9–5
Specifi cations
Specifi cations
Lubricant Quality
Lubricant Classifi cation
Engine oil Refer to Recommended Oil on page 6-23 .
Coolant FL-22 type
Manual transaxle oil API Service
GL-4
SAE 75W-80
Automatic transaxle fl uid Mazda Genuine ATF-FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fl uid SAE J1703 or FMVSS116 DOT-3

NOTE
Refer to Introduction on (page 6-2 ) for owner's responsibility in protecting your
investment.

Capacities
(Approximate Quantities)
Item Capacity
Engine oil SKYACTIV-G
2.0
With oil
fi lter replacement 4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil fi lter replacement 4.0 L (4.2 US qt, 3.5 Imp qt)
SKYACTIV-G
2.5 With oil
fi lter replacement 4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil fi lter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
Coolant SKYACTIV-G
2.0
Manual transaxle
7.0 L (7.4 US qt, 6.2 Imp qt)
Automatic transaxle 7.6 L (8.0 US qt, 6.7 Imp qt)
SKYACTIV-G
2.5 U.S.A. and Canada
7.4 L (7.8 US qt, 6.5 Imp qt)
Mexico 7.7 L (8.1 US qt, 6.8 Imp qt)
Manual transaxle oil 1.65 L (1.74 US qt, 1.45 Imp qt)
Automatic transaxle fl uid 7.8 L (8.2 US qt, 6.9 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank 2WD
56.0 L (14.8 US gal, 12.3 Imp gal)
AWD 58.0 L (15.3 US gal, 12.8 Imp gal)
Check oil and fl uid levels with dipsticks or reservoir gauges.

CX-5_8FN1-EA-16L_Edition1.indb 52016/12/12 10:07:38

9–6
Specifi cations
Specifi cations
Dimensions
Item Vehicle specifi cation
Overall length 4,550 mm (179.1 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,675 mm (65.9 in)
Front tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Rear tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Wheelbase 2,698 mm (106.2 in)

Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Item Indication on display
GVWR (Gross Vehicle Weight Rating) 1,944 kg (4,286 lbs)
GAWR (Gross Axle Weight Rating) Front
981 kg (2,163 lbs)
Rear 966 kg (2,130 lbs)

SKYACTIV-G 2.5
Item Indication on display
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,048 kg (4,515 lbs) 2,106 kg (4,643 lbs)
GAWR (Gross Axle Weight Rating) Front
1,057 kg (2,330 lbs) 1,075 kg (2,370 lbs)
Rear 994 kg (2,191 lbs) 1,034 kg (2,280 lbs)

CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:07:39

9–7
Specifi cations
Specifi cations
Mexico
SKYACTIV-G 2.0
Item Indication on display
Without moonroof With moonroof
GVW (Gross Vehicle Weight) Total
2,087 kg (4,601 lbs)
Front 1,044 kg (2,302 lbs)
Rear 1,043 kg (2,299 lbs)
GAW (Permissible axle load) Front
1,045 kg (2,304 lbs) 1,050 kg (2,315 lbs)
Rear 1,095 kg (2,414 lbs) 1,105 kg (2,436 lbs)

SKYACTIV-G 2.5
Item Indication on display
2WD AWD
GVW (Gross Vehicle Weight) Total
2,103 kg (4,636 lbs) 2,143 kg (4,725 lbs)
Front 1,062 kg (2,341 lbs) 1,073 kg (2,366 lbs)
Rear 1,041 kg (2,295 lbs) 1,070 kg (2,359 lbs)
GAW (Permissible axle load) Front
1,060 kg (2,337 lbs) 1,070 kg (2,359 lbs)
Rear 1,110 kg (2,447 lbs) 1,150 kg (2,535 lbs)

Air Conditioner
The type of refrigerant used is indicated on a label attached to the ins\
ide of the engine
compartment. Check the label before recharging the refrigerant. Refer to Climate Control
System on page 5-4 .
Item Classifi cation
Refrigerant Type HFC134a (R-134a)

