Page 1877 of 3371
EI-36
FLOOR TRIM
Revision: August 20072004 QX56
FLOOR TRIMPFP:74902
Removal and InstallationEIS002XK
1. Remove front seats. Refer to SE-96, "FRONT SEAT" .
Remove subwoofer. Refer to AV- 4 6 , "Removal and Installation of Subwoofer" .
Remove navigation display control unit. Refer to AV- 1 5 8 , "Removal and Installation of Display Control
Unit" .
2. Remove second row seats. Refer to SE-103, "
Second Row Outboard" and SE-103, "Second Row Cen-
ter" , if equipped.
3. Remove third row rear seat. Refer to SE-103, "
Third Row" .
4. Remove lower seat belt anchors. Refer to SB-3, "
SEAT BELTS" .
5. Remove lower body side trim. Refer to EI-34, "
BODY SIDE TRIM" .
6. Remove luggage lower side finishers (left / right). Refer to EI-39, "
LUGGAGE FLOOR TRIM" .
7. Remove kicking plates. Refer to EI-34, "
BODY SIDE TRIM" .
8. Remove center console. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
9. Remove rear console, if equipped. Refer to IP-17, "
Rear Console" .
10. Remove rear lower finisher. Refer to EI-39, "
LUGGAGE FLOOR TRIM" .
11. Remove carpet.
12. Remove floor mat hooks from front carpet.
Installation is in the reverse order of removal.
1. Inspection hole cover 2. Seal 3. Carpet
4. Floor mat hook 5. Plastic clip
WIIA0267E
Page 2084 of 3371
PRECAUTIONS
GI-3
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: August 20072004 QX56
PRECAUTIONSPFP:00001
DescriptionEAS00146
Observe the following precautions to ensure safe and proper servicing. These precautions are not
described in each individual section.
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EAS00147
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WA RN ING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM -
NATS) (If Equipped)
EAS001QV
NVIS/IVIS (NATS) will immobilize the engine if someone tries to start it without the registered key of NVIS/IVIS
(NATS).
Both of the originally supplied ignition key IDs have been NVIS/IVIS (NATS) registered.
The security indicator is located on the instrument panel. The indicator blinks when the immobilizer system is
functioning.
Therefore, NVIS/IVIS (NATS) warns outsiders that the vehicle is equipped with the anti-theft system.
When NVIS/IVIS (NATS) detects trouble, the security indicator lamp lights up while ignition switch is in
"ON" position.
This lighting up indicates that the anti-theft is not functioning, so prompt service is required.
When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), CONSULT-II hardware and CONSULT-II NVIS/IVIS (NATS)
software is necessary.
Regarding the procedures of NVIS/IVIS (NATS) initialization and NVIS/IVIS (NATS) ignition key ID regis-
tration, refer to CONSULT-II operation manual, NVIS/IVIS (NATS).
Therefore, CONSULT-II NVIS/IVIS (NATS) software (program card and operation manual) must be kept
strictly confidential to maintain the integrity of the anti-theft function.
When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), it may be necessary to re-register original key identification.
Therefore, be sure to receive all keys from vehicle owner. A maximum of four or five key IDs can be regis-
tered into NVIS/IVIS (NATS).
When failing to start the engine first time using the key of NVIS/IVIS (NATS), start as follows.
1. Leave the ignition key in "ON" position for approximately 5 seconds.
2. Turn ignition key to "OFF" or "LOCK" position and wait approximately 5 seconds.
3. Repeat step 1 and 2 again.
4. Restart the engine while keeping the key separate from any others on key-chain.
Page 2109 of 3371
GI-28
SERVICE INFORMATION FOR ELECTRICAL INCIDENT
Revision: August 20072004 QX56
Freezing
Water intrusion
Electrical load
Cold or hot start up
Get a thorough description of the incident from the customer. It is important for simulating the conditions of the
problem.
Vehicle Vibration
The problem may occur or become worse while driving on a rough road or when engine is vibrating (idle with
A/C on). In such a case, you will want to check for a vibration related condition. Refer to the following illustra-
tion.
CONNECTORS & HARNESS
Determine which connectors and wiring harness would affect the electrical system you are inspecting. Gently
shake each connector and harness while monitoring the system for the incident you are trying to duplicate.
This test may indicate a loose or poor electrical connection.
HINT
Connectors can be exposed to moisture. It is possible to get a thin film of corrosion on the connector termi-
nals. A visual inspection may not reveal this without disconnecting the connector. If the problem occurs inter-
mittently, perhaps the problem is caused by corrosion. It is a good idea to disconnect, inspect and clean the
terminals on related connectors in the system.
SENSORS & RELAYS
Gently apply a slight vibration to sensors and relays in the system you are inspecting.
This test may indicate a loose or poorly mounted sensor or relay.
ENGINE COMPARTMENT
There are several reasons a vehicle or engine vibration could cause an electrical complaint. Some of the
things to check for are:
Connectors not fully seated.
Wiring harness not long enough and is being stressed due to engine vibrations or rocking.
Wires laying across brackets or moving components.
Loose, dirty or corroded ground wires.
Wires routed too close to hot components.
To inspect components under the hood, start by verifying the integrity of ground connections. (Refer to Ground
Inspection described later.) First check that the system is properly grounded. Then check for loose connection
by gently shaking the wiring or components as previously explained. Using the wiring diagrams inspect the
wiring for continuity.
BEHIND THE INSTRUMENT PANEL
An improperly routed or improperly clamped harness can become pinched during accessory installation. Vehi-
cle vibration can aggravate a harness which is routed along a bracket or near a screw.
SG I8 39
Page 2136 of 3371
GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION GW
A
B
GW
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Handling for Adhesive and Primer ........................... 3
Trouble Diagnosis Precaution .................................. 3
PREPARATION ........................................................... 4
Special Service Tool ................................................. 4
Commercial Service Tool ......................................... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINER ....................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
WINDSHIELD GLASS ...............................................11
Removal and Installation .........................................11
REMOVAL ............................................................11
INSTALLATION ....................................................11
REAR WINDOW GLASS AND MOLDING ............... 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 14
POWER WINDOW SYSTEM .................................... 15
Component Parts and Harness Connector Location ... 15
System Description ................................................ 15
MANUAL OPERATION ....................................... 16AUTO OPERATION ............................................. 18
POWER WINDOW SERIAL LINK ....................... 18
POWER WINDOW LOCK ................................... 18
RETAINED POWER OPERATION ...................... 18
ANTI-PINCH SYSTEM ........................................ 18
POWER WINDOW CONTROL BY THE FRONT
DOOR LOCK ASSEMBLY LH (KEY CYLINDER
SWITCH) ............................................................. 19
CAN Communication System Description .............. 19
Schematic ............................................................... 20
Wiring Diagram — WINDOW — ............................. 22
Terminal and Reference Value for Main Power Win-
dow and Door Lock/Unlock Switch ......................... 30
Terminal and Reference Value for Power Window
and Door Lock/Unlock Switch RH .......................... 30
Terminal and Reference Value for BCM ................. 32
Work Flow ............................................................... 33
CONSULT-II Function (BCM) ................................. 33
CONSULT-II INSPECTION PROCEDURE .......... 33
ACTIVE TEST ..................................................... 34
WORK SUPPORT ............................................... 34
DATA MONITOR ................................................. 34
Trouble Diagnoses Symptom Chart ....................... 36
BCM Power Supply and Ground Circuit Check ...... 38
Main Power Window and Door Lock/Unlock Switch
Power Supply and Ground Circuit Check ............... 39
Power Window and Door Lock/Unlock Switch RH
Power Supply and Ground Circuit Check ............... 40
Front Power Window Motor LH Circuit Check ........ 41
Front Power Window Motor RH Circuit Check ....... 42
Limit Switch Circuit Check Front LH ....................... 43
Limit Switch Circuit Check Front RH ...................... 44
Encoder Circuit Check Front LH ............................. 46
Encoder Circuit Check Front RH ............................ 48
Door Switch Check ................................................. 50
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 52
Power Window Serial Link Check Front LH and RH ... 54
Rear Power Window Control Unit LH or RH Power
Supply and Ground Circuit Check .......................... 56
Page 2142 of 3371
SQUEAK AND RATTLE TROUBLE DIAGNOSES
GW-7
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
80845-71L00: 30 mm (1.18 in) thick, 30×50 mm (1.18×1.97 in)
FELT CLOTH TAPE
Used to insulate where movement does not occur. Ideal for instrument panel applications.
