JEEP RENEGADE 2023 Owners Manual

SERVICING AND MAINTENANCE 309
Rear Cargo Fuse/Relay Distribution Unit
To access the fuses, remove the access door from
the left rear panel of the rear cargo area.

Rear Fuse Access Door
The fuses may be contained in two units. Fuse
holder


No. 1 and fuse holder No. 2 (if equipped
with trailer towing) are located closest to the rear
of the vehicle.

Rear Cargo Fuse Cavities

F43
20 Amp YellowBi-directional Pump Washer
F47 20 Amp YellowPower Rear Window (Driver Side)
F48 20 Amp YellowPower Rear Window (Passenger Side)
F49 7.5 Amp BrownSupply ParkSense, SGW, Mirror, Heated Front Seats, Stabilizer Battery, ESC System, S&S
Inhib
i

tion Command, Blind Spot, Rain/Light Sensor, Humidity Sensor
F50 7.5 Amp BrownSupply Air Bag
F51 7.5 Amp BrownAir Conditioning, Lane Departure Warning, Terrain Selector, Trailer Tow Module, Compass
Module
,

Rear View Camera
F53 7.5 Amp BrownSupply IPC/Starter Device/System Keyless Enter ‘n Go™
F94 15 Amp BluePower Socket
Cavity Mini Fuse Description
1 — Fuse Holder No. 1
2 — Fuse Holder No. 2
8

310 SERVICING AND MAINTENANCE
Fuse Holder No. 1
Fuse Holder No. 2
On the controller there is also a 20 amp fuse for the sun visor of the retractable roof.
Cavity Mini Fuse Description
F130 Amp BluePower Inverter
F2 20 Amp YellowHIFI Audio System
F3 20 Amp YellowMY SKY
F5 30 Amp GreenPower Seat (Driver Side)
F6 7.5 Amp BrownLumbar Adjustment Front Seat (Driver Side)
F8 20 Amp YellowHeating Front Seats
CavityMini Fuse Description
F515 Amp BlueController Exterior Lighting Lights (Drivers Side)
F6 15 Amp BlueController Exterior Lighting Lights (Passenger Side)

SERVICING AND MAINTENANCE 311
BULB REPLACEMENT
General Information
Before you replace a bulb, check the contacts to
be sure they are not oxidized.
Replace the bulbs with the same type and
wattage.
After replacing a light bulb, always check the
correct orientation.
Before replacing a bulb that is not functioning,
check that the fuse is intact.
NOTE:
Lens fogging can occur under certain atmospheric
condit i
ons. This will usually clear as atmospheric
conditions change to allow the condensation to
change back into a vapor. Turning the lamps on will
usually accelerate the clearing process.Replacement Bulbs, Names, And Part
Numbers
In the instance a bulb needs to be replaced, this
section includes bulb description and replacement
part numbers.
NOTE:
See an authorized dealer for LED bulb
repla c
ement.
Interior Bulbs
Lamps Bulb Number
Front Courtesy Light C5W
Front Courtesy Lights (Sun Visors) C5W
Rear Dome Light (Models Without Retractable Roof) C5W
Rear Interior Lights (Models With Retractable Roof) C5W
Interior Lights W5W
Dome Light (Glove Compartment) W5W
Exterior Bulbs
Lamps Bulb Number
Low Beam/High Beam Headlamps (LED Version) LED (Serviced at an authorized dealer)
Low Beam/High Beam Headlamps H13
8

312 SERVICING AND MAINTENANCE
Front Position/Daytime Running Lights (DRL)/Front Turn Indicator PSY24W
Front Direction Indicator Lamps (If Equipped With LED Headlamps) PSY24W
Front Fog Lamps H11
Front Fog Lamps (LED Versions) LED (Serviced at an authorized dealer)
Side Indicators (Front And Side View Mirror) WY5W
Tail/Brake Lights/Turn Indicators (LED Versions) LED (Serviced at an authorized dealer)
Tail/Brake Lights/Turn Indicators P21W
Center High Mounted Stop Lamp (CHMSL) LED (Serviced at an authorized dealer)
Reverse W16W
License Plate Lamp W5W
Exterior Bulbs
Lamps Bulb Number

SERVICING AND MAINTENANCE 313
Replacing Exterior Bulbs
Headlamps
Hi/Lo Beam Light Halogen
See the following steps to replace:

1. O
pen the engine compartment and remove
the he a

dlamp bulb cap.

Headlamp Bulb Cap

2. Rotate the headlamp bulb socket counter -
clock w

ise then pull outwards.
Headlamp Bulb Socket

3. P ush on the locking tab on the headlamp bulb
conne c

tor and remove the bulb and socket.

Headlamp Bulb Headlamp Bulb

4. Install the new headlamp bulb making sure it is pr operly locked.
5. Install the headlamp bulb and socket; turn it clockw
ise making sure it is properly locked.
LED Headlamps – If Equipped
For replacement see an authorized dealer.
CAUTION!
During bulb replacement do not touch the new
glass bulb with your fingers. Oil contamination
will severely shorten bulb life. If the bulb comes
in contact with any oily surface, clean the bulb
with rubbing alcohol.
WARNING!
Carry out the operation of replacing lamps only
with the engine off. Also make sure that the
engine is cold, to avoid the danger of burns.
8

314 SERVICING AND MAINTENANCE
Position Lights/Daytime Running Lights/Fog
Lights
See the following steps to replace:

1. Turn the front wheels completely.

2. Us e

a suitable tool to remove the access door.

