- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
14-95
2187 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
27. REMOVE NO.2 CAMSHAFT
(a) Using several steps, loosen and remove the 10 bearing
cap bolts uniformly in the sequence shown in the illustra-
tion. Remove the 5 bearing caps and No. 2 camshaft.
NOTICE:

Do not pry out the camshaft.

Be careful not to damage the contact surface of the
cylinder head that receives the shaft thrust.
(b) Remove the oil seal from the No. 2 camshaft.
28. REMOVE CAMSHAFT TIMING GEAR ASSY
NOTICE:
Do not remove or install the camshaft timing gear (VVT-i)
unless you are replacing the VVT-i or camshaft.
(a) Clamp the camshaft in a vise on the hexagonal lobe.
NOTICE:
Be careful not to damage the camshaft.
(b) Using a 46 mm socket wrench, remove the lock nut by
turning it clockwise.
NOTICE:

Remove it with the lock pin engaged and locked at the
most retard angle position.

The lock nut has LH threads.

Never use any tools other than the socket wrench.
Other tools will deform the cam angle rotor.
(c) Remove the camshaft VVT-i.
NOTICE:
Never remove the 3 bolts on the gear.
If it is difficult to remove VVT-i, tap it lightly using a plastic-faced
hammer, then remove it.
29. REMOVE CAMSHAFT SUB GEAR
(a) Clamp the camshaft in a vise on the hexagonal lobe.
NOTICE:
Be careful not to damage the camshaft.

A78715
SST
A52353
P12595
A78732
Camshaft
Sub Gear
Camshaft Gear
Bolt Washer Wave Washer
A52353
14-96
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
2188 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using SST, turn the sub gear counterclockwise, then re-
move the service bolt.
SST 09960-10010 (09962-01000, 09963-00500)
(c) Using snap ring pliers, remove the snap ring.
(d) Remove the wave washer, camshaft sub gear and cam-
shaft gear bolt washer.
30. INSTALL CAMSHAFT SUB GEAR
(a) Clamp the camshaft in a vise on the hexagonal lobe.
NOTICE:
Be careful not to damage the camshaft.
(b) Install the camshaft gear bolt washer and camshaft sub
gear.
HINT:
Attach the pins on the gears to the gear bolt washer ends.
(c) Install the wave washer.
(d) Using snap ring pliers, install the snap ring.

A78733
SST
A78734
Align
A05738
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
14-97
2189 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(e) Using SST, align the holes of the camshaft main gear and
sub gear by turning the camshaft sub gear counterclock-
wise, then temporarily install a service bolt.
SST 09960-10010 (09962-01000, 09963-00500)
(f) Align the gear teeth of the main gear and sub gear, then
tighten the service bolt.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
NOTICE:
Be careful not to damage the camshaft journals.
HINT:
When installing the camshaft, make certain that the torsional
spring force of the sub gear has been eliminated by installation
of the service bolt.
31. INSTALL CAMSHAFT TIMING GEAR ASSY
(a) Align the alignment pin with the alignment pin groove,
then install the VVT-i on the camshaft.
NOTICE:
Install it with the lock pin engaged and locked at the most
retard angle position.
(b) Apply engine oil to the nut, mounting surface of the VVT-i
and screw threads.
NOTICE:

Be sure to apply the oil, otherwise the specified
torque cannot be obtained.

New nut must be used when replacing the VVT-i unit.
(c) Using a 46 mm socket wrench, install and tighten a lock
nut by turning it counterclockwise.
Torque: 150 NVm (1,530 kgfVcm, 111 ftVlbf)
NOTICE:

The lock nut has LH threads.

Never use any tools other than the socket wrench.
Other tools will deform the cam angle rotor.
32. INSTALL NO.2 CAMSHAFT
NOTICE:
Since the thrust clearance of the camshaft is small, the
camshaft must be kept level while being installed. If the
camshaft is not kept level, the cylinder head or camshaft
may be damaged. To avoid this, the following steps must
be carried out.
(a) Apply new engine oil to the thrust portion and journal of
the camshaft.

