For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
ix
Page
1Door lock switch and power window
switches 28, 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Driving position memory switches 178. . . . . . . . . . .
3Power rear view mirror control switches 183. . . . . .
4Side vents 205. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5Instrument panel light control dial 68. . . . . . . . . . . . . .
6Headlight, turn signal and
fog light switches 34, 37, 40, 41. . . . . . . . . . . . . . . . . . .
7Multi-information display control switches 66. . . . .
8Ignition switch 268. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9Wiper and washer switches 41. . . . . . . . . . . . . . . . . . . .
10Seat heater switches 56. . . . . . . . . . . . . . . . . . . . . . . . . .
11Emergency flasher switch 54. . . . . . . . . . . . . . . . . . . . .
12Clock 74. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Car audio 211, 235. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Front passenger's seat belt reminder light 57. . . . . .
15AIRBAG OFFº indicator light 152. . . . . . . . . . . . . . . .
16AIRBAG ONº indicator light 152. . . . . . . . . . . . . . . . . Page
17Security indicator light 16, 30. . . . . . . . . . . . . . . . . . . .
18Glove box 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Automatic air conditioning controls 192. . . . . . . . . .
20Rear window and outside rear view mirror
defogger switch 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Ashtray 75. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Automatic transmission selector lever 272. . . . . . . .
23Rear electric sunshade switch 88. . . . . . . . . . . . . . . . .
24Electronic modulated suspension
control switch 282. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Traction control system off switch 284. . . . . . . . . . .
26Cruise control switch 279. . . . . . . . . . . . . . . . . . . . . . .
27Power adjustable pedals switch 181. . . . . . . . . . . . . .
28Parking brake pedal 269. . . . . . . . . . . . . . . . . . . . . . . . .
29Auxiliary box 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Hood lock release lever 92. . . . . . . . . . . . . . . . . . . . . . .
31Trunk lid opener 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Fuel filler door opener 96. . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 1 ± 6
104
INSTRUMENTS AND CONTROLS
Occupant restraint system
Seats105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front seats105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints11 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts11 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS driver airbag and front passenger airbag124 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS side airbags and curtain shield airbags137 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front passenger occupant classification system152 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint156 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system178 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OCCUPANT RESTRAINT SYSTEM
178
DRIVING POSITION MEMORY
SYSTEM
The microcomputer can memorize the positions of the driver's
seat, accelerator and brake pedals, and outside rear view
mirrors. Two different driving position profiles can be entered
into the computer's memory.
Recording a driving position in the computer's memory can
only be done when the ignition key is in the ONº position and
the selector lever is in the Pº position.
Setting the driving position
1. Adjust the driver's seat, accelerator and brake pedals,
and outside rear view mirrors to the desired position.
2. While pushing the SETº button, push button 1º or 2º
until the signal beeps.
The beep sound means that the positions are recorded in the
computer's memory.By repeating these two steps and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
When you push button 1º or 2º, the driving position will
be automatically adjusted to the position recorded for that
button.

OCCUPANT RESTRAINT SYSTEM
179 Conditions for memorized position activation
Ignition key ONº and selector lever in Pº position.
Ignition switch off and within 30 seconds of opening driver's
door.
If any driving position memory switch is pushed while one of the
memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (1º or 2º)
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle's battery is disconnected, the computer's
memory will be erased and the memorized positions will have
to be set again.
CAUTION
Do not start the vehicle while the adjustments are
being made.
Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.

ELECTRICAL COMPONENTS
420
54WASHER15Windshield washer
55FA N
RLY10Electric cooling fans
56STOP15Stop lights, high mounted
stoplight
57FUEL
OPEN5Fuel filler door opener
58DOOR
NO.225
Multiplex communication
system (power door lock
system, auto- door locking
system, wireless remote
control system)
59AMP25Car audio system
60PWR NO.320Rear passenger's power
window (right side)
No.FUSEAMPERECIRCUIT
61PWR
SEAT30Power seats, driving position
memory system
62PWR NO.130Driver's door lock system,
driver's power window, electric
moon roof
63DEF40Rear window defogger
