MAZDA CX90 2024 Owners Manual

Convenient Ways to Usethe Outside Mirrors
Driving Position Memory*
The angle of the outside mirrors can be
programmed to the Driving Position
Memory.
Refer to Driving Position Memory on
page 3-33.
Auto fold function
*
When locking/unlocking the doors
while the vehicle power is switched
OFF, the outside mirrors automatically
fold in and out.
When the outside mirrors are folded in
and the vehicle power is switched ON,
or the hybrid system is started, the
outside mirrors fold out automatically.
Turn the auto fold function on using
the center display.
Refer to Settings section in the Mazda
Connect Owner's Manual or consult
an Authorized Mazda Dealer.
Operation function after hybrid
system is stopped
The angle of the outside mirrors can be
adjusted and they can be folded in and
out for about 40 seconds after the
vehicle power is switched from ON to
OFF.
Auto tilt-down outside mirror
function for reversing *
The outside mirrors can be set to tilt
downwards automatically when
reversing the vehicle. When the vehicle
is finished reversing , the outside
mirrors return to their original angle.
1. Press the select switch on the side of the door mirror to be tilted
down.
Turn on the indicator light of the
select switch.
2. Shift the selector lever to the Rposition.
The outside mirror on the side
where you pressed the select switch
will tilt downward.
NOTE
When any of the following condition is
met, the outer mirrors return to their
normal positions.
The vehicle power is switched to a
position other than ON.
The shift selector lever is shifted to a
position other than R.
The select switch is pressed again.
Automatic glare prevention function
*
In conjunction with the glare
prevention function of the auto-type
rearview mirror, only the driver's side
outside mirror reduces the light from
the headlights of on-coming vehicles.
Operation Function After Vehicle
power is Switched OFF
The outside mirrors can be operated
for about 40 seconds after the vehicle
power is switched from ON to off with
all doors closed. If any door is opened,
the outside mirrors will stop operating.
Driving
Mirrors
5-10*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautions
for the Rearview Mirror
WARNING
Do not stack luggage higher than the
seatback.
Loading luggage higher than the
seatback is dangerous. The rearview
mirror visibility may be obstructed,
which may result in a collision with
another vehicle when changing lanes.
How to Use the Rearview Mirror
Move and adjust the rearview mirror
body.
Driving
Mirrors
5-11
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Rearview Mirror
Glare prevention function
Prevents glare from the headlights of
rear on-coming vehicles.
Manual type
Push the day/night lever forward for
day driving. Pull it back to reduce glare
of headlights from vehicles at the rear.
Automatic type
Automatically operates when the
vehicle power is switched ON and the
selector lever is in a position other
than R.
Driving
Mirrors
5-12
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Powe r Sw i tc h
Press the power switch to start/stop
the hybrid system or to switch the
vehicle power position (OFF/ACC/
ON).
Vehicle power position
OFF
All electrical accessories cannot be
used.
ACC
Some electrical accessories such as
audio can be used.
ON
All electrical accessories can be used.
Warning and Cautions forUsing the Power Switch
WARNING
Before leaving the driver's seat,
always switch the vehicle power off,
set the parking brake, and make sure
the selector lever is in the P position.
Leaving the driver's seat without
switching the vehicle power off, setting
the parking brake, and shifting the
selector lever to the P position is
dangerous. Unexpected vehicle
movement could occur which could
result in an accident. In addition, if
your intention is to leave the vehicle for
even a short period, it is important to
switch the vehicle power position to
OFF, as leaving it in another position
will disable some of the vehicle's
security systems and run the lead-acid
battery down.
Radio waves from the key may affect
medical devices such as pacemakers.
Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will affect
the device.
Other than for an emergency
situation, do not attempt to stop the
hybrid system while driving the
vehicle.
If the hybrid system is stopped while
driving the vehicle, loss of brake power
and power steering functions could
occur, making it difficult to control the
vehicle which could result in an
accident.
Driving
Po we r Sw i tc h
5-13
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

