these outputs vary by the requirements of the mar-
ket for which the vehicle is manufactured. In all
cases, the visual output will be a flashing on and off
of the exterior lamps. For vehicles equipped with the
North American or the ROW base version of the
VTA, the audible output will be a pulsing of the horn.
For vehicles with the ROW premium version of the
VTA, the audible output will be a cycling of the
alarm siren. See the owner's manual in the vehicle
glove box for details of the alarm output require-
ments of the specific market for which the vehicle
was manufactured. The inputs that will trigger the
alarm include the door ajar switches, the tailgate
ajar switch, the flip-up glass ajar switch, and in vehi-
cles built for certain markets where they are
required, the hood ajar switch and the Intrusion
Transceiver Module (ITM).
²TAMPER ALERT- The VTA tamper alert fea-
ture will pulse the horn (or the alarm siren for the
ROW premium version of the VTA) three times upon
VTA disarming, if the alarm was triggered and has
since timed-out. This feature alerts the vehicle oper-
ator that the VTA alarm was activated while the
vehicle was unattended.
²INTRUSION ALARM- The intrusion alarm is
an exclusive feature of the ROW premium version of
the VTA, which is only available in certain markets
where it is required. When the VTA is armed, a
motion sensor in the Intrusion Transceiver Module
(ITM) monitors the interior of the vehicle for move-
ment. If motion is detected, the ITM sends an elec-
tronic message to the BCM over the PCI data bus to
invoke the visual alarm feature, and sends an elec-
tronic message to the alarm siren in the engine com-
partment over a dedicated serial bus to invoke the
audible alarm feature. The motion detect feature of
the ITM can be disabled by depressing the ªLockº
button on the RKE transmitter three times within
fifteen seconds during VTA arming, while the secu-
rity indicator is still flashing rapidly. The VTA pro-
vides a single short siren ªchirpº as an audible
confirmation that the motion detect disable request
has been received. The ITM must be electronically
enabled in order for the intrusion alarm to perform
as designed. The logic in the ITM keeps its intrusion
alarm function dormant until it is enabled using a
DRBIIItscan tool. The intrusion alarm function of
the ITM is enabled on vehicles equipped with thisoption at the factory, but a service replacement ITM
must be configured and enabled by the dealer using a
DRBIIItscan tool. Refer to the appropriate diagnos-
tic information.
SENTRY KEY IMMOBILIZER SYSTEM The Sen-
try Key Immobilizer System (SKIS) is designed to
provide passive protection against unauthorized vehi-
cle use by disabling the engine after about two sec-
onds of running, whenever any method other than a
valid Sentry Key is used to start the vehicle. The
SKIS is considered a passive protection system
because it is always active when the ignition system
is energized and does not require any customer inter-
vention. The SKIS uses Radio Frequency (RF) com-
munication to obtain confirmation that the key in the
ignition switch is a valid key for operating the vehi-
cle. The microprocessor-based SKIS hardware and
software also use electronic messages to communi-
cate with other electronic modules in the vehicle over
the Programmable Communications Interface (PCI)
data bus. (Refer to 8 - ELECTRICAL/ELECTRONIC
CONTROL MODULES/COMMUNICATION - OPER-
ATION).
Pre-programmed Sentry Key transponders are pro-
vided with the vehicle from the factory. Each Sentry
Key Immobilizer Module (SKIM) will recognize a
maximum of eight Sentry Keys. If the customer
would like additional keys other than those provided
with the vehicle, they may be purchased from any
authorized dealer. These additional keys must be pro-
grammed to the SKIM in the vehicle in order for the
system to recognize them as valid keys. This can be
done by the dealer using a DRBIIItscan tool or, if
Customer Learn programming is an available SKIS
feature in the market where the vehicle was pur-
chased, the customer can program the additional
keys, as long as at least two valid Sentry Keys are
already available. (Refer to 8 - ELECTRICAL/VEHI-
CLE THEFT SECURITY - STANDARD PROCE-
DURE - TRANSPONDER PROGRAMMING).
The SKIS performs a self-test each time the igni-
tion switch is turned to the On position, and will
store fault information in the form of Diagnostic
Trouble Codes (DTC's) if a system malfunction is
detected. The SKIS can be diagnosed, and any stored
DTC's can be retrieved using a DRBIIItscan tool.
Refer to the appropriate diagnostic information.
KJVEHICLE THEFT SECURITY 8Q - 5
VEHICLE THEFT SECURITY (Continued)

DIAGNOSIS AND TESTING - VEHICLE THEFT
SECURITY SYSTEM
The Vehicle Theft Security System (VTSS) is
divided into two basic subsystems: Vehicle Theft
Alarm (VTA) and Sentry Key Immobilizer System
(SKIS). Following are the recommended procedures
for diagnosis and testing of each of these two sub-
systems.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
VEHICLE THEFT ALARM
Models equipped with the Rest-Of-World (ROW)
premium version of the Vehicle Theft Alarm (VTA)
provide some preliminary diagnostic feedback by illu-minating the security indicator located in the Elec-
troMechanical Instrument Cluster (EMIC). If the
security indicator illuminates with the ignition
switch in the On position, it indicates that there is a
communication problem between the Intrusion
Transceiver Module (ITM) and the Body Control
Module (BCM), or between the ITM and the siren
module. The BCM will also turn on the security indi-
cator if it receives a message from the ITM indicating
that the ITM has stored a Diagnostic Trouble Code
(DTC) for a siren module fault.
The hard wired circuits and components of the
VTA may be diagnosed and tested using conventional
diagnostic tools and procedures. However, conven-
tional diagnostic methods may not prove conclusive
in the diagnosis of the Body Control Module (BCM),
the ElectroMechanical Instrument Cluster (EMIC),
the Intrusion Transceiver Module (ITM), or the Pro-
grammable Communications Interface (PCI) data bus
network. The most reliable, efficient, and accurate
means to diagnose the BCM, the EMIC, the ITM,
and the PCI data bus network inputs and outputs
related to the VTA requires the use of a DRBIIIt
scan tool. Refer to the appropriate diagnostic infor-
mation.