A78735
90
A78736
Front
A78737Seal Packing
A05283
A78738
10
1
2
3
45
6
7
8
9 14-98
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
2190 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Place the No. 2 camshaft at a 90 angle of the timing mark
(2 dot marks) on the cylinder head.
(c) Apply multi-purpose grease to a new oil seal lip.
(d) Install the oil seal to the camshaft.
NOTICE:

Do not turn over the oil seal lip.

Insert the oil seal until it stops.
(e) Remove any old packing material from the contact sur-
face.
(f) Apply seal packing to the bearing cap No. 1 as shown in
the illustration.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:

Install the bearing cap No. 1 within 5 minutes after ap-
plying seal packing.

Do not expose the seal packing to engine oil within 2
hours after installing.
(g) Install the 5 bearing caps in their proper locations.
(h) Apply a light coat of engine oil to the threads of the bear-
ing cap bolts.
(i) Using several steps, tighten the 10 bearing cap bolts uni-
formly in the sequence shown in the illustration.
Torque: 16 NVm (163 kgfVcm, 12 ftVlbf)

A78739
Align
A05204
A78740
101
23
4
5
6
7
8
9
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
14-99
2191 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
33. INSTALL CAMSHAFT
NOTICE:
Since the thrust clearance of the camshaft is small, the
camshaft must be kept level while being installed. If the
camshaft is not kept level, the cylinder head or camshaft
may be damaged. To avoid this, the following steps must
be carried out.
(a) Apply new engine oil to the thrust portion and journal of
the camshaft.
(b) Align the timing marks (2 dot marks) of the camshaft drive
and driven gears.
(c) Place the camshaft on the cylinder head.
(d) Install the 5 bearing caps in their proper locations.
(e) Apply a light coat of engine oil to the threads of the bear-
ing cap bolts.
(f) Using several steps, tighten the 10 bearing cap bolts uni-
formly in the sequence shown in the illustration.
Torque: 16 NVm (163 kgfVcm, 12 ftVlbf)
(g) Remove the service bolt.
34. INSTALL TIMING BELT NO.3 COVER
(a) Visually check for cracks and breaks on the gasket of the
timing belt cover.
HINT:
If there is a trace of water intrusion when checking visually, re-
pair the gasket with seal packing when the crack length is within
2 to 3 cm (0.79 to 1.18 in.). Replace the gasket when the crack
length is 3 to 4 cm (1.18 to 1.57 in.) or longer.

A78748
Seal Packing
Gasket
A78749
E
F
Joining
Line D
G
Gasket Joining Portion:
Seal Packing E
Joining
Line
A78750
FrontFront
Belt
GuideBelt
Guide
14-100
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
2192 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) If the timing belt cover gasket is needed to repair, follow
the procedure below.
(1) Repair the cracks and breaks by applying seal
packing to the damaged area.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
When applying the seal packing, apply it as wide and high
as the gasket.
(c) If the timing belt cover gasket is needed to replace, follow
the procedure below.
(1) Using a screwdriver and gasket scraper, remove
the remaining gasket.
NOTICE:
Be careful not to damage the timing belt cover.
(2) Remove the backing paper from a new gasket, then
affix the gasket along the groove of the timing belt
cover as shown in the illustration.
NOTICE:

Affix the gasket in the center of the groove.

At the corners, try to keep the gasket thickness uni-
form.
HINT:
GasketDEFG
Length335 mm
(13.19 in.)180 mm
(7.09 in.)133 mm
(5.24 in.)72 mm
(2.83 in.)
(3) If there is a gap between the ends of the gasket, ap-
ply seal packing to close the gap.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
When applying the seal packing, apply it as wide and high
as the gasket.
(d) Install the timing belt cover with the 6 bolts.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
35. INSTALL CAMSHAFT TIMING PULLEY
(a) Pay attention to the orientation of the belt guide. Install
the camshaft timing pulley with the belt guide properly ori-
ented, then tighten the bolt temporarily.
HINT:

Align the belt guide of the RH timing pulley so it faces the
front of the engine as illustrated.

Align the belt guide of the LH timing pulley so it faces the
rear of the engine as illustrated.

