3TABLE OF CONTENTS
LEXUS NX300h Owners Manual_USA_M78578_en
1
2
3
4
5
6
7
8
9
4-1. Before driving
Driving the vehicle ........................ 156
Cargo and luggage ....................... 161
Vehicle load limits ......................... 164
Trailer towing (vehicles with towing package) ........................................ 165
Trailer towing (vehicles without towing package) ......................... 173
Dinghy towing ................................ 173
4-2. Driving procedures Power (ignition) switch ............... 174
EV drive mode ............................... 178
Hybrid transmission ..................... 180
Turn signal lever............................. 183
Parking brake ................................. 184
Brake Hold....................................... 187
ASC (Active Sound Control) .. 188
4-3. Operating the lights and wipers Headlight switch ............................ 190
Automatic High Beam ................ 193
Fog light switch .............................. 196
Windshield wipers and washer 196
Rear window wiper and washer ............................................................ 201
4-4. Refueling Opening the fuel tank cap........ 2034-5. Using the driving support systems
Lexus Safety System + 2.0....... 205
PCS (Pre-Collision System) ...... 211
LTA (Lane Tracing Assist) ........ 218
LDA (Lane Departure Alert with steering control) ......................... 227
RSA (Road Sign Assist)............. 235
Dynamic radar cruise control with full-speed range......................... 237
PKSA (Parking Support Alert) 247
Intuitive parking assist ................ 248
Parking Support Brake function (for static objects).............................. 253
BSM (Blind Spot Monitor) ........262
Driving mode select switch ..... 270
Driving assist systems ................. 272
4-6. Driving tips Hybrid vehicle driving tips ........ 277
Winter driving tips ....................... 279
Utility vehicle precautions........ 282
5-1. Remote Touch Remote Touch............................... 286
5-2. Using the air conditioning system and defogger
Automatic air conditioning system............................................................ 291
Heated steering wheel/seat heat- ers/seat ventilators................... 299
5-3. Using the interior lights Interior lights list ........................... 302
5-4. Using the storage features List of storage features .............. 305
4Driving
5Interior features

4TABLE OF CONTENTS
LEXUS NX300h Owners Manual_USA_M78578_en
Luggage compartment features
........................................................... 308
5-5. Using the other interior features Other interior features ............... 312
Garage door opener.................. 322
Compass.......................................... 328
6-1. Maintenance and care Cleaning and protecting the vehi-cle exterior ................................... 332
Cleaning and protecting the vehi- cle interior .................................... 335
6-2. Maintenance Maintenance requirements ..... 339
General maintenance ................ 340
Emission inspection and mainte- nance (I/M) programs ............ 342
6-3. Do-it-yourself maintenance Do-it-yourself service precautions........................................................... 344
Hood.................................................. 346
Positioning a floor jack............... 346
Engine compartment.................. 348
12-volt battery................................ 354
Tires ................................................... 357
Tire inflation pressure ................. 365
Wheels.............................................. 367
Air conditioning filter..................368
Electronic key battery ................ 369
Checking and replacing fuses . 371
Headlight aim................................. 373
Light bulbs ....................................... 3757-1. Essential information
Emergency flashers .................... 380
If your vehicle has to be stopped in an emergency ............................ 380
If the vehicle is trapped in rising water ............................................... 381
7-2. Steps to take in an emergency If your vehicle needs to be towed.......................................................... 383
If you think something is wrong .......................................................... 386
If a warning light turns on or a warn- ing buzzer sounds..................... 388
If a warning messa ge is displayed
.......................................................... 398
If you have a flat tire .................... 402
If the hybrid syst em will not start
.......................................................... 409
If you lose your keys....................... 411
If the fuel filler door cannot be opened ............................................. 411
If the electronic key does not oper- ate properly ................................... 412
If the 12-volt battery is discharged ............................................................ 414
If your vehicle overheats ............ 418
If the vehicle becomes stuck ..... 421
8-1. Specifications Maintenance data (fuel, oil level, etc.) .................................................. 424
Fuel information .