Refer to the appropriate wiring information. The
wiring information includes wiring diagrams, proper
wire and connector repair procedures, further details
on wire harness routing and retention, as well as
pin-out and location views for the various wire har-
ness connectors, splices and grounds.
8Q - 6 VEHICLE THEFT SECURITYKJ
VEHICLE THEFT SECURITY (Continued)

electronic circuitry of the ITM which includes a
microprocessor, and an ultrasonic receive transducer.
A molded plastic connector receptacle containing six
terminal pins that is soldered to a small circuit board
and extends through a clearance hole in the left front
corner of the ITM housing, and an ultrasonic trans-
mit transducer housing extends from the center of
the right side of the ITM housing. Both the transmit
transducer on the right side of the module and the
receive transducer on the ITM circuit board are
aimed through two small round holes in the sight
shield of the trim cover. The ITM is connected to the
vehicle electrical system by a dedicated take out and
connector of the overhead wire harness that is inte-
gral to the headliner.
The ITM unit cannot be adjusted or repaired and,
if faulty or damaged, it must be replaced. The ITM is
serviced as a unit with the trim cover.
OPERATION
The microprocessor in the Intrusion Transceiver
Module (ITM) contains the motion sensor logic cir-
cuits and controls all of the features of the premium
version of the Vehicle Theft Alarm (VTA). The ITM
uses On-Board Diagnostics (OBD) and can communi-
cate with other electronic modules in the vehicle as
well as with the DRBIIItscan tool using the Pro-
grammable Communications Interface (PCI) data bus
network. This method of communication is used by
the ITM to communicate with the Body Control Mod-
ule (BCM) and for diagnosis and testing through the
16-way data link connector located on the driver side
lower edge of the instrument panel. The ITM also
communicates with the alarm siren over a dedicated
serial bus circuit.
The ITM microprocessor continuously monitors
inputs from its on-board motion sensor circuitry as
well as inputs from the BCM and the alarm siren
module. The on-board ITM motion sensor circuitry
transmits ultrasonic signals into the vehicle cabin
through a transmit transducer, then listens to the
returning signals as the bounce off of objects in the
vehicle interior. If an object is moving in the interior,
a detection circuit in the ITM senses this movement
through the modulation of the returning ultrasonic
signals that occurs due to the Doppler effect. The
motion detect function of the ITM can be disabled by
depressing the ªLockº button on the Remote Keyless
Entry (RKE) transmitter three times within fifteen
seconds, while the security indicator is still flashing
rapidly. The ITM will signal the alarm siren module
to provide a single siren ªchirpº as an audible confir-
mation that the motion sensor function has been dis-
abled.
If movement is detected, the ITM sends an elec-
tronic message to the BCM over the PCI data bus toflash the exterior lighting and sends an electronic
message to the alarm siren module over a dedicated
serial bus line to sound the siren. When the BCM
detects a breach in the perimeter protection through
a door, tailgate, flip-up glass, or hood ajar switch
input, it sends an electronic message to the ITM and
the ITM sends an electronic message to the BCM
over the PCI data bus to flash the exterior lighting
and sends an electronic message to the alarm siren
module over a dedicated serial bus line to sound the
siren. The ITM also monitors inputs from the alarm
siren module for siren battery or siren input/output
circuit tamper alerts, and siren battery condition
alerts, then sets active and stored Diagnostic Trouble
Codes (DTC) for any monitored system faults it
detects. An active fault only remains for the current
ignition switch cycle, while a stored fault causes a
DTC to be stored in memory by the ITM. If a fault
does not recur for fifty ignition cycles, the ITM will
automatically erase the stored DTC.
The ITM is connected to the vehicle electrical sys-
tem through a dedicated take out and connector of
the overhead wire harness. The ITM receives battery
current on a fused B(+) circuit through a fuse in the
Junction Block (JB), and receives ground through a
ground circuit and take out of the body wire harness.
This ground take out has a single eyelet terminal
connector that is secured by a ground screw to the
base of the left D-pillar behind the quarter trim
panel. These connections allow the ITM to remain
operational, regardless of the ignition switch position.
The hard wired inputs and outputs for the ITM may
be diagnosed and tested using conventional diagnos-
tic tools and procedures. However, conventional diag-
nostic methods will not prove conclusive in the
diagnosis of the ITM, the PCI data bus network, or
the electronic message inputs to and outputs from
the ITM. The most reliable, efficient, and accurate
means to diagnose the ITM, the PCI data bus net-
work, and the electronic message inputs to and out-
puts from the ITM requires the use of a DRBIIIt
scan tool. Refer to the appropriate diagnostic infor-
mation.
REMOVAL
(1) Disconnect and isolate the battery negative
cable.
(2) While pulling downward lightly on either rear
corner of the Intrusion Transceiver Module (ITM)
trim cover, insert a small thin-bladed screwdriver
through each of the service holes on the rear edge of
the trim cover to depress and release the two inte-
gral rear latch features of the module from the
mounting bracket above the headliner (Fig. 11).
(3) Pull the ITM trim cover rearward far enough
to disengage the two integral front latch features of
KJVEHICLE THEFT SECURITY 8Q - 15
INTRUSION TRANSCEIVER MODULE (Continued)

²Normally Closed Terminal- The normally
closed terminal (87A) is connected to the low speed
brush of the front wiper motor through a front wiper
high/low relay low speed output circuit, and is con-
nected to the low speed brush whenever the relay is
de-energized.
The wiper high/low relay can be diagnosed using
conventional diagnostic tools and methods.
