JEEP WRANGLER 2005 TJ / 2.G Service Manual
Manufacturer: JEEP, Model Year: 2005, Model line: WRANGLER, Model: JEEP WRANGLER 2005 TJ / 2.GPages: 352, PDF Size: 12.81 MB
Page 41 of 352
Installing Child Restraints Using the Vehicle Seat
Belt
The passenger seat belts are equipped with cinching latch
plates, which are designed to keep the lap portion tight
around the child restraint so that it is not necessary to use
a locking clip. Pull up on the shoulder portion of the
lap/shoulder belt to tighten the belt. The cinching latch
plate will keep the belt tight, however, any seat belt
system will loosen with time, so check the belt occasion-
ally and pull it tight if necessary.In the rear seat, you may have trouble tightening the
lap/shoulder belt on the child restraint because the
buckle or latch plate is too close to the belt path opening
on the restraint. Disconnect the latch plate from the
buckle and twist the short buckle-end belt several times
to shorten it. Insert the latch plate into the buckle with the
release button facing out.
If the belt still cannot be tightened, or if by pulling and
pushing on the restraint loosens the belt, you may need
to do something more. Disconnect the latch plate from
the buckle, turn the buckle around, and insert the latch
plate into the buckle again. If you still can’t make the
child restraint secure, try a different seating position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2
Page 42 of 352
To attach a child restraint tether strap:
For the rear outboard seating positions, route the tether
over the rear seat and attach to the rear floor tether
anchors. If the Add-A-Trunk™ option is present in the
vehicle, the lid should be opened and positioned against
the back of the rear seat prior to attaching and adjusting
the strap.
Rear Seat Tether Anchor
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 43 of 352
WARNING!
An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.
Children Too Large for Booster Seats
Children who are large enough to wear the shoulder belt
comfortably, and whose legs are long enough to bend
over the front of the seat when their back is against the
seat back should use the lap/shoulder belt in a rear seat.
•Make sure that the child is seated upright in the seat.
•The lap belt portion should be low on the hips and as
snug as possible.
•Check belt fit periodically. A child’s squirming or
slouching can move the belt out of position.
•If the shoulder belt contacts the child’s face or neck,
move the child closer to the center of the vehicle.
Never allow a child to put the shoulder belt under an
arm or behind their back.
Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2
Page 44 of 352
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the engine in
your new vehicle.
Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or 55
mph (80 or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration, within the
limits of local traffic laws, contributes to a good break-in.
Wide open throttle acceleration in low gear can be
detrimental and should be avoided.
The engine oil installed in the engine at the factory is a
high quality energy conserving type lubricant. Oil
changes should be consistent with anticipated climate
conditions under which vehicle operations will occur.
The recommended viscosity and quality grades are
shown in Section 7 of this manual. NON-DETERGENT
OR STRAIGHT MINERAL OILS MUST NEVER BE
USED.A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered as a normal part of the break-in and not
interpreted as an indication of difficulty.
SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
•Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas which can kill.
Never run the engine in a closed area, such as a
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 45 of 352
garage, and never sit in a parked vehicle with the
engine running for a extended period. If the vehicle is
stopped in an open area with engine running for more
than a short period, adjust the ventilation system to
force fresh, outside air into the vehicle.
•Guard against carbon monoxide with proper mainte-
nance. Have the exhaust system inspected every time
the vehicle is raised. Have any abnormal conditions
repaired promptly. Until repaired, drive with all side
windows fully open.
•Always run the climate control in panel or floor mode
when driving with any windows open, even if only
slightly, to help keep fresh air circulating inside ve-
hicle. Otherwise poisonous gases could be drawn into
the vehicle.
•On hardtop models, keep the tailgate window closed
when driving your vehicle. On fabric top models, do
not drive with the rear window curtain up unless theside curtains are also open. This will prevent carbon
monoxide and other poisonous exhaust gases from
entering the vehicle.
Safety Checks You Should Make Inside The
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Seat belt assemblies must be replaced after an accident if
they have been damaged (bent retractor, torn webbing,
etc.). If there is any question regarding belt or retractor
condition, replace the belt.
Airbag Warning Light
The light should come on and remain on for 6 to 8
seconds as a indicator check when the ignition switch is
first turned on. If the indicator is not lit during starting,
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45
2
Page 46 of 352
have it serviced. If the light stays on or comes on while
driving, have the system checked by an authorized
dealer.
Defrosters
Check operation by selecting the defrost mode and place
the blower control on high speed. You should feel the air
directed against the windshield.
Safety Checks You Should Make Outside The
Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect for tread cuts or sidewall
cracks. Check wheel nuts for tightness and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of all exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
coolant, oil, or other fluid leaks. Also, if gasoline fumes
are detected, the cause should be located and corrected
immediately.
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 47 of 352
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
Mirrors...............................50
▫Inside Day/Night Mirror.................50
▫
Inside Automatic Dimming Compass/Temperature
Mirror — If Equipped
....................50
▫Compass Calibration....................52
▫Outside Mirrors.......................54
Seats.................................55
▫Front Seat Adjustment...................55
▫Front Seat Adjustment — Recline...........56▫Tilting Front Seats......................57
▫Fold And Tumble Rear Seat...............57
▫Removing The Rear Seat.................58
▫Replacing The Rear Seat.................59
To Open And Close The Hood..............60
Lights................................61
▫Interior Lights........................61
▫Multi-Function Control Lever..............62
3
Page 48 of 352
▫Parking Lights, Instrument Panel Lights, And
Headlights...........................62
▫Lights-On Reminder....................63
▫Headlight Dimmer Switch................63
▫Passing Light.........................63
▫Front Fog Lights — If Equipped............63
▫Turn Signals..........................63
▫Daytime Running Lights — Canada Only.....64
Windshield Wipers And Washers.............64
▫Intermittent Wiper System................64
▫Windshield Wiper Operation..............65
▫Windshield Washers....................65
▫Mist Feature..........................65Tilt Steering Column.....................66
Electronic Speed Control...................66
▫To Activate...........................67
▫To Set At A Desired Speed................67
▫To Deactivate.........................67
▫To Resume Speed......................67
▫To Vary The Speed Setting................68
▫To Accelerate For Passing................68
Electrical Power Outlet....................69
▫Electrical Outlet Use With Engine Off........70
Cup Holders...........................70
Storage...............................71
▫Glove Compartment....................71
48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 49 of 352
▫Console Storage Compartment — If Equipped . .72
▫Add-A-Trunk™ — If Equipped............72
Dual Top — If Equipped..................73
▫Removing The Soft Top..................73
▫Installing The Soft Top..................75
HardTop .............................86
▫Hard Top Removal.....................87
▫Hard Top Installation...................90
Soft Top..............................91
▫Folding Down The Soft Top...............92
▫Putting Up The Soft Top.................99
Soft Top — Unlimited Models..............108
▫Folding Down The Soft Top..............110▫Putting Up The Soft Top................117
▫Sunrider — If Equipped
(Unlimited Models Only)................125
Door Frame...........................128
▫Door Frame Removal..................128
▫Door Frame Installation.................129
Folding Windshield.....................130
▫Lowering The Windshield And Removing Side
Bars...............................132
▫Raising The Windshield And Replacing Side
Bars...............................136
Rear Window Features — Hard Top Only.....137
▫Rear Window Defogger.................137
▫Rear Window Wiper/Washer.............138
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 49
3
Page 50 of 352
MIRRORS
Inside Day/Night Mirror
The mirror should be adjusted to center on the view
through the rear window. A two-point pivot system
allows for horizontal and vertical adjustment of the
mirror.Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Inside Automatic Dimming Compass/Temperature
Mirror — If Equipped
The automatic day/night mirror is equipped with three
buttons: the left switch for the left LED lamp, the right
switch for the right side LED lamp and the center switch
for the compass/temperature function. Pressing the left
and right switches simultaneously for more than 5 sec-
onds will turn the auto dim function on or off. If the
feature is turned off, it will automatically turn back on
with the next ignition cycle. A green light next to the right
button will indicate when the dimming feature is acti-
vated active. The mirror also senses the backup lamp
circuit, and will automatically disable its self-dimming
feature whenever the transmission gear selector is in the
R (Reverse) position.
Adjusting Rearview Mirror
50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
