fuse box LINCOLN NAVIGATOR 2004 Owners Manual

Note: Always replace a fuse with one that has the specified amperage
rating. Using a fuse with a higher amperage rating can cause severe wire
damage and could start a fire.
Standard fuse amperage rating and color
COLOR
Fuse
rating Mini
fuses Standard
fuses Maxi
fuses Cartridge
maxi
fuses Fuse link
cartridge
2A Grey Grey ———
3A Violet Violet ———
4A Pink Pink ———
5A Tan Tan ———
7.5A Brown Brown ———
10A Red Red ———
15A Blue Blue ———
20A Yellow Yellow Yellow Blue Blue
25A Natural Natural ———
30A Green Green Green Pink Pink
40A —— Orange Green Green
50A —— Red Red Red
60A —— Blue — Yellow
70A —— Ta n — Brown
80A —— Natural — Black
Passenger compartment fuse panel / power distribution box
The fuse panel is located under the right-hand side of the instrument
panel.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
266

To remove the trim panel for access
to the fuse box, pull the panel
toward you and swing it out away
from the side and remove it. To
reinstall it, line up the tabs with the
grooves on the panel, then push it
shut.
To remove the fuse box cover, place
a finger behind the PULL tab and
your thumb above the PULL tab as
shown in the illustration, then pull
the cover off.
To reinstall the fuse box cover, place the top part of the cover on the
fuse panel, then push the bottom part of the cover until you hear it click
shut. Gently pull on the cover to make sure it is seated properly.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
267

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
R04 Rear window
defrost relay Fuse 8 (heated mirrors), Rear window
defroster, Heated outside mirrors, Rear
window defroster indicator (climate control
head)
R05 Trailer tow
battery
charge relay Trailer tow 7 – wire connector (battery
charge)
R06 Front blower
relay Front blower motor
R201 Trailer tow
park lamp
relay Trailer tow 7 – and 4 – wire connectors (park
lamps)
R202 Foglamp
relay Front foglamps
R203 PCM relay Fuse 32, Fuse 33, Fuse 34, Fuel pump relay,
Fuel pump, PCM solenoids and sensors
R301 Trailer tow
back-up lamp
relay Trailer tow 7 – wire connector (back-up
lamps)
R302 Speed
control relay Speed control servo
R303 Fuel pump
relay Fuel pump shut-off switch, PCM (fuel pump
monitor), Fuel pump
R304 Battery saver
relay Roof rail lamps, Vanity mirror lamps,
Map/Dome lamp, Glove box lamp, Cargo
area lamp, Outside mirror puddle lamps,
Instrument cluster (interior lamps)
R305 Horn relay Dual note horn
* Mini Fuses ** Maxi Fuses
Note: Relays R301 – R305 are not serviceable components; see your
dealer or a qualified technician for assistance.