68370-4B000: 15×25 mm (0.59×0.98 in) pad/68239-13E00: 5 mm (0.20 in) wide tape roll. The following mate-
rials not found in the kit can also be used to repair squeaks and rattles.
UHMW (TEFLON) TAPE
Insulates where slight movement is present. Ideal for instrument panel applications.
SILICONE GREASE
Used instead of UHMW tape that will be visible or not fit.
Note: Will only last a few months.
SILICONE SPRAY
Use when grease cannot be applied.
DUCT TAPE
Use to eliminate movement.
CONFIRM THE REPAIR
Confirm that the cause of a noise is repaired by test driving the vehicle. Operate the vehicle under the same
conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
Generic Squeak and Rattle TroubleshootingEIS002UJ
Refer to Table of Contents for specific component removal and installation information.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between:
1. The cluster lid A and instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar garnish
4. Instrument panel to windshield
5. Instrument panel mounting pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by
pressing on the components while driving to stop the noise. Most of these incidents can be repaired by apply-
ing felt cloth tape or silicone spray (in hard to reach areas). Urethane pads can be used to insulate wiring har-
ness.
CAUTION:
Do not use silicone spray to isolate a squeak or rattle. If you saturate the area with silicone, you will
not be able to recheck the repair.
CENTER CONSOLE
Components to pay attention to include:
1. Shifter assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Pay attention to the:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from
the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
Page 2240 of 3371
IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Brake lines and cables inspection ..................... MA-27
Brake master cylinder ....................................... BR-15
Brake switch .................................................... EC-551
BRK/SW - Wiring diagram ............................... EC-552
Bulb specifications ........................................... LT-170
Bumper, front ...................................................... EI-13
Bumper, rear ....................................................... EI-15
C
Cabin air filter .................................................... MA-20
Camshaft ........................................................... EM-43
Camshaft inspection .......................................... EM-47
Camshaft position sensor (PHASE) ................ EC-261
CAN - Wiring diagram EC-136, LAN-18, LAN-52, LAN-
92, LAN-128
CAN (Controller Area Network) .. WT-9, BRC-10, LAN-
16, LAN-50, LAN-90, LAN-126
CAN communication . EC-31, EC-135, AT-103, WT-9,
BRC-10
, LAN-16, LAN-50, LAN-90, LAN-126
Canister-See EVAP canister ........................... EC-636
Center case (Transfer) ..................................... TF-113
CHARGE - Wiring diagram ............................... SC-18
Charging system ............................................... SC-17
Chassis and body maintenance ........................ MA-20
Chassis and body maintenanceSchedule 1 ........ MA-7
Chassis and body maintenanceSchedule 2 ........ MA-9
CHIME - Wiring diagram ..................................... DI-46
Circuit breaker ................................................... PG-67
Clock ................................................................... DI-70
CLOCK - Wiring diagram .................................... DI-70
Closed loop control ........................................... EC-27
Closed loop control (Bank 1) ........................... EC-407
Closed loop control (Bank 2) ........................... EC-407
Clutch drum (Transfer) ..................................... TF-116
Clutch force release limit adjustment ................. TF-42
Clutch pressure switch (Transfer) ...................... TF-95
Coil spring (front) ............................................. FSU-10
Collision diagnosis .......................................... SRS-60
Combination lamp, front, removal and installation . LT-
33
Combination lamp, rear, removal and installation .. LT-
122
Combination meter ................................................ DI-5
Combination switch ............................................ LT-97
COMBSW - Wiring diagram ............................... LT-97
COMM - Wiring diagram ................................... AV-87
COMPAS - Wiring diagram ................................. DI-27
Compass ............................................................. DI-26
Component Location (auto A/C) ...................... ATC-37
Compressor clutch removal and installation . ATC-167
Compressor mounting ................................... ATC-166
Compressor precaution ................................... ATC-11
