ESP Mercury Villager 1996 Owner's Manuals

2
*
[IN01630(ALL)04/95]
n
Continuous improvement is essential to our success.We
must strive for excellence in everything we do: in our
products Ð in their safety and value Ð and in our services,
our human relations, our competitiveness, and our
profitability.
*
[IN01635(ALL)04/95]
n
Employee involvement is our way of life. We are a team.
We must treat one another with trust and respect.
*
[IN01640(ALL)04/95]
n
Dealers and suppliers are our partners.We must maintain
mutually beneficial relationships with dealers, suppliers, and
our other business associates.
*
[IN01645(ALL)04/95]
n
Integrity is never compromised.Our conduct worldwide
must be pursued in a manner that is socially responsible and
commands respect for its integrity and for its positive
contributions to society.
*
[IN01650(ALL)08/95]
Things to Know About Using This Guide
*
[IN01655(ALL)08/95]
Congratulations on the purchase of your new vehicle. This
guide has information about the equipment and the options for
your new vehicle. You may not have bought all of the options
available to you. If you do not know which information applies
to your vehicle, talk to your dealer.
*
[IN01660(ALL)08/95]
This guide describes equipment and gives specifications for
equipment that was in effect when this guide was approved for
printing. Ford may discontinue models or change specifications
or design without any notice and without incurring obligation.
*
[IN01665(ALL)07/95]
NOTES and WARNINGS
*
[IN01666(ALL)05/95]
NOTESgive you additional information about the subject
matter you are referencing.
*
[IN01667(ALL)05/95]
WARNINGSremind you to be especially careful in those areas
where carelessness can cause damage to your vehicle or
personal injury to yourself, your passengers or other people.
Please read allWARNINGScarefully.
File:02vxinn.ex
Update:Mon Jun 3 08:15:32 1996

4
[IN02900(ALL)01/93]
Warranties
*
[IN03000(ALL)04/95]
Your vehicle is covered by three types of warranties:Basic
Vehicle Warranty,Extended Warrantieson certain parts, and
Emissions Warranties.
%*
[IN03400(ALL)03/95]
Read yourWarranty Information Bookletcarefully to find out
about your vehicle's warranties and your basic rights and
responsibilities.
*
[IN03600(ALL)03/95]
If you lose yourWarranty Information Booklet,you can get a new
one free of charge. Contact any Ford or Lincoln-Mercury dealer,
or refer to the addresses and phone numbers on the first page
of this owner guide.
[IN04300(ALL)01/93]
Ford's Extended Service Plan (ESPH)
[IN04400(ALL)05/96]
More Protection for Your Vehicle
[IN04425(ALL)05/96]
You can get more protection for your new car or light truck by
purchasing a Ford Extended Service Plan (Ford ESP). Ford ESP
is the only extended service program with the Ford name on it
and the only service contract backed by Ford Motor Company.
[IN04450(ALL)05/96]
Ford ESP is an optional service contract, backed and
administered by Ford. It provides:
[IN04475(ALL)05/96]
n
protection against repair costs after your Bumper to Bumper
Warranty expires;
[IN04500(ALL)05/96]
and
[IN04525(ALL)05/96]
n
other benefits during the warranty period (such as:
reimbursement for rentals; coverage for certain maintenance
and wear items).
[IN04550(ALL)05/96]
You may purchase Ford ESP from any participating Ford Motor
Company dealer. There are several Ford ESP plans available in
various time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including reimbursement
benefits for towing and rental. (In Hawaii, rules vary. See your
dealer for details.)
File:02vxinn.ex
Update:Mon Jun 3 08:15:32 1996

Introductory Information
5
[IN04575(ALL)05/96]
When you purchase Ford ESP, you receive peace-of-mind
protection throughout the United States and Canada, provided
by a network of more than 5,100 participating Ford Motor
Company dealers.
[IN04600(ALL)05/96]
NOTE: Repairs performed outside the United States and
Canada are not eligible for ESP coverage.
[IN04700(ALL)05/96]
This information is subject to change. Ask your dealer for
complete details about Ford ESP coverage.
[IN05500(ALL)01/93]
Break-In Period for Your Villager
[IN05600(ALL)02/95]
Your new vehicle will go through an adjustment or break-in
period during the first 1,000 miles (1,600 km) of driving. During
the break-in period, you need to pay careful attention to how
you drive your vehicle.
[IN05700(ALL)01/93]
n
Change your speed often as you drive.Do not drive at one
speed for a long time.
%*
[IN05800(ALL)01/95]
n
Use only the type of engine oil that Ford recommends.See
Engine oil recommendationsin the Index. Do not use special
ªbreak-inº oils.
%*
[IN05900(ALL)01/95]
n
Avoid sudden stops.Because your vehicle has new brake
linings, you should take these steps:
*
[IN06000(ALL)01/95]
Ð Watch traffic carefully so that you can anticipate when to stop.
*
[IN06100(ALL)01/95]
Ð Begin braking well in advance.
*
[IN06200(ALL)01/95]
Ð Apply the brakes gradually.
[IN06300(ALL)05/93]
The break-in period for new brake linings lasts for 100 miles
(160 km) of city driving or 1,000 miles (1,600 km) of highway
driving.
File:02vxinn.ex
Update:Mon Jun 3 08:15:32 1996

