Lexus Supports ASE CertificationPage 1 of 1
Title:
TIRE POSITIONING BEFORE NEW
VEHICLE DELIVERY
Models:
'05 ± '06 All Lexus
Technical Service
Information Bulletin
March 2, 2005
PG002-05
During the manufacturing process, tire characteristics are measured. Tires are then
mounted on the vehicle as matched sets to help reduce conditions such as pulling or
drifting. If the wheels are replaced or refinished before vehicle delivery, it is important
that the tires remain on the vehicle in the same location and in the same direction
of rotation.
Please refer to the following procedure to ensure that the original tires stay in the same
location on the vehicle.
All 2005 ± 2006 model year Lexus vehicles.
1. Mark the tire installation position on the inward facing tire sidewall.
Example: Front Right = FR, Front Left = FL, Rear Right = RR, Rear Left = RL
2. Install the original tires on the new or refinished wheels with the marked side
facing inwards.
3. Place the tire/wheel assemblies on the vehicle in the marked positions.
NOTE:
Torque the wheel nuts to the proper torque value in sequence.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Installation
Procedure
Warranty
Information

Lexus Supports ASE CertificationPage 1 of 2
Title:
REPLACEMENT VIN PLATES
Models:
All Models
Technical Service
Information Bulletin
January 18, 2002
PG003-02
TSB UPDATE NOTICE:
The information contained in this TSIB updates PG016±01 dated May 4, 2001.
Revised text is red
and underlined. The changes will take place February 1, 2002.
Replacement VIN plates (metal plates riveted to dashboard) may be available from
Lexus providing the request meets the criteria listed below.
VIN Plate Location
All Lexus vehicles.
The vehicle is in an accident and the plate is damaged.
NOTE:
The original plate to be replaced MUST accompany the request.
NOTE:
If a plate is stolen, be sure to contact the State Police or your State's Department of
Motor Vehicles (DMV). In most cases the State DMV will issue a unique number so that
the original number can be included on stolen vehicle listings. If this is the case, a
replacement plate is NOT available from Lexus. However, the original VIN, NOT the
state issued VIN, must be used on all warranty claims.
To request a replacement plate, complete a copy of the form on the back of this page.
Note that the damaged VIN plate MUST accompany the request form. Your dealer parts
account will be billed $25.00
for each replacement of a damaged plate.
NOTE:
All replacement plates for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Replacement
VIN Plate
Criteria
Procurement
Procedure
Warranty
Information

DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT VIN PLATE
DEALER INFORMATION
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD PLATE TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA. 90509±2991
( )
ATTACH DAMAGED PLATE HERE

Lexus Supports ASE CertificationPage 1 of 4
Title:
BATTERY MAINTENANCE FOR
IN-STOCK VEHICLES & PRE-DELIVERY
Models:
All Models & Model Years Through Current
Technical Service
Information Bulletin
September 12, 2002
PG009-02
A battery in a stored vehicle is subject to conditions that can reduce its performance and
life. These conditions include storage period, temperature, parasitic drain, and battery
load. Because of these factors, battery inspection and maintenance are required in
order to ensure proper operation and optimal battery life.
As a matter of policy, Lexus does not provide battery warranty coverage for discharged
and/or failed batteries due to lack of maintenance; it is the dealer's responsibility to
maintain the specified state of charge of the vehicle's battery while in stock and assure
proper state of charge at delivery.
To eliminate customer service concerns due to an undercharged battery during the first
few weeks of ownership, all dealers should check battery state of charge and
recharge, if necessary, just prior to delivery (i.e., within 48 hours of delivery).
This new procedure will improve the new vehicle ownership experience by greatly
reducing the risk of having a low performance battery concern due to extended storage
periods and/or short engine run times prior to the vehicle sale.
All models and model years through current.
SPECIAL SERVICE TOOLS (SSTs)MANUFACTURERPART NUMBER
MICROPRO 815 Digital
Battery Analyzer
(Essential SST)*Midtronics00002±MP815±T
* This SST can be ordered through SPX/OTC by calling 1±800±933±8335.
NOTE:
MICROPRO 815 Digital Battery Analyzer should be periodically updated through the
Technical Information System (TIS) for new vehicle models. For detailed information,
please see TSIB SS002±02, ªMidtronics Battery Tester Software Update.º
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Required
Tools &
Material
Warranty
Information

