Engine Compartment Relay Box On left inner fender panel,
behind battery.
Fusible Links In engine compartment
relay box.
Joint Connector (J/C) Behind left side of dash.
Page 470 of 1501
Door Lock Control Unit Behind left side of dash.
ELC 4-Speed Automatic Transmission
Control Module Behind left side of dash.
Engine Control Module (ECM) Behind right kick panel.
Keyless Entry Control Unit Behind right side quarter
panel.
Rear Differential Lock Control Unit Mounted on top of left rear
wheelwell.
SRS Air Bag Control Unit Behind center of dash.
Sun Roof Control Unit On center of roof, behind
sun roof.
Variable Shock Absorber Control Unit Behind left rear wheelwell,
behind quarter panel.
4WD Indicator Control Unit Behind center of dash.
\
\
\
\
\
\
\
MOTORS
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
Blower Motor Behind right side of dash.
Condenser Fan Motor On left front of engine
compartment.
Fuel Pump In fuel tank.
Headlight Washer Motor Right side of engine
compartment, in washer fluid
reservoir.
Idle Air Control Motor On throttle body.
Motor Antenna Rear of right front wheelwell.
Rear Differential Lock Air Pump On left rear of vehicle.
Rear Washer Motor In rear of cargo area.
Rear Wiper Motor On center of tailgate.
Sun Roof Motor On center of roof, behind
sun roof.
Windshield Washer Motor Bottom of windshield washer
reservoir.
Windshield Wiper Motor On left side of firewall.
\
\
\
\
\
\
\
SENDING UNITS & SENSORS
Page 471 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
Component Compo](/img/19/57333/w960_57333-470.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
Component Compo")
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
ABS Speed Sensors (4) On bracket, on each wheel hub.\
Air Inlet Sensor In evaporator air duct.
Camshaft Position Sensor At bottom of left camshaft
gear.
Crankshaft Position Sensor Above crankshaft gear.
Engine Coolant Temperature Gauge Unit On thermostat housing.
Engine Coolant Temperature Sensor On thermostat housing.
Front Impact Sensor (Left) (SRS) On left front of engine
compartment.
Front Impact Sensor (Right) (SRS) On right front of engine
compartment.
Fuel Gauge Unit In fuel tank.
Fuel Tank Differential Pressure Sensor
(Calif.) Top of fuel tank.
G-Sensor (ABS) In center console, rear of
parking brake lever.
Geomagnetic Sensor (Compass) On top center of dash.
Page 472 of 1501
Heated Oxygen Sensor (Front)
(Federal) Underside of vehicle, forward
of catalytic converter.
Heated Oxygen Sensor (Front)
(Left Bank) (Calif.) In left exhaust manifold.
Heated Oxygen Sensor (Front)
(Right Bank) (Calif.) In right exhaust manifold.
Heated Oxygen Sensor (Rear)
(Federal) Underside of vehicle, behind
catalytic converter.
Heated Oxygen Sensor (Rear) (Left Bank)
(Calif.) In left exhaust pipe, below
engine.
Heated Oxygen Sensor (Rear) (Right Bank)
(Calif.) In right exhaust pipe, below
engine.
Input Shaft Speed Sensor On side of transmission.
Intake Air Temperature Sensor Mounted on outside of
evaporator case.
Manifold Differential Pressure Sensor On top left rear of engine.
Output Shaft Speed Sensor On rear of transmission.
Page 473 of 1501
Outside Air Temperature Sensor Below left headlamp.
Park/Neutral Position Sensor On left side of transmission.
Throttle Position Sensor On throttle body.
Vehicle Speed Sensor (VSS) On transmission tailshaft.
Volume Airflow Sensor In air cleaner duct (includes
intake air temperature sensor
& barometric pressure sensor).
\
\
\
\
\
\
\
SOLENOIDS & SOLENOID VALVES
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
ABS Hydraulic Unit (w/Built-In
Solenoid Valve) In right rear corner of engine
compartment.
Cruise Control Actuator (w/Built-In
Control Valve & Release Valve)
(Calif.) In right rear of engine
compartment.
Cruise Control Actuator (w/Built-In
Control Valve & Release Valve)
(Federal) In left rear of engine
compartment.
EGR Solenoid In right rear of engine
compartment.
ELC 4-Speed Automatic Transmission
Control Solenoid Inside transmission.
Evaporative Emission Purge Solenoid On front of engine.
Evaporative Emission Ventilation
Solenoid In left rear of engine
compartment.
Solenoid Valves "A" & "B" In right side of engine
compartment.
\
\
\
\
\
\
\
SWITCHES
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
A/T Fluid Temperature Switch On left side of transmission.
Brake Fluid Level Switch In brake master cylinder
reservoir.
Center Differential Lock Detection
Switch On transfer case.
Page 474 of 1501
Center Differential Lock Operation
Detection Switch On transfer case.
Dual Pressure Switch On high pressure line, on
receiver-drier.
Engine Coolant Temperature Switch Top right front of engine.
Free Wheel Engage Switch Right side of engine
compartment.
High Range/Low Range Detection Switch On transfer case.
Low Range Operation Detection Switch On transfer case.
Oil Pressure Switch Lower left front of engine.
Parking Brake Switch At base of parking brake
lever.
Power Steering Pressure Switch On power steering pump.
Rear Differential Lock Detection
Switch Under rear of vehicle, on
differential.
Reed Switch Integral with speedometer.
Seat Belt Switch On driver-side seat belt
buckle.
Stoplight Switch On bracket, above brake pedal.
2WD/4WD Detection Switch On transfer case.
4WD Operation Detection Switch On transfer case.
\
\
\
\
\
\
\
MISCELLANEOUS
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
Amplifier Under center console, below
floor.
Data Link Connector (DLC) Behind left side of dash,
near relay box.
Page 476 of 1501
Diode (MFI System Circuit) Behind center of dash,
taped to harness.
Engine Speed Detection Connector Taped to wiring harness, on
right side of firewall.
Page 477 of 1501
Fuel Pump Check Connector Taped to wiring harness, on
right side of firewall.
Ignition Timing Adjustment
Connector Taped to wiring harness, on
right side of firewall.
Ignition Coil Top left side of engine.
Page 478 of 1501
Ignition Power Transistor Top left side of engine, next
to ignition coil.
IOD Or Storage Connector In engine compartment relay
box.
Noise Capacitor Top of engine.
Resistor On blower motor housing.
\
\
\
\
\
\
\
Page 481 of 1501