6
[IN07100(ALL)04/95]
Cleaning the Outside of Your Villager
%*
[IN07200(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300(ALL)04/95]
Wash the outside of your vehicle, including the underside, with
a mild detergent.
*
[IN07400(ALL)06/95]
DO NOT:
*
[IN07500(ALL)04/95]
n
Wash your vehicle with hot water
*
[IN07600(ALL)04/95]
n
Wash your vehicle while it sits in direct sunlight
*
[IN07700(ALL)04/95]
n
Wash your vehicle while the body is hot
*
[IN07800(ALL)07/95]
Pollen, bird droppings and tree sap can damage the paint,
especially in hot weather. Wash your vehicle as often as
necessary to keep it clean.
*
[IN07900(ALL)07/95]
Take similar precautions if your vehicle is exposed to chemical
industrial fallout.
*
[IN08000(ALL)08/95]
Paint damage resulting from fallout is not related to a defect in
paint materials or workmanship and therefore, is not covered by
warranty. Ford, however, believes that continual improvement
in customer satisfaction is a high priority. For this reason, Ford
has authorized their dealers to repair, at no charge to the
owner, the surfaces of new vehicles damaged by environmental
fallout within 12 months or 12,000 miles (20,000 km) of
purchase, whichever comes first. Customers may be required to
bring their vehicle in for inspection by a Ford representative.
*
[IN08100(ALL)04/95]
Polish your vehicle to remove harmful deposits and protect the
finish.
File:02vxinn.ex
Update:Mon Jun 3 08:15:32 1996

Safety Restraints
25
*
[SR13301(ALL)08/95]
RWARNING
If a passenger is not properly seated and restrained, an
inflating air bag could cause serious injury.
*
[SR13302(ALL)09/95]
RWARNING
Rear-facing infant seats should never be placed in the
front seat.
*
[SR13303(ALL)07/95]
In rear-facing infant seats, the infant's head is closer to the air
bag. The force of the rapidly inflating air bag could push the
top of the rear-facing seat against the vehicle seatback or center
armrests (if so equipped), or center console (if so equipped).
REAR-FACING INFANT CARRIERS MUST ALWAYS BE
SECURED IN THE REAR SEAT, and other child safety seats
and infant seats should be secured in the rear seat whenever
possible.
*
[SR13304(ALL)07/95]
Your vehicle is equipped with a right front passenger air bag.
Air bags deploy with great force, faster than the blink of an eye.
Front passengers, especially children and small adults, must
never sit on the front edge of the seat, stand near the glove
compartment of the instrument panel, or lean over near the air
bag cover when the vehicle is moving. All occupants should sit
with their backs against the seatback, move the seat to the most
rearward position if possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should use child or
infant seats.
%*
[SR13305(ALL)07/95]
RWARNING
When using forward-facing child seats move the
passenger seat as far back from the instrument panel as
possible. NEVER SECURE REAR-FACING INFANT
SEATS IN THE FRONT SEAT.
File:03vxsrn.ex
Update:Wed Jun 5 12:21:10 1996

26
*
[SR13306(ALL)11/95]
The force of the rapidly inflating passenger air bag could push
the top of the rear-facing seat against the vehicle seatback,
armrests or console. Rear-facing infant seats must always be
secured in the rear seat.
*
[SR13307(ALL)07/95]
RWARNING
Do not place objects or mount equipment on or near the
air bag cover on the steering wheel or in front seat areas
that may come in contact with a deploying air bag.
Failure to follow this instruction may increase the risk of
personal injury in the event of a collision.
*
[SR13308(ALL)07/95]
For further information about the proper mounting of
equipment in the front seat of this vehicle, please refer to Ford's
brochure entitledSome Important Information About Air Bag
Supplemental Restraint Systemwhich can be obtained by calling
Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
*
[SR13309(ALL)08/95]
For additional important safety information on the proper use of
seat belts, child seats, and infant seats, please read the other
sections of this chapter of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats for Children.
%*
[SR13310(ALL)01/95]
How the Air Bag Supplemental Restraint System
Operates
*
[SR13315(ALL)06/95]
The Air Bag Supplemental Restraint System consists of the
driver and passenger air bags, impact sensors, a system
diagnostic module, a readiness light and tone, and the electrical
wiring which connects the components.
*
[SR13320(ALL)06/95]
The driver air bag is in the center of the steering wheel. The
front passenger seat air bag is located in the center of the
instrument panel ledge above the glove compartment. Both air
bags are designed to stay out of sight until they are activated.
File:03vxsrn.ex
Update:Wed Jun 5 12:21:10 1996

