alarm JEEP COMMANDER 2006 1.G Owners Manual

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys..................14
▫Ignition Key..........................14
▫Key-In-Ignition Reminder................15

Sentry Key Immobilizer System..............15
▫Important Note About Service.............16
▫Replacement Keys......................16
▫Customer Key Programming..............17
▫General Information....................17

Illuminated Entry........................18
Doors And Door Locks....................18
▫Manual Door Locks.....................18
▫Power Door Locks.....................20

Remote Keyless Entry.....................21
▫To Unlock The Doors...................21
▫To Lock The Doors.....................22
▫To Release The Liftgate Flipper Glass........22
▫Using The Panic Alarm..................23
▫General Information....................24
2

▫Transmitter Battery Service...............24

Security Alarm System — If Equipped.........25
▫ToSetTheAlarm ......................26
▫To Disarm The System...................26

Liftgate...............................27
▫Liftgate Flipper Glass...................28

Power Windows........................29
▫Auto Down..........................30
▫Auto Up Feature With Anti-Pinch Protection
(Driver’s And Front Passenger Door Only)....30
▫Window Lockout Switch.................31
▫Wind Buffeting........................31

Occupant Restraints......................32▫Lap/Shoulder Belts.....................33
▫Lap/Shoulder Belt Operating Instructions.....34
▫Adjustable Upper Shoulder Belt Anchorage....37
▫Automatic Locking Mode — If Equipped.....38
▫Energy Management Feature..............38
▫Seat Belt Pretensioners...................39
▫Enhanced Seat Belt Use Reminder System
(BeltAlert)...........................40
▫Seat Belts And Pregnant Women............41
▫Seat Belt Extender......................41
▫Driver And Front Passenger Supplemental
Restraint Systems (SRS)..................42
▫Child Restraint........................58

Engine Break-In Recommendations...........68
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Automatic Unlock on Exit Feature — Only
Available if Auto Lock is Enabled
This feature will unlock all the doors when the driver’s
door is opened if the vehicle is stopped and in P (Park) or
N (Neutral). Refer to “Electronic Vehicle Information
Center (EVIC) — Customer Programmable Features” in
Section 4 of this manual or see your authorized dealer.
REMOTE KEYLESS ENTRY
This system allows you to lock or unlock the doors,
liftgate, or activate the panic alarm from distances up to
about 23 feet (7 meters) using a hand held radio trans-
mitter. The transmitter need not be pointed at the vehicle
to activate the system.
NOTE:If the key is in the ignition switch, then all
buttons on that transmitter will be disabled. The buttons
on the remaining transmitters will work. If the vehicle is
shifted out of P (Park), all the transmitter buttons are
disabled for all keys.
To Unlock the Doors
Press and release the “Unlock” button on the transmitter
once to unlock the driver’s door, or twice to unlock all
doors. The turn signal lights will flash twice to acknowl-
edge the unlock signal. The illuminated entry system also
turns on.
Four Button Transmitter
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

WARNING!
Driving with the flipper glass open can allow poi-
sonous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the flipper glass closed when you are operating the
vehicle.
Using The Panic Alarm
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
if the vehicle speed is 15 mph (24 km/h) or greater.NOTE:The interior lights will turn off when the ignition
is switched to the ACC or ON position after the panic
alarm is activated. However, the exterior lights and horn
will remain on.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.To Turn Off “Flash Lights On Lock/Unlock”
NOTE:If desired, the “Flash Lights On Lock/Unlock”
feature can be turned on and off by referring to the
Customer Programmable Features of the “Electronic Ve-
hicle Information Center (EVIC)” section or by following
these steps.
1. Press and hold the “Unlock” button for 4 to 10
seconds.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

2. Remove and replace the battery. Avoid touching the
new battery with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.3. To reassemble the transmitter case, join the two halves
of the case together. Install and tighten the screw until
snug. Make sure there is an even “gap” between the two
halves. Test transmitter operation.
SECURITY ALARM SYSTEM — IF EQUIPPED
This system monitors the vehicle doors, liftgate, liftgate
flipper glass, and ignition for unauthorized operation.
When the alarm is activated, the system provides both
audible and visual signals. The horn will sound repeat-
edly for three minutes and the headlights and taillights
will flash for an additional 15 minutes.
Separating Transmitter Halves
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

To Set the Alarm
The alarm will set when you use the remote keyless entry
transmitter to lock the doors and liftgate or when you use
the power door lock switch while the door is open. After
all the doors are locked and closed, a red light (located in
the instrument cluster) will flash rapidly for about 16
seconds to signal that the system is arming. During this
16 second pre-arm period, opening any door or the
liftgate will cancel the arming. If the system successfully
arms, the red light will flash at a slower rate to indicate
the alarm is set. A manual lock of the doors, either with
the door lock plunger located on the inside of the doors
or with the driver’s door key lock cylinder, will not set
the alarm.
To Disarm the System
To disarm the system, use the remote keyless entry
transmitter. Also, using a valid sentry key and moving
the ignition switch to the ON/START position will
disarm the system. If something has triggered the system
in your absence, the horn will sound three times when
you unlock the doors. Check the vehicle for tampering.
The Security Alarm System is designed to protect your
vehicle; however, you can create conditions where the
system will arm unexpectedly. If you remain in the
vehicle and lock the doors with the transmitter, once the
system is armed (after 16 seconds), when you pull the
door handle to exit the alarm will sound. If this occurs,
press the “Unlock” button on the remote keyless entry
transmitter to disarm the system. The Security Alarm
System will not disarm with a manual unlock, either
through the lock plunger located on the inside of the
door, or through a key in the driver’s door key cylinder.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