DIAGNOSIS AND TESTING - WIPER HIGH/LOW
RELAY
The wiper high/low relay (Fig. 26) is located in the
Power Distribution Center (PDC) in the engine com-
partment near the battery. Refer to the appropriate
wiring information. The wiring information includes
wiring diagrams, proper wire and connector repair
procedures, details of wire harness routing and
retention, connector pin-out information and location
views for the various wire harness connectors, splices
and grounds.
(1) Remove the wiper high/low relay from the
PDC. (Refer to 8 - ELECTRICAL/WIPERS/WASH-
ERS/WIPER HIGH/LOW RELAY - REMOVAL).
(2) A relay in the de-energized position should
have continuity between terminals 87A and 30, and
no continuity between terminals 87 and 30. If OK, go
to Step 3. If not OK, replace the faulty relay.
(3) Resistance between terminals 85 and 86 (elec-
tromagnet) should be 75   8 ohms. If OK, go to Step
4. If not OK, replace the faulty relay.
(4) Connect a battery to terminals 85 and 86.
There should now be continuity between terminals30 and 87, and no continuity between terminals 87A
and 30. If OK, reinstall the relay and use a DRBIIIt
scan tool to perform further testing. Refer to the
appropriate diagnostic information.
REMOVAL
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the cover from the Power Distribution
Center (PDC) (Fig. 27).
(3) Remove the wiper high/low relay by grasping it
firmly and pulling it straight out from the receptacle
in the PDC.
INSTALLATION
(1) Position the wiper high/low relay to the proper
receptacle in the Power Distribution Center (PDC)
(Fig. 27).
(2) Align the wiper high/low relay terminals with
the terminal cavities in the PDC receptacle.
(3) Push firmly and evenly on the top of the wiper
high/low relay until the terminals are fully seated in
the terminal cavities in the PDC receptacle.
(4) Reinstall the cover onto the PDC.
(5) Reconnect the battery negative cable.
Fig. 26 ISO Micro Relay
30 - COMMON FEED
85 - COIL GROUND
86 - COIL BATTERY
87 - NORMALLY OPEN
87A - NORMALLY CLOSED
Fig. 27 Power Distribution Center
1 - FUEL PUMP RELAY
2 - STARTER MOTOR RELAY
3 - BLOWER MOTOR RELAY
4 - A/C COMPRESSOR CLUTCH RELAY
5 - OXYGEN SENSOR DOWNSTREAM RELAY
6 - AUTO SHUT DOWN RELAY
7-SPARE
8-SPARE
9a - (M/T) CLUTCH INTERLOCK RELAY
9b - (A/T) TRANSMISSION CONTROL RELAY
10 - SPARE
11 - WIPER HIGH/LOW RELAY
12 - WIPER ON/OFF RELAY
8R - 24 FRONT WIPERS/WASHERSKJ
WIPER HIGH/LOW RELAY (Continued)

DIAGNOSIS AND TESTING - WIPER ON/OFF
RELAY
The wiper on/off relay (Fig. 29) is located in the
Power Distribution Center (PDC) in the engine com-
partment near the battery. Refer to the appropriate
wiring information. The wiring information includes
wiring diagrams, proper wire and connector repair
procedures, details of wire harness routing and
retention, connector pin-out information and location
views for the various wire harness connectors, splices
and grounds.
(1) Remove the wiper on/off relay from the PDC.
(Refer to 8 - ELECTRICAL/WIPERS/WASHERS/
WIPER ON/OFF RELAY - REMOVAL).
(2) A relay in the de-energized position should
have continuity between terminals 87A and 30, and
no continuity between terminals 87 and 30. If OK, go
to Step 3. If not OK, replace the faulty relay.
(3) Resistance between terminals 85 and 86 (elec-
tromagnet) should be 75   8 ohms. If OK, go to Step
4. If not OK, replace the faulty relay.
(4) Connect a battery to terminals 85 and 86.
There should now be continuity between terminals
30 and 87, and no continuity between terminals 87A
and 30. If OK, reinstall the relay and use a DRBIIIt
scan tool to perform further testing. Refer to the
appropriate diagnostic information.
REMOVAL
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the cover from the Power Distribution
Center (PDC) (Fig. 30).
(3) Remove the wiper on/off relay by grasping it
firmly and pulling it straight out from the receptacle
in the PDC.
INSTALLATION
(1) Position the wiper on/off relay to the proper
receptacle in the Power Distribution Center (PDC)
(Fig. 30).
(2) Align the wiper on/off relay terminals with the
terminal cavities in the PDC receptacle.
(3) Push firmly and evenly on the top of the wiper
on/off relay until the terminals are fully seated in the
terminal cavities in the PDC receptacle.
(4) Reinstall the cover onto the PDC.
(5) Reconnect the battery negative cable.
