hood open KIA SELTOS 2023 Features and Functions Guide

2*IF EQUIPPEDS E LT O S FEATURES & FUNCTIONS GUIDE
TABLE OF CONTENTS
VIDEOS & QR CODES Inside Cover
INSTRUMENT CLUSTERInstrument Cluster Overview 03Indicators & Warning Lights 04Tire Pressure Monitoring System (TPMS) 05Fuel Economy / Tips for Economical Driving 05Drive Mode Integrated Control System 06
VEHICLE SETTINGSLCD Instrument Cluster Modes 07Trip Modes / Trip Computer 07Instant Fuel Economy 07Service Interval Mode* 08Ambient Light and Sound Mood Lamp* 08User Settings – Instrument Cluster 09Vehicle Settings* – Infotainment System 09Vehicle Auto-Shut Off* 10
ADVANCED DRIVER ASSISTANCE
SYSTEMS (ADAS)Forward Collision-Avoidance Assist (FCA) 11Lane Keeping Assist (LK A) 12Blind-Spot Collision-Avoidance Assist (BCA)* 13 Safe Exit Warning (SEW)* 14Driver Attention Warning (DAW) 14Leading Vehicle Departure Alert (LVDA)* 15Smart Cruise Control (SCC)* 16Cruise Control (CC) 17Lane Following Assist (LFA) 18Highway Driving Assist (HDA)* 19Rear View Monitor (RVM) 20Rear Cross-Traffic Collision Avoidance Assist (RCCA)* 21
DRIVER’S PANELInstrument Cluster Control* 22Electronic Stability Control (ESC) 22Hill-Start Assist Control (HAC) 22
DRIVER’S PANEL (CONTINUED)Engine Start/Stop Button* 23Power Windows, Window Lock & Central Door Lock 24Rear Door Locks – Double Pull to Open 24Auto Door Lock/Unlock 24Power Outside Mirrors 25Heated Outside Mirrors* 25Manual Folding Mirrors* 25
STEERING WHEEL CONTROLSTilt/Telescoping Steering Wheel 25Headlights & High Beams 26Daytime Running Lights (DRL)* 26High Beam Assist 26Turn Signals & Fog Lights* 26Windshield Wipers & Washers 27Rear Wiper & Washer* 27
INFOTAINMENT SYSTEMSBluetooth® Wireless Technology 28 Audio Controls 30 Android Auto™ / Apple CarPlay® Setup 31Standard Audio System* 32Kia Connect Activation* 33Kia Connect Assistance* 33Kia Access App Download 34Kia Access App Features Guide 34Kia Connect with Navigation* 35
CENTER PANELDigital Clock (Infotainment System) 36Multimedia USB Port, Power Outlets & USB Charger Port 36Wireless Smartphone Charging System* 37Automatic Climate Control* 38Manual Climate Control* 39Idle, Stop & Go (ISG) System 40Automatic Gear Shift / Sportmatic® Shifting 41
CENTER PANEL (CONTINUED)Dual Clutch Transmission (DCT)* 41Electronic Parking Brake (EPB)* / Auto Hold* 42Downhill Brake Control 43All Wheel Drive (AWD) System* 43Seat Warmers* 44
SEATINGPower Adjustable Driver ’s Seat* 456-Way Manual Adjustable Driver ’s Seat* 45Folding Rear Seats 46Rear Occupant Alert (ROA) with Door Monitoring 46Front Seat Headrest Adjustment 47Unfastening Center Seat Belt 47
OTHER KEY FEATURESSmart Key* 48Remote Keyless Entry (Folding Key)* 49Fuel Cap / Malfunction Indicator 50Fuel Filler Door Release 50Hood Release Lever and Latch 50Map/Room Lamps 51Sunroof Operation* 52Sunvisor 52Manual Liftgate / Liftgate Release Button 53
SAFETY FEATURESSeat Belts 54Occupant Detection System (ODS) / Passenger Airbag Off Indicator 54Child-Protector Rear Door Lock 54
TURBO MAINTENANCE CHART 56
LEGAL DISCLAIMERS Inside Back Cover
NON-TURBO MAINTENANCE
CHART Back Cover
MY23 Seltos FFG Inside March 2022.indd 2MY23 Seltos FFG Inside March 2022.indd 24/15/22 3:39 AM4/15/22 3:39 AM

