ON-VEHICLE SERVICE
ENGINE COOLING14-21
ON-VEHICLE SERVICE
ENGINE COOLANT LEAK CHECKM1141001000300
WARNING
When pressure testing the cooling system,
slowly release cooling system pressure to
avoid getting burned by hot coolant.
CAUTION
•Be sure to completely clean away any mois-
ture from the places checked.
•When the tester is taken out, be careful not to
spill any coolant.
•
ACX01844
Cap adapter
Adapter
AC
Be careful when installing and removing the
tester and when testing not to deform the
filler neck of the radiator.
1. Check that the coolant leve l is up to the filler neck.
Install a radiator tester and apply 160 kPa
pressure, and then check for leakage from the
radiator hose or connections.
2. If there is leakage, repair or replace the
appropriate part.
RADIATOR CAP VALVE OPENING
PRESSURE CHECK
M1141001300389
NOTE: Be sure that the cap is clean before test-
ing. Rust or other foreign material on the cap seal
will cause an improper reading.
AC211643AB
Cap adapter
1. Use a cap adapter to attach the cap to the tester.
2. Increase the pressure until the indicator of the gauge stops moving.
Minimum limit: 83 kPa
Standard value: 93 − 123 kPa
3. Replace the radiator cap if the reading does not remain at or above the limit.
ENGINE COOLANT REPLACEMENT
M1141001200434
WARNING
When removing the radiator cap, use care to
avoid contact with hot coolant or steam.
Place a shop towel over the cap and turn the
cap counterclockwise a little to let the pres
-
sure escape through the vinyl tube. After
relieving the steam pres sure, remove the cap
by slowly turning it counterclockwise.
1. Drain the water from the radiator, heater core and
engine after unplugging the radiator drain plug
and removing the radiator cap.
AC208283AC
Cylinder block
drain plug
<4G1>
Inlet side
AC303355
<4G6>
Inlet side
Cylinder block
drain plug
AB
2. Drain the water in the water jacket by unplugging the drain plug of the cylinder block.
3. Remove the radiator condenser tank and drain
the coolant.
4. Drain the coolant then clean the path of the coolant by injecting water into the radiator from
the radiator cap area.

CHARGING SYSTEM
ENGINE ELECTRICAL16-5
OUTPUT CURRENT TEST
M1161001000368
AK203362
Alternator
Ammeter
(clamp-type)
Voltmeter
Battery
Inition switch
Engine-ECU
or
Engine-A/T-ECU
Load
B FR
L
S
G
+
AH
–
Charging indicator
Brake warning light
This test determine s whethe r the a l terna t or outp u t
curren
t is normal.
1.Befo re the t e st, always be sure t o che c k the
fo llowi ng.
•Alternator inst allatio n
•Battery (Refer to GROUP 54 A − Battery − On-vehi-
cle Serv ice P.54A-5).
NOTE: The battery sh ould be sligh t ly discharg ed.
The
load neede d by a fully-charge d batte ry is
in
sufficient for an accurat e test.
•Drive belt tension
(Ref er to GROUP 1 1 A − On-vehicle Service <4G1>
P.11A-7 or GROUP 1 1 C − On-vehicle Se rvice
<4G6> P.11C-7.)
•Fusible link
• Abnormal noise from the altern ator while the
eng
ine is ru nning .
2.T u rn the ignition switch to the "LOCK" (OFF)
po sit i on.
3.Disco nnect the ne gative ba ttery cable.
CAUTION
Never use clips but tighten bolts and nuts to con-
nect the line. Otherwise loose connections (e.g.
using clips) will lead to a serious accident
because of high current.
4. Connect a clamp-type DC test ammeter with a
range of 0
− 120 A to the alternator "B" terminal
output wire.
NOTE: The way of disconnecting the alternator
output wire and of connecting the ammeter is pos
-
sibly not found the problem that the output current
is dropping due to the insufficient connection
between terminal "B" and the output wire.
5. Connect a voltmeter with a range of 0 − 20 V
between the alternator "B" terminal and the earth
[Connect the (+) lead of the voltmeter to the "B"
terminal, and then con nect the (-) lead of the
voltmeter to the earth].
6. Connect the negative battery cable.
7. Connect a tachometer or the M.U.T.-II/III (Refer to GROUP 11A
− On-vehicle Service − Idle speed
check <4G1>
P.11A-11 or GROUP 11C −
On-vehicle Service − Idle speed check <4G6>
P.11C-11).
8. Leave the hood open.

ON-VEHICLE SERVICE
WHEEL AND TYRE31-7
ON-VEHICLE SERVICE
TYRE INFLATION PRESSURE CHECKM1311000900312
NOTE: For information on tyre inflation pressure,
refer to the label attached to the centre pillar on the
driver's side.
TYRE WEAR CHECK
M1311001000334
Measure the tread depth of the tyres.
Minimum limit: 1.6 mm
If the remaining tread depth is less than the minimum
limit, replace the tyre.
NOTE: When the tread depth of the tyres is reduced
to 1.6 mm or less, wear indicators will appear.
WHEEL RUNOUT CHECKM1311001100353
ACX00651 ABLateralRadial
Jack up
the vehicle so tha t the whe e ls are clear o f
the floor
. Wh ile slo w ly tur n ing the wheel, me asure
wh
eel ru nout wit h a dial indicator .
Limit:
ItemSt e e l wheelAluminium
whee
l
Radial runout mm1.21.0
Lateral runou t
mm1.21.0
If wheel runout exceeds the limit, rep l ace the whe e l.
WHEEL AND TYRE
INSTALLA T ION SER VICE POINTM131 1 0013 0029 4
Ti ghten the whee l nut s to the specified torq ue.
Ti ghte n ing torque: 98 ± 10 N⋅m
