weight MERCEDES-BENZ C CLASS COUPE 2003 Owners Manual

Contents
Technical data................................. 305
Spare parts service ............................ 306
Warranty coverage ............................. 307 Loss of Service and Warranty
Information Booklet ..................... 307
Identification labels ........................... 308 Certification label ......................... 308
Vehicle Identification Number
(VIN) ............................................. 308
Identification labels and numbers 308
Layout of poly-V-belt drive ................. 309 C 230 Kompressor ....................... 309
C 320 ........................................... 309
Engine ................................................ 310
Rims and Tires ................................... 311 Same size tires ............................. 311
Mixed size tires ............................ 312
Spare wheel ................................. 313 Electrical system ................................ 314
Main Dimensions ................................ 315
Weights .............................................. 316
Fuels, coolants, lubricants etc. .......... 317
Capacities ..................................... 317
Engine oils .................................... 319
Engine oil additives ....................... 319
Air conditioning refrigerant .......... 319
Brake fluid .................................... 319
Premium unleaded gasoline ......... 320
Fuel requirements ........................ 320
Gasoline additives ........................ 321
Coolants ...................................... 321
Windshield and headlamp
washer system ............................. 324
Consumer information ....................... 325 Uniform tire quality grading ......... 325
Technical terms ...............................327Index .................................................333

194 Controls in detailLoadingLoading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not ex-
ceed the vehicle capacity weight indicated
on the certification tag which can be found
on the left door pillar.
The handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible. The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Warning!
G
Always fasten items being carried as secure-
ly as possible.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.
Never drive vehicle with trunk lid open.
Deadly carbon monoxide (CO) gases may
enter vehicle interior resulting in uncon-
sciousness and death.

235
Operation
Tires and wheels
Tire pressure changes by approximately
1.5 psi (0.1 bar) per 18°F (10°C) of air
temperature change. Keep this in mind
when checking tire pressure where the
temperature is different from the outside
temperature.
Tire temperature and tire pressure are also
increased while driving, depending on the
driving speed and the tire load.
Check the spare tire periodically for condi-
tion and inflation. Spare tires will age and
become worn over time even if never used,
and thus should be inspected and replaced
when necessary.
Rotating wheels
On vehicles with the same wheel size all
around, wheels can be rotated every 3000
to 6000 miles (5 000 to 10 000 km), or sooner if necessary, according to the de-
gree of tire wear. The same direction of tire
rotation must be retained.
Rotate the wheels before the characteris-
tic tire wear pattern becomes visible
(shoulder wear on front wheels and tread
center wear on rear wheels).
Thoroughly clean the inner side of the
wheels after each rotation. Check and en-
sure proper tire inflation pressure.
Warning!
G
Follow recommended inflation pressures.
Do not overinflate tires. Overinflating tires
can result in sudden de
flation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes
etc.
Do not underinflate tires. Underinflated tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the pillar in the driver’s
door opening). Overloading the tires can
overheat them, possibly causing a blowout.Warning!
G
Rotate front and rear wheels only if they are
of the same size.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
80 ft.lb. (110 Nm).
Use only genuine Mercedes-Benz wheel
bolts specified for your vehicle's rims.

291
Practical hints
Flat tire

Unscrew the alignment bolt, install last
wheel bolt and tighten slightly.
Lowering the vehicle

Lower vehicle by turning crank coun-
terclockwise until vehicle is resting ful-
ly on its own weight.

Remove the jack.
1-5 Wheel bolts

Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1 to 5), until all bolts are tight.
Observe a tightening torque of 80 ft lb
(110 Nm).
!To avoid paint damage, place wheel flat
against hub and hold it there while in-
stalling first wheel bolt.Warning!
G
Always replace wheel bolts that are dam-
aged or rusted.
Never apply oil or grease to wheel bolts.
Damaged wheel hub threads should be re-
paired immediately. Do not continue to drive
under these circumstances! Contact an au-
thorized Mercedes-Benz Center or call
Roadside Assistance.
Incorrect mounting bolts or improperly
tightened mounting bolts can cause the
wheel to come off. This could cause an acci-
dent. Be sure to use the correct mounting
bolts.
Warning!
G
Use only genuine equipment
Mercedes-Benz wheel bolts. They are identi-
fied by the Mercedes star. Other wheel bolts
may come loose.
Do not tighten the wheel bolts when the ve-
hicle is raised. Otherwise the vehicle could
tip over.


