411
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
■Switching between outside air and recirculated air modes
Recirculated air mode or outside air mode may be automatically switched to in
accordance with the temperature setting, the inside temperature, outside tempera-
ture, etc.
■Using the system in recirculated air mode
The windows will fog up more easily if the recirculated air mode is used.
■When the outside temperature exceeds 75 °F (24 °C) and the air conditioning
system is on
●In order to reduce the air conditioning power consumption, the air conditioning
system may switch to recirculated air mode automatically.
This may also reduce fuel consumption.
●Recirculated air mode is selected as a default mode when the “ENGINE START
STOP” switch is turned to IGNITION ON mode.
●It is possible to switch to outside air mode at any time by pressing .
■Window defogger feature
Recirculated air mode may automatically switch to
(outside air) mode in situ-
ations where the windows need to be defogged.
■Automatic mode for air intake control (vehicles with a rear automatic air condi-
tioning system)
In automatic mode, the system detects exhaust gas and other pollutants and auto-
matically switches between outside air and recirculated air modes.
When the air conditioning is off, and the fan is operating, turning automatic mode
on will activate the air conditioning system.
■Micro dust and pollen filter
●In order to prevent the windows from fogging up when the outside air is cold,
the following may occur.
• Outside air mode does not switch to (recirculated air) mode.
• The air conditioning system operates automatically.
• The operation cancels after 1 minute.
●In rainy weather, the windows may fog up. Press .
■When outside air temperature is below 32 °F (0 °C)
The cooling and dehumidification function may not operate even when the “A/C”
button is pressed.
GX460_OM_OM60J63U_(U).book Page 411 Thursday, March 29, 2012 9:10 AM

412
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)
■When the “A/C ON” in the multi-information display (accessory meter) flashes
Press
the “A/C” button and turn off the cooling and dehumidification function and
turn it on again. There may be a problem in the air conditioning system if the indica-
tor light continues to flash. Turn the air conditioning system off and have it inspected
by your Lexus dealer.
■Air conditioning odors
●During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to be
emitted from the vents.
●To reduce potential odors from occurring:
• It is recommended that the air conditio ning system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time immediately after the air conditioning system is started in AUTO mode.
■Customization
Settings (e.g. enable/disable automatic operation of the air conditioning compres-
sor when the “AUTO” switch ON) can be changed.
(Customizable features →P. 788)
CAUTION
■To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The dif-
ference between the temperature of the outside air and that of the windshield can
cause the outer surface of the windshield to fog up, blocking your vision.
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine
is stopped.
GX460_OM_OM60J63U_(U).book Page 412 Thursday, March 29, 2012 9:10 AM

555
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Heated steering wheel∗
∗: If equipped
■The heated steering wheel can be used when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■Timer
The heated steering wheel will automatically turn off after about 30 minutes.
■If the indicator light flashes
Press the button to turn the heated steering wheel off and then press the button
again. If the indicator light still flashes, a malfunction may be occurring. Turn the
heated steering wheel off and have the vehicle inspected by your Lexus dealer.
The heated steering wheel heats the leather portion of the steering wheel.
Turns the heater on/off
The indicator light comes on
when the heater is operating.
GX460_OM_OM60J63U_(U).book Page 555 Thursday, March 29, 2012 9:10 AM

605
4-2. Maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
■Repair and replacement
It is recommended that genuine Lexus parts be used for repair to ensure perfor-
mance of each system. If non-Lexus parts are used in replacement or if a repair
shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
■Reset the maintenance data (U.S.A. only)
After the required maintenance is performed according to the maintenance sched-
ule, please reset the maintenance data.
To reset the data, follow the procedures described below:Press the Menu switch ( →P. 216) to change the multi-information display
to blank.
Turn the “ENGINE START STOP” switch off.
While pressing the ODO/TRIP button ( →P. 199), turn the “ENGINE
START STOP” switch to IGNITION ON mode.
Continue to press and hold the butto n for more than 7 seconds after the
“ENGINE START STOP” switch is turned to IGNITION ON mode.
STEP1
STEP2
STEP3
STEP4
The message shown in the illustration will
appear on the display. After 5 seconds, the
system reset will be completed.
GX460_OM_OM60J63U_(U).book Page 605 Thursday, March 29, 2012 9:10 AM

