Lexus CT200h 2013 Owner's Manual (in English)
Manufacturer: LEXUS, Model Year: 2013, Model line: CT200h, Model: Lexus CT200h 2013Pages: 688
Page 181 of 688

181
3 3-5. Opening, closing the windows and moon roof
Operation of each component
CT200h_OM_OM76102E_(EE)
Moon roof
Opens the moon roof*
Push and hold “OPEN” for more
than 1 second. The moon roof tilts
up and then opens automatically.
Closes the moon roof*
Push and hold “CLOSE” for more
than 1 second. The moon roof closes
automatically to the tilt up position.
Push and hold “CLOSE” again to
fully close the moon roof.
*: Lightly press either end of the moon
roof switch to stop the moon roof
partway.
Tilts the moon roof up*
Tilts the moon roof down*
*
: Lightly press either end of the moon
roof switch to stop the moon roof
partway.
: If equipped
Use the overhead switches to open and close the moon roof and tilt it up
and down.
Opening and closing
1
2
Tilting up and down
1
2
Page 182 of 688

1823-5. Opening, closing the windows and moon roof
CT200h_OM_OM76102E_(EE)
The moon roof can be operated when
The power switch is in ON mode.
Operating the moon roof after turning the hybrid system off
The moon roof can be operated for approximately 45 seconds even after the
power switch is turned to ACCESSORY mode or turned off. It cannot, however,
be operated once either front door is opened.
Jam protection function
If an object is detected between the moon roof and the frame while the moon roof
is closing or tilting down, travel is stopped and the moon roof opens slightly.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade will
open automatically to slightly before the fully open position when the moon roof
is opened.
When the moon roof does not close normally
Perform the following procedure:
If the moon roof closes but then re-opens slightly
Stop the vehicle.
Press and hold the “CLOSE” switch.
*1
The moon roof will close, reopen and pause for approximately 10 sec-
onds.
*2 Then it will close again and tilt down. Finally it will be adjusted
slightly and then stop.
Check to make sure that the moon roof completely stops and then release the
switch.
If the moon roof tilts down but then tilts back up
Stop the vehicle.
Press and hold the “DOWN” switch.
*1
The moon roof will close, reopen and pause for approximately 10 seconds in
the tilt up position.
*2 Then it will close again and tilt down. Finally it will be
adjusted slightly and then stop.
Check to make sure that the moon roof has completely stopped and then
release the switch.
*1: If the switch is released at the incorrect time, the procedure will have to be
performed again from the beginning.
*2: If the switch is released after the above mentioned 10 second pause, auto-
matic operation will be disabled. In that case, press and hold the “CLOSE”
or “DOWN” switch, and the moon roof will close, be adjusted slightly and
then stop. Check to make sure that the moon roof has completely stopped
and then release the switch.
If the moon roof does not fully close even after performing the above procedure
correctly, have the vehicle inspected by any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
1
2
3
1
2
3
Page 183 of 688

1833-5. Opening, closing the windows and moon roof
3
Operation of each component
CT200h_OM_OM76102E_(EE)
Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the power switch is turned off and the driver’s door
is opened with the moon roof open.
WA R N I N G
Observe the following precautions.
Failing to do so may cause death or serious injury.
Opening the moon roof
Do not allow any passengers to put their hands or heads outside the vehicle
while it is moving.
Do not sit on top of the moon roof.
Closing the moon roof
Check to make sure that all passengers do not have any part of their body in a
position where it could be caught when the moon roof is being operated.
Do not allow children to operate the moon roof.
Closing the moon roof on someone can cause death or serious injury.
Jam protection function
Never use any part of your body to intentionally activate the jam protection
function.
The jam protection function may not work if something gets caught just
before the moon roof fully closes.
Page 184 of 688

1843-5. Opening, closing the windows and moon roof
CT200h_OM_OM76102E_(EE)
Page 185 of 688

