tire pressure MAZDA MODEL 626 2001 Owners Manual

Form No. 8P95-EA-00G
Protecting Your Mazda
4-7
WARNING
!
Snow Blocking the Exhaust Gas:Running the engine when a
vehicle is stopped in deep snow is
dangerous. The exhaust pipe
could be blocked by the snow,
allowing exhaust gas to enter the
cabin. Because exhaust gas
contains poisonous carbon
monoxide, anyone in the cabin
could be injured or killed. Clear
the snow from underneath and
around your vehicle before
starting the engine.
034-1AE
Before DrivingBefore Getting In
• Be sure the windows, outside
mirror(s), and outside lights are
clean.
• Inspect inflation pressures and
condition of tires.
• Look under the vehicle for any sign
of a leak.
• If you plan to back up, make sure
nothing will be in your way.
034-2AE
NOTEEngine oil, engine coolant,
brake/clutch fluid, washer fluid,
and other fluid levels should be
inspected daily, weekly, or at
refueling, depending on the fluid.
See Maintenance, Section 8.

Form No. 8P95-EA-00G
Protecting Your Mazda4-12

Q037-7IE
 Winter Driving
• Carry emergency gear, including
tire chains, window scraper, flares,
a small shovel, jumper cables, and
a small bag of sand or salt.
• Have the proper ratio of antifreeze
in the radiator (page 8-22).
• Inspect the battery and its cables.
Cold reduces battery capacity.
• Use only cold-weather engine oil
(page 8-16).
• Inspect the ignition system for
damage and loose connections. •
Use washer fluid made with
antifreeze—but don’ t use engine
coolant antifreeze for washer fluid
(page 8-33).
• Don’ t use the parking brake if it
might freeze. Instead, shift to P
with an automatic transaxle and to
1 or R with a manual. Block the
rear wheels.

037-8H1E
 Snow tires
Your vehicle is originally equipped
with all season radials designed to be
used all year around. In some extreme
climates you may find it necessary to
replace them with snow tires during
the winter months to further improve
traction on snow and ice covered roads.
Use snow tires on all four wheels.
Don’ t go faster than 120 km/h (75
mph). Inflate snow tires 28 kPa (0.3
kgf/cm
2, 4 psi) more than
recommended on the tire pressure
label (driver ’s door), but never more
than the maximum cold-tire pressure
shown on the tires.

Form No. 8P95-EA-00G
Protecting Your Mazda4-18Tire Pressure LabelJ94A3005

Form No. 8P95-EA-00G
In Case of Emergency6-26
If you’re unsure of how tight the
nuts should be, have them
inspected at a service station. The
specified torque is 90 to 120 N·m
(9.0 to 12.0 kgf·m, 65 to 87
ft·lbf).
WARNING
!
Loose Lug Nuts:Improperly or loosely tightened
lug nuts are dangerous. The
wheel could wobble or come off.
This could result in loss of vehicle
control and cause a serious
accident. Always securely and
correctly tighten the lug nuts.
WARNING
!
Metric Studs and Lug Nuts:Because the wheel studs and lug
nuts on your Mazda have metric
threads, using a nonmetric nut
would be dangerous. On a metric
stud, it would not secure the
wheel and would damage the
stud, which could cause the wheel
to slip off and cause an accident.
Be sure to reinstall the same nuts
you removed or replace them with
metric nuts of the same
configuration.
WARNING
!
Incorrect Tire Air Pressure:Driving on tires with incorrect air
pressure is dangerous. Tires with
incorrect pressure could affect
handling and result in an
accident. Don’t drive with any
tires that have incorrect air
pressure. When you check the
regular tire’ s air pressure, check
the spare tire, too.

Form No. 8P95-EA-00G
I: Inspect and repair, clean, adjust, or replace if necessary
L : Lubricate
Maintenance
8-9
Schedule 2 (Cont ’d)
MAINTENANCE
INTERVALS
Number of months or miles (kilometers), whichever comes first
INTERVALS
Months
4
8
12
16
20
24
28
32
36
40
44
48
MAINTENANCE

1000 km
8
16
24
32
40
48
56
64
72
80
88
96
MAINTENANCE

ITEM
(
1000 miles)
(5)
(10)
(15)
(20)
(25)
(30)
(35)
(40)
(45)
(50)
(55)
(60)
Brake and clutch fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Drum brakes
I
I
Disc brakes
I
I
I
I
Tire inflation pressure and tire wear
I
I
I
I
I
I
I
I
I
I
I
I
Steering operation and linkages
I
I
Power steering fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Front suspension ball joints
I
I
Driveshaft dust boots
I
I
Bolts and nuts on chassis and body
I
I
I
I
Exhaust system heat shields
I
I
All locks and hinges
L
L
L
L
L
L
L
L
L
L
L
L