659
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
6SUB BATT30 ATo w i n g
7IG220 AInjector, ignition, meter
8HORN10 AHorn
9EFI25 AEFI ECU, A/F heater relay, fuel pump
relay, EFI NO.2
10A/F20 AA/F SSR
11FUEL OPN 10 AFuel lid opener
12S/HTR RR20 ARear seat heater
13FOLD SEAT LH30 AFolding seat (left)
14FOLD SEAT RH30 AFolding seat (right)
15TOW I N G TA I L30 ATo w i n g
16A/C COMP10 AAir conditioning system
17STRG HTR 10 ASteering heater
18CDS FAN20 ACondenser fan
19STOP10 A
Stop lights, high mount stop light, stop
light switch, VSC ECU, towing, Smart
access system with push button start
20AIR SUS NO.27. 5 AAIR SUS ECU
21H-LP RH-HI15 AHeadlight high beam (right)
22H-LP LH-HI15 AHeadlight high beam (left)
FuseAmpereCircuit
GX460_OM_OM60J63U_(U).book Page 659 Thursday, March 29, 2012 9:10 AM

708
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
(Flashes)or
(Flashes)
(If equipped)
Indicates a malfunction in the radar cruise control
system Press the “ON-OFF” button once to deactivate the
system, and then press the button again to reactivate
the system.
(Flashes)
(If equipped)
Indicates a malfunction in the LDA system Stop the vehicle in a safe place. Turn the “ENGINE
START STOP” switch off and then turn it to IGNI-
TION ON mode again to reset the LDA system.
Wa r n i n g m e s s a g eDetails
GX460_OM_OM60J63U_(U).book Page 708 Thursday, March 29, 2012 9:10 AM

742
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
If the shift lever cannot be shifted from P
If the shift lever cannot be shifted with your foot on the brake, there may be
a problem with the shift lock system (a system to prevent accidental opera-
tion of the shift lever). Have the vehicle inspected by your Lexus dealer
immediately.
The following steps may be used as an emergency measure to ensure that
the shift lever can be shifted:
Set the parking brake.
Turn the “ENGINE START STOP” switch to ACCESSORY
mode.
Depress the brake pedal.
Pry the cover up with a flathead
screwdriver or tool.
Press the shift lock override but-
ton.
The shift lever can be shifted
while the button is pressed.
STEP1
STEP2
STEP3
STEP4
STEP5
GX460_OM_OM60J63U_(U).book Page 742 Thursday, March 29, 2012 9:10 AM

834
Alphabetical index
GX460_OM_OM60J63U_(U)
SeatsAdjustment................................67, 71, 82
Adjustment precautions ....................... 70, 80, 85
Child seats/child restraint system installation ........................... 155
Cleaning.................................................. 601
Driver’s seat position memory....... 82
Folding down the second seatbacks ...................................... 73, 74
Folding down the third seats .......... 76
Head restraint......................................... 86
Properly sitting in the seat ............... 124
Seat heaters .......................................... 557
Seat position memory ........................ 82
Ventilated seats .................................. 557
Service reminder indicators ............202
Shift lever Automatic transmission................... 190
If the shift lever cannot be shifted from P ....................................742
Shift lever lighting .................................525
Shift lock system .................................... 742
Side airbags.............................................. 126
Side marker lights Replacing light bulbs............ 675, 677
Switch ...................................................... 223
Wattage.................................................. 769 Side mirror
Adjusting and folding ..........................101
Mirror position memory ....................82
Side turn signal lights
Replacing light bulbs .......................680
Smart access system with
push-button startAntenna location ...................................34
Entry functions ......................................... 31
Starting the engine.............................. 183
Spare tire Inflation pressure ............................... 768
Storage location .................................726
Spark plug ............................................... 763
Specifications ......................................... 758
Speedometer ...........................................199
Steering Column lock release ......................... 187
Fluid .......................................................... 768
Steering wheel
Adjustment ............................................... 97
Audio switches ................................... 466
Heated steering wheel ................... 555
Steering wheel position memory ..................................................82
Stop light
Replacing light bulbs .......................680
Storage feature ..................................... 529
Stuck If your vehicle becomes stuck .....752
Sun visors ................................................. 544
GX460_OM_OM60J63U_(U).book Page 834 Thursday, March 29, 2012 9:10 AM