CX-5_8FN1-EA-16L_Edition1.indb 72016/12/12 10:07:39

9–8
Specifi cations
Specifi cations
*Some models.
Light Bulbs
Exterior light
Light bulb Category
Wattage UNECE *1 (SAE)
Headlights/Daytime running lights LED *2 — (—)
Parking lights LED type LED *2 — (—)
Front turn signal lights/Parking lights * 28/8 — (#7444NA)
Front side-marker lights LED type
LED *2 — (—)
Bulb type 5 W5W (—)
Fog lights
* LED *2 — (—)
Side turn signal lights LED *2 — (—)
High-mount brake light LED *2 — (—)
Rear turn signal lights 21 WY21W (7443NA)
Rear side-marker lights LED type
LED
*2 — (—)
Bulb type 21/5 W21/5W (7443)
Brake lights/Taillights LED type
LED
*2 — (—)
Bulb type 21/5 W21/5W (7443)
Reverse lights LED
*2 — (—)
License plate lights 5 W5W (—)
*1 UNECE stands for United Nations Economic Commission for Europe.
*2 LED is the abbreviation for Light Emitting Diode.


Interior light
Light bulb Category
Wattage UNECE *1
Luggage compartment light 8 —
Overhead light (Front)/Map lights 8 —
Rear map lights 8 —
Vanity mirror lights
* 2 —
*1 UNECE stands for United Nations Economic Commission for Europe.
*2 LED is the abbreviation for Light Emitting Diode.


CX-5_8FN1-EA-16L_Edition1.indb 82016/12/12 10:07:39

9–9
Specifi cations
Specifi cations
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fi tted to your vehicle. For details, contact an Authorized Mazda Dealer.

Check the tire pressure label for tire size and in fl ation pressure.
Refer to Tire In fl ation Pressure on page 6-39 .

Standard tire
(U.S.A. and Canada)
Tire size Infl
ation pressure
Front Rear
P225/65R17 100H 230 kPa (34 psi) 230 kPa (34 psi)
P225/55R19 99V 240 kPa (35 psi) 240 kPa (35 psi)

(Mexico)
Tire size Infl
ation pressure
Up to 3 persons —Full load
225/65R17 102V Front
230 kPa (2.3 bar, 33 psi) 260 kPa (2.6 bar, 38 psi)
Rear 230 kPa (2.3 bar, 33 psi) 280 kPa (2.8 bar, 41 psi)
225/55R19 99V Front
250 kPa (2.5 bar, 36 psi) 260 kPa (2.6 bar, 38 psi)
Rear 250 kPa (2.5 bar, 36 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg

Temporary spare tire
(U.S.A. and Canada)
Tire size Infl ation pressure
T145/90D16 106M 420 kPa (60 psi)

(Mexico)
Tire size Infl ation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)

Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N·m (12—14 kgf·m, 80—108 ft·lbf)
CX-5_8FN1-EA-16L_Edition1.indb 92016/12/12 10:07:39

9–10
Specifi cations
Specifi cations
Fuses
Refer to Fuses on page 6-50 .
CX-5_8FN1-EA-16L_Edition1.indb 102016/12/12 10:07:39

9–11
Specifi cations
Personalization Features
Personalization Features
The following personalization features can be set or changed by the customer or an
Authorized Mazda Dealer. Consult an Authorized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer
depending on the feature.
Personalization features and settings which can be changed differ depending on the market
and specifi cation.
Settings Change Method

Settings can be changed by operating the center display screen.
A: Refer to Settings on page 5-124 .
B: Refer to Fuel Economy Monitor on page 4-86 .
C: Refer to Active Driving Display on page 4-28 .

Settings can be changed by operating the vehicle switches.
D: Refer to Auto Lock/Unlock Function on page 3-17 .
E: Refer to Transmitter on page 3-5 .
F: Refer to Locking, Unlocking with Request Switch (With the advanced keyless function) on page 3-14 .