OVERHEAD CONSOLE — IF EQUIPPED
The overhead console contains an optional universal
garage door opener (HomeLink), storage for sunglasses,
and optional power sunroof switches.
GARAGE DOOR OPENER — IF EQUIPPED
The HomeLinkUniversal Transceiver replaces up to
three remote controls (hand held transmitters) that oper-
ate devices such as garage door openers, motorized
gates, or home lighting. It triggers these devices at the
push of a button. The Universal Transceiver operates off
your vehicle’s battery and charging system; no batteries
are needed.
NOTE:The HomeLinkUniversal Transceiver is dis-
abled when the Vehicle Theft Alarm is active.
For additional information on HomeLink, call 1–800–
355–3515, or on the internet at www.homelink.com.
Overhead Console
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

If the ABS light is on, the brake system should be serviced
as soon as possible to restore the benefits of Anti-Lock
brakes. If the ABS light does not turn on when the
Ignition switch is turned to the ON position, have the
light inspected by an authorized dealer.
8. Tachometer
The red segments indicate the maximum permissible
engine revolutions-per-minute (r.p.m. x 1000) for each
gear range. Before reaching the red area, ease up on the
accelerator.
9. Security Alarm System Indicator Light — If
Equipped
This light will flash rapidly for approximately 15 seconds
when the vehicle theft alarm is arming. The light will
flash at a slower speed continuously after the alarm is set.
The security light will also come on for about three
seconds when the ignition is first turned on.10. Oil Pressure Warning Light
This light shows low engine oil pressure. The light
should turn on momentarily when the engine is
started. If the light turns on while driving, stop the
vehicle, and shut off the engine as soon as possible. A
continuous chime will sound when this light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
11. Electronic Stability Program (ESP) Indicator
Light/Traction Control System (TCS) Indicator Light
This indicator light starts to flash as soon as the
tires lose traction and the ESP system becomes
active. The “ESP/TCS Indicator Light” also
flashes when TCS is active. If the “ESP/TCS
Indicator Light” begins to flash during acceleration, ease
up on the accelerator and apply as little throttle as
possible. Be sure to adapt your speed and driving to the
180 UNDERSTANDING YOUR INSTRUMENT PANEL

5. Connect the other cable, first to the negative terminal
of the booster battery and then connect the other end to
a non-paint metal surface on the engine of the vehicle
with the discharged battery. Make sure you have a good
contact on the engine.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.
NOTE:To start the vehicle following connection of a
booster battery, the Security Alarm System must first be
disabled by cycling a front door key cylinder or by using
the keyless entry transmitter.WARNING!
Jump starting can be dangerous. To avoid personal
injury or damage to electrical components in vehicle,
observe the following warnings:
•Battery fluid is a corrosive acid solution and can burn
or even blind you. Don’t allow battery fluid to contact
your eyes, skin, or clothing. Don’t lean over a battery
when attaching clamps. If acid splashes in eyes or on
skin, flush the area immediately with large amounts of
water.
•Do not use a booster battery or any other booster
source that has a greater than 12–volt system, i.e., do
not use a 24–volt power source.
•Never attempt to jump start a discharged battery that
is frozen, because it could rupture or explode during
jump starting.
WHAT TO DO IN EMERGENCIES 339
6

ABS (Anti-Lock Brake System)............179,271
Adding Washer Fluid..................... 169
Adjustable Pedals....................... 147
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 358
Air Conditioner Maintenance............... 360
Air Conditioning........................ 232
Air Conditioning, Operating Tips............ 236
Air Conditioning, Rear Zone................ 243
Air Conditioning Refrigerant............... 361
Air Conditioning System.................. 232
AirFilter .............................. 358
Air Pressure, Tires....................... 290
Airbag................................ 42
Airbag Deployment....................... 54
Airbag Light....................... 56,70,179
Airbag Maintenance....................... 56
Alarm (Security Alarm)................. 25,180
Alarm System (Security Alarm)............... 25
Alignment and Balance................... 296Alterations/Modifications, Vehicle............. 9
Antenna, Satellite Radio................... 229
Antifreeze (Engine Coolant)................ 388
Anti-Lock Brake System (ABS)............132,271
Anti-Lock Warning Light.................. 179
Anti-Theft System..................... 25,180
Appearance Care........................ 377
Auto Down Power Windows................ 30
AutomaticDimmingMirror ................. 79
Automatic Door Locks..................... 20
Automatic Headlights.................... 123
Automatic Temperature Control (ATC)......... 237
Automatic Transmission................256,372
Adding Fluid......................... 374
Fluid and Filter Changes................. 372
Fluid Level Check...................... 373
FluidType ........................... 372
Special Additives...................... 375
Torque Converter...................... 262
420 INDEX
