Starting Your Mystique
51
*
[ST11700(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
*
[ST11800(ALL)03/95]
If your engine cranks but does not start after a collision or
substantial jolt:
*
[ST11900(ALL)04/95]1.
Turn the ignition key to the OFF position.
*
[ST12000(ALL)03/95]2.
Check under the vehicle for leaking fuel.
*
[ST12050(ALL)03/95]3.
If you do not see or smell fuel, push the red reset button
down. If the button is already set, you may have a different
mechanical problem.
*
[ST12100(ALL)03/95]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ST12150(ALL)03/95]5.
Check under the vehicle again for leaking fuel.If you see or
smell fuel, do not start your vehicle again.If you do not
see or smell fuel, you can try to start your vehicle again.
*
[ST12175(ALL)03/95]6.
Check all vehicle warning lights before driving the vehicle.
File:cdstz.ex
Update:Fri Feb 23 11:08:15 1996

60
*
[LG07650(ALL)03/95]
Check Engine Warning Light
*
[LG07750(ALL)05/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
*
[LG07800(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
[LG07850(ALL)03/95]
6 pica art:0000640-B*
[LG07900(ALL)05/95]
This light comes on briefly when you turn the ignition to the
ON position, but should turn off when the engine starts. If the
light does not come on when you turn the ignition to the ON
position or if it comes on and stays on when you are driving,
have your vehicle serviced as soon as possible. This indicates a
possible problem with one of the engine's emission control
systems.You do not need to have your vehicle towed in.
*
[LG07950(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
File:cdlgz.ex
Update:Fri Feb 23 11:08:00 1996

67
Instrument Panel Controls
*
[IP00310(ALL)01/95]
The instrument panel (dashboard) on your vehicle is divided
into several different sections. The illustrations on the following
pages show the major parts of the instrument panel that are
described in this chapter. Some items shown may not be on all
vehicles.
[IP00400(ALL)05/95]
The main controls for the climate control system, clock, and
radio are on the instrument panel.
*
[IP00420(ALL)03/95]
Clean the instrument panel lens and woodtone trim with a soft
cloth and a glass cleaner. Do not use paper towel or any
abrasive cleaner to clean either the lens or the woodtone trim as
these may cause scratches.
%*
[IP00430(ALL)05/95]
NOTE: Any cleaner or polish that increases the gloss (shine)
of the upper part of the instrument panel should be
avoided. The dull finish in this area is to help protect
the driver from undesirable windshield reflection.
File:cdipz.ex
Update:Fri Feb 23 11:07:15 1996

76
%*
[IP24700( Z)05/95]
Cleaning the Exterior Lamps
[IP25000(ALL)01/95]
10-1/2 pica
art:0001186-D
Turning on the high beams
[IP25100(ALL)05/95]
To change the headlamps from low to high beam, push the
lever away from you until it latches, and release. The high beam
indicator in the instrument cluster glows when the headlamps
are on high beam. To change the headlamps from high beam to
low beam, pull the lever toward you until it latches.
*
[IP25200(ALL)04/95]
Fog Lamps (If equipped)
[IP25220(ALL)05/94]
The fog lamps act as a supplement to the low beam headlamps
under limited visibility conditions such as rain, snow, dust or
fog.
[IP25300(ALL)05/94]
The fog lamps operate only when the low beam headlamps are
on. To operate the fog lamps, turn the headlamp control knob
to the second position (headlamps on) and pull the knob out.
An indicator lamp will glow when the fog lamps are on.
[IP25325(ALL)02/94]
To turn off, push the headlamp control knob in.
*
[IP25401(ALL)02/93]
To maximize fog lamp bulb life it is recommended that the fog
lamp switch be turned off after each use prior to turning off the
headlamps.
File:cdipz.ex
Update:Fri Feb 23 11:07:15 1996

Instrument Panel Controls
77
*
[IP25605(ALL)01/95]
Daytime Running Light System
*
[IP25610(ALL)03/95]
(Canadian vehicles only)
*
[IP25615(ALL)03/95]
The Daytime Running Light (DRL) system is designed to turn
the high beam headlamps on, with a reduced light output and
without illuminating the high beam indicator lamp in the
instrument panel. The DRL system operates when all of the
following conditions are met:
*
[IP25620(ALL)03/95]
n
The vehicle is ªrunning.º
*
[IP25630(ALL)03/95]
n
The headlamp system is in the OFF position.
*
[IP25632(ALL)05/95]
The high beam indicator light on the instrument cluster will not
be on.
[IP25633(ALL)05/94]
A flashing high beam light in the instrument cluster indicates a
failure in the DRL system circuit, like a burnt bulb or fuse.
*
[IP25638(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
[IP25700(ALL)06/95]
Cleaning the Exterior Lamps
*
[IP25800(ALL)05/95]
Do not use dry paper towel, chemical solvents or abrasive
cleaners to clean the lamps, as these may cause scratches or
crack the lamps.
*
[IP29800(ALL)01/95]
Lighting Up the Interior and Instrument Panel
[IP29850(ALL)05/94]
When either front door is opened, the footwell lights and the
door courtesy lights come on.
[IP29900(ALL)05/94]
The instrument panel lights, window control lights and door
handle lights come on whenever the headlamp switch is turned
from the OFF position. To dim the instrument panel lights, use
the thumbwheel on the instrument panel to the right of the
steering wheel.
File:cdipz.ex
Update:Fri Feb 23 11:07:15 1996

