Cavity Fuse Description
1 20 Amp Yel-
lowPark Lights, Skim (Sentry
Key)
2 20 Amp Yel-
lowStop Lights
3 20 Amp Yel-
lowSubwoofer System
4 10 Amp Red Door Switch Defeat
5 10 Amp Red Airbag
6 20 Amp Yel-
lowRear Wiper
7 10 Amp Red Back-Up Lights, Rear Win-
dow Defroster Relay, ABS
8 10 Amp Red HEVAC
9 10 Amp Red Airbag
10 10 Amp Red Instrument Cluster
11 10 Amp Red Solenoids, DRLCavity Fuse Description
12 10 Amp Red Power Distribution Relays,
Skim (Sentry Key)
13 10 Amp Red Turn Signals
14 10 Amp Red Radio
15 10 Amp Red HBL (Rear Window De-
froster) Switch
16 10 Amp Red Headlamp Aim (Export
Only)
17 25 Amp
NaturalFront Wiper
18 20 Amp Yel-
lowCigar Lighter
19 20 Amp Yel-
lowSpare
20 20 Amp Yel-
lowSpare
MAINTAINING YOUR VEHICLE 287
7

Underhood Fuses (Power Distribution Center)
Your vehicle is equipped with an electrical power distri-
bution center located in the engine compartment near the
battery. This power center houses plug-in “Cartridge”
fuses, ISO relays, and Mini (Micro) fuses.A label inside the latching cover of the center identifies
each component for ease of replacement, if necessary.
Cartridge and mini (micro) fuses can be obtained from
your authorized dealer.
Cavity Fuse/Color Description
1 40 Amp Green HEVAC
2 40 Amp Green HBL (Rear Window De-
froster)
3 40 Amp Green Exterior Lighting
4 40 Amp Green Radiator Fan
5 20 Amp Yellow Transmission
6 30 Amp Pink Starter
7 Open
8 40 Amp Green ABS Motor
9 20 Amp Yellow ASD
10 40 Amp Green HD/LP
11 Open IOD Storage
12 30 Amp Pink ABS Valve
Power Distribution Center
288 MAINTAINING YOUR VEHICLE

Cavity Fuse/Color Description
13 40 Amp Green Accessories
14 Open
15 50 Amp Red IOD
16 Open
17 20 Amp Yellow Power
18 20 Amp Yellow Horn
19 20 Amp Yellow Fog Lights
20 15 Amp Lt. Blue Radio
21 10 Amp Red A/C Clutch
22 25 Amp Natural Ignition Switch
23 20 Amp Yellow Fuel
24 20 Amp Yellow Off Road
25 Open
26 10 Amp Red Accessories
27 20 Amp Yellow MFSW
28 10 Amp Red Clutch OverrideCavity Fuse/Color Description
29 Relay ASD
30 Relay A/C Clutch
31 Relay Transmission
32 Relay Starter
33 Relay ABS
34 Open
35 Relay Fog Lamp
36 Relay Horn
37 Relay Fuel Pump
38 Relay HBL (Rear Window De-
froster)
39 Relay Front Differential Locker
(Rubicon) or High Speed
Fan (2.4L Engines)
40 Relay Rear Differential Locker
(Rubicon) or Low Speed
Fan (2.4L Engines)