Fig. 29 ISO Micro Relay
30 - COMMON FEED
85 - COIL GROUND
86 - COIL BATTERY
87 - NORMALLY OPEN
87A - NORMALLY CLOSED
Fig. 30 Power Distribution Center
1 - FUEL PUMP RELAY
2 - STARTER MOTOR RELAY
3 - BLOWER MOTOR RELAY
4 - A/C COMPRESSOR CLUTCH RELAY
5 - OXYGEN SENSOR DOWNSTREAM RELAY
6 - AUTO SHUT DOWN RELAY
7-SPARE
8-SPARE
9a - (M/T) CLUTCH INTERLOCK RELAY
9b - (A/T) TRANSMISSION CONTROL RELAY
10 - SPARE
11 - WIPER HIGH/LOW RELAY
12 - WIPER ON/OFF RELAY
8R - 26 FRONT WIPERS/WASHERSKJ
WIPER ON/OFF RELAY (Continued)

8W-02 COMPONENT INDEX
Component Page
A/C Compressor Clutch Relay........... 8Wa-42
A/C Compressor Clutch................ 8Wa-42
A/C-Heater Control................... 8Wa-42
A/C High Pressure Switch.............. 8Wa-42
A/C Low Pressure Switch............... 8Wa-42
A/C Pressure Transducer............... 8Wa-42
Accelerator Pedal Position Sensor........ 8Wa-30
Airbag Control Module................. 8Wa-43
Ambient Temperature Sensor............ 8Wa-45
Antenna Module...................... 8Wa-47
Antenna............................ 8Wa-47
Ash Receiver Lamp................... 8Wa-44
Auto Shut Down Relay................. 8Wa-30
Back-Up Lamp Switch................. 8Wa-31
Battery Temperature Sensor......... 8Wa-20, 30
Battery............................. 8Wa-20
Blend Door Actuator................... 8Wa-42
Blower Motor Relay................... 8Wa-42
Blower Motor Resistor Block............ 8Wa-42
Blower Motor........................ 8Wa-42
Body Control Module.................. 8Wa-45
Boost Pressure Sensor................. 8Wa-30
Brake Lamp Switch................... 8Wa-33
Brake Pressure Switch................. 8Wa-35
Cabin Heater Relay................... 8Wa-42
Cabin Heater........................ 8Wa-42
Camshaft Position Sensor.............. 8Wa-30
Capacitor........................... 8Wa-30
Cargo Lamp......................... 8Wa-44
CD Changer......................... 8Wa-47
Center High Mounted Stop Lamp........ 8Wa-51
Cigar Lighter........................ 8Wa-41
Circuit Breakers...................... 8Wa-12
Clockspring................. 8Wa-33, 41, 43, 47
Clutch Interlock Switch................ 8Wa-21
Clutch Switch Override Relay........... 8Wa-21
Coil On Plugs........................ 8Wa-30
Coil Rail............................ 8Wa-30
Compass Mini-Trip Computer........... 8Wa-49
Controller Antilock Brake.............. 8Wa-35
Courtesy Lamps...................... 8Wa-44
Crankshaft Position Sensor............. 8Wa-30
Curtain Airbags...................... 8Wa-43
Cylinder Lock Switches................ 8Wa-61
Data Link Connector.................. 8Wa-18
Daytime Running Lamp Relay........... 8Wa-50
Defogger Relay....................... 8Wa-48
Diagnostic Junction Port............... 8Wa-18
Dome Lamp......................... 8Wa-44
Door Ajar Switches.................... 8Wa-45
Door Lock Motor/Ajar Switches.......... 8Wa-61
Door Lock Relay...................... 8Wa-61Component Page
Door Lock Switches................... 8Wa-61
Door Speakers....................... 8Wa-47
Driver Airbag Squib 1................. 8Wa-43
Driver Airbag Squib 2................. 8Wa-43
Driver Door Unlock Relay.............. 8Wa-61
Driver Seat Belt Switch................ 8Wa-40
Driver Seat Belt Tensioner.............. 8Wa-43
EGR Solenoid........................ 8Wa-30
Electric Brake Provision................ 8Wa-54
Engine Control Module................ 8Wa-30
Engine Coolant Level Sensor............ 8Wa-40
Engine Coolant Temperature Sensor...... 8Wa-30
Engine Oil Pressure Sensor............. 8Wa-30
EVAP/Purge Solenoid.................. 8Wa-30
Flip-Up Glass Release Motor............ 8Wa-61
Flip-Up Glass Release Switch........... 8Wa-61
Fog Lamps.......................... 8Wa-50
Front Fog Lamp Relay................. 8Wa-50
Front Wiper Motor.................... 8Wa-53
Fuel Heater Relay.................... 8Wa-30
Fuel Heater......................... 8Wa-30
Fuel Injectors........................ 8Wa-30
Fuel Pressure Sensor.................. 8Wa-30
Fuel Pressure Solenoid................. 8Wa-30
Fuel Pump Module.................... 8Wa-30
Fuel Pump Relay..................... 8Wa-30
Fuses........................... 8Wa-10, 12
Fusible Link......................... 8Wa-20
Grounds............................ 8Wa-15
Generator........................... 8Wa-20
Glow Plugs.......................... 8Wa-30
Hazard Switch/Combination Flasher...... 8Wa-52
Headlamp Leveling Switch.............. 8Wa-50
Headlamps.......................... 8Wa-50
Heated Seats........................ 8Wa-63
High Beam Relay..................... 8Wa-50
Horns.............................. 8Wa-41
Hood Ajar Switch..................... 8Wa-45
Idle Air Control Motor................. 8Wa-30
Ignition Switch....................... 8Wa-10
Impact Sensors....................... 8Wa-43
Input Speed Sensor................... 8Wa-31
Instrument Cluster................... 8Wa-40
Instrument Panel Speakers............. 8Wa-47
Intake Air Temperature Sensor.......... 8Wa-30
Intrusion Sensor..................... 8Wa-49
Junction Block....................... 8Wa-12
Knock Sensor........................ 8Wa-30
Leak Detection Pump.................. 8Wa-30
Leveling Motors...................... 8Wa-50
License Lamp........................ 8Wa-51
