Average fuel economy display
Instantaneous electrical power consumption rate display
Instantaneous fuel economy display
3. High voltage battery temperature gauge Engine coolant temperature gauge
4. i-ACTIVSENSE status symbol (Warning/Risk avoidance support system)
5. Compass display
6. Message display
*1
*1 Displayed only when a warning occurs.
The screen will switch automatically when some i-ACTIVSENSE systems are used.
Driving
Instrument Cluster
5-30
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Instrument Cluster
Display information can be switched
using Settings in Mazda Connect.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Speedometer
The speedometer indicates the speed
of the vehicle.
Driving
Instrument Cluster
5-31
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute
(rpm).
Displays while driving in SPORT
mode/OFF-ROAD mode/TOWING
mode.
Refer to How to Use the Mazda
intelligent Drive Select (Mi-Drive) on
page 5-96.
CAUTION
Do not run the engine with the
tachometer needle in the RED ZONE.
This may cause severe engine damage.

1. STRIPED ZONE
2. RED ZONE
NOTE
When the tachometer needle enters
the STRIPED ZONE, this indicates to
the driver that the gears should be
shifted before entering the RED ZONE.
Odometer/Trip Meter
Odometer
The odometer records the total
distance the vehicle has been driven.
Tr i p m e te r
The driving distance for a specified
interval is indicated. Two types (TRIP A,
TRIP B) of interval distance can be
measured.
Driving
Instrument Cluster
5-32
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
Odometer/Trip Meter

The display changes each time the TRIP
switch is pressed.
1. Odometer display
2. Trip meter A display
3. Trip meter B display

When returning the trip meter to “0”,
press the TRIP switch for 2 seconds or
longer while the trip meter is
displayed.
NOTE
If the lead-acid battery is disconnected
for vehicle maintenance or other
reasons, the trip meter display returns
to “0”.
High Voltage Battery Temperature Gauge
Displays the high voltage battery
temperature. The blue range of the
gauge indicates that the high voltage
battery temperature is low and the red
range indicates that it is high and
overheating.

Driving
Instrument Cluster
5-33
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Engine Coolant
Temperature Gauge
Displays the engine coolant
temperature. The blue range of the
gauge indicates that the engine coolant
temperature is low, and the red range
of the gauge indicates that the engine
coolant temperature is high and
overheating.

CAUTION
If the engine coolant temperature
gauge needle is in the red range, there
is the possibility of overheating. Drive
slowly to reduce engine load.
Refer to Taking Action with
Overheating on page 8-20.
High Voltage Battery Powe r G au ge
The remaining power of the high
voltage battery is indicated when the
vehicle power is switched ON.
When the high voltage battery is fully
charged, F is indicated. As the level
lowers, the needle approaches E.

NOTE
After charging, it may require some
time for the needle to stabilize.
The arrow indicates that the
charging port is on the right side.
Driving
Instrument Cluster
5-34
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the vehicle power is switched
ON.
When the fuel tank is full, F (Full) is
indicated, and as the level lowers the
needle approaches E (Empty).

NOTE
After refueling , it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve
since the fuel moves in the tank.
The direction of the arrow
indicates that the fuel-filler lid is on
the left side of the vehicle.
Dashboard Illumination
When the lights are turned on with the
vehicle power switched ON, the
brightness of the dashboard
illumination is dimmed. However,
when the light sensor detects that the
surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination
does not dim.
NOTE
When the vehicle power is switched
ON in the early evening or at dusk, the
dashboard illumination is dimmed for
several seconds until the light sensor
detects the brightness of the
surrounding area, however, the
dimming may cancel after the
brightness is detected.
Driving
Instrument Cluster
5-35
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
Dashboard Illumination
Brightening the dashboard
illumination
Dimming the dashboard illumination
If you press the - switch again while
the dashboard illumination is at
maximum dimness, a sound is
activated to notify you that the dimmer
setting is at maximum dimness.
Function for canceling illumination
dimmer
The illumination dimmer can be
canceled by pressing the + switch
while the instrument cluster is at
maximum dimness and while the
vehicle power is switched ON. If you
press the + switch again while the
illumination dimmer is canceled, a
sound is activated to notify you that it
is canceled. If the instrument cluster's
visibility is reduced due to glare from
surrounding brightness, cancel the
illumination dimmer.
Driving
Instrument Cluster
5-36
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Outside TemperatureDisplay
When the vehicle power is switched
ON, the outside temperature is
displayed.

NOTE
The outside temperature display may
differ from the actual outside
temperature depending on the
surroundings and vehicle conditions.
Maximum Driving
Distance Display
The maximum driving distance is
calculated and displayed based on the
current remaining charge of the high
voltage battery/fuel tank level and the
electrical power consumption rate/
fuel economy. When the maximum
driving distance is 50 km (30 miles) or
farther, the maximum driving distance
indication decreases in 10 km (10
mile) increments, and when the
maximum driving distance is 50 km
(30 miles) or shorter, it decreases in 1
km (1 mile) increments.
1. Remaining distance-to-full discharge display for high voltage
battery only
2. Maximum driving distance display for fuel and high voltage battery
NOTE
The maximum driving distance is just
an approximate numerical value and
differs from the actual driving distance.
Drive the vehicle while checking the
high voltage battery power gauge/fuel
gauge.
Driving
Instrument Cluster
5-37
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Average Electrical PowerConsumption Rate Display
The average energy efficiency is
calculated every 30 seconds from the
total traveled distance and the total
electrical power consumption since
the vehicle was purchased or the past
data was reset, and the rate is
displayed.

How to Use the Average
Electrical Power
Consumption Rate
Display
To reset the displayed average
electrical power consumption rate
data, press the INFO switch for 2
seconds or longer.
After resetting the data, - - - kWh/100
km (- - - mile/kWh) is displayed
before the average electrical power
consumption rate is recalculated and
displayed.
The average electrical power
consumption rate is also reset at the
same time as the average fuel
economy.
Driving
Instrument Cluster
5-38
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Average Fuel EconomyDisplay
This mode displays the average fuel
economy by calculating the total
traveled distance and the total fuel
consumption since the vehicle was
purchased or the past data was reset.
The average fuel economy is calculated
and displayed every 30 seconds.
How to Use the AverageFuel Economy Display
To reset the displayed average fuel
economy data, press the INFO switch
for 2 seconds or longer.
After resetting the data, - - - L/100 km
(- - - mpg) is displayed until the
average fuel economy is recalculated
and displayed.
The average fuel economy is also reset
at the same time as the average
electrical power consumption rate.
Driving
Instrument Cluster
5-39