185
4Driving
CT200h_OM_OM76102E_(EE)
4-1. Before driving
Driving the vehicle............ 186
Cargo and luggage ............ 194
Trailer towing.................... 195
4-2. Driving procedures
Power (ignition) switch ..... 196
EV drive mode .................. 201
Hybrid transmission .......... 203
Turn signal lever ............... 209
Parking brake .................... 2104-3. Operating the lights
and wipers
Headlight switch ................211
Fog light switch ................ 216
Windshield wipers and
washer ............................. 218
Rear window wiper and
washer ............................. 222
Headlight cleaner switch .. 223
4-4. Refueling
Opening the fuel tank cap . 224
4-5. Using the driving support
systems
Cruise control ................... 228
Dynamic radar cruise
control ............................. 231
Lexus parking
assist-sensor .................... 245
Rear view monitor system 253
Driving mode select
switch.............................. 265
Driving assist systems ...... 266
Hill-start assist control ...... 271
PCS (Pre-Crash Safety
system)............................ 273
4-6. Driving tips
Hybrid vehicle driving tips 281
Winter driving tips ............ 284
Page 186 of 688

1864-1. Before driving
CT200h_OM_OM76102E_(EE)
Driving the vehicle
P. 1 9 6
With the brake pedal depressed, shift the shift position to D. (P. 203)
Check that the shift position indicator shows D.
Release the parking brake. (P. 210)
Gradually release the brake pedal and gently depress the accelerator
pedal to accelerate the vehicle.
With the shift position in D, depress the brake pedal.
If necessary, set the parking brake.
If the vehicle is to be stopped for an extended period of time, shift the shift
position to P. (P. 205)
Stop the vehicle completely.
Set the parking brake. (P. 210)
Shift the shift position to P. (P. 205)
Check that the shift position indicator shows P.
Press the power switch to stop the hybrid system.
Slowly release the brake pedal.
Lock the door, making sure that you have the electronic key on your
person.
If parking on a hill, block the wheels as needed.
The following procedures should be observed to ensure safe driving:
Starting the hybrid system
Driving
Stopping
Parking the vehicle
1
2
3
1
2
1
2
3
4
5
6
Page 187 of 688

1874-1. Before driving
4
Driving
CT200h_OM_OM76102E_(EE)
Firmly set the parking brake with the brake pedal depressed, and then
shift the shift position to D.
Release the brake pedal and gently depress the accelerator pedal.
Release the parking brake.
When starting off on a uphill
The hill-start assist control is available. (P. 271)
For fuel-efficient driving
Keep in mind that hybrid vehicles are similar to conventional vehicles, and it is
necessary to refrain from activities such as sudden acceleration, etc. Refer to
“Hybrid vehicle driving tips”. (281)
Driving in the rain
Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.
Drive carefully when it starts to rain, because the road surface will be especially
slippery.
Refrain from high speeds when driving on an expressway in the rain, because
there may be a layer of water between the tires and the road surface, preventing
the steering and brakes from operating properly.
Breaking in your new Lexus
To extend the life of the vehicle, observing the following precautions is recom-
mended:
For the first 300 km (200 miles):
Avoid sudden stops.
For the first 2000 km (1200 miles):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive at a constant speed for extended periods.
Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (P. 639)
Starting off on a uphill
1
2
3
Page 188 of 688

