MAZDA CX90 2024 Owners Manual

Dealing with the Cause
If trouble arises while charging such as
not being able to charge the high
voltage battery, refer to the following
table. If the problem cannot be solved
even after checking the following table,
there may be a problem with the
vehicle or charger. Contact an
Authorized Mazda Dealer.
Charging is not possible.
CauseAction
The selector
lever is in a
position
other than P. Shift the selector lever to the P
position.
The high
voltage bat-
tery is al-
ready fully
charged. Charging is not performed when
the high voltage battery is al-
ready fully charged.
The high
voltage bat-
tery temper-
ature is ex-
tremely high
or low. Check the high voltage battery
temperature gauge in the instru-
ment cluster. If the high voltage
battery temperature gauge is in
the red or blue range, charging
may not be possible.
The
Lead-acid
battery is
depleted. If the instrument cluster does not
turn on even if the vehicle power
is switched ON, the Lead-acid
battery may be depleted. Charge
or replace the Lead-acid battery.
Normal charging is not possible.
Cause
Action
The outlet
has no pow-
er. Check if a ground-fault circuit in-
terrupter has operated or if a
power outage occurred. If the
power source has a timer func-
tion, electrical power may not be
supplied to the outlet until the
time set to supply power.
Cause
Action
The charge
plug is not
properly
plugged into
the outlet. Check if the charge plug is prop-
erly plugged into the outlet.
The charge
connector is
not properly
connected. Check if the charge connector is
properly connected.
Charging
timer is set. Cancel the charging timer using
EV Settings in Mazda Connect,
or the charging timer cancella-
tion function.
Troubleshooting for functions using a
Smartphone or computer
If you are having trouble with the
remote function service, such as when
the remote function does not work,
consult an Authorized Mazda Dealer.
What to Do in Case of Emergency
Charging Is Not Possible
8-16
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

Forcibly Stopping theHybrid System
Press and hold the power switch or
press it quickly and repeatedly.
The hybrid system stops and the
vehicle power is switched ACC.
What to Do in Case of Emergency
Hybrid System Cannot be Stopped
8-17
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Applying the EmergencyBrake
Continue pulling the EPB switch.
The brakes are applied and the vehicle
can be decelerated/stopped.
A sound is activated when the brake is
applied and when the EPB switch is
released, the brake will be released
and the sound stops.
WARNING
Use only in emergency situations.
Use this function only in an emergency.
Excessive use will cause the brake parts
to wear out quickly or cause the brakes
to generate heat, reducing their
effectiveness.
What to Do in Case of Emergency
Problem With the Brake System (Foot Brake)
8-18
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Forcibly Canceling theAUTOHOLD
The AUTOHOLD can be canceled
forcibly by fully depressing the
accelerator pedal for about 1 second
while the AUTOHOLD is operating.
Forcibly cancel the AUTOHOLD only
when the AUTOHOLD cannot be
canceled due to a system malfunction
or it is necessary to cancel the
AUTOHOLD in an emergency.
What to Do in Case of Emergency
AUTOHOLD Cannot be Canceled
8-19
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Ta k i n g A c t i o n w i t hOverheating
If the engine coolant temperature
gauge indicates overheating and the
high engine coolant temperature
warning light is displayed, the vehicle
loses power or you hear a loud
knocking or pinging noise, the engine
is probably too hot.
WARNING
Pull over to a safe location, then
switch the vehicle power off and
make sure the fan is not running
before attempting to work near the
cooling fan.
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if
the engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.
Do not remove either
cooling system cap when the engine
and radiator are hot.
When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.
Open the hood ONLY after steam is
no longer escaping from the engine.
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.

1. Drive safely to the side of the road and park off the right-of-way.
2. Shift into park (P).
3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is escaping from the engine
compartment.

If steam is coming from the engine
compartment:
Do not go near the front of the
vehicle. Stop the engine.
Wait until the steam dissipates,
then open the hood and start the
engine.

If neither coolant nor steam is
escaping:
Open the hood and idle the engine
until it cools.
CAUTION
If the cooling fan does not operate
while the engine is running, the
engine temperature will increase.
Stop the engine and call an
Authorized Mazda Dealer.
6. Make sure the cooling fan is operating, then turn off the engine
after the temperature has
decreased.
7. When cool, check the coolant level. If it is low, look for coolant leaks
from the radiator and hoses.

What to Do in Case of Emergency
Overheating
8-20
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

