MERCEDES-BENZ CL-CLASS 2007 Owners Manual

190 Control systems
COMAND navigation system (Point of interest entry)
Main category list with input characters
When this list appears, the input charac-
ters 5 are automatically activated.
1Top list entry based on the input data
up to that point
2Characters entered by the user
3Characters automatically added by the
system
4Symbol for available POIs or other
available subcategories
5Input characters
6Currently non-selectable characters
7Currently selectable character
8Currently selected character
9Main category listWhile the characters are being selected as
described below, the top list entry 1 al-
ways shows the category which best corre-
sponds to the input data as it has been
entered up to that point.
At the same time, COMAND automatically
supplements characters 2 entered by the
user with appropriate characters 3.
Selecting characters: Slide omp or
rotate ymz.
Confirming character selection:
Press n.
Deleting individual characters:
Select) in the bottom line and
pressn.
Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.
Canceling an entry: Select “Back” in
the bottom line and press n.
or
Press back button L in the center
console (
page 82).
As soon as COMAND can clearly attribute
the characters entered to a category, the
input characters 5 disappear.
You see the list of main categories without
the input characters. Here you can confirm
the current entry or make another selec-
tion.
You can also manually switch to the main
category list without input characters at
any time.
Switching manually to the main cat-
egory list without input characters:
Slide qm.
or
Select ? in the second line from the
bottom and press n.
iIn the list of input characters 5, you can
only select currently selectable characters.
Which characters are included depends on the
sequence in which you have entered your desti-
nation and the data version of the digital map.
ProCarManuals.com

191 Control systems
COMAND navigation system (Point of interest entry)
Main category list without input
characters
Example illustration: main category list for
POIs in the surrounding area
1Category
2Symbol for available POIs or other
available subcategories
Selecting a main category: Slide
qmr or rotate ymz.
Canceling selection: Select “Back”
and press n.
or
Press back button L in the center
console (
page 82).
Confirming selection: Press n.
Main categories with symbol 2 con-
tain either POIs or subcategories. Fur-
ther operation depends on whether the
selected main category contains sub-
categories or only POIs.
Selected main category contains subcate-
gories:
Selecting such a main category opens a list
of subcategories. The illustration below
shows by way of example the “RESTAU-
RANT” main category with available sub-
categories 4.1Main category
2To show all POIs for all subcategories
under category 1
3Symbol for available POIs
4Subcategory
Selecting a subcategory: Slide qmr
or rotate ymz.

ProCarManuals.com

192 Control systems
COMAND navigation system (Point of interest entry)
Canceling selection: Select “Back”
and press n.
or
Press back button L in the center
console (
page 82).
Confirming selection: Press n.
After selecting a subcategory, a list of
POIs appears. It contains the POIs
available within the search radius of
the subcategory.
Selected main category contains no sub-
categories, but only POIs:
Selecting such a main category immedi-
ately opens a list of POIs. The POI list con-
tains the available POIs within the search
radius of the main category.POI list
Depending on the situation, COMAND first
shows the following list or the POI list with
input characters.
The illustration below shows by way of ex-
ample the POI list for the “RESTAURANT”
main category, “FRENCH CUISINE” subcat-
egory within the surrounding area.
1Compass heading to the destination
2Linear distance to the destination
3Special destinationIn the POI list, you can either select a POI
or enter the name of the POI.
Selecting a POI
Select desired POI.
The POI list disappears and the address
of the POI appears.
Back to POI list: Select “Back” and
press n.
or
Press back button L in the center
console (
page 82).
Starting route calculation:
Select “Start”, see also (
page 181).
Entering name of POI
Select “Options”
“Spell”.
The POI list appears with input charac-
ters; the input characters are automat-
ically activated.
iIf you have selected list item 2, the POI list
contains all POIs for all subcategories within the
search radius of main category 1.
iDisplays 1 and 2 are not visible if you
have already entered a POI within a particular
town or city. Displays 1 and 2 are static; they
do not change while you are driving.

