136 Navigation*Destination entrySwitching to a selection list is possible at
any time while entering a city.
Press the
List
soft key.
A selection list appears indicated by
Se-
lect city
displayed in the status bar.
Now continue with selecting a city.
Selecting a city

Useor  to select the destina-
tion city.
The
Page
soft keys allow scrolling
through the list page by page.

Press.
After selecting the desired city, one of
the following menus appears:
For larger cities with more than 15
streets:
Enter Street menu (
page 139).

For smaller cities with up to
15 streets:
Select Street menu (
page 139).

If no streets are registered for the
selected city:
Select City Center menu
(page 137).
The appropriate menu can be identified
from the display in the status bar.
iThe selection is cancelled if the
Back

soft key is pressed.

137 Navigation*
Destination entry
Besides entering a street name
(page 138), the following soft keys are
available for narrowing the destination.

Map
soft key
Provides access to destination input di-
rectly via road map (
page 144),

CityCtr
soft key
Provides access to the input of a city
section (center) (
page 137),

POIs
soft key
Provides access to the input of a POI
referring to the destination city
(
page 178).
After the destination city (
page 135) has
been entered, the associated city center
(section of the city) can be selected.

Press the
CityCtr
soft key.
Enter center
is displayed in the status
bar.
Accepting the destination displayed

Press .
Narrowing of the destination after
selecting a city
Entering a city center

138 Navigation*Destination entryEntering a center
Use the keypad menu or the 12 button
keypad to enter the data of the center
(page 129).
After entering the center a selection
list of centers appears indicated by
Se-
lect center
displayed in the status bar.
Now continue with selecting a center.
Switching to a selection list is possible at
any time while entering a center.

Press the
List
soft key.
A selection list appears indicated by
Se-
lect center
displayed in the status bar.
Now continue with selecting a center.Selecting a center

Useor  to select a city center.
The Page soft keys allow scrolling
through the list page by page.

Press .
The Start Route Guidance menu
(page 150) appears.
The system accesses one of the following
menus after entering of a destination city
(
page 135):

For larger cities with more than 15
streets:
Enter Street menu (
page 139).

For smaller cities with up to 15 streets:
Select Street menu (
page 139).
Entering a street in the destination
city

139 Navigation*
Destination entry

If no streets are registered for the se-
lected city:
Select City Center menu (
page 137).
The appropriate menu can be identified
from the display in the status bar.
Entering a street

Use the keypad menu or the 12 button
keypad to enter the data of the street
(page 129).
After entering the street a selection list
of streets appears indicated by
Select
street
displayed in the status bar. Now
continue with selecting a street.
Switching to a selection list is possible at
any time while entering a street.

Press the
List
soft key.
A selection list appears indicated by
Se-
lect street
displayed in the status bar.
Now continue with selecting a street.
A selection list of streets appears indi-
cated by Select street
displayed in the
status bar.Selecting a street

Use or  to select a street.
The
Page
soft keys allow scrolling
through the list page by page.

Press .
The Start Route Guidance menu with
the selected destination information
appears;
or


140 Navigation*Destination entry
If the street extends through several
city centers, the list of city centers re-
ferring to the street selected appears.
Selecting the city center referring to
the street selected
The system distinguishes between streets
with the same name in a city by specifying
the center. After selecting a street, a list of
city centers may appear.
The status bar shows how many times the
system found the same street name within
a given city.

Use or  to select a center.

Press .
The Start Route Guidance menu with
the selected destination information
appears.The following soft keys are available to
continue narrowing the destination after
entering the street:
Narrowing of the destination after
selecting a street

141 Navigation*
Destination entry

Map
soft key
Provides access to further destination
input directly via road map
(page 144),

Intrsct.
soft key
An intersection with the destination
street can be entered (
page 141),

Hse. no.
soft key
A house number on the destination
street can be entered (
page 142),

POIs
soft key
A POI on or near the destination street
can be entered (
page 178).The following soft keys can also be select-
ed:

Mode
soft key
For setting the route mode
(
page 126),

Save
soft key
Stores the entered destination in the
destination memory (
page 175).
After entering a street (
page 138), a
street intersecting with this street can be
entered.

Press the
Intrsct.
soft key.The Enter Intersection menu or a list of
all intersecting streets appears.
Enter Intersection menu
iOnly the entry of either an intersecting
road or a house number is possible.
Entering an intersection

iThe
Intrsct.
soft key is only available if
streets intersecting the destination
street are stored as intersections on
the navigation DVD.

142 Navigation*Destination entry
Proceed the same as when entering a
city name (
page 135).
List of intersecting streets

Use or  to select an intersec-
tion.
The
Page
soft keys allow scrolling
through the list page by page.

Press .
The Start Route Guidance menu
(page 150) appears.
A house number can be entered after en-
tering the destination street (
page 138).

Press the
Hse. no.
soft key.
The Enter House Number menu ap-
pears (
page 143);
or
The house number list appears. A
house number range can be selected.
(
page 144).
Entering a house numberiAn intersection instead of a house
number can be entered (
page 141).
Entry of both is not possible.

143 Navigation*
Destination entry
Enter house number menu

Use , , , , + or ( to
select the numbers. Press  after
each selection;
or

Press3 - " to enter the numbers.

Press the
Delete
soft key if necessary.
The number last accepted by the sys-
tem is deleted.

Press and hold  for approx. 2 sec-
onds to confirm the input;
or

Useor  to select the sym-
bol and press.
The house number list appears. Now a
house number range can be selected.
iThe
Hse. no.
soft key is only available
when registered house numbers are
stored on the navigation DVD for the
selected street.
iDo not confuse the
Delete
soft key (de-
letion of the last number) with the
Back

soft key (deletion of the complete en-
try).
iThe symbol can only be selected if
the system has recognized the house
number.
ok
ok

144 Navigation*Destination entrySelecting a house number range
Use  or to select the desired
range of house numbers.
The
Page
soft keys allow scrolling
through the list page by page.

Press .
The Start Route Guidance menu
(page 150) appears.

Press%;
or

Press the
Map
soft key if it appears in a
menu.
The map appears in full-screen display.
1Symbol = current position

If the soft key displays are hidden,
press any soft key.
The soft key displays appear.
Selectable soft keys

Coord.
soft key
Allows entering a destination via geo
coordinates (
page 146),

Memory
soft key
The current location is stored
(
page 148),
Entering a destination using the map
iIf no soft key is selected within
approx. 8 seconds, the soft key dis-
plays will disappear.

145 Navigation*
Destination entry

Display
soft key
You can select which POIs will appear
as symbols on the map (
page 166).

soft key
The map scale will change to display a
more detailed map,

soft key
The map scale will change to display a
map that shows a wider area.Moving the map and selecting a desti-
nation

Move the cursor using, , ,
, + or ( to select the desired
destination.

Release the buttons.
If the system finds a street name at the
location the cursor is pointing to, the
corresponding street name is shown in
the status bar.
In this example:
WATER ST
iThe
Coord.
, Memory
and
Display
soft key
are visible only if the map has been
called up using%.
iThe destination selection will be lost
when pressing the
Back
soft key.
The system reverses to the details of
the previously entered destination.
To store the destination selection,
press the
Memory
soft key. For details on
storing map locations (
page 148).