293
Practical hints
Flat tire

To switch off the air pump turn the key
in the starter switch to position
0
(page 31).

If the tire pressure is above 36 psi (2.5
bar), release excess tire pressure using
the vent screw.

Detach the electric air pump.

Store the electrical plug and the air
hose behind the flap and place the air
pump back in the trunk.
!Do not operate the electric air pump
longer than six minutes without inter-
ruption. Otherwise it may overheat.
You may operate the air pump again af-
ter it has cooled off.
Warning!
G
Follow recommended inflation pressures.
Do not overinflate tires. Overinflated tires
can result in sudden deflation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes
etc.
Do not underinflate tires. Underinfalted tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the driver’s door latch
post). Overloading the tires can overheat
them, possibly causing a blowout.

305
Technical data
Spare parts service
Warranty coverage
Identification labels
Layout of poly-V-belt drive Engine
Rims and Tires
Electrical system
Main Dimensions Weights
Fuels, coolants, lubricants etc.
Consumer information

316 Technical dataWeights
WeightsRoof load max.
220 lb (100 kg)
Trunk load max.
220 lb (100 kg)

351
Index
Resetting functions in
Control system 115
Selecting 114
Settings menu 114
Vehicle 122
Sun visors 141
Sunshades for the sliding/pop-up roof Closing 185
Opening 185
Stopping 185
Supplemental Restraint System (SRS) 331
Switching off Audio system 162
Automatic central locking (control system) 122
Delayed (exterior lamps) 120
Engine 52
ESP 76
Hazard warning flasher 99
Headlamps 52
Seat heating 92
Switching on Audio system 162
Automatic central locking (control system) 122
ESP 77 Front fog lamps 98
Hazard warning flasher 99
Headlamps 47
High beams 99
Rapid seat heating 92
Rear fog lamp 98
Seat heating* 92
Windshield wipers 48
Synchronizing Sliding/pop-up roof 188, 279
T
Tachometer 23, 103 Displaying gear range 134
Overspeed range 103
Tail lamps Cleaning 242
Replacing bulbs 281, 285
Tailgate Message in display 269
Tar stains 241
Technical data 319 Brake fluid 319
Coolant 317
Coolants 321
Electrical system 314
Engine 310 Engine oil 319
Engine oil additives 319
Fuel requirements 320
Fuels 317
Gasoline additives 321
Lubricants 317
Main dimensions 315
Premium unleaded gasoline 320
Rims and tires 311
Weights 316
Windshield and headlamp washer
system 318, 324
Tele Aid Information 206
Initiating an emergency call manually 204
Messages in display 269
Roadside assistance 204
Tele Aid System 201
Tele Aid System 331
Tele Aid* 201 Emergency calls 202
Remote door unlock 208
Stolen vehicle tracking services 209
System self-check 202
Upgrade signals 207

354 IndexVehicle tool kit 272Alignment bolt 272
Spare fuses 272
Special fuse puller 272
Towing eye bolt 272
Vehicle jack 272
Wheel bolts 272
Wheel wrench 272
Vehicle washing 242
Ventilated storage compartment 148
Ventilation Storage compartment 148
VIN (Vehicle Identification Number) 308, 331
Voice control system* 331
Voice recognition system* Hands-free microphone 26
W
Warning sounds Drivers seat belts 62
Parking brake 46
Warranty coverage 307
Washer fluid see Windshield washer fluid
Washing the vehicle 240
Wear pattern (tires) 235
Weights 316 Wheel change
Tightening torque 291
Wheels Rotating 235
Tires and wheels 233
Window curtain airbags 61
Windows see Side windows
Windshield Defogging 145, 153
Refilling washer fluid 232
Replacing wiper blades 287
Washer fluid 232, 324
Washer system 324
Windshield washer fluid 324 Message in display 270
Mixing ratio 324
Refilling 232
Wiping with 49
Windshield washer system 324
Windshield wipers 48 Fast wiper speed 48
Replacing wiper blades 287
Single wipe 49
Switching on 48
Wiping with windshield washer fluid 49 Winter driving 236
Block heater 237
Snow chains 237
Tires 236
Transmission program mode 136
Winter driving instructions 220
Winter tires 236
Wiper blades Cleaning 243
Installing 287
Removing 287
Removing insert 287
Replacing 287
Wiping And washing simultaneously 49
Interval 48
With windshield washer fluid 49
X
Xenon headlamps Bi-Xenon 327
