alternator MITSUBISHI LANCER EVOLUTION X 2008 Workshop Manual

16-1
GROUP 16
ENGINE
ELECTRICAL
CONTENTS
STARTER MOTOR . . . . . . . . . . . . . .16-2
ALTERNATOR . . . . . . . . . . . . . . . . . .16-2
IGNITION COIL . . . . . . . . . . . . . . . . . .16-2
SPARK PLUG . . . . . . . . . . . . . . . . . . .16-3

STARTER MOTOR
ENGINE ELECTRICAL16-2
STARTER MOTORM2161002000160
The starter motor is a reduction drive planetary gear type.
ALTERNATORM2162001000126
The alternator is a battery detection type.
It uses a pulley with a one-way clutch.
IGNITION COILM2163001000174
The ignition coil is a plug-top type.
AK603841
AK603842
AK602597
Plug boots
Rain cover Coil
AC

SENSOR
MULTIPORT FUEL SYSTEM (MFI)13A-21
.
GENERATOR FR TERMINAL
Generator turns ON/OFF the power transistor in the voltage
regulator to adjust current flow in the field coil according to
alternator output current. In this way generator's output voltage
is kept adjusted (to about 14.7 V). The ratio of power transistor
ON time (ON duty) is output from generator FR terminal to
ECM. ECM uses this signal to detect generator's output current
and drives throttle actuator control motor according to output
current (electric load). This prevents change in idle speed due
to electric load and helps maintain stable idle speed.
.
AK602229AD
FR BS
Field coil
IC regulator
GeneratorIgnition switch-IG
Battery
ECM