BATTERY MAINTENANCE FOR IN±STOCK VEHICLES & PRE±DELIVERY ± PG009-02 September 12, 2002
Page 2 of 4
TOOLS & EQUIPMENTMANUFACTURERPART NUMBER
Fast Battery Charger**AssociatedASE6003
Fast Battery Charger**ChristieCAPPDQ
** These tools can be ordered through the Lexus Approved Dealer Equipment program by calling
1±800±368±6787.
NOTE:
The ªFast Battery Chargersº listed above have been tested and approved by Lexus.
These state±of±the±art ªsmartº chargers were designed to charge batteries at an
accelerated rate, without the possibility of damage. Using non±microprocessor
controlled battery chargers for fast charging purposes can damage the battery.
All vehicles are to be inspected according to the procedures listed below using the
MICROPRO 815 battery tester no more than 48 hours prior to customer vehicle delivery.
PRIOR TO TESTING:
If necessary, remove battery surface charge by turning on high beam headlights for 60
seconds, then let battery voltage recover for one minute.
1. Connect test clamps to battery.
(Display will show four zeros
indicating a good connection).
2. For cold battery (<32
F) or after
charge test, press TEST MODE key
until appropriate test is selected.
3. Input battery stock number.
NOTE:
Stock number must be used for
warranty cases because you cannot
read the warranty code if CCA/CA
rating is input.
4. Press STK#/Code key to start test.
NOTE:
Stock numbers are listed on the
reference card located in the tester's
cover. Stock numbers can also be
referenced on TIS. The TIS listings
will always have up±to±date
information.
Stock number location in TIS:
1. Go to TIS Home Page.
2. Click on ªDiagnostics.º
3. Click on ªMidtronics Battery Tester
Software.º
4. Click on ªStock Number Chart.º Recommended
Equipment
Inspection
Procedure

BATTERY MAINTENANCE FOR IN±STOCK VEHICLES & PRE±DELIVERY ± PG009-02 September 12, 2002
Page 3 of 4
5. Read STATE OF CHARGE and
BATTERY CONDITION.
a. If battery is at 75% STATE OF
CHARGE or greater, release
vehicle to new owner.
b. If battery is less than 75%
STATE OF CHARGE proceed
to Battery Service Procedure.
Follow the procedures below according to the BATTERY CONDITION results.
BATTERY CONDITION: ªGood return to serviceº (less than 75% State of Charge)
Charge battery using one of the recommended chargers indicated above (or equivalent)
following the Quick Charge instructions accompanying that machine.
BATTERY CONDITION: ªCharge and return to serviceº
Charge battery using one of the recommended chargers indicated above (or equivalent)
following the Quick Charge instructions accompanying that machine.
BATTERY CONDITION: ªCharge and retestº
The battery must be Quick Charged and retested using the After charge test mode.
Carry out the service according to the result of the retest.
BATTERY CONDITION: ªReplaceº
The battery must be replaced. Press the STK#/CODE key to show the warranty code for
the repair order and for the Warranty Battery Label.
If a vehicle battery needs to be replaced
for a warrantable condition, make sure to
complete a Warranty Battery Label and
affix it to the failed battery for proper
warranty parts and claim processing.
Please include the Vehicle
Identification Number and warranty
code on the Warranty Battery Label.Inspection
Procedure
(Continued)
Battery
Service
Procedure
Battery
Replacement
Repair Order No.
Repair Date
Failure Code

WARRANTY BATTERY LABEL
ETIQUETA PARA BATERIA DE GARANTIA
Dealer Code

Veh. Date of First Use
Fecha de Primer
Uso del Veh.Original Install Date
Fecha
(Svc. part replacement only/
solamente para el reemplazo
de partes de servicio)Battery Mos. In Svc.
N–mero de meses que
Bater‹a est€ en servicio
00404±BTTRY±LABEL (Please Print / Ll‡nese con Letra de Molde Por Favor)
Vehicle Identification Number (VIN)
(NIV)
08/02

