fuel cap LEXUS SC300 1999 Owners Manual

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
FUEL GAUGE
The gauge is displayed when the ignition switch is on and
indicates the approximate quantity of fuel remaining in
the tank.
It is a good idea to keep the tank over 1/4 full.
This fuel gauge has a non±return type needle which remains
at the last indicated position when the ignition switch is turned
off.
If the fuel level approaches ºEº or the low fuel level warning
light comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
See the inner back cover for fuel capacity and recommended
fuel selection.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
57
The light may occasionally flicker when the engine is idling
or it may come on briefly after a hard stop. There is no cause
for concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low.
It is not designed to indicate low oil level, and the oil level
must be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on ± even
for one block. It may ruin the engine.
(f) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil
as soon as possible. (For instructions, see ºChecking the
engine oil levelº on page 342.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
NOTICE
Continued engine operation with low engine oil will
damage the engine.
(g) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ºFuel gaugeº on
page 49 for instructions.)
b. The fuel tank cap is not tightened securely (SC400 only).
(See ºFuel tank capº on page 85 for instructions.)
c. There is a problem
somewhere in your engine or automatic
transmission electrical system.
If it comes on while you are driving in case ºc.º, have your
vehicle checked/repaired by your Lexus dealer as soon as
possible.
(h) ºABSº Warning Light
This light warns that there is a problem somewhere in your
anti±lock brake system.
If the light comes on while you are driving, have your vehicle
checked by your Lexus dealer as soon as possible.
The light will come on when the ignition key is turned to
ºONº, and will go off after about a few seconds.
When the ºABSº warning light is on (and the brake system
warning light is off), the brake system operates
conventionally but anti±lock brake system is not assisting
brake performance so that the wheels could lock up during a
sudden brake or braking on slippery road surfaces.

INTERIOR EQUIPMENT
80
LUGGAGE STOWAGEPRECAUTIONS
When stowing luggage or cargo in the vehicle, observe the
following:

Put luggage or cargo in the trunk when at all possible. Be
sure all items are secured in place.

Be careful to keep the vehicle level. Placing the weight as
far forward as possible helps maintain vehicle balance.

For better fuel economy, do not carry unnecessary weight.
CAUTION

Do not place anything on the filler panel behind the rear
seatback. Such items may be thrown about and possibly
injure people in the vehicle during sudden braking or an
accident.

Do not drive with objects left on top of the instrument
panel. They may interfere with the driver's field of view.
Or they may move during sharp vehicle acceleration or
turning, and impair the driver's control of the vehicle. In
an accident they may injure the vehicle occupants.
NOTICE
Do not load the vehicle beyond the vehicle capacity
weight specified on the tire pressure label.

SECTION 1 ± 5
81
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
81
Trunk lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
83
Fuel tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
85
Moon roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
88
HOOD
To open the hood, pull the hood lock release lever under
the instrument panel. The hood will spring up slightly.

EXTERIOR EQUIPMENT
85
3. If you do not want to activate the trunk lid opener
system, push in the main switch.
4. To activate the system, insert the master key and turn
it counterclockwise.
To protect things put in the trunk, when you have your vehicle
parked, turn off the trunk lid opener system.FUEL TANK CAP

EXTERIOR EQUIPMENT
87
CAUTION

Do not smoke, cause sparks or allow open flames when
refuelling. The fumes are flammable.

When opening the cap, do not remove the cap quickly. In
hot weather, fuel under pressure could cause injury by
spraying out of the filler neck if the cap is suddenly
removed.
2. To remove the fuel tank cap, turn the cap slowly
counterclockwise, then pause slightly before removing it.
The removed cap can be stored on the back side of the fuel
filler door.
It is not unusual to hear a slight swoosh when the cap is
opened. When installing the cap, turn the cap clockwise until
you hear a click.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.

EXTERIOR EQUIPMENT
88
CAUTION

Make sure the cap is tightened securely to prevent fuel
spillage in case of an accident.

Use only a genuine Lexus fuel tank cap for replacement. It
has a built±in check valve to reduce fuel tank vacuum.
In case the opener is not actuated
Pull the manual lever toward the back.
This is used in case the fuel filler door cannot be opened due
to a discharged battery or other trouble.MOON ROOF

DRIVING TIPS
260

Do not rest your foot on the brake pedal while
driving. It can cause dangerous overheating,
needless wear, and poor fuel economy.

To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 234.

Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to spin or skid.

Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140
km/h (85 mph) unless your vehicle has high±speed
capability tires. Driving over 140 km/h (85 mph)
may result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are high±speed
capability tires or not before driving at such speeds.

Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a
longer stopping distance, and it may pull to one side
when the brakes are applied. Also, the parking
brake will not hold the vehicle securely.WINTER DRIVING TIPS
Make sure you have a proper freeze protection of engine
coolant.
Your coolant must contain ethylene±glycol type coolant for
a proper corrosion protection of aluminum components. Use
ºToyota Long Life Coolantº or equivalent. See ºChecking
the engine coolant levelº on page 347 for instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60%
solution for your Lexus, to provide protection down to about
±50 C (±58F). Do not use more than 70% solution for better
coolant performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 380 tells you how to visually inspect the
battery. Your Lexus dealer and most service stations will be
pleased to check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 346 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call

ENGINE
331
Oil capacity
Drain and refillwith filter
without filter
Oil grade
Recommended oil viscosity (SAE):
4.7 L (5.0 qt., 4.2 lmp.qt.)
4.8 L (5.1 qt., 4.2 lmp.qt.)
API SJ, ºEnergy±Conservingº multigrade engine oil or
ILSAC multigrade engine oil
± COOLING SYSTEM
Capacity
Coolant type
11.6 L (12.3 qt., 10.2 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
± FUEL
Fuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher

ENGINE
335
Oil capacity
Drain and refillwith filter
without filter
Oil grade
Recommended oil viscosity (SAE):
5.2 L (5.5 qt., 4.5 lmp.qt.)
4.9 L (5.2 qt., 4.4 lmp.qt.)
API SJ, ºEnergy±Conservingº multigrade engine oil or
ILSAC multigrade engine oil
± COOLING SYSTEM
Capacity
Coolant type
8.4 L (8.9 qt., 7.4 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
± FUEL
Fuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher
