Page 8 of 569
Contents
Oxidation catalyst
(diesel engine).............................. 349
Emission control .......................... 350
Coolant temperature .................... 350
At the gas station .............................. 352
Refueling ...................................... 352
Check regularly and before a
long trip........................................ 354
Engine compartment ......................... 356
Hood ............................................ 356
Engine oil ..................................... 358
Transmission fluid level ................ 360
Coolant level ................................ 360
Windshield/rear window washer
system and headlamp cleaning
system* ....................................... 362
Tires and wheels ................................ 363
Important guidelines .................... 363
Tire care and maintenance........... 364
Direction of rotation ..................... 365
Loading the vehicle ...................... 366
Recommended tire inflation
pressure ....................................... 371
Checking tire inflation pressure ... 373
Tire labeling.................................. 384
Load identification ....................... 388DOT, Tire Identification Number
(TIN) .............................................. 388
Maximum tire load ........................ 390
Maximum tire inflation pressure ... 390
Uniform Tire Quality Grading
Standards (U.S. vehicles) .............. 391
Tire ply material ............................ 393
Tire and loading terminology......... 393
Rotating tires ................................ 396
Winter driving ..................................... 398
Winter tires ................................... 398
Snow chains.................................. 399
Maintenance....................................... 400
Maintenance service indicator
message ....................................... 400
Calling up the maintenance
service indicator display ............... 402
Resetting the maintenance
service indicator ........................... 402
Vehicle care........................................ 403
Cleaning and care of the vehicle ... 403
Practical hints.................................. 413
What to do if … ................................... 414
Lamps in instrument cluster ......... 414
Lamp in center console ................ 425
Vehicle status messages in the
multifunction display .................... 427
Where will I find ...? ............................ 467
First aid kit.................................... 467
Vehicle tool kit.............................. 467
Spare wheel .................................. 471
Unlocking / locking in an emergency .. 474
Unlocking the vehicle ................... 474
Locking the vehicle ....................... 475
Fuel filler flap ................................ 475
Resetting activated head restraints.... 477
Vehicles without Rear Seat
Entertainment Package................. 477
Vehicles with Rear Seat
Entertainment Package*............... 478
Replacing SmartKey batteries ............ 479
Replacing bulbs .................................. 480
Bulbs............................................. 480
Replacing bulbs for front lamps .... 483
Replacing bulbs for rear lamps ..... 487
Page 9 of 569
Contents
Replacing wiper blades ...................... 489
Front wiper blades ....................... 489
Rear wiper blade .......................... 490
Flat tire .............................................. 492
Preparing the vehicle.................... 492
Mounting the spare wheel ............ 493
Bleeding the fuel system
(diesel engine only) ............................ 502
Battery ............................................... 503
Disconnecting, removing,
reinstalling and reconnecting
the battery.................................... 505
Charging the battery .................... 510
Jump starting ..................................... 511
Towing the vehicle ............................. 513
Installing towing eye bolt.............. 515
Stranded vehicle .......................... 517
Fuses ................................................. 518
Fuse box in engine compartment . 519
Fuse box in cargo compartment ... 519
Fuse box in passenger
compartment................................ 520
Emergency engine shut-down ...... 520
Technical data................................. 521
Parts service ...................................... 522
Warranty coverage............................. 523
Loss of Service and Warranty
Information Booklet ..................... 523
Identification labels ........................... 524
Layout of poly-V-belt drive ................. 526
R 320 CDI 4MATIC ....................... 526
R 350, R 350 4MATIC,
R 550 4MATIC .............................. 526
Engine................................................ 527
Rims and tires.................................... 529
Same size tires ............................. 530
Spare wheel ................................. 532
Electrical system ............................... 533
Main Dimensions ............................... 534
Weights.............................................. 535Fuels, coolants, lubricants, etc. ......... 536
Capacities .................................... 536
Engine oils ................................... 538
Engine oil additives ...................... 538
Air conditioning refrigerant .......... 538
Brake fluid.................................... 539
Premium unleaded gasoline
(gasoline engine).......................... 539
Fuel requirements ........................ 540
Gasoline additives
(gasoline engine).......................... 540
Coolants ...................................... 541
Windshield washer system and
headlamp cleaning system*......... 544
Index................................................. 545
Page 24 of 569
23 At a glance
Exterior view
ItemPage
1Tailgate119
Power tailgate*119
Cargo compartment
Loading instructions
Cargo tie-down rings
Hooks
Expanding
Cover blind
Cargo net*
289
290
291
292
299
301
Vehicle tool kit467
Spare wheel471
2Rear window defroster207
3Rear lamps481
4Fuel filler flap352
Refueling352
Fuel353,
540
ItemPage
5Exterior rear view mirrors
Adjusting48
Auto-dimming rear view
mirrors*203
Power folding*204
6Towing eye bolt467
Installing towing eye bolt515
7Tires and wheels363,
529
Checking tire inflation
pressure373
General information363
Flat tire492
Spare wheel471
8Hood
Opening356
Engine oil358
Coolant360
ItemPage
9Windshield wipers59
Wiper blades, replacing489
Wiper blades, cleaning409
aWindshield
Cleaning with wiper fluid61
Cleaning409
bPower tilt/sliding sunroof*248
Panorama roof with power
tilt/sliding panel*252
cDoors
Locking and unlocking110
Opening and closing118
Locking/unlocking in an
emergency474
dFront lamps480
eHeadlamp cleaning system*203
Page 36 of 569
35 At a glance
Storage compartments
ItemPage
1Parcel net in front
passenger footwell307
2Glove box304
3Door pocket
4Parcel net on front
passenger seat backrest307
5Door pocket
6Cup holder308
7Third-row storage
compartment304
8First aid kit, vehicle tool kit,
spare wheel467
9Third-row storage
compartment304
aCup holder308
bDoor pocket
ItemPage
cParcel net on driver’s seat
backrest307
dDoor pocket
eStorage compartment in
center console304
fAshtray311
gCupholders308
hFront armrest storage
compartment/telephone
tray304
jCup holders
Rear storage compartment
Rear seat ashtray308
304
311
kCup holders*308
lRear armrest storage
compartment*304
Page 105 of 569
104 Safety and Security
Driving safety systems
Switching off the ESP®
To improve the vehicle’s traction, switch
off the ESP® in driving situations where it
would be advantageous to have the drive
wheels spin and thus cut into surfaces for
better grip such as:
when driving with snow chains
in deep snow
in sand or gravelWhen you switch off the ESP
®
the ESP® does not stabilize the vehicle
the engine output is not limited, which
allows the drive wheels to spin and
thus cut into surfaces for better grip
the Electronic Traction System will still
apply the brake to a spinning wheel
the ESP® continues to operate when
you are braking
you cannot activate the cruise control
or the Distronic* system
the cruise control or the Distronic*
system switch off if currently activatedThe ESP
® switch is located on the upper
part of the center console.
1ESP
® switch
With the engine running, press ESP®
switch1.
The ESP
®warning lampv in the in-
strument cluster comes on.
The ESP
® is deactivated.
Warning!G
The ESP® should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
Do not switch off the ESP
® when a spare
wheel is mounted.
Warning!G
Switch on the ESP® immediately if the afore-
mentioned circumstances do not apply any-
more. Otherwise the ESP
® will not stabilize
the vehicle when it is starting to skid or a
wheel is spinning.
iWhen the ESP® is switched off and one or
more drive wheels are spinning, the ESP® warn-
ing lamp v in the instrument cluster flashes.
However, the ESP
® will then not stabilize the
vehicle.
Page 290 of 569
289 Controls in detail
Loading
Loading instructions
Load distribution
The gross vehicle weight which is the
weight of the vehicle including fuel, tools,
spare wheel, installed accessories, pas-
sengers, and luggage/cargo must never
exceed the load limit and the Gross Vehicle
Weight Rating (GVWR) for your vehicle as
specified on the placard located on the
driver’s door B-pillar (
page 524). In addi-
tion, the load must be distributed in such a
way so that the weight on each axle never
exceeds the Gross Axle Weight Rating
(GAWR) for the front and rear axle. The
GVWR and GAWR for your vehicle are indi-
cated on the certification label which can
be found on the driver’s door B-pillar
(
page 524).
For more information, see “Tire and Load-
ing Information” (
page 367).
The handling characteristics of a fully
loaded vehicle depend greatly on the load
distribution. It is therefore recommended
to load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
Warning!G
Always fasten items being carried as
securely as possible using cargo tie-down
rings and fastening materials appropriate
for the weight and size of the load.
In an accident, during hard braking or
sudden maneuvers, loose items will be
thrown around inside the vehicle, and can
cause injury to vehicle occupants unless the
items are securely fastened in the vehicle.
To help avoid personal injury during a
collision or sudden maneuver, always use
tie-down rings and, if so equipped, always
use the cargo net* when transporting cargo.
Never drive vehicle with the tailgate open.
Deadly carbon monoxide (CO) gases may
enter vehicle interior resulting in uncon-
sciousness and death.
Page 327 of 569
326 Controls in detail
Useful features
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Light Truck Center. For
services such as labor and/or towing,
charges may apply. Refer to the Roadside
Assistance Manual for more information.
The following is only available in the USA:
Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.Information button¡
The Information button¡ is located
below the center armrest cover.
1Information button¡
Open the telephone* tray
(
page 306).
Press and hold button1 (for longer
than 2 seconds).
A call to the Customer Assistance
Center will be initiated. The button will
flash while the call is in progress. The
message
Connecting Call will appear
in the multifunction display.
iThe indicator lamp on the Roadside
Assistance button• remains illuminated in
red for approximately 10 seconds during the
system self-check after switching on the ignition
(together with the SOS button and the
Information button¡).