62
*
[ST08200(ALL)05/95]
A computer system controls the engine's idle speed. When you
start your vehicle, the engine's idle speed normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than its normal idle speed. It should, however, slow down
after a short time. If it does not, have the idle speed checked.
*
[ST08290(ALL)06/95]
If the engine idle speed does not slow down automatically, do
not allow your vehicle to idle for more than 10 minutes. Have
the vehicle checked.
*
[ST08300(ALL)05/95]
RWARNING
Extended idling at high engine speeds can produce very
high temperatures in the engine and exhaust system,
creating the risk of fire or other damage.
*
[ST08400(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
*
[ST08500(ALL)03/95]
If you consistently start your vehicle in subzero temperatures,
use an engine block heater (if your vehicle has this option).
%*
[ST08600(ALL)06/95]
Engine Block Heater (If equipped)
[ST08700(ALL)02/95]
Engine block heaters are strongly recommended if you live in a
region where temperatures reachs10ÊF (s23ÊC) orbelow. An
engine block heater warms the engine coolant, which improves
starting, warms up the engine faster, and allows the
heater-defrost system to respond more quickly.
*
[ST08900(ALL)05/95]
RWARNING
To prevent electrical shock, do not use your heater with
ungrounded electrical systems or two-pronged (cheater)
adapters.
File:04vxstn.ex
Update:Mon Jun 3 08:20:06 1996

Instrument Panel Controls
101
[IP10000(ALL)06/95]
Rear Passenger Compartment Climate Control System
for Vehicles with Non-Automatic Temperature Control
Systems (If equipped)
[IP10100(ALL)04/95]
If your vehicle is equipped with rear passenger compartment
climate controls, the rear seat occupants can select their own
personal climate comfort level.
[IP10150(ALL)04/95]
The rear seat climate control system is controlled from the main
climate control system on the instrument panel. If the main
system is off, the rear system will also be off. If the rear
passenger compartment climate control lever is set in OFF, the
rear climate controls are turned off. If the lever is set in any of
the fan speed positions (1-4), air will be discharged from the
rear seat vents at the corresponding speed. However, when the
lever is set at REAR, rear seat passengers can control their own
fan speed.
[IP10200(ALL)04/95]
The rear passenger compartment climate control system has a
fan speed knob which controls the speed at which air is
discharged from the vents. The vent selection switch determines
whether the air is discharged from the upper vents or the lower
(floor) vents. The temperature control knob controls the air
temperature.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996

Instrument Panel Controls
109
[IP10640(ALL)06/95]
If the rear seat climate control lever is set in any of the fan
speed positions (1-4), air will be discharged from the rear seat
vents at the corresponding speed. Rear seat passengers can
choose airflow to be distributed out of the upper or lower vents
by using the vent selection switch on the rear climate control
panel. The air temperature from the rear climate control system
will be automatically controlled by the front ATC system. Rear
seat passengers cannot control fan speed or air temperature by
using the temperature control knobs on the rear climate control
panel.
[IP10650(ALL)06/95]
If the rear seat climate control lever is set in the REAR position,
the front ATC system will not control the rear climate control
system. Rear seat passengers can control fan speed, upper or
lower air distribution, and temperature control from the rear
system by using the rear climate controls.
[IP10660(ALL)06/95]
13-1/2 pica
art:0040079-A
Rear seat climate control system panel
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996

123
Steering Column Controls
*
[SC00900(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[SC01000(ALL)01/93]
Turn Signal Lever
*
[SC01100(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC01200(ALL)01/93]
n
operate the turn signals.
*
[SC01300(ALL)01/93]
n
turn the headlamps to high beam.
*
[SC01400(ALL)01/93]
n
flash the headlamps.
*
[SC01500(ALL)01/93]
n
turn the windshield wipers and washer on/off.
*
[SC01600(ALL)01/95]
Turn Signals
[SC01700(ALL)02/95]
Move the lever up to signal a right turn. Move it down to
signal a left turn. The corresponding indicator light in the
instrument cluster will flash.
*
[SC01900(ALL)11/93]
7-1/2 pica art:0040085-D
The turn signal lever
[SC02000(ALL)02/95]
If the turn signal stays on after you turn, move the lever back
to the center (off) position.
[SC02100(ALL)02/95]
For lane changes, move the lever far enough to signal but not to
latch. The lever will return to the off position when you release
it.
File:07vxscn.ex
Update:Mon Jun 3 14:47:35 1996