ProCarManuals.com

193 Control systems
COMAND navigation system (Point of interest entry)
POI list with input characters
1Top list entry based on the input data
up to that point
2Characters entered by the user
3Characters automatically added by the
system
4Input characters
5Currently selectable character
6Currently non-selectable characters
7POI list
8Currently selected characterWhile the characters are being selected as
described below, the top list entry 1 al-
ways shows the POI that best corresponds
to the input data as it has been entered up
to that point.
At the same time, COMAND automatically
supplements characters 2 entered by the
user with appropriate characters 3.
Selecting characters: Slide omp or
rotate ymz.
Confirming character selection:
Press n.
Deleting individual characters:
Select) in the bottom line and
pressn.
Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.
Canceling an entry: Select “Back” in
the bottom line and press n.
or
Press back button L in the center
console (
page 82).
As soon as COMAND can clearly attribute
the characters entered to a POI, the input
characters 4 disappear.
You see the POI list without input charac-
ters. Here you can confirm the current en-
try or make another selection.
You can also manually switch to the POI
list without input characters at any time.
Switching manually to the POI list
without input characters: Slide qm.
or
Select ? in the second line from the
bottom and press n.
iFor POIs in other regions, this list also shows
the compass heading to the destination as well
as the linear distance to the destination, as in the
previous illustration.
iIn the list of input characters 4, you can
only select currently selectable characters.
Which characters are included depends on the
sequence in which you have entered your desti-
nation and the data version of the digital map.
ProCarManuals.com

194 Control systems
COMAND navigation system (Point of interest entry)
POI list without input characters
Selecting a destination: Slide qmr or
rotate ymz.
Canceling selection: Select “Back”
and press n.
or
Press back button L in the center
console (
page 82).
Confirming selection: Press n.
Starting route calculation:
Select “Start”, see also (
page 181).List options
Options in category and POI lists
If you enter a POI in the surrounding area,
initially, only categories and POIs within a
radius of approximately 12 mi around the
vehicle position are available.
The same applies if you enter a POI within
a given town or city and have previously
entered more than the state (USA) or prov-
ince (CDN) and the city or town.
If you expand the list, the search radius in-
creases to around 90 mi. This gives you ac-
cess to all categories and POIs within a
radius of about 90 mi.
Expanding list: In one of the lists se-
lect “Options”
“Expand Search”.
The list is expanded.
Options only in POI lists
Displaying details of the selected
entry: Select “Options”
“Details”.
The detailed view appears.
Closing detailed view: Select “OK”.
ProCarManuals.com

195 Control systems
COMAND navigation system (Point of interest entry)
Entering a POI from the map
Select “Guide” in the map view with the
menu system displayed (
page 157).
You will see POI symbols on the map,
depending on whether POIs are avail-
able and which map scale is set.
The scale at which the symbols are dis-
played on the map varies according to
the symbol.
You can set which symbols COMAND
should display (
page 159).
The POI closest to the center of the
screen is automatically marked.
If there are no POIs available, the
“Back” menu item is automatically
highlighted and you cannot select oth-
er menu items.1Highlighted POI
2Information about the highlighted POI
Selecting a POI: Select “Next” or “Pre-
vious”.
The next or the previous POI is marked.
Displaying details of the selection:
Select “Details”.
Starting route calculation:
Select “Start”, see also (
page 181).
A prompt appears asking whether the
POI should be used as the destination.
Select “Yes” or “No”.
If you select “Yes”, the route calcula-
tion begins. If you select “No”, you can
select a new POI.
iIf the crosshair is shown on the map, you
can enter POIs in the vicinity of the crosshair.
If the crosshair is not shown on the map, you can
enter POIs in the vicinity of the vehicle’s current
position.
ProCarManuals.com

196 Control systems
COMAND navigation system (route guidance)
Route guidance
COMAND guides you to the destination us-
ing navigation commands in the form of
audible navigation announcements and
route guidance displays.
If, for any reason, you do not follow the
navigation commands or if you leave the
calculated route, COMAND automatically
calculates a new route to the destination.
If the map data contains the relevant infor-
mation, COMAND tries to avoid roads that
only have limited access, e.g. roads closed
to through-traffic and non-residents.Roads that have time restrictions (e.g.
closed on Sundays and public holidays) are
not considered for route guidance, if the
digital map contains the relevant informa-
tion.
Examples of displays and announce-
ments for a driving maneuver
Driving maneuvers have three phases:

Preparation phase

Announcement phase

Maneuver phase
Warning!G
COMAND calculates the route to the desti-
nation without taking account of the follow-
ing, for example:

Traffic lights

Stop and right-of-way signs

Parking or stopping prohibited areas

Lane merges

Other road and traffic rules and regula-
tions

Narrow bridges
COMAND may give incorrect navigation
commands if the data in the digital map
does not correspond with the actual
road/traffic situation. For example, if the
traffic routing has been changed or the di-
rection of a one-way road has been re-
versed.
For this reason, you must always observe
applicable road and traffic rules and regula-
tions during your journey. Road and traffic
rules and regulations always have priority
over the navigation commands generated by
the system.
iThe route guidance displays can only be
seen if the display is switched to navigation
mode.
ProCarManuals.com