82
*
[SC02800(ALL)05/95]
High Beams and Flashing the Lamps
[SC02900(ALL)05/95]
To turn on the high beams, turn the headlamp control knob to
the headlamp ON position and push the turn signal lever away
from you until it latches. When the high beams are on, the high
beam indicator light on the instrument cluster comes on.
[SC03000(ALL)10/93]
To turn off the high beams, pull the lever back to the off
position.
*
[SC03400(ALL)06/95]
To flash the headlamps, pull the lever toward you for a moment
and then release it. The headlamps will flash whether the
headlamp knob is in the on or off position.
*
[SC03700(ALL)03/95]
Windshield Wipers and Washer
*
[SC03800(ALL)03/95]
To turn on the windshield wipers, the ignition key must be
turned to the ON or ACC position.
[SC04400(ALL)05/95]
10-1/2 pica
art:0001189-D
Using the windshield wiper
[SC04500(ALL)02/94]
The windshield wipers can be set on high, low speed or interval
wipe. Turn the ring on the lever to set a longer or shorter pause
between wiping cycles.
File:cdscz.ex
Update:Fri Feb 23 11:06:33 1996

92
[FV01240(ALL)01/95]
Find the lever at the black label with word LOCKED in white
letters. Move the lever toward the inside of the door.
*
[FV01260(ALL)03/95]
To release the childproof lock, open the rear door from the
outside.
[FV01280(ALL)01/95]
Move the lever toward the outside of the door.
*
[FV01300(ALL)04/95]
Power Door Locks (If equipped)
[FV01400(ALL)01/95]
If your vehicle has power door locks, the controls to lock the
doors are on the trim panel of the front door. When you close
the doors after you set the door locks, the doors remain locked.
If the power mechanism fails, the manual door lock will
automatically override the power controls.
[FV01500(ALL)05/94]
10-1/2 pica
art:0001250-B
The power door lock on the driver's door
%*
[FV01530(ALL)01/95]
Using the Illuminated Entry System (If equipped)
[FV01560(ALL)05/95]
If your vehicle is equipped with the illuminated entry system,
the interior lights turn on when you lift the outside door handle
on either front door.
[FV01590(ALL)01/95]
These lights automatically turn off after 12 seconds or when you
turn the ignition key to ON or ACC. The inside lights will not
File:cdfvz.ex
Update:Fri Feb 23 11:06:10 1996

Features
95
*
[FV03300(ALL)11/93]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
[FV03400(ALL)05/94]
7-1/2 pica art:0001315-A
Replacing the batteries
*
[FV03500(ALL)02/95]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
%*
[FV03600(ALL)02/95]
Replacement/additional transmitters
*
[FV03700(ALL)02/95]
In the event a transmitter is lost, return the remaining
transmitters to your dealer for reprogramming of your remote
entry system. This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV03800(ALL)02/95]
Additional transmitters may be purchased from your dealer
(remote entry system will work with up to four transmitters).
Return your existing transmitters to your dealer so the remote
entry system can be reprogrammed with your new and existing
transmitters.
File:cdfvz.ex
Update:Fri Feb 23 11:06:10 1996

Features
99
[FV10100(ALL)11/93]
7-1/2 pica art:0001188-A
The moon roof
*
[FV10150(ALL)01/95]
RWARNING
Do not let children play with the moon roof. They may
seriously hurt themselves.
*
[FV10200(ALL)01/95]
Sliding Shade
*
[FV10300(ALL)01/95]
The moon roof has a sliding shade that you can manually open
or close to block the sun when the glass panel is shut.
[FV10400(ALL)05/95]
To close the sliding shade, pull the shade toward the front of
the vehicle. The shade automatically opens when the moon roof
is opened.
*
[FV10500(ALL)01/95]
Seats
*
[FV10525(ALL)04/95]
Head Restraints
*
[FV10600(ALL)04/95]
If you use them properly, head restraints will help protect your
head and neck in a collision.
*
[FV10700(ALL)05/95]
A head restraint helps protect you best if you position it behind
your head and not behind your neck.
[FV10750(ALL)05/95]
If your vehicle has the four-way head restraint, you can adjust it
in four directions. You can raise it two (2) inches (50 mm) from
its normal position, or you can move it forward up to 60Ê until
you reach the desired position.
File:cdfvz.ex
Update:Fri Feb 23 11:06:10 1996

Features
109
*
[FV17000(ALL)01/95]
Storage Compartments
[FV17100(ALL)01/95]
Your vehicle may have several storage compartments:
[FV17201(ALL)01/95]
n
two map pockets on the panels of the front doors. The back
of the front seats may also have map pockets.
[FV17301(ALL)01/95]
n
a coin holder on the instrument panel
[FV17401( Z)01/95]
n
a stowage compartment on the lower left side of the
instrument panel
[FV17501(ALL)01/95]
n
a small storage pocket on the outside of the front seat base
*
[FV17800(ALL)01/95]
Trunk
[FV17900(ALL)11/93]
To open the trunk manually, use the oval key.
[FV18000(ALL)01/95]
Remote Trunk Release (If equipped)
[FV18100(ALL)05/94]
The remote trunk release is on the floor to the left of the
driver's seat.
[FV18200(ALL)05/94]
7-1/2 pica art:0000984-E
The remote trunk release
[FV18300(ALL)05/94]
You can disable the remote trunk release. If you depress the
lever on the trunk latch that is marked in orange before closing
the trunk, the trunk can only be opened with the key.
File:cdfvz.ex
Update:Fri Feb 23 11:06:10 1996