........................... 432
Tire information ............................ 434
6Maintenance and care
7When trouble arises
8Vehicle specifications

15Pictorial index
LEXUS NX300h Owners Manual_USA_M78578_en
■Instrument panel
Power switch ............................................................................................................ P.174
Starting the hybrid system/changing the mo des......................................... P.174, 177
Emergency stop of the hybrid system ..................................................................... P.380
When the hybrid system will not start ......................................................................P.409
Warning messages ..........................................................................................................P.398
Shift lever.................................................................................................................... P.181
Changing the shift position ..............................................................................................P.181
Precautions against towing...........................................................................................P.383
When the shift lever does not move ............................................................................P.181
Meters ......................................................................................................................... P.84
Reading the meters/adjusting the instrume nt panel light.......................... P.84, 88
Warning lights/indicator lights ......................................................................................P.80
When the warning lights come on ............................................................................ P.388
Multi-information display ...................................................................................... P.89
Display ...................................................................................................................................... P.90
Energy monitor ..................................................................................................................... P.99A
B
C
D

291-1. For safe use
LEXUS NX300h Owners Manual_USA_M78578_en
1
For safety and security
plate into the buckle until a clicking
sound is heard.
Plate A
Plate B
Buckle 1
To release the hooked buckle, push
the buckle release button .
2 Insert the mechanical key
(P.106) or plate B into the notch
of buckle and remove the belt.
Retract the belt slowly when releasing and
stowing the seat belt.
Mechanical key
Plate B
Buckle
3 Stow in the cover in the order of
plate B and then plate A.
In order to securely fix it, firmly insert it to
WARNING
■When using the rear center seat belt
Do not use the rear center seat belt with
either buckle released. Fastening only
one of the buckles may result in death or
serious injury in case of sudden braking
or a collision.
A
B
C
Releasing and stowing the seat
belt (for the rear center seat)
A
A
B
C

301-1. For safe use
LEXUS NX300h Owners Manual_USA_M78578_en
the back.
Plate A
Plate B
4 Stow the seat belt buckle in the
pockets.
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sud-
den stop or on impact. It may also lock if you
lean forward too quickly. A slow, easy
motion will allow the belt to extend so that
you can move around fully.
■Automatic locking retractor (ALR)
When a passenger’s sh oulder belt is com-
pletely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used to
hold the child restraint system (CRS) firmly.
To free the belt again, fully retract the belt
and then pull the belt out once more.
1
Push the seat belt shoulder anchor
down while pressing the release
button .
2 Push the seat belt shoulder anchor
up.
Move the height adjuster up and down as
needed until you hear a click.
The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehi-
A
B
Adjusting the seat belt shoulder
anchor height (front seats)
WARNING
■Adjustable shoulder anchor
Always make sure the shoulder belt is
positioned across the center of your
shoulder. The belt should be kept away
from your neck, but not falling off your
shoulder. Failure to do so could reduce
the amount of protection in an accident
and cause death or serious injuries in the
event of a sudden stop, sudden swerve or
accident.
Seat belt pretensioners (front
seats)
A

371-1. For safe use
LEXUS NX300h Owners Manual_USA_M78578_en
1
For safety and securityWARNING
■SRS airbag precautions
Observe the following precautions
regarding the SRS airbags.
Failure to do so may cause death or seri-
ous injury.
●The driver and all passengers in the
vehicle must wear their seat belts
properly.
The SRS airbags are supplemental
devices to be used with the seat belts.
●The SRS driver airbag deploys with
considerable force, and can cause
death or serious injury especially if the
driver is very close to the airbag. The
National Highway Traffic Safety
Administration (NHTSA) advises:
Since the risk zone for the driver’s air-
bag is the first 2 - 3 in. (50 - 75 mm) of
inflation, placing yourself 10 in. (250
mm) from your driver airbag provides
you with a clear margin of safety. This
distance is measured from the center
of the steering wheel to your breast-
bone. If you sit less than 10 in. (250
mm) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals
comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many
drivers can achieve the 10 in. (250
mm) distance, even with the driver seat
all the way forward, simply by reclining
the back of the seat somewhat. If
reclining the back of your seat makes it
hard to see the road, raise yourself by
using a firm, non-slippery cushion, or
raise the seat if your vehicle has that
feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag
toward your chest instead of your head
and neck.
The seat should be adjusted as recom-
mended by NHTSA above, while still
maintaining control of the foot pedals,
steering wheel, and your view of the
instrument panel controls.