197 Control systems
COMAND navigation system (route guidance)
Preparation phase
COMAND prepares you for the upcoming
driving maneuver. Based on the example
display below, the driving maneuver is an-
nounced with the “Prepare to turn left”
message. The display is not split and
shows the map over the full screen.
1Point at which the driving maneuver
takes place (light blue dot)
2Route (highlighted blue)
3Current vehicle position; the triangle
points in the vehicle’s direction of trav-
elAnnouncement phase
COMAND announces the next driving ma-
neuver. Based on the example display be-
low, the driving maneuver is announced
700 feet in advance with the “Turn left in
700 feet to your destination” message.
The display is divided in two. In the left
half, you see the normal map view. In the
right half, there is either an enlarged view
of the area surrounding the intersection
(intersection zoom) or simply a symbol for
the next driving maneuver.
The following example illustration shows
the intersection zoom in the right half.1Next road
2Driving maneuver (turn left)
3Graphical representation of the dis-
tance to the driving maneuver
4Point at which the driving maneuver
takes place (light blue dot, shown in
both the left and right displays)
5Information about distance to the next
driving maneuver
6Route (highlighted in blue; shown in
both the left and right displays)
7Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
(shown in both the left and right dis-
plays)
8Street on which you are currently driv-
ing, if included on the digital map
9Destination
iThe filled-in section of distance graphic 3
gets shorter the nearer you get to the announced
driving maneuver.
ProCarManuals.com

198 Control systems
COMAND navigation system (route guidance)
Maneuver phase
COMAND announces the next driving ma-
neuver. Based on the example display be-
low, the driving maneuver is announced
150 feet in advance with the “Now turn
left” message. The display is also split into
two halves, as for the announcement
phase.
1Graphical representation of the dis-
tance to the next driving maneuver
2Information about distance to the next
driving maneuverExample of a display without driving
maneuvers
1Main destination <
2Stopover = (only visible if a stopover
has been entered)
3Route (highlighted blue)
4Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
5Set map orientation – for an explana-
tion and settings, see (
page 159)
6Set scale – for an explanation and set-
tings, see (
page 157)Destination or destination area
reached
Once you have reached your destination,
you will hear the announcement “You have
reached the destination”. For certain POIs
(airports or highway junctions), you will
hear the announcement “You have reached
the destination area”. In addition, you will
see a corresponding display and route
guidance is automatically ended.
1Destination on the map
2Destination flag
iOnce the maneuver is completed, COMAND
automatically switches back to the non-split
screen.
ProCarManuals.com

199 Control systems
COMAND navigation system (route guidance)
Partially digitized areas If the destination is within a partially
digitized area
COMAND guides you through fully digitized
areas for as long as possible. Route guid-
ance is conducted in the usual manner, i.e.
with navigation announcements and route
guidance displays.
Before the vehicle reaches a partially digi-
tized area, COMAND notifies you of this
with the following announcements:

“Be prepared to enter an area where
turn by turn guidance cannot be provid-
ed.”

“In 700 feet you will enter an area
where turn by turn guidance cannot be
provided.”

“You are about to enter an area where
turn by turn guidance cannot be provid-
ed.”Route guidance within a partially digi-
tized area
If you start route guidance in this type of
area, you will hear the following announce-
ment: “You are currently in an area where
turn by turn guidance cannot be provided.”
Route guidance is provided by means of a
direction arrow showing the compass
heading to the destination. COMAND will
not generate automatic navigation an-
nouncements.
If you try to call up an announcement man-
ually, (page 202) you will hear the an-
nouncement “You are currently in an area
where turn by turn guidance cannot be pro-
vided.”.
iThe digital map may contain areas that are
only partially digitized although they are within a
digitized region.
Warning!G
Due to incomplete digitization, the route
shown on the map may differ from the actual
road/traffic situation.
If you follow the route shown on the map, for
example, it is possible that you could drive
the wrong way down a one-way street or
that a street cannot be driven on.
When using route guidance in a partially dig-
itized area, you must therefore be sure to
observe all relevant traffic regulations and
the course of the road.
All relevant traffic regulations and the
course of the road always take priority over
the route shown on the map.
iThe indicated distance can be seen here by
way of example. In reality, it may be different.
iWhen you call up the route info to this type
of destination, (
page 204) the following data
shown there may differ from the actual situation:

Distance to the destination

Estimated driving time to the destination

Estimated arrival time
ProCarManuals.com