If you find a leak or other damage, or
if coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.
1. Cooling system cap
2. Coolant reservoir
3. Cooling fan
4. Radiator
If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required
(page 9-14).
CAUTION
If the engine continues to overheat or
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.
What to Do in Case of Emergency
Overheating
8-21
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Changing a Flat Tire (WithSpare Tire)
NOTE
If the following occurs while driving , it
could indicate a flat tire.
Steering becomes difficult.The vehicle begins to vibrate
excessively.
The vehicle pulls in one direction.
If you have a flat tire, drive slowly to a
level spot that is well off the road and
out of the way of traffic to change the
tire.
Stopping in traffic or on the shoulder
of a busy road is dangerous.
WARNING
Do not install the temporary spare tire
on the rear wheels (driving wheels).
Driving with the temporary spare tire
on one of the rear driving wheels is
dangerous. Handling will be affected.
You could lose control of the vehicle,
especially on ice or snow bound roads,
and have an accident. Move a regular
tire to the rear wheel and install the
temporary spare tire to the front.
Be sure to follow the directions for
changing a tire.
Changing a tire is dangerous if not
done properly. The vehicle can slip off
the jack and seriou sly injure someone.
No person should place any portion of
their body under a vehicle that is
supported by a jack.
Never allow anyone inside a vehicle
supported by a jack.
Allowing someone to remain in a
vehicle supported by a jack is
dangerous. The occupant could cause
the vehicle to fall resulting in serious
injury.
NOTE
Make sure the jack is well lubricated
before using it.
1. Park on a hard, level surface off the
right-of-way and firmly set the
parking brake.
2. Shift into Park (P) and turn off the
engine.
3. Turn on the hazard warning flasher.
4. Have passengers get out of the
vehicle and away from the vehicle
and traffic.
5. Remove any luggage, the jack (page
7-76), spare tire (page 7-77), and
tools.
1. Lug wrench
2. Jack lever
6. Block the wheel diagonally opposite the flat tire. When
blocking a wheel, place a tire block
both in front and behind the tire.
What to Do in Case of Emergency
Tire is Punctured or Bursts
8-22
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
When blocking a tire, use rocks or
wood blocks of sufficient size if
possible to hold the tire in place.
Removing a Flat Tire
WARNING
When jacking-up a vehicle, always
shift the selector lever to P position,
apply the parking brake, and place
wheel blocks in the position
diagonally opposed to the jack.
Changing a flat tire without using
wheel blocks is dangerous because the
vehicle may move and fall off the jack
even with the selector lever is in P
position, which could result in an
accident.
1. Loosen the lug nuts by turning them counterclockwise one turn each,
but do not remove any lug nuts
until the tire has been raised off the
ground.
NOTE
If your Mazda is equipped with the
optional antitheft wheel lug nuts, a
special key must be used to unlock
the locking lug nut for each wheel.
For details, refer to “Locking Lug
Nuts” below.
2. Place the jack on the ground.
3. Turn the jack screw in the direction shown in the figure and adjust the
jack head so that it is close to the
jack-up position.
4. Place the jack under the jack-upposition closest to the tire being
changed with the jack head
squarely under the jack-up point.
5. Continue raising the jack headgradually by rotating the screw with
your hand until the jack head is
inserted into the jack-up position.
What to Do in Case of Emergency
Tire is Punctured or Bursts
8-23
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

WARNING
Use only the front and rear jacking
positions recommended in this
manual.
Attempting to jack the vehicle in
positions other than those
recommended in this manual is
dangerous. The vehicle could slip
off the jack and seriously injure or
even kill someone. Use only the
front and rear jacking positions
recommended in this manual.
Do not jack up the vehicle in a
position other than the designated
jack-up position or place any
objects on or under the jack.
Jacking up the vehicle in a position
other than the designated jack-up
position or placing objects on or
under the jack is dangerous as it
could deform the vehicle body or
the vehicle could fall off the jack
resulting in an accident.
Use only the jack provided with
your Mazda.
Using a jack that is not designed for
your Mazda is dangerous. The
vehicle could slip off the jack and
seriously injure someone.
Never place objects under the
jack.
Jacking the vehicle with an object
under the jack is dangerous. The
jack could slip and someone could
be seriously injured by the jack or
the falling vehicle.
NOTE
When raising the jack head into the
jacking position and aligning the
groove in the jack head with the rail
under the vehicle body, the top of
the jack head contacts the vehicle's
underbody without the rail
contacting the bottom of the
groove.
6. Insert the jack lever and attach the lug wrench to tire jack.
7. Turn the jack handle clockwise andraise the vehicle high enough so
that the spare tire can be installed.
Before removing the lug nuts, make
sure your Mazda is firmly in
position and that it cannot slip or
move.
WARNING
Do not jack up the vehicle higher
than is necessary.
Jacking up the vehicle higher than is
necessary is dangerous as it could
destabilize the vehicle resulting in
an accident.
What to Do in Case of Emergency
Tire is Punctured or Bursts
8-24
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Do not start the engine or shake
the vehicle while it is jacked up.
Starting the engine or shaking the
vehicle while it is jacked up is
dangerous as it could cause the
vehicle to fall off the jack resulting
in an accident.
Never go under the vehicle while it
is jacked up.
Going under the vehicle while it is
jacked up is dangerous as it could
result in death or serious injury if
the vehicle were to fall off the jack.
8. Remove the lug nuts by turning them counterclockwise; then
remove the wheel and center cap.
Locking Lug Nuts
If your Mazda is equipped with the
optional antitheft wheel lug nuts, a
special key must be used to unlock the
locking lug nut for each wheel. The key
is stored in the glove compartment,
center console storage, storage box, or
trunk. Register the key and lug nuts
with the lock manufacturer by filling
out the registration card and mailing it
in using the accompanying envelope. If
the key is lost, consult an Authorized
Mazda Dealer or use the lock
manufacturer’s order form to order a
new key.
Antitheft wheel lug nuts cannot be
installed on a steel wheel spare tire.
When installing a temporary spare tire,
use one of the original lug nuts in place
of the locking lug nut. The original lug
nuts are stored inside your Mazda.
1. Antitheft lug nut
2. Special key
To remove an antitheft lug nut
1. Obtain the special key for the antitheft lug nut.
2. Place the special key on top of the antitheft lug nut, and be sure to
hold the key square to it. If you
hold the key at an angle, you may
damage both key and nut. Do not
use a power impact wrench.
3. Place the lug wrench on top of the key and apply pressure. Turn the
wrench counterclockwise.
To install the antitheft lug nut
1. Place the special key on top of the nut, and be sure to hold the key
square to it. If you hold the key at
an angle, you may damage both key
and nut. Do not use a power
impact wrench.
2. Place the lug wrench on top of the special key, apply pressure, and
turn it clockwise.
Nut tightening torque
N·m (kgf·m, ft·lbf) 108―
147 (12 ―14,
80― 108)
What to Do in Case of Emergency
Tire is Punctured or Bursts
8-25
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