Settings can be changed by an Authorized Mazda Dealer.
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Safety
Smart City Brake
Support (SCBS)
(page 4-148 )
Smart Brake
Support (SBS)
(page 4-153 ) The system can be changed so that Smart
City Brake Support (SCBS)/Smart Brake
Support (SBS) does not operate.
*1
On On/Off A —

The distance at which the collision warning
activates can be changed. Mid Near/Mid/Far A —


The volume of the collision warning can be
changed. High High/Low/Off A —


CX-5_8FN1-EA-16L_Edition1.indb 112016/12/12 10:07:39

9–12
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Lane-keep Assist
System (LAS) &
Lane Departure
Warning System
(LDWS) (page
4-135 ) The system can be changed so that the
steering wheel assist does not operate.
On On/Off A —


When the steering wheel
operation assistance is
turned on The cancel
sensitivity of
the steering
assistance for the
Lane-keep Assist
System (LAS) &
Lane Departure
Warning System
(LDWS) can be
changed.
High High/Low A —


The system can
be changed so
that the Lane
Departure
Warning does not
activate. On On/Off A —


When the steering wheel
operation assistance is
turned off The warning
timing in which
the Lane-keep
Assist System
(LAS) & Lane
Departure
Warning System
(LDWS) system
determines that
the vehicle may
be deviating
from its lane can
be changed.
At At/Before A —


The sensitivity
of the warning
for the Lane-
keep Assist
System (LAS) &
Lane Departure
Warning System
(LDWS) can be
changed. Often Often/Rare A —


The type of Lane-keep Assist System (LAS)
& Lane Departure Warning System (LDWS)
warning can be changed. Vibration
Vibration/Beep/
Rumble A —


The warning intensity/
volume of the Lane-keep
Assist System (LAS) &
Lane Departure Warning
System (LDWS) system
can be changed. Vibration
Low High/Low A —


Rumble Low High/Mid/Low A —


Beep Low High/Low A —


CX-5_8FN1-EA-16L_Edition1.indb 122016/12/12 10:07:39

9–13
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Blind Spot
Monitoring (BSM)
(page 4-99 ) The system can be changed so that Blind
Spot Monitoring (BSM) does not operate.
*1
On On/Off A —

Warning beep volume
*2 High High/
Low/ Off A —

Distance
Recognition
Support System
(DRSS) (page
4-112 ) The system can be changed so that Distance
Recognition Support System (DRSS) does
not operate.
*1
On On/Off A —

The distance at which the vehicle ahead and
your vehicle indicated in the display fl ashes
in white can be changed. Near
Far/Medium/
Near A —


Traffi c Sign
Recognition
System (TSR)
*3
(page 4-105 ) The Traf
fi c Sign Recognition System (TSR)
can be set to inoperable.
*1 On On/Off A —

The warning pattern of the excessive speed
warning can be changed. Off Off/
Visual/
Audio & Visual A —


The activation timing for the excessive speed
warning can be changed.
0 0/ 5/ 10
A —

CX-5_8FN1-EA-16L_Edition1.indb 132016/12/12 10:07:40

9–14
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Vehicle
Door locks (page
3-17 ) Operation condition of auto lock/unlock
function Lock:
Driving, Unlock:
IGN Off Off/
Lock When Driving/
Lock: Driving, Unlock: IGN Off/
Lock When
Shifting Out Of P/
Lock: Shift From P,
Unlock: In P/
Lock: Driving, Unlock: In P A D


Keyless entry
system (page
3-3 ) Method for unlocking door using transmitter
Once:
Driver's,
Twice: All Doors Touch Once:
All Doors/
Once: Driver's, Twice: All Doors A E


Time for locking door automatically 60 seconds 90 seconds/
60 seconds/
30 seconds A —


Advanced keyless
entry system (page
3-10 ) Method for unlocking door using request
switch/transmitter
Once:
Driver's,
Twice: All Doors Touch Once:
All Doors/
Once: Driver's, Twice: All Doors A
E,
F

Time for locking door automatically 60 seconds 90 seconds/
60 seconds/
30 seconds A —


Auto-lock function operation/non-operational Off On/Off A —

Beep volume when locking/unlocking Medium High/
Medium/ Low/ Off A
E,
F

Illuminated entry
system (page
5-140 ) Time until interior lights turn off after
closing door
15 seconds 60 seconds/
30 seconds/
15 seconds/
7.5 seconds A —


Time until interior lights turn off
automatically when any door is not closed
completely 30 minutes 60 minutes/
30 minutes/
10 minutes A —


Auto-wiper control
(page 4-58 ) Operational/non-operational
On On/Off
*4 A —

CX-5_8FN1-EA-16L_Edition1.indb 142016/12/12 10:07:40