Line Pressure Sensor.................. 8Wa-31
KJ8W-02 COMPONENT INDEX8Wa-02-1

Component Page
Low Beam Relay..................... 8Wa-50
Manifold Absolute Pressure Sensor....... 8Wa-30
Multi-Function Switch........... 8Wa-50, 52, 53
Output Speed Sensor.................. 8Wa-31
Overhead Map/Reading Lamp........... 8Wa-44
Oxygen Sensors...................... 8Wa-30
Oxygen Sensor Downstream Relay........ 8Wa-30
Park Brake Switch.................... 8Wa-40
Park Lamp Relay..................... 8Wa-50
Park/Turn Signal Lamps............ 8Wa-50, 52
Passenger Airbag..................... 8Wa-43
Passenger Door Unlock Relay........... 8Wa-61
Passenger Seat Belt Switch............. 8Wa-40
Position Lamps...................... 8Wa-50
Power Distribution Center.............. 8Wa-10
Power Mirrors....................... 8Wa-62
Power Outlet........................ 8Wa-41
Power Seats......................... 8Wa-63
Power Steering Pressure Switch......... 8Wa-30
Power Windows...................... 8Wa-60
Powertrain Control Module............. 8Wa-30
Radiator Fans....................... 8Wa-30
Radio Choke......................... 8Wa-47
Radio.............................. 8Wa-47
Rear Fog Lamp Relay................. 8Wa-51
Rear Power Outlet.................... 8Wa-41
Rear Power Window Switch............. 8Wa-60
Rear Wheel Speed Sensor.............. 8Wa-35
Rear Window Defogger................. 8Wa-48
Rear Wiper Motor.................... 8Wa-53
Red Brake Warning Indicator Switch...... 8Wa-40Component Page
Remote Keyless Entry Module........... 8Wa-45
Remote Radio Switches................ 8Wa-47
Splices............................. 8Wa-10
Sentry Key Immobilizer Module.......... 8Wa-39
Shifter Assembly..................... 8Wa-31
Side Impact Airbag Control Modules...... 8Wa-43
Side Marker Lamps................ 8Wa-50, 52
Side Repeater Lamps............... 8Wa-50, 52
Siren.............................. 8Wa-49
Speed Control Servo................... 8Wa-33
Speed Control Switches................ 8Wa-33
Starter Motor Relay................... 8Wa-21
Starter Motor........................ 8Wa-21
Sunroof............................ 8Wa-64
Tail/Stop Lamps...................... 8Wa-51
Tailgate Cylinder Lock Switch........... 8Wa-61
Tailgate Flip-Up Ajar Switch............ 8Wa-61
Tailgate Lock Motor/Ajar Switch......... 8Wa-61
Throttle Position Sensor................ 8Wa-30
Trailer Tow.......................... 8Wa-54
Transfer Case Position Sensor........ 8Wa-30, 31
Transmission Control Module........... 8Wa-31
Transmission Control Relay............. 8Wa-31
Transmission Solenoid/TRS Assembly..... 8Wa-31
Visor/Vanity Lamps................... 8Wa-44
Washer Fluid Level Switch............. 8Wa-53
Washer Pump........................ 8Wa-53
Water In Fuel Sensor.................. 8Wa-30
Wheel Speed Sensors.................. 8Wa-35
Wiper High/Low Relay................. 8Wa-53
KJ8W-02 COMPONENT INDEX8Wa-02-1

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch Relay . . . 8Wa-10-11, 13, 22,
26
A/C Compressor Clutch.............. 8Wa-10-26
Auto Shut Down Relay...... 8Wa-10-10, 12, 19, 22
Battery....................... 8Wa-10-10, 12
Blower Motor Relay........... 8Wa-10-10, 12, 14
Blower Motor..................... 8Wa-10-14
Body Control Module................ 8Wa-10-23
Cabin Heater Relay........... 8Wa-10-13, 22, 26
Cabin Heater...................... 8Wa-10-26
Camshaft Position Sensor............ 8Wa-10-22
Capacitor...................... 8Wa-10-19, 21
Circuit Breaker No. 1............... 8Wa-10-16
Circuit Breaker No. 3 (JB)........... 8Wa-10-27
Clutch Interlock Switch.............. 8Wa-10-28
Clutch Switch Override Relay......... 8Wa-10-28
Coil On Plug No. 1................. 8Wa-10-21
Coil On Plug No. 2................. 8Wa-10-21
Coil On Plug No. 3................. 8Wa-10-21
Coil On Plug No. 4................. 8Wa-10-21
Coil On Plug No. 5................. 8Wa-10-21
Coil On Plug No. 6................. 8Wa-10-21
Coil Rail......................... 8Wa-10-19
Controller Antilock Brake . 8Wa-10-10, 11, 12, 13, 14
Daytime Running Lamp Relay........ 8Wa-10-16
Defogger Relay.................... 8Wa-10-24
EGR Solenoid..................... 8Wa-10-22
Engine Control Module.............. 8Wa-10-22
Fuel Heater Relay............... 8Wa-10-13, 18
Fuel Heater....................... 8Wa-10-18
Fuel Injector No. 1................. 8Wa-10-20
Fuel Injector No. 2................. 8Wa-10-20
Fuel Injector No. 3................. 8Wa-10-20
Fuel Injector No. 4................. 8Wa-10-20
Fuel Injector No. 5................. 8Wa-10-20
Fuel Injector No. 6................. 8Wa-10-20
Fuel Pressure Solenoid.............. 8Wa-10-22
Fuel Pump Module................. 8Wa-10-26
Fuel Pump Relay................ 8Wa-10-11, 26
Fuse 1.................. 8Wa-10-10, 12, 14, 25
Fuse 2.................. 8Wa-10-10, 12, 14, 15
Fuse 3.................. 8Wa-10-10, 12, 16, 25
Fuse 4..................... 8Wa-10-10, 12, 14
Fuse 5.................. 8Wa-10-10, 12, 17, 18
Fuse 6............... 8Wa-10-10, 12, 19, 22, 24
Fuse 7..................... 8Wa-10-10, 12, 15
Fuse 8..................... 8Wa-10-10, 12, 23
Fuse 9.................. 8Wa-10-10, 12, 13, 24
Fuse 10.............. 8Wa-10-10, 12, 13, 15, 18
Fuse 11.................... 8Wa-10-13, 15, 18
Fuse 12............ 8Wa-10-10, 11, 13, 15, 17, 18