CAUTION
If the KEY warning light (red) is
displayed, or the power switch
indicator light (amber) flashes, this
could indicate a problem with the
hybrid starting system. This may
prevent the hybrid system from
starting or from switching the vehicle
power position to ACC or ON. Have
your vehicle inspected at an
Authorized Mazda Dealer as soon as
possible.
Refer to KEY Warning Light (Red) on
page 8-48.
 Before leaving the vehicle, make sure
that the vehicle power is switched
OFF.
How to Use the Power
Switch
The power switch starts/stops the
hybrid system and switches the vehicle
power position depending on the
vehicle status and the driver's
operation.
Starting the Hybrid system
1. Make sure that the parking brake isapplied.
2. Make sure that the selector lever is in the P position.
3. Depress the brake pedal. The power switch indicator light
(green) and the KEY indicator light
(green)
in the instrument
cluster turn on.
4.
The hybrid system starts and the
KEY indicator light (green)
in
the instrument cluster turns off.
The READY indicator light
in the instrument cluster turns on.
NOTE
Do not use high engine speeds until
reaching the operating temperature.
Driving
Power Switch
5-14
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Stopping The Hybrid system
1. Stop the vehicle.
2. Shift the selector lever to the Pposition.
3.
The hybrid system stops and the
vehicle power is switched OFF.
The READY indi cator light
in the instrument cluster turns off.
NOTE
If the hybrid system is turned off while
the selector lever is in a position other
than P, the AUTO P (parking lock)
function operates and the vehicle
power is switched OFF. For safety, shift
the selector lever to the P position and
switch the vehicle power OFF.
Switching the Vehicle power Position
Press the power switch without
depressing the brake pedal.
Each time the power switch is pressed,
the vehicle power position is switched
in the order of ACC, ON, and OFF.
When the vehicle power is switched to
ACC, the power switch indicator light
(amber) turns on.
When the vehicle power is switched
OFF and a door is opened/closed or
locked, the power switch indicator
light (amber) turns off.
NOTE
If you leave the vehicle power switched
to ACC while the selector lever is in
the P position, the vehicle power is
switched OFF in about 25 minutes.
Driving
Po we r Sw i tc h
5-15
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

e-SKYACTIV PHEV
The e-SKYACTIV PHEV is a hybrid
system with the ability to recharge the
battery from an external power supply,
and achieves both excellent fuel
economy and power performance by
efficiently combining EV driving, which
runs solely on electricity, and driving
using both the engine and motor.
The e-SKYACTIV PHEV can supply
power stored in the high voltage
battery to electrical appliances.
Refer to AC Power Outlet (120 V/
1,500 W) on page 7-50.
Driving
e-SKYACTIV PHEV
5-16
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

e-SKYACTIV PHEV Overview
1. Engine
2. Motor and regenerative braking
3. High voltage battery
4. Charge port
5. AC Power Outlet (120 V/1,500 W)
6. Approaching vehicle audible system
Engine
Depending on the driving condition and driving mode, the engine operates as a
power source or generator for the wheels, and stops when power or power
generation is not required.
Motor
The motor transmits the motor power to the wheels using the electrical power of the
high voltage battery.
Regenerative Braking
Regenerative braking uses the motor to decelerate the vehicle. Power is generated
by the wheels rotating the motor while decelerating and the generated power
charges the high voltage battery.
High Voltage Battery
The high voltage battery is a large-capacity battery and stores the charged power and
the electrical power generated by regenerative braking.
Driving
e-SKYACTIV PHEV
5-17
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Charge port
The charge port connects the charge connector of the charge cable and charges the
high voltage battery with power from an external power supply.
AC Power Outlet (120 V/1,500 W)
The AC power outlet (120 V/1,500 W) provides power for household electrical
appliances while the vehicle power is switched ON (hybrid system off).
Approaching Vehicle Audible System
The approaching vehicle audible system notifies pedestrians of the vehicle
approaching using a warning sound while driving at low speeds.
Driving
e-SKYACTIV PHEV
5-18
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warning and Cautions for Using the e-SKYACTIV PHEV
The hybrid system has high voltage areas and high temperature areas. Labels
indicating the cautions on use are applied to these areas. Always follow the
instructions on the label and use the vehicle correctly.
WARNING
Be very careful of high voltage areas. In addition, do not disassemble, modify, or
remove any high voltage parts.
The following areas contain high voltage parts and may cause electrical shock if
touched.
1. Motor
2. High voltage battery
3. Onboard charger
4. AC Power Outlet (120 V/1,500 W)
5. Warning label example
6. Service plug
7. High voltage cable
8. Water heater
9. Inverter
10.DC-DC converter
11.Electric compressor
Driving
e-SKYACTIV PHEV
5-19
