ENGINE
Versions 1.4 Turbo MultiAir 136/140 HP 1.6 16V MultiJet 115/120 HP
Type code 55263624 55263113
Cycle Otto Diesel
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 72.0 x 84.0 79.5 x 80.5
Total displacement (cm³) 1368 1598
Compression ratio 10 : 1 16.5 : 1
Maximum power (EC) (kW)
100
(*)/ 103 85(*)/88
Maximum power (EC) (HP)
136
(*)/ 140 115(*)/ 120
corresponding engine speed (rpm) 5000 3750
Maximum torque (EC) (Nm) 230 320
Maximum torque (EC) (kgm) 23.5 32.6
corresponding engine speed (rpm) 1750 1750
Spark plugs NGK IKR9J8 –
FuelUnleaded petrol 95 RON (EN 228
Specification)Diesel for motor vehicles (EN 590
Specification)
(*) Where provided
167

Versions 2.0 16V MultiJet 120 HP 2.0 16V MultiJet 140 HP 2.0 16V MultiJet 170 HP
Type code 55263087 55263087 55263088
Cycle Diesel Diesel Diesel
Number and position of cylinders 4 in line 4 in line 4 in line
Piston bore and stroke (mm) 83 x 90.4 83 x 90.4 83 x 90.4
Total displacement (cm³) 1956 1956 1956
Compression ratio 16.5 16.5 16.5
Maximum power (EC) (kW) 88 103 125
Maximum power (EC) (HP) 120 140 170
corresponding engine speed (rpm) 4000 3750 3750
Maximum torque (EC) (Nm) 320 350 350
Maximum torque (EC) (kgm) 32.6 35.7 35.7
corresponding engine speed (rpm) 1250 1500 1750
FuelDiesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)
168
TECHNICAL SPECIFICATIONS