Fuse 13............... 8Wa-10-10, 11, 13, 23, 27
Fuse 14.................... 8Wa-10-11, 13, 23
Fuse 15................. 8Wa-10-11, 13, 25, 27Component Page
Fuse 16................. 8Wa-10-19, 20, 22, 24
Fuse 17.......................... 8Wa-10-24
Fuse 18.......................... 8Wa-10-24
Fuse 19.................... 8Wa-10-11, 13, 24
Fuse 20.......................... 8Wa-10-27
Fuse 21.................... 8Wa-10-11, 13, 26
Fuse 22.......................... 8Wa-10-27
Fuse 24.................... 8Wa-10-11, 26, 29
Fuse 25................. 8Wa-10-11, 13, 14, 29
Fuse 26................. 8Wa-10-12, 19, 20, 22
Fuse 28.......................... 8Wa-10-28
Fuse 29.......................... 8Wa-10-15
Fuse 30.......................... 8Wa-10-24
Fuse 31.......................... 8Wa-10-27
Fuse 32.......................... 8Wa-10-27
Fuse 33.......................... 8Wa-10-16
Fuse 34.......................... 8Wa-10-15
Fuse 36.......................... 8Wa-10-27
Fuse 37.......................... 8Wa-10-29
Fuse 38.......................... 8Wa-10-29
Fuse 39.......................... 8Wa-10-29
Fusible Link................... 8Wa-10-10, 12
G202............................ 8Wa-10-23
Generator.................. 8Wa-10-10, 12, 22
Glow Plug Assembly................ 8Wa-10-18
Glow Plug Relay No. 1......... 8Wa-10-13, 18, 22
Glow Plug Relay No. 2......... 8Wa-10-13, 18, 22
High Beam Relay.................. 8Wa-10-16
Horn Relay....................... 8Wa-10-25
Ignition Switch . . . 8Wa-10-10, 11, 12, 13, 23, 27, 29
Junction Block . . . 8Wa-10-10, 11, 12, 13, 15, 16, 24,
25, 27, 29
Low Beam Relay................... 8Wa-10-25
Oxygen Sensor 1/1 Upstream......... 8Wa-10-19
Oxygen Sensor 1/2 Downstream.... 8Wa-10-19, 20
Oxygen Sensor 2/1 Upstream......... 8Wa-10-19
Oxygen Sensor 2/2 Downstream....... 8Wa-10-20
Oxygen Sensor Downstream Relay . . 8Wa-10-19, 20
Park Lamp Relay.................. 8Wa-10-16
Power Distribution Center . 8Wa-10-2, 3, 10, 11, 12,
13, 14, 15, 16, 17, 18, 19, 22, 23, 24, 25, 26, 27, 28
Power Window Master Switch......... 8Wa-10-29
Powertrain Control Module . . 8Wa-10-11, 19, 26, 28
Radiator Fan Relay.............. 8Wa-10-10, 14
Starter Motor Relay.............. 8Wa-10-23, 28
Starter Motor..................... 8Wa-10-23
Trailer Tow Circuit Breaker..... 8Wa-10-10, 12, 15
Trailer Tow Circuit Breaker.......... 8Wa-10-15
Trailer Tow Connector............... 8Wa-10-15
Trailer Tow Relay.................. 8Wa-10-15
Transmission Control Module . . . 8Wa-10-10, 17, 28
Transmission Control Relay........ 8Wa-10-10, 17
Transmission Solenoid/TRS Assembly . . . 8Wa-10-17
KJ8W-10 POWER DISTRIBUTION8Wa-10-1

8W-12 JUNCTION BLOCK
Component Page
A/C Compressor Clutch Relay...............8Wa-12-19
A/C-Heater Control.................8Wa-12-26, 28, 35
Airbag Control Module.................8Wa-12-18, 25
Antenna Module.....................8Wa-12-23, 24
Ash Receiver Lamp......................8Wa-12-35
Auto Shut Down Relay...................8Wa-12-19
Back-Up Lamp Switch....................8Wa-12-28
Blend Door Actuator.....................8Wa-12-26
Blower Motor Relay.....................8Wa-12-25
Body Control Module . 8Wa-12-9, 10, 11, 13, 14, 15, 18, 21 22, 23
, 24, 27, 28, 30, 31, 32, 33, 34
Brake Lamp Switch.....................8Wa-12-16
Brake Pressure Switch....................8Wa-12-25
Cargo Lamp........................8Wa-12-30, 34
Center High Mounted Stop Lamp.............8Wa-12-16
Cigar Lighter.......................8Wa-12-23, 24
Circuit Breaker No. 1....................8Wa-12-29
Circuit Breaker No. 3 (JB)...............8Wa-12-23, 24
Clockspring...........................8Wa-12-9
Compass Mini-Trip Computer.............8Wa-12-18, 30
Controller Antilock Brake...............8Wa-12-16, 25
Data Link Connector.....................8Wa-12-29
Daytime Running Lamp Relay...............8Wa-12-27
Defogger Relay........................8Wa-12-28
Dome Lamp........................8Wa-12-30, 34
Door Lock Relay........................8Wa-12-11
Driver Door Unlock Relay..................8Wa-12-11
Engine Control Module...................8Wa-12-20
EVAP/Purge Solenoid....................8Wa-12-19
Front Fog Lamp Relay.................8Wa-12-21, 22
Front Wiper Motor......................8Wa-12-32
Fuel Pump Relay.......................8Wa-12-19
Fuse 1..............................8Wa-12-9
Fuse 2..............................8Wa-12-10
Fuse 3..............................8Wa-12-9
Fuse 4..............................8Wa-12-10
Fuse 5..............................8Wa-12-10
Fuse 6..............................8Wa-12-11
Fuse 7..............................8Wa-12-16
Fuse 9....................8Wa-12-13, 14, 15, 21, 22
Fuse 11.............................8Wa-12-17
Fuse 12.............................8Wa-12-16
Fuse 13.............................8Wa-12-18
Fuse 15...........................8Wa-12-19, 20
Fuse 16...........................8Wa-12-21, 22
Fuse 17...........................8Wa-12-21, 22
Fuse 18...........................8Wa-12-21, 22
Fuse 19...........................8Wa-12-21, 22
Fuse 20...........................8Wa-12-23, 24
Fuse 22...........................8Wa-12-23, 24
Fuse 23........................8Wa-12-13, 14, 15
Fuse 24.............................8Wa-12-25
Fuse 25.............................8Wa-12-26