See section 5 in the Owner ’s Manual for more information
CENTER PANEL
40 *IF EQUIPPEDS E LT O S FEATURES & FUNCTIONS GUIDE
Idle, Stop & Go (ISG) System
The ISG system is designed to help reduce fuel consumption by automatically shutting down the engine when the vehicle is at a standstill
When the ISG system is ON and the vehicle is at a standstill, the engine will stop, and the green AUTO STOP indicator A on the instrument cluster will illuminate green
The engine will restart when the brake pedal is released or the shift lever is moved from D (Drive) to the R (Reverse) position or to Manual Shift mode When engine restarts, the green AUTO STOP indicator on the instrument cluster will turn off
To deactivate the ISG System, press the ISG OFF button B If you press again, the system will be activated
CENTERPANEL
(Cluster B shown)
(But tons located on left of Steering Wheel)
Refer to the inside front cover for more information on QR codes www youtube com/KiaFeatureVideos
Idle, Stop & Go (ISG)Video
QR CODE
•The ISG system will not activate when:
– A seat belt is unfastened
– The hood or a door is opened
– Bat ter y condition is not adequate
– The front or rear defroster is turned on
– Engine coolant temperature is low
– The outside ambient temperature is too low/high
– Emission control devices activate
– The vehicle is on a steep slope
QUICK TIPSREMINDERS:
•
When the ISG system is on and the vehicle is at a standstill, the engine may not stop and the AUTO STOP indicator on the instrument cluster will illuminate YELLOW This indicates the system is functional but not all enabling criteria have been met
•
ISG is active by default at vehicle star tup When ignition is cycled, ISG will turn ON again
•
Under cer tain conditions, the engine will restar t automatically even if the brake pedal is still depressed
•
If the AUTO STOP indicator is continuously blinking yellow and the ISG but ton LED is on, please contact an authorized Kia dealer
A
B
MY23 Seltos FFG Inside March 2022.indd 40MY23 Seltos FFG Inside March 2022.indd 404/15/22 3:40 AM4/15/22 3:40 AM

50 *IF EQUIPPEDS E LT O S FEATURES & FUNCTIONS GUIDE
Place the Fuel Cap on the inside of the Fuel Filler Lid when fueling F
QUICK TIP
REMINDERS:
•
While lowering and closing, keep hands away from under the Hood
•
Open the Hood only after turning the engine off, on a flat sur face, with the gear shift in P (Park) position and set ting the parking brake
•
Make sure the hood is securely closed before driving
Fuel Filler Door ReleaseFuel Cap / Malfunction Indicator
(Check Engine Light)To open the Fuel Filler door:
1 Pull the Fuel Filler Door Open Lever A inside the vehicle (at floor level, left of Driver ’s Seat)
2 Pull the Fuel Filler door to fully open B
To open the Fuel Cap, turn it counterclockwise C
To access the Fuel Cap, pull the Fuel Filler Door Open Lever A inside the vehicle (on floor left of Driver ’s Seat) Tighten for ONE CLICK to prevent Malfunction Indicator from illuminating
See section 4 in the Owner ’s Manual for more information
See section 4 in the Owner ’s Manual for more information
See section 4 in the Owner ’s Manual for more information
OTHER KEY FEATURES
Refer to the inside front cover for more information on QR codes www youtube com/KiaFeatureVideos
Kia Fuel Cap Video
Fuel Filler Lid Release Video
QR CODE
Hood Release Lever and Latch
Opening the Hood:
1 Pull the Hood Release Lever E to unlatch the Hood
2 In the front of the vehicle, lift the Hood slightly, push the secondary Latch to the front inside of the Hood’s center and lift the Hood
Closing the Hood:
Lower the Hood first to about 12 inches away from being closed Then, press down to securely lock in place
A
REMINDER: It is normal operation when tightening to hear one click, and then when Fuel Cap is released, it clicks back
OTHER KEY FEATURES
E
B
C
D
MY23 Seltos FFG Inside March 2022.indd 50MY23 Seltos FFG Inside March 2022.indd 504/15/22 3:40 AM4/15/22 3:40 AM
