Mercury Mystique 2000 s Owner's Guide
Manufacturer: MERCURY, Model Year: 2000, Model line: Mystique, Model: Mercury Mystique 2000Pages: 248, PDF Size: 2.2 MB
Page 31 of 248
Controls and features
31 • PNL/FLR – Distributes outside
air through the instrument panel
registers and the floor ducts.
However, the air will not be cooled
below the outside temperature
because the air conditioning does
not operate in this mode. For
added customer comfort, when the
temperature control knob is
anywhere in between the full hot
and full cold positions, the air
distributed through the floor ducts
will be slightly warmer than the air
sent to the instrument panel
registers.
• FLOOR – Allows for maximum
heating by distributing outside air
through the floor ducts. However,
the air will not be cooled below the
outside temperature because the
air conditioning does not operate in
this mode.
• FLR/DEF – Distributes outside
air through the windshield
defroster ducts and the floor ducts.
Heating and air conditioning
capabilities are provided in this
mode. For added customer
comfort, the air distributed through
the floor ducts will be slightly
warmer than the air sent to the
windshield defroster ducts. If the
temperature is about 10°C (50°F)
or higher, the air conditioner will
automatically dehumidify the air to
reduce fogging.
13MCfen 24.6.99 15:05 Uhr Seite 31
Page 32 of 248
Controls and features
32• DEF – Distributes outside air
through the windshield defroster
ducts. It can be used to clear ice or
fog from the windshield. If the
temperature is about 10°C (50°F)
or higher, the air conditioner will
automatically dehumidify the air to
reduce fogging.
Operating tips
• In humid weather, select DEF
before driving. This will reduce
fogging on your windshield. After a
few minutes, select any desired
position.
• To reduce humidity buildup
inside the vehicle, don’t drive with
the climate control system in the
OFF position.
• Don’t put objects under the front
seat that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves
from the air intake area (at the
bottom of the windshield under the
hood).
• If your vehicle has been parked
with the windows closed during hot
weather, the air conditioner will do
a much faster job of cooling if you
drive for two or three minutes with
the windows open. This will force
most of the hot, stale air out of the
vehicle. Then operate your air
conditioner as you would normally.
13MCfen 24.6.99 15:05 Uhr Seite 32
Page 33 of 248
Controls and features
33 Cabin air filter
Your vehicle is equipped with an air
filter that removes pollen and road
dust from outside air before it is
directed to the interior of the
vehicle. Refer to the Maintenance
and carechapter for maintenance
of this filter. • Do not place objects over the
defroster outlets. These objects
can block airflow and reduce your
ability to see through your
windshield. Also, avoid placing
small objects on top of your
instrument panel. These objects
can fall down into the defroster
outlets and block airflow and
possibly damage your climate
control system.
13MCfen 24.6.99 15:05 Uhr Seite 33
Page 34 of 248
Controls and features
34
MIRRORS
OFF LO PNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWER AUDIO AM/FM
SCAN
SEEK 31245ANSSIDE 1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH20 406055
80120 10 0
14 0
160
18 0
200EF12
03
x 1000
4
5
6
7
8
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
CLOCK
TRACTION
TROL
CH
AUDIO SYSTEMS
Compact disc radio
13MCfen 24.6.99 15:05 Uhr Seite 34
Page 35 of 248
Controls and features
35
Electronic stereo radio with cassette
Electronic stereo radio
13MCfen 24.6.99 15:05 Uhr Seite 35
Page 36 of 248
Controls and features
36
SIDE 1-2
13MCfen 24.6.99 15:05 Uhr Seite 36
Page 37 of 248
Controls and features
37
SIDE 1-2
1-2
SIDE
13MCfen 24.6.99 15:05 Uhr Seite 37
Page 38 of 248
Controls and features
38Power control
Press the control to turn the audio
system on or off.
Volume control
Press the control to raise or lower
volume.
If the volume is set above a certain
level and the ignition is turned off,
the volume will come back on at a
“nominal” listening level when the
ignition switch is turned back on.
AM/FM select
The AM/FM select control works in
radio mode and allows you to select
AM or FM frequency bands.
Press the control to switch
between AM, FM1 or FM2 memory
preset stations.
Tune adjust
The tune control works in radio
mode.
13MCfen 24.6.99 15:06 Uhr Seite 38
Page 39 of 248
Controls and features
39
The tune adjust with electronic
stereo radio
• Press (–) to move to the next
frequency down the band (whether
or not a listenable station is located
there). Hold the control to move
through the frequencies quickly.
• Press (+) to move to the next
frequency up the band (whether or
not a listenable station is located
there). Hold for quick movement.
Tune adjust with compact disc
radio
• Press the SCAN/TUNE control
twice.
• Within approximately five
seconds press and release either
or on the SEEK button to
change to the next frequency up or
down.
• Press and hold down or to
quickly move through the
frequencies.
Tune adjust with electronic
stereo cassette radio
• Press the AMS control.
13MCfen 24.6.99 15:06 Uhr Seite 39
Page 40 of 248
Controls and features
40
• Within approximately five
seconds, press and release either
or on the SEEK control to
change to the next frequency up or
down.
• Press and hold down or to
quickly move through the
frequencies.
Seek function
The seek function control works in
radio or tape mode.
Seek function in radio mode
• Press to find the next
listenable station down the
frequency band.
• Press to find the next
listenable station up the frequency
band.
Seek function in tape mode
• Press the AMS control.
• Press to listen to the
previous selection on the tape.
• Press to listen to the next
selection on the tape.
13MCfen 24.6.99 15:06 Uhr Seite 40