Fuse 26.............................8Wa-12-27
Fuse 27.............................8Wa-12-27
Fuse 29.............................8Wa-12-17
Fuse 30.............................8Wa-12-28
Fuse 31...........................8Wa-12-23, 24
Fuse 32...........................8Wa-12-23, 24
Fuse 33.............................8Wa-12-29
Fuse 34.............................8Wa-12-30
Fuse 36.............................8Wa-12-18
Fuse 37.............................8Wa-12-25
Fuse 38.............................8Wa-12-25
Fuse 39.............................8Wa-12-28
G202...................8Wa-12-11, 13, 14, 15, 27, 32
Hazard Switch/Combination Flasher......8Wa-12-17, 28, 35
Headlamp Leveling Switch...............8Wa-12-14, 15
Heated Seat Module.....................8Wa-12-17
High Beam Relay.......................8Wa-12-27Component Page
High Note Horn.........................8Wa-12-9
Horn Relay...........................8Wa-12-9
Horn Switch...........................8Wa-12-9
Instrument Cluster..........8Wa-12-13, 14, 15, 18, 30, 35
Intrusion Sensor.......................8Wa-12-30
Junction Block . 8Wa-12-2, 3, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18,
19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 31, 32, 33, 34, 35,
Left Courtesy Lamp...................8Wa-12-30, 34
Left Cylinder Lock Switch.................8Wa-12-33
Left Door Lock Switch.............8Wa-12-23, 24, 31, 33
Left Fog Lamp......................8Wa-12-21, 22
Left Front Door Lock Motor/Ajar Switch.......8Wa-12-11, 12
Left Front Park/Turn Signal Lamp............8Wa-12-13
Left Headlamp......................8Wa-12-10, 27
Left Heated Seat Switch...................8Wa-12-26
Left Position Lamp....................8Wa-12-14, 15
Left Power Mirror......................8Wa-12-28
Left Power Seat Switch...................8Wa-12-29
Left Rear Door Lock Motor/Ajar Switch.........8Wa-12-12
Left Side Impact Airbag Control Module.........8Wa-12-18
Left Side Marker Lamp...................8Wa-12-13
Left Tail/Stop Lamp..............8Wa-12-13, 14, 15, 16
Left Visor/Vanity Lamp...................8Wa-12-30
Left Visor/Vanity Lamp...................8Wa-12-31
License Lamp.....................8Wa-12-13, 14, 15
Low Beam Relay.......................8Wa-12-10
Low Note Horn.........................8Wa-12-9
Multi-Function Switch...............8Wa-12-23, 24, 27
Overhead Map/Reading Lamp...........8Wa-12-30, 31, 34
Park Lamp Relay..................8Wa-12-13, 14, 15
Passenger Door Unlock Relay...............8Wa-12-11
Power Distribution Center........8Wa-12-16, 21, 22, 31, 32
Power Mirror Switch.....................8Wa-12-26
Power Outlet..........................8Wa-12-9
Powertrain Control Module.................8Wa-12-19
Radio Choke........................8Wa-12-21, 22
Radio.......................8Wa-12-23, 24, 30, 35
Rear Fog Lamp Relay....................8Wa-12-10
Rear Power Outlet....................8Wa-12-21, 22
Rear Window Defogger....................8Wa-12-28
Rear Wiper Motor....................8Wa-12-21, 22
Right Courtesy Lamp..................8Wa-12-30, 34
Right Cylinder Lock Switch.................8Wa-12-33
Right Door Lock Switch............8Wa-12-23, 24, 31 33
Right Fog Lamp.....................8Wa-12-21, 22
Right Front Door Lock Motor/Ajar Switch......8Wa-12-11, 12
Right Front Park/Turn Signal Lamp...........8Wa-12-13
Right Headlamp.....................8Wa-12-10, 27
Right Heated Seat Switch..................8Wa-12-26
Right Position Lamp...................8Wa-12-14, 15
Right Power Mirror......................8Wa-12-28
Right Power Seat Switch..................8Wa-12-29
Right Rear Door Lock Motor/Ajar Switch........8Wa-12-12
Right Side Impact Airbag Control Module........8Wa-12-18
Right Side Marker Lamp..................8Wa-12-13
Right Tail/Stop Lamp...........8Wa-12-10, 13, 14, 15, 16
Right Visor/Vanity Lamp................8Wa-12-30, 31
Sentry Key Immobilizer Module.........8Wa-12-19, 20, 29
Shifter Assembly.....................8Wa-12-25, 35
Siren...............................8Wa-12-30
Sunroof Motor.......................8Wa-12-23, 24
Tailgate Lock Motor/Ajar Switch..............8Wa-12-32
Trailer Tow Brake Lamp Relay..........8Wa-12-16, 21, 22
Trailer Tow Connector...............8Wa-12-13, 14, 15
Trailer Tow Relay.......................8Wa-12-26
Transmission Control Module...............8Wa-12-19
Transmission Solenoid/TRS Assembly..........8Wa-12-28
Wiper On/Off Relay...............8Wa-12-23, 24, 31, 32
KJ8W-12 JUNCTION BLOCK8Wa-12-1

8W-15 GROUND DISTRIBUTION
Component Page
A/C Compressor Clutch...................8Wa-15-6
A/C Low Pressure Switch.................8Wa-15-3
A/C- Heater Control...................8Wa-15-7, 8
Airbag Control Module...................8Wa-15-7
Ash Receiver Lamp.....................8Wa-15-8
Battery.............................8Wa-15-2
Blend Door Actuator.....................8Wa-15-8
Blower Motor Relay.....................8Wa-15-4
Body Control Module....................8Wa-15-8
Brake Lamp Switch.....................8Wa-15-8
Cabin Heater.........................8Wa-15-6
Capacitor............................8Wa-15-2
Center High Mounted Stop Lamp...........8Wa-15-14
Cigar Lighter.........................8Wa-15-8
Compass Mini-Trip Computer..............8Wa-15-14
Controller Antilock Brake.................8Wa-15-2