A78763
150 mm
(5.91 in.)SST RH:
A78762
SSTLH:
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
14-101
2193 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using SST, tighten the RH pulley bolt.
SST 09960- 10010 (09962- 01000, 09963- 01000),
09249-63010
Torque: 125 NVm (1,275 kgfVcm, 92 ftVlbf)
NOTICE:
The torque indicated above is used without SST on the ex-
tension tool. If you are using the extension tool, find the
reading of the torque wrench by the formula (see page
01-5).
Extended length:
SST (09249-63010) 150mm (5.91 in.)
(c) Using SST, tighten the LH pulley bolt.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 125 NVm (1275 kgfVcm, 92 ftVlbf)
36. INSTALL TIMING BELT IDLER SUB-ASSY NO.2
Torque: 43 NVm (438 kgfVcm, 32 ftVlbf)
37. INSPECT TIMING BELT (See page 14-79)
38. INSTALL TIMING BELT (See page 14-79)
SST 09960-10010 (09962-01000, 09963-01000)
39. INSTALL TIMING BELT TENSIONER ASSY (See page 14-79)
40. INSTALL TIMING BELT GUIDE NO.2 (See page 14-79)
41. INSTALL ENGINE MOUNTING BRACKET RH (See page 14-79)
42. INSTALL TIMING BELT NO.2 COVER (See page 14-79)
43. INSTALL TIMING BELT NO.1 COVER (See page 14-79)
44. INSTALL CRANKSHAFT PULLEY (See page 14-79)
SST 09213-54015 (91651-60855), 09330-00021
45. INSTALL GENERATOR BRACKET NO.2 (See page 14-79)
46. INSTALL ENGINE MOUNTING STAY NO.2 RH (See page 14-79)
47. INSTALL ENGINE MOVING CONTROL ROD (See page 14-79)
48. INSPECT VALVE CLEARANCE (See page 14-7)
49. ADJUST VALVE CLEARANCE (See page 14-7)
SST 09248-55040 (09248-05410, 09248-05420)
50. INSTALL VANE PUMP V BELT (See page 14-5)
51. INSTALL V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See page 14-5)
52. INSPECT DRIVE BELT DEFLECTION AND TENSION (See page 14-1)
53. INSTALL CYLINDER HEAD COVER SUB-ASSY (See page 14-7)
54. INSTALL IGNITION COIL ASSY (See page 14-7)

14-102
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
2194 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
55. INSTALL INTAKE AIR SURGE TANK (See page 11-13)
56. INSTALL EMISSION CONTROL VALVE SET (See page 11-13)
57. INSTALL AIR CLEANER CAP SUB-ASSY (See page 10-1 1)
58. CHECK CONNECTION OF VACUUM HOSE (See page 14-29)
59. INSTALL V-BANK COVER SUB-ASSY (See page 10-1 1)
60. INSTALL FRONT SUSPENSION UPPER BRACE CENTER (W/O TEMS) (See page 10-1 1)
61. INSTALL FRONT WHEEL RH (See page 14-5)
62. ADD ENGINE COOLANT (See page 16-9)
63. CHECK FOR ENGINE COOLANT LEAKS (See page 16-1)
64. SYSTEM INITIALIZATION (See page 19-15)

141JE-01
A84916
64 (653, 47)
64 (653, 47)
Front Fender Apron
Seal RH
Vane Pump V Belt
V Belt No. 1
Generator Bracket No. 2
Engine Mounting Stay No. 2 RHEngine Moving Control Rod
N´m (kgf´cm, ft´lbf)
: Specified torque
23 (235, 17)
58 (591, 43)
28 (286, 21)
Radio Setting Condenser
- ENGINE MECHANICALCAMSHAFT (LH BANK) (3MZ-FE)
14-103
2195 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
CAMSHAFT (LH BANK) (3MZ-FE)
COMPONENTS

A78353
N´m (kgf´cm, ft´lbf)
: Specified torque
8.5 (87, 75 in.Vlbf)
220 (2,250, 162)8.5 (87, 75 in.Vlbf)
28 (286, 21)
27 (280, 20)
Timing Belt Tensioner AssyCrankshaft PulleyTiming Belt No. 1 Cover
Timing Belt Guide No. 2
Engine Mounting Bracket RH Timing Belt No. 2 Cover
Timing Belt
Engine Wire
Protector
14-104
- ENGINE MECHANICALCAMSHAFT (LH BANK) (3MZ-FE)
2196 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