See system self-check (
page 323) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp on the Roadside Assistance
button• is flashing continuously and there
was no voice connection to the Response Center
established, then the Tele Aid system could not
initiate a Roadside Assistance call (e.g. the rele-
vant cellular phone network was not available).
The message
Call Failed appears in the
multifunction display.
Roadside Assistance calls can be terminated
using thet button on the multifunction
steering wheel or the END button on the
COMAND system headunit.
Page 365 of 569
364 Operation
Tires and wheels
Tire care and maintenance
Regularly check the tire inflation pressure
at least once a month. For more informa-
tion on checking tire inflation pressure,
see “Recommended tire inflation pres-
sure” (
page 371).Tire inspection
Every time you check the tire inflation
pressure, you should also inspect your
tires for the following:
excessive treadwear (page 365)
cord or fabric showing through the
tire’s rubber
bumps, bulges, cuts, cracks or splits in
the tread or side of the tire
Replace the tire if you find any of the above
conditions.
Make sure you also inspect the spare tire
periodically for condition and inflation.
Spare tires will age and become worn over
time even if never used, and thus should be
inspected and replaced when necessary.Life of tire
The service life of a tire is dependent upon
varying factors including but not limited to:
Driving style
Tire inflation pressure
Distance driven
Warning!G
Regularly check the tires for damage.
Damaged tires can cause tire inflation pres-
sure loss. As a result, you could lose control
of your vehicle.
Worn, old tires can cause accidents. If the
tire tread is badly worn, or if the tires have
sustained damage, replace them.
Warning!G
Tires and spare tire should be replaced after
6 years, regardless of the remaining tread.
Page 367 of 569
366 Operation
Tires and wheels
Loading the vehicle
Two labels on your vehicle show how much
weight it may properly carry.
1) The Tire and Loading Information
placard can be found on the driver’s
door B-pillar. This placard tells you im-
portant information about the number
of people that can be in the vehicle and
the total weight that can be carried in
the vehicle. It also contains information
on the proper size and recommended
tire inflation pressures for the original
equipment tires on your vehicle.2) The certification label, also found on
the driver’s door B-pillar. It tells you
about the gross weight capacity of your
vehicle, called the Gross Vehicle
Weight Rating (GVWR). The GVWR
includes the weight of the vehicle, all
occupants, fuel and cargo. The certifi-
cation label also tells you about the
front and rear axle weight capacity,
called the Gross Axle Weight Rating
(GAWR). The GAWR is the total allow-
able weight that can be carried by a
single axle (front or rear). Never exceed
the GVWR or GAWR for either the front
axle or rear axle.
1Driver’s door B-pillar
Following is a discussion on how to work
with the information contained on the Tire
and Loading Information placard with
regards to loading your vehicle.
iSpare wheels may be mounted against the
direction of rotation (spinning) even with a
unidirectional tire for temporary use only until
the regular drive wheel has been repaired or
replaced. Always observe and follow applicable
temporary use restrictions and speed limitations
indicated on the spare wheel.
Page 375 of 569
374 Operation
Tires and wheels
Install the valve cap.
Repeat this procedure for each tire.
Run Flat Indicator (Canada only)
While the vehicle is being driven, the Run
Flat Indicator monitors the set tire inflation
pressures by evaluating each wheel’s rota-
tional speed. This allows the system to de-
tect a significant loss of pressure in a tire.
If a wheel’s rotational speed changes due
to falling tire inflation pressure, you will
see a corresponding warning message in
the multifunction display.The Run Flat Indicator may function in a re-
stricted manner or with a delay
if snow chains are mounted to the
vehicle
in presence of ice and snow
if you are driving on a loose surface
(e.g. sand or gravel)
if you are driving in a very sporty
manner (involving rapid acceleration or
high speeds in curves)
iIf you have overfilled the tire, release tire in-
flation pressure by pushing the metal stem of the
valve with e.g. a tip of a pen. Then recheck the
tire inflation pressure with the tire gauge.Warning!G
When the multifunction display shows the
message
Tire Pressure Check Tires,
one or more of your tires is significantly un-
derinflated. You should stop and check your
tires as soon as possible, and inflate them to
the proper tire inflation pressure as in-
dicated on the vehicle’s Tire and Loading
Information placard or, if available, on the
tire inflation pressure label. Driving on a sig-
nificantly underinflated tire causes the tire
to overheat and can lead to tire failure. Un-
derinflation also reduces fuel efficiency and
tire tread life, and may affect the vehicle’s
handling and stopping ability. Each tire, in-
cluding the spare, should be checked
monthly when cold and set to the recom-
mended tire inflation pressure as specified
on the Tire and Loading Information placard
(
page 366) or on the tire inflation pres-
sure label located on the inside of the fuel
filler flap (
page 352).