Data Link Connector....................8Wa-15-2
Engine Control Module...................8Wa-15-7
Engine Coolant Level Sensor...............8Wa-15-6
Flip-Up Glass Release Motor..............8Wa-15-14
Front Wiper Motor......................8Wa-15-3
Fuel Heater..........................8Wa-15-6
Fuel Heater Relay......................8Wa-15-4
Fuel Pump Module.....................8Wa-15-15
G100.............................8Wa-15-2, 7
G101...............................8Wa-15-6
G102...............................8Wa-15-2
G103...............................8Wa-15-6
G104...............................8Wa-15-7
G105...............................8Wa-15-2
G106...............................8Wa-15-2
G110...............................8Wa-15-2
G111 .............................8Wa-15-3, 4
G112...............................8Wa-15-3
G200...............................8Wa-15-7
G201...............................8Wa-15-7
G202...............................8Wa-15-8
G300............................8Wa-15-9, 11
G301............................8Wa-15-9, 10
G302............................8Wa-15-9, 12
G310.........................8Wa-15-13, 14, 15
G311 ..............................8Wa-15-14
G312..............................8Wa-15-14
G320..............................8Wa-15-15
Hazard Switch/Combination Flasher..........8Wa-15-8
Headlamp Leveling Switch................8Wa-15-8
Heated Seat Module....................8Wa-15-10
High Note Horn.......................8Wa-15-3
Hood Ajar Switch.......................8Wa-15-4
Ignition Switch........................8Wa-15-8
Instrument Cluster.....................8Wa-15-8
Intrusion Sensor......................8Wa-15-14
Junction Block........................8Wa-15-8
Left Door Lock Switch...................8Wa-15-11
Left Fog Lamp........................8Wa-15-5
Left Front Door Ajar Switch...............8Wa-15-11
Left Front Door Lock Motor/Ajar Switch.......8Wa-15-11
Left Front Door Speaker..................8Wa-15-7
Left Front Park/Turn Signal Lamp...........8Wa-15-5
Left Headlamp........................8Wa-15-3
Left Heated Seat Assembly...............8Wa-15-10
Left Heated Seat Switch.................8Wa-15-10Component Page
Left Leveling Motor.....................8Wa-15-3
Left Position Lamp.....................8Wa-15-3
Left Power Mirror.....................8Wa-15-11
Left Power Seat Switch..................8Wa-15-10
Left Rear Door Ajar Switch...............8Wa-15-11
Left Rear Door Lock Motor/Ajar Switch.......8Wa-15-11
Left Side Impact Airbag Control Module........8Wa-15-9
Left Side Repeater Lamp..................8Wa-15-5
Left Tail/Stop Lamp....................8Wa-15-15
License Lamp........................8Wa-15-15
Line Pressure Sensor....................8Wa-15-2
Low Note Horn........................8Wa-15-3
Multi- Function Switch...................8Wa-15-8
Oxygen Sensor 1/2 Downstream.............8Wa-15-6
Oxygen Sensor 2/2 Downstream.............8Wa-15-6
Power Mirror Switch.................8Wa-15-11, 12
Power Outlet.........................8Wa-15-8
Power Steering Pressure Switch.............8Wa-15-6
Power Window Master Switch.............8Wa-15-10
Powertrain Control Module................8Wa-15-2
Radiator Fan Motor.....................8Wa-15-3
Radiator Fan Relay.....................8Wa-15-3
Radio..............................8Wa-15-7
Radio Choke..........................8Wa-15-9
Rear Power Outlet.....................8Wa-15-15
Rear Window Defogger..................8Wa-15-14
Rear Wiper Motor.....................8Wa-15-14
Red Brake Warning Indicator Switch..........8Wa-15-4
Right Door Lock Switch..................8Wa-15-12
Right Fog Lamp.......................8Wa-15-5
Right Front Door Ajar Switch..............8Wa-15-12
Right Front Door Lock Motor/Ajar Switch......8Wa-15-12
Right Front Door Speaker.................8Wa-15-7
Right Front Park/Turn Signal Lamp..........8Wa-15-5
Right Headlamp.......................8Wa-15-4
Right Heated Seat Assembly..............8Wa-15-10
Right Heated Seat Switch................8Wa-15-10
Right Leveling Motor....................8Wa-15-4
Right Position Lamp....................8Wa-15-4
Right Power Mirror....................8Wa-15-12
Right Power Seat Switch.................8Wa-15-10
Right Rear Door Ajar Switch..............8Wa-15-12
Right Rear Door Lock Motor/Ajar Switch......8Wa-15-12
Right Side Impact Airbag Control Module.......8Wa-15-9
Right Side Repeater Lamp.................8Wa-15-5
Right Tail/Stop Lamp...................8Wa-15-15
Sentry Key Immobilizer Module.............8Wa-15-8
Shifter Assembly.......................8Wa-15-9
Siren...............................8Wa-15-4
Speed Control Servo.....................8Wa-15-3
Starter Motor Relay.....................8Wa-15-4
Sunroof Motor........................8Wa-15-14
Tailgate Flip-Up Ajar Switch..............8Wa-15-14
Trailer Tow Brake Lamp Relay.............8Wa-15-13
Trailer Tow Connector...................8Wa-15-13
Trailer Tow Left Turn Relay...............8Wa-15-13
Trailer Tow Relay......................8Wa-15-13
Trailer Tow Right Turn Relay..............8Wa-15-13
Transmission Control Module...............8Wa-15-2
Transmission Control Relay................8Wa-15-4
Washer Fluid Level Switch................8Wa-15-3
KJ8W-15 GROUND DISTRIBUTION8Wa-15-1