Posi t

ion Light/Daytime Running Light/Fog Light Access

3. Remove the electrical connector.
4. Re l

easing the two tabs, and remove the bulb
and b

ulb socket from the housing.
Position Light/Daytime Running Light Assembly

5. Install the new bulb and socket into the housi n

g, and engage the two tabs, making
sure that it is properly locked.
6. Reconnect the electrical connector.
7. Re i

nstall the access door.
Front

Fog Lights
See the following steps to replace:

1. T urn the front wheels completely.

2. Us e

a suitable tool to remove the access door.
Posi
t
ion Light/Daytime Running Light/Fog Light Access

3. By pushing the electrical connector tab remov e

the electrical connector.

Fog Light Assembly

1 — Screws
2 — Access Door
1 — Bulb Socket1 — Screws
2 — Access Door

SERVICING AND MAINTENANCE 315
4. Rotate the bulb counterclockwise, and then
replace the bulb.
5. Insert the new bulb in the socket, making sure the b
ulb is locked into place.
6. Reconnect the electrical connector.
7. R ein

stall the access door.
LE D
F
r

ont Fog Lamps – If Equipped
For replacement see an authorized dealer.
Front Side Indicators
See the following steps to replace:

1. O perating from inside the engine
comp a

rtment using a suitable tool release
the retaining clip.

2. Remove lamp assembly by sliding it toward the outsi d

e.

Lamp Assembly
3. Remove the electrical connector by pushing
the t

ab then disconnect the electrical
connector.
4. Rotate counterclockwise to release the bulb socke t

from the lamp assembly, and remove it.

Bulb Socket
5. Remove the bulb from the socket.

Bulb

6 .

Insert the new bulb in the socket.
7. Rei
nstall the bulb and socket into the lamp
asse m

bly by turning it clockwise, making sure
it is locked into place.
8. Reconnect the electrical connector.
9. R ein

stall the lamp assembly on the car,
m a
ki
n

g sure it is locked into place.8

316 SERVICING AND MAINTENANCE
Side Indicators on External Rear View Mirrors – (If
Equipped)
See the following steps to replace:

1. Remove the mirror cap on the outside rear
view m

irror.

Mirror Cap Removing the mirror cap

2. Remove the transparent lens assembly as shown .

T

ransparent Lens
3. Remove the bulb socket and bulb from the
trans
parent lens assembly by rotating the
socket counterclockwise.

Transparent Lens Assembly

4. Remove the bulb from the bulb socket by pulli
ng the bulb straight out.
5. Insert the new bulb, making sure that it is locked
into place.
6. Reinstall the socket in to the transparent lens assem
bly.
7. Reinstall the cover on the outside rear view mirror
, making sure it is locked into place.
CAUTION!
The procedure is described as a guideline. For
the replacement of the lamp it is recommended
that you contact an authorized dealer.

SERVICING AND MAINTENANCE 317
Rear Tail Lamps
Contain the following:
Position Lights
Stop Lights
Direction Indicator
REVERSE Lights
See the following steps to replace:

1. O pen the liftgate.

2. Usi
ng a suitable tool remove the door as
shown .

T

rim Panel Door

3. Using a suitable tool remove fastener.
4. Di s

connect the electrical connector by pushing
the r

elease.
Rear Lamp Fastener and Electrical Connector

5. Remove the rear tail lamp, sliding it toward the outsi d

e as shown.

Tail Lamp Removal
6. Unscrew the screws and remove the rear tail
lamp
holder.

Rear Lamp Assembly

1 — Electrical Connector
2 — Fastener
1 — Mounting Screws
8

318 SERVICING AND MAINTENANCE
7. Replace the bulb as necessary.

Rear Tail Lamp Holder

8. Insert the new bulb, making sure it is properly locke
d.
9. Reassemble the lamp assembly on the rear tail
lamp housing, tightening the screws.
10. Reposition the rear tail lamp on the car.
11. Se
cure the fastener of the rear tail lamp and
recon n

ect the electrical connector.
12. Reinstall the door making sure it locked into place
.
13. Finally close the liftgate. LED Re
ar Tail Lamps – If Equipped
For replacement see an authorized dealer.
Reverse Lights – If Equipped With LED Tail Lamps
See the following steps to replace:

1. U se a suitable tool to remove the screws and
remove

the access door.

Reverse Light Access
2. B
y pushing the electrical connector tab
remove
the electrical connector.

Reverse Light Assembly

3. R otate the bulb counterclockwise, and then
r e p
la

ce the bulb.
4. Insert the new bulb in the socket, making sure the b
ulb is locked into place.
5. Reconnect the electrical connector.
6. Rei
nstall the access door.
Cent e

r High Mounted Stop Lamp (CHMSL)
The CHMSL is LED. For replacement see an
a uthori

zed dealer.
1 — Tail Light
2 — Reverse Bulb
3 — Position Light/Stop Light/Turn Signal
1 — Screw
2 — Screw
3 — Access Door
1 — Bulb