Compressor special service tool ..................... ATC-14
Condenser ..................................................... ATC-173
Connecting rod .................................................. EM-91
Connecting rod bearing clearance .................... EM-91
Connecting rod bushing clearance .................... EM-91
Console box - See Instrument panel ................... IP-10
Console box lamp ............................................. LT-152
CONSULT for all-mode 4WD ............................. TF-31
CONSULT for VDC ......................................... BRC-28
CONSULT-II for engine ................................... EC-103
Control units (terminal arrangement) ................. PG-71
Control valve (A/T) ............................................. AT-37
Control valve (Transfer) .................................... TF-119
Controller Area Network (CAN) . WT-9, BRC-10, LAN-
16, LAN-50, LAN-90, LAN-126
Converter housing installation ............ AT-257, AT-260
COOL/F - Wiring diagram ................................ EC-413
Coolant mixture ratio ......................................... MA-11
Coolant replacement ......................................... MA-12
Cooling circuit (engine) ........................................ CO-6
Cooling fan ........................................................ CO-13
Cooling fan control ........................................... EC-410
Cooling fan motor ............................................ EC-419
Cooling unit (A/C evaporator) ....... ATC-144, ATC-175
Corrosion protection ......................................... BL-167
Crankcase ventilation system - See Positive crankcase
ventilation ........................................................ EC-645
Crankshaft ......................................................... EM-74
Crankshaft position sensor (POS) ................... EC-255
Crash zone sensor .......................................... SRS-55
Cylinder block .................................................... EM-73
Cylinder block boring ......................................... EM-94
D
D/LOCK - Wiring diagram ................................... BL-20
Data link connector .......................................... EC-105
Daytime light system .......................................... LT-34
Daytime running light - See Daytime light system .. LT-
34
DEF - Wiring diagram ....................................... GW-82
Diagnosis sensor unit ...................................... SRS-58
Diagnostic trouble code (DTC) .......................... EC-53
Diagnostic trouble code (DTC) for OBD system .. EC-8
Diagnostic trouble code (DTC) inspection priority chart
EC-76
Differential carrier assembly ............................ RFD-11
Differential carrier disassembly ....................... RFD-13
Differential gear oil replacement ........................ MA-25
Dimensions ......................................................... GI-49
Direct clutch solenoid valve ................ AT-157, AT-160
Display and amp.assembly .............................. ATC-60
Display Control Unit ......................................... AV-158
Dome light - See Interior lamp .......................... LT-129
Door glass .......................................... GW-69, GW-72
Door lock .......................................................... BL-132
Door mirror lamp ............................................... LT-129
Door trim .............................................................. EI-31
Door, front ........................................... BL-129, GW-69
Door, rear ........................................... BL-129, GW-72
Drive belt ........................................................... EM-12
Drive chain (Transfer) ....................................... TF-115
Drive pinion diff. inspection .............................. RFD-12
Drive pinion height ........................................... RFD-17
Drive shaft (rear) ................................................ RAX-7
Page 2242 of 3371
IDX-5
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
H
H/AIM - Wiring diagram ...................................... LT-66
H/LAMP - Wiring diagram .................................. LT-10
Handling precautions for plastics ..................... BL-189
Harness connector ............................................ PG-68
Harness layout .................................................. PG-40
Hazard warning lamp ......................................... LT-80
Headlamp ............................................................. LT-6
Headlamp aiming control ................................... LT-65
Headlamp leveler - See Headlamp aiming control . LT-
65
Headlamp removal and installation .................... LT-33
Heated oxygen sensor 2 (bank 1) .... EC-186, EC-196,
EC-383
, EC-395
Heated oxygen sensor 2 (bank 2) .... EC-186, EC-196,
EC-383