381-1. For safe use
LEXUS NX300h Owners Manual_USA_M78578_en
WARNING
●If the seat belt extender has been con-
nected to the front seat belt buckles
but the seat belt extender has not also
been fastened to the latch plate of the
seat belt, the SRS front airbags will
judge that the driver and front passen-
ger are wearing the seat belt even
though the seat belt has not been con-
nected. In this case, the SRS front air-
bags may not activate correctly in a
collision, resulting in death or serious
injury in the event of a collision. Be
sure to wear the seat belt with the seat
belt extender.
●The SRS front passenger airbag also
deploys with considerable force, and
can cause death or serious injury
especially if the front passenger is very
close to the airbag. The front passen-
ger seat should be as far from the air-
bag as possible with the seatback
adjusted, so the front passenger sits
upright.
●Improperly seated and/or restrained
infants and children can be killed or
seriously injured by a deploying airbag.
An infant or child who is too small to
use a seat belt should be properly
secured using a child restraint system.
Lexus strongly recommends that all
infants and children be placed in the
rear seats of the vehicle and properly
restrained. The rear seats are safer for
infants and children than the front pas-
senger seat. ( P.47)
●Do not sit on the edge of the seat or
lean against the dashboard.
●Do not allow a child to stand in front of
the SRS front passenger airbag unit or
sit on the knees of a front passenger.
●Do not allow the front seat occupants
to hold items on their knees.
●Do not lean against the door, the roof
side rail or the front, side and rear pil-
lars.
●Do not allow anyone to kneel on the
passenger seat toward the door or put
their head or hands outside the vehi-
cle.

541-2. Child safety
LEXUS NX300h Owners Manual_USA_M78578_en
High back type
4 Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s in structions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.
Check that the shoulder belt is correctly
positioned over the child’s shoulder and
that the lap belt is as low as possible.
(  P.27)
■Removing a child restraint system
installed with a seat belt
Press the buckle release button and
fully retract the seat belt.
When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.
WARNING
■When installing a child restraint sys-
tem
Observe the following precautions. Fail-
ure to do so may result in death or seri-
ous injury.
●Do not allow children to play with the
seat belt. If the seat belt becomes
twisted around a child’s neck, it may
lead to choking or other serious inju-
ries that could result in death. If this
occurs and the buckle cannot be
unfastened, scissors should be used to
cut the belt.
●Ensure that the belt and plate are
securely locked and the seat belt is not
twisted.
●Shake the child rest raint system left
and right, and forward and backward
to ensure that it has been securely
installed.
●After securing a child restraint system,
never adjust the seat.
●When a booster seat is installed,
always ensure that th e shoulder belt is
positioned across the center of the
child’s shoulder. The belt should be
kept away from the child’s neck, but
not so that it could fall off the child’s
shoulder.
●Follow all installation instructions pro-
vided by the child restraint system
manufacturer.