1884-1. Before driving
CT200h_OM_OM76102E_(EE)
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury.
When starting the vehicle
Always keep your foot on the brake pedal while stopped with the “READY”
indicator is illuminated. This prevents the vehicle from creeping.
When driving the vehicle
Do not drive if you are unfamiliar with the location of the brake and accelera-
tor pedals to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake pedal
will result in sudden acceleration that may lead to an accident.
• When backing up, you may twist your body around, leading to a difficulty
in operating the pedals. Make sure to operate the pedals properly.
• Make sure to keep a correct driving posture even when moving the vehicle
only slightly. This allows you to depress the brake and accelerator pedals
properly.
• Depress the brake pedal using your right foot. Depressing the brake pedal
using your left foot may delay response in an emergency, resulting in an
accident.
The driver should pay extra attention to pedestrians when the vehicle is pow-
ered only by the electric motor (traction motor). As there is no engine noise,
the pedestrians may misjudge the vehicle’s movement.
Do not drive the vehicle over or stop the vehicle near flammable materials.
The exhaust system and exhaust gases can be extremely hot. These hot parts
may cause a fire if there is any flammable material nearby.
During normal driving, do not turn off the hybrid system. Turning the hybrid
system off while driving will not cause loss of steering or braking control,
however, power assist to the steering will be lost. This will make it more diffi-
cult to steer smoothly, so you should pull over and stop the vehicle as soon as
it is safe to do so. In the event of an emergency, such as if it becomes impossi-
ble to stop the vehicle in the normal way: P. 5 6 1
Use engine braking (shift position B instead of shift position D) to maintain a
safe speed when driving down a steep hill.
Using the brakes continuously may cause the brakes to overheat and lose
effectiveness. (P. 204)
Do not adjust the positions of the steering wheel, the seat, or the inside or out-
side rear view mirrors while driving.
Doing so may result in a loss of vehicle control.
Always check that all passengers’ arms, heads or other parts of their body are
not outside the vehicle.
Page 189 of 688

1894-1. Before driving
4
Driving
CT200h_OM_OM76102E_(EE)
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury.
When driving on slippery road surfaces
Sudden braking, acceleration and steering may cause tire slippage and reduce
your ability to control the vehicle.
Sudden acceleration, engine braking due to shift changing, or changes in
engine speed could cause the vehicle to skid.
After driving through a puddle, lightly depress the brake pedal to make sure
that the brakes are functioning properly. Wet brake pads may prevent the
brakes from functioning properly. If the brakes on only one side are wet and
not functioning properly, steering control may be affected.
When shifting the shift position
Do not let the vehicle roll backward while a forward driving position is
selected, or roll forward while the shift position is in R.
Doing so may result in an accident or damage to the vehicle.
Do not shift the shift position to P while the vehicle is moving.
Doing so can damage the transmission and may result in a loss of vehicle con-
trol.
Do not shift the shift position to R while the vehicle is moving forward.
Doing so can damage the transmission and may result in a loss of vehicle con-
trol.
Do not shift the shift position to D while the vehicle is moving backward.
Doing so can damage the transmission and may result in a loss of vehicle con-
trol.
Moving the shift position to N while the vehicle is moving will disengage the
hybrid system. Engine braking is not available with the hybrid system disen-
gaged.
Be careful not to change the shift position with the accelerator pedal
depressed.
Changing the shift position to any positions other than P or N may lead to
unexpected rapid acceleration of the vehicle that may cause an accident and
result in death or serious injury.
After changing the shift position, make sure to confirm the current shift posi-
tion displayed on the shift position indicator inside the meter.
Page 190 of 688

1904-1. Before driving
CT200h_OM_OM76102E_(EE)
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury.
If you hear a squealing or scraping noise (brake pad wear indicators)
Have the brake pads checked and replaced by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional as soon as possi-
ble.
Rotor damage may result if the pads are not replaced when needed.
Front brakes only: Moderate levels of brake pad and disc wear allow enhanced
front braking power. As a result, the discs may wear more quickly than conven-
tional brake discs. Therefore, when replacing the brake pads, Lexus recom-
mends that you also have the thickness of the discs measured.
It is dangerous to drive the vehicle when the wear limits of the brake pads and/
or those of the brake discs are exceeded.
When the vehicle is stopped
Do not depress the accelerator pedal unnecessarily.
If the shift position is any position other than P or N, the vehicle may acceler-
ate suddenly and unexpectedly, causing an accident.
In order to prevent accidents due to the vehicle rolling away, always keep
depressing the brake pedal while stopped with the “READY” indicator is illu-
minated, and apply the parking brake as necessary.
If the vehicle is stopped on an incline, in order to prevent accidents caused by
the vehicle rolling forward or backward, always depress the brake pedal and
securely apply the parking brake as needed.
Avoid revving or racing the engine.
Running the engine at high speed while the vehicle is stopped may cause the
exhaust system to overheat, which could result in a fire if combustible mate-
rial is nearby.