, EC-395
Heated oxygen sensor 2 heater (bank 1) ........ EC-138
Heated oxygen sensor 2 heater (bank 2) ........ EC-138
Heated seat ....................................................... SE-89
Heater and cooling unit (Heater core) . ATC-144, ATC-
147
Heater unit (heater core) ............... ATC-144, ATC-147
Height (Dimensions) ........................................... GI-49
HFC134a (R134a) system identification ........... ATC-7
HFC134a (R134a) system precaution ............... ATC-5
HFC134a (R134a) system service procedure ATC-162
HFC134a (R134a) system service tools ......... ATC-14
HFC134a system service equipment precaution ATC-
11
High and low reverse clutch solenoid valve .... AT-163,
AT-166
Horn ................................................................ WW-56
HORN - Wiring diagram .................................. WW-56
How to erase DTC for OBD system .................. EC-62
HSEAT - Wiring diagram ................................... SE-91
I
I/MIRR - Wiring diagram ................................... GW-76
IATS - Wiring diagram ..................................... EC-162
ICC - Wiring diagram ....................................... ACS-20
ICC/BS - Wiring diagram ................................. EC-527
ICC/SW - Wiring diagram ................................ EC-512
ICCBOF - Wiring diagram ............................... EC-614
Identification plate .............................................. GI-47
Idle air volume learning ..................................... EC-44
Idle mixture ratio ................................................ EC-33
Idle speed .......................................................... EC-33
Idle speed control (ISC) .................... EC-342, EC-344
Ignition coil .......................................... EM-26, EC-583
Ignition control system .................................... EC-583
Ignition key hole illumination ............................ LT-129
Ignition timing .................................................... EC-33
IGNSYS - Wiring diagram ............................... EC-584
ILL - Wiring diagram ......................................... LT-158
Illumination ....................................................... LT-152
Illumination control .............................. LT-152, LT-169
In vehicle sensor ........................... ATC-128, ATC-137
In-cabin Microfilter ............................................. MA-20
INJECT - Wiring diagram ................................. EC-596
Injector ............................................................. EC-595
Input clutch solenoid valve ................. AT-145, AT-148
Instrument panel .................................................. IP-10
Instrument panel speaker .................................. AV-46
INT/L - Wiring diagram ..................................... LT-135
Intake air temperature sensor ............ EC-161, EC-181
Intake door control linkage adjustment . ATC-78, ATC-
80
Intake door motor ........................... ATC-76, ATC-151
Intake manifold .................................................. EM-15
Intake sensor ................................ ATC-133, ATC-139
Intelligent cruise control (ICC) system ............... ACS-6
Interior ................................................................. EI-34
Interior lamp ...................................................... LT-129
Interior lamp on-off control ................................ LT-129
Internal gear (Transfer) ..................................... TF-127
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-17
IVIS (Infiniti vehicle immobilizer system) precautions ...
GI-3
J
Jacking points ..................................................... GI-40
Junction box (J/B) .............................................. PG-76
K
Key illumination ................................................ LT-129
Keyless entry system - See Multi-remote control system
BL-44
Knock sensor (KS) ........................................... EC-250
KS - Wiring diagram ........................................ EC-251
L
Length (Dimensions) .......................................... GI-49
License lamp .................................................... LT-108
Lifting points ....................................................... GI-41
Line pressure solenoid valve ........................... AT-124
Line pressure switch (Transfer) .......................... TF-95
Line pressure test (A/T) ..................................... AT-59
Liquid gasket application ......................... LU-2, FFD-2
Location of electrical units ................................. PG-64
Low coast brake solenoid valve .......... AT-169, AT-172
Low tire pressure warning system ...................... WT-7
Low tire pressure warning system - trouble diagnoses
WT-10
Low tire pressure warning system - Wiring diagram .....