641-3. Lexus Enform
LEXUS NX300h Owners Manual_USA_M78578_en
■Stolen Vehicle Location
If your vehicle is stolen, Safety Connect
can work with local authorities to assist
them in locating and recovering the
vehicle. After filing a police report, call
the Safety Connect response center at
1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-
539-8777 in Puerto Rico or 1-800-
265-3987 in Canada, and follow the
prompts for Safety Connect to initiate
this service.
In addition to assisting law enforce-
ment with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle
location data may, under certain cir-
cumstances, be shared with third par-
ties to locate your vehicle. Further
information is available at Lexus.com.
■Emergency Assistance Button
(“SOS”)
In the event of an emergency on the
road, push the “SOS” button to reach
the Safety Connect response center.
The answering agent will determine
your vehicle’s location, assess the
emergency, and dispatch the neces-
sary assistance required.
If you accidentally press the “SOS” button,
tell the response-center agent that you are
not experiencing an emergency.
■Enhanced Roadside Assistance
Enhanced Roadside Assistance adds
GPS data to the already included war-
ranty- based Lexus roadside service.
Subscribers can press the “SOS” but-
ton to reach a Safety Connect
response-center agent, who can help with a wide range of needs, such as:
towing, flat tire, fuel delivery, etc. For a
description of the Roadside Assistance
services and their limitations, please
see the Safety Connect Terms and
Conditions, which are available at
Lexus.com.
Important! Read this information about
exposure to radio frequency signals
before using Safety Connect;
The Safety Connect system installed in
your vehicle is a low-power radio trans-
mitter and receiver. It receives and also
sends out radio frequency (RF) signals.
In August 1996, the Federal Commu-
nications Commission (FCC) adopted
RF exposure guidelines with safety lev-
els for mobile wireless phones. Those
guidelines are consistent with the
safety standards previously set by the
following U.S. and international stan-
dards bodies.

ANSI (American National Stan-
dards Institute) C95.1 [1992]
 NCRP (National Council on Radia-
tion Protection and Measurement)
Report 86 [1986]
 ICNIRP (International Commission
on Non-Ionizing Radiation Protec-
tion) [1996]
Those standards were based on com-
prehensive and periodic evaluations of
the relevant scientific literature. Over
120 scientists, engineers, and physi-
Safety information for Safety
Connect

721-4. Hybrid system
LEXUS NX300h Owners Manual_USA_M78578_en
The cooling air intake and discharge
vents for the hybrid battery (traction
battery) are located under the rear
seats and between the rear seats and
deck board, respectively. If the air
intake vents are blocked, it could lead
to a reduction in hybrid battery (trac-
tion battery) output.
The hybrid battery (traction battery) out-
put will not be reduced, even if the space
between the upper part of the air dis-
charge vents on the back of the rear seat
and deck board is blocked with luggage,
etc.
WARNING
●If your vehicle needs to be towed, do
so with four wheels raised. If the
wheels connected to the electric
motor (traction motor) are on the
ground when towing, the motor may
continue to generate electricity. This
may cause a fire. ( P.383)
●Carefully inspect the ground under the
vehicle. If you find that liquid has
leaked onto the ground, the fuel sys-
tem may have been damaged. Leave
the vehicle as soon as possible.
■Hybrid battery (traction battery)
●Never resell, hand over or modify the
hybrid battery. To prevent accidents,
hybrid batteries that have been
removed from a disposed vehicle are
collected through Lexus dealers. Do
not dispose of the battery yourself.
Unless the battery is properly collected,
the following may occur, resulting in
death or serious injury:
• The hybrid battery may be illegally dis- posed of or dumped, and it is hazard-
ous to the environment or someone
may touch a high voltage part, result-
ing in an electric shock.
• The hybrid battery is intended to be used exclusively with your hybrid vehi-
cle. If the hybrid battery is used outside
of your vehicle or modified in any way,
accidents such as electric shock, heat
generation, smoke generation, an
explosion and electrolyte leakage may
occur.
When reselling or handing over your
vehicle, the possibility of an accident is
extremely high because the person
receiving the vehicle may not be aware
of these dangers.
●If your vehicle is disposed of without
the hybrid battery having been
removed, there is a danger of serious
electric shock if hi gh voltage parts,
cables and their connectors are
touched. In the event that your vehicle
must be disposed of, the hybrid battery
must be disposed of by your Lexus
dealer or a qualified service shop. If
the hybrid battery is not disposed of
properly, it may cause electric shock
that can result in death or serious
injury.
NOTICE
■Hybrid battery (traction battery)
Do not carry large amounts of water
such as water cooler bottles in the vehi-
cle. If water spills onto the hybrid battery
(traction battery), the battery may be
damaged.
Have the vehicle inspected by your
Lexus dealer.
Hybrid battery (traction bat-
tery) air intake and discharge
vents