Form No. 8P95-EA-00G
Maintenance
8-11
083-1AE
Owner MaintenanceOwner Maintenance Schedule
The owner or a qualified service
technician should make these vehicle
inspections at the indicated intervals to
ensure safe and dependable operation.
Bring any problem to the attention of
an Authorized Mazda Dealer or
qualified service technician as soon as
possible.
 When refueling
• Brake and clutch fluid level
(page 8-25) •
Engine coolant level
(page 8-21)
• Engine oil level
(page 8-17)
• Washer fluid level
(page 8-33)
 At least monthly
• Tire inflation pressures
(page 8-41)
083-46A1E
At least twice a year
(for example, every spring and
fall)
• Automatic transaxle fluid level
(page 8-29)
• Power steering fluid level
(page 8-27)
You can do the following scheduled
maintenance items if you have some
mechanical ability and a few basic
tools and if you closely follow the
directions in this manual.
• Air filter
(page 8-34)

Form No. 8P95-EA-00G
Maintenance8-40•Keep terminals and connections
clean, tight, and coated with
petroleum jelly or terminal grease.
• Rinse off spilled electrolyte
immediately with a solution of
water and baking soda.
• If the vehicle will not be used for
an extended time, disconnect the
battery cables.


083-33A4E
Tires
For reasons of proper performance,
safety, and better fuel economy,
always maintain recommended tire
inflation pressures and stay within the
recommended load limits and weight
distribution.
WARNING
!
Using Different Tire Types:Driving your vehicle with
different types of tires is
dangerous. It could cause poor
handling and poor braking;
leading to loss of control. Except
when using the temporary spare
tire, use only the same type tires
(radial, bias-belted, bias-type) on
all four wheels.

Form No. 8P95-EA-00G
Maintenance
8-41
WARNING
!
Using Wrong-Sized Tires:Using any other tire size than
what is specified for your Mazda
(page 10-6) is dangerous. It could
seriously affect ride, handling,
ground clearance, tire clearance,
and speedometer calibration. This
could cause you to have an
accident. Use only tires that are
the correct size specified for your
Mazda.
J94A3005_7GrTire inflation pressure
Inspect all tire pressures monthly
(including the spare) when the tires are
cold. Maintain recommended
pressures for the best ride, top
handling, and minimum tire wear. Refer to the specification charts (page
10-6).

Form No. 8P95-EA-00G
Maintenance8-42NOTE•Warm tires normally exceed
recommended pressures. Don’ t
release air from warm tires to
adjust the pressure.
• Underinflation can cause
reduced fuel economy and poor
sealing of the tire bead, which
will deform the wheel and
cause separation of tire from
rim.
• Overinflation can produce a
harsh ride and a greater
possibility of damage from road
hazards.
(Continued)
•Keep your tire pressure at the
correct levels. If one frequently
needs inflating, have it
inspected.
WARNING
!
Incorrect Tire Inflation:Overinflation or underinflation of
tires is dangerous. Adverse
handling or unexpected tire
failure could result in a serious
accident. Always inflate the tires
to the correct pressure (page
10-6).
083-34A2E
J94A7027_a (J18T7031)
Front
Do not include (TEMPORARY USE ONLY
spare tire) in rotation.
 Tire rotation
To equalize tread wear, rotate the tires
every 6,000 km (3,750 miles), or
sooner if irregular wear develops.
During rotation, inspect them for
correct balance.

Form No. 8P95-EA-00G
Maintenance
8-43
Also, inspect them for uneven wear
and damage. Abnormal wear is usually
caused by one or a combination of the
following:
•Incorrect tire pressure
• Improper wheel alignment
• Out-of-balance wheel
• Severe braking
After rotation, bring all tire pressures
to specification (page 10-6) and
inspect the lug nuts for tightness.
083-37AE
J94A7028
(J18Y7061+62)
New tread Worn tread
Tread wear indicator

Replacing a tire
If a tire wears evenly, a wear indicator
will appear as a solid band across the
tread. Replace the tire when this
happens. You may need to replace it
before the band is across the entire
tread.
083-38A1E
WARNING
!
Worn Tires:Driving with worn tires is
dangerous. Reduced braking,
steering, and traction could result
in an accident. Always use tires
that are in good condition.