WT-10
Lubricant (R134a) A/C ..................................... ATC-22
Lubricants .......................................................... MA-10
Lubrication circuit (engine) .................................. LU-5
Lubrication oil A/C ........................................... ATC-22
Lubrication-locks, hinges and hood latches ....... MA-30
Page 2246 of 3371
IP-1
INSTRUMENT PANEL
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION IP
A
B
IP
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 3
SQUEAK AND RATTLE TROUBLE DIAGNOSIS ...... 4
Work Flow ................................................................ 4
CUSTOMER INTERVIEW ..................................... 4
DUPLICATE THE NOISE AND TEST DRIVE ....... 5
CHECK RELATED SERVICE BULLETINS ........... 5
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 5
REPAIR THE CAUSE ........................................... 5
CONFIRM THE REPAIR ....................................... 6
Generic Squeak and Rattle Troubleshooting ........... 6INSTRUMENT PANEL .......................................... 6
CENTER CONSOLE ............................................. 6
DOORS ................................................................. 6
TRUNK .................................................................. 7
SUNROOF/HEADLINING ..................................... 7
OVERHEAD CONSOLE (FRONT AND REAR) ..... 7
SEATS ................................................................... 7
UNDERHOOD ....................................................... 7
Diagnostic Worksheet ............................................... 8
INSTRUMENT PANEL ASSEMBLY ......................... 10
Removal and Installation ........................................ 10
REMOVAL AND INSTALLATION ........................ 12
Disassembly and Assembly .................................... 15
CENTER CONSOLE ........................................... 15
Disassembly and Assembly .................................... 17
REAR CONSOLE ................................................ 17
Page 2251 of 3371
IP-6
SQUEAK AND RATTLE TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
73982-9E000: 45 mm (1.77 in) thick, 50 x 50 mm (1.97 x 1.97 in)/73982-50Y00: 10 mm (0.39 in) thick, 50 x 50
mm (1.97 x 1.97 in)
INSULATOR (Light foam block)
80845-71L00: 30 mm (1.18 in) thick, 30 x 50 mm (1.18 x 1.97 in)
FELT CLOTH TAPE
Used to insulate where movement does not occur. Ideal for instrument panel applications.
68370-4B000: 15 x 25 mm (0.59 x 0.98 in) pad/68239-13E00: 5 mm (0.20 in) wide tape roll
The following materials, not found in the kit, can also be used to repair squeaks and rattles.
UHMW (TEFLON) TAPE
Insulates where slight movement is present. Ideal for instrument panel applications.
SILICONE GREASE
Used in place of UHMW tape that will be visible or not fit.
Note: Will only last a few months.
SILICONE SPRAY
Use when grease cannot be applied.
DUCT TAPE
Use to eliminate movement.
CONFIRM THE REPAIR
Confirm that the cause of a noise is repaired by test driving the vehicle. Operate the vehicle under the same
conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
Generic Squeak and Rattle TroubleshootingEIS00637
Refer to Table of Contents for specific component removal and installation information.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between:
1. The cluster lid A and instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar garnish
4. Instrument panel to windshield
5. Instrument panel mounting pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by
pressing on the components while driving to stop the noise. Most of these incidents can be repaired by apply-
ing felt cloth tape or silicone spray (in hard to reach areas). Urethane pads can be used to insulate wiring har-
ness.
CAUTION:
Do not use silicone spray to isolate a squeak or rattle. If you saturate the area with silicone, you will
not be able to recheck the repair.
CENTER CONSOLE
Components to pay attention to include:
1. Shifter assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Pay attention to the:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Page 2255 of 3371
IP-10
INSTRUMENT PANEL ASSEMBLY
Revision: August 20072004 QX56
INSTRUMENT PANEL ASSEMBLYPFP:68200
Removal and InstallationEIS00639
WIIA0589E
