006 December 2006 FX35/FX45
Aiming AdjustmentNKS002X9
Front fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb. Before performing aiming
adjustment, make sure of the following.
Keep all tires inflated to correct pressure.
Place vehicle on level ground.
See that vehicle is unloaded (except for full levels of coolant, engine oil and fuel, and spare tire, jack, and
tools). Have the driver or equivalent weight placed in driver seat.
Adjust aiming in the vertical direction by turning adjusting screw.
1. Set the distance between the screen and the center of front fog lamp lens as shown at left.
2. Turn front fog lamps ON.
3. Adjust front fog lamps using adjusting screw so that the top edge of the high intensity zone is 100 mm (3.94 in) below the height of
front fog lamp centers as shown at left.
When performing adjustment, if necessary, cover headlamps
and opposite front fog lamp.
PKIC9713E
PKIB1672E
PKIB1673E
Page 4455 of 4462
REAR WIPER AND WASHER SYSTEM WW-53
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
Washer Nozzle AdjustmentNKS0033J
Adjust washer nozzle with suitable tool as shown in the figure.
Unit: mm (in)
Removal and Installation of Washer NozzleNKS0033K
REMOVAL
1. Remove high-mounted stop lamp. Refer to LT- 1 3 0 , "High-
Mounted Stop Lamp" .
2. Remove screw and remove washer nozzle from high-mounted stop lamp.
INSTALLATION
Installation is the reverse order of removal.
Spray position h (height) (width) φ
S
A, B 2.5 (0.098) 80 (3.15) 30 (1.18)
Adjustable range : ±15 ° (In any direction)
SKIA5088E
SKIA5087E
PKIB6132E