BATTERY MAINTENANCE FOR IN±STOCK VEHICLES & PRE±DELIVERY ± PG009-02 September 12, 2002
Page 4 of 4
In addition to this new pre±delivery battery test, a monthly battery inspection is still
required for stored vehicles. If your dealership is located in an area subject to extreme
temperatures (hot or cold), periodic maintenance may need to be performed more
frequently.
To reduce parasitic battery drain for vehicles in storage for one week or more, the
negative battery cable should always be disconnected to reduce battery discharge.
When the negative battery cable is reconnected, please check and reset electrical
components such as the clock, radio, etc.
NOTE:
For your reference, the electrical system is made inoperative by removing the
appropriate fuse indicated in the Electrical Wiring Diagram. Recom-
mended
Battery
Maintenance

Lexus Supports ASE CertificationPage 1 of 6
Title:
FAILURE TO INITIALIZE CAN
INTERFACE MODULE
Models:
'04 ± '05 Applicable Models
Technical Service
Information Bulletin
March 11, 2005
SS001-05
TSIB REVISION NOTICE:
June 23, 2005: The ªRequired SSTsº section has been updated.
The previous TSIB should be discarded.
If the Diagnostic Tester fails to initialize CAN±based communication with on±board
vehicle controllers, a damaged cable or inoperative CAN Interface Module may be at
fault. This bulletin provides test procedures to check the integrity of the Diagnostic Tester
cables and the CAN Interface Module.
2004 ± 2005 model year CAN±equipped vehicles including 2004 model year LS 430
and 2005 model year GX 470 and LS 430.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
SPECIAL SERVICE TOOLS
Introduction
Applicable
Vehicles
Warranty
Information

FAILURE TO INITIALIZE CAN INTERFACE MODULE ± SS001-05 Revised March 11, 2005
Page 2 of 6
ITEM
NO.SPECIAL SERVICE TOOLS (SSTs)PART NUMBERQTYDRW**
1Diagnostic Tool Set*LEX22003618
COMPONENT(S) OF KIT/SETTester
(P/N 02002019)
14/26 Pin DLC Cable
(P/N 02001637) 12 Megabyte Program Card Kit
(P/N 01002593±005) with version 12.2a Software
(or later)
14 Pin DLC Self Test Adapter
(P/N 02001607)
Four (4) components from this kit/set are required:
2CAN Module Kit*0100274418
COMPONENT(S)
OF KIT/SETNOTE:
All components from this kit/set are required
Module box cannot be ordered separately
J1962 OBD2±II (CAN DLC)
(P/N 02003180)
* Essential SSTs.
** Refers to drawer number in SST Storage System.
NOTE:
Additional Diagnostic Tool Sets, CAN Module Kits, Program Cards, or other SSTs may
be ordered by calling SPX/OTC at 1-800-933-8335. Required
SSTs

FAILURE TO INITIALIZE CAN INTERFACE MODULE ± SS001-05 Revised March 11, 2005
Page 3 of 6
Failure to initialize CAN±based communications between the Diagnostic Tester and
on±board vehicle controllers can be caused by the following issues:
The 14/26 Pin DLC cable is damaged, causing an open communication circuit.
The DLC cable is damaged, causing an open communication circuit.
The CAN Interface Module is damaged.
The vehicle's CAN Communication System has a fault, requiring further
vehicle diagnostics.
NOTE:
The Diagnostic Tester may operate properly in other modes such as OBD/MOBD and
CARB OBDII with a damaged cable or CAN module.
NOTE:
To lengthen the Diagnostic Tester cable life, do not wrap the cable around the tester, or
hold the tester only by the cable.J1962 OBD2±II
Cable (CAN DLC)
Only (P/N 02003180)
CAN Interface
Module Only
14/26 Pin
DLC Cable
(P/N 02001637)
J1962 OBD2±II Cable &
CAN Interface Module
(P/N 01002744) Figure 1
Diagnostic
Procedure
