ESP NISSAN 350Z 2005 Z33 Navigation Manual

Five types of facilities can be displayed on the
map using respective icons, including:
— ATMs
— Gas stations
— Hotels
— Restaurants
— Rest areas
1. Press the SETTING button on the control
panel.
2. Select the
Navigation key on the [SET-
TINGS] screen.3. Select the
Nearby Display Icons key on the
[NAVIGATION SETTINGS] screen.
The [NEARBY DISPLAY ICONS] screen will be
displayed.
INV1466
INV2458
SETTINGTHE NEARBY DISPLAY
ICONS
How do I use the Point of Interest (POI) feature?
6-15


04.7.6/Z33-N


WARNING
To operate the navigation system or to
use the screen functions, first park the
vehicle in a safe place and set the park-
ing brake. Using the system while driv-
ing can distract the driver and may re-
sult in a serious accident.BASICS OF VOICE GUIDANCEThe voice guidance will verbally tell you which
direction to turn when the vehicle approaches
the intersection in which you have to make a turn
to reach your destination.

There may be some cases in which the
voice guidance and the actual road con-
ditions do not correspond. This may
occur because of discrepancies be-
tween the actual road and the informa-
tion on the DVD or due to the vehicle’s
speed.

In case the content of the voice guid-
ance does not match the actual road
conditions, follow the information ob-
tained from traffic signs or notices on
the road.
ADJUSTING THE GUIDE VOLUME1. Press the SETTING button on the control
panel.
2. When turning on/off the voice guidance,
push the PUSH ENTER button. When the
Guidance Volume key is illuminated with a
green indicator, it is activated. When turning
up/down the voice guidance, touch theLouder or
Softer key. The voice will be-
come louder/softer.
DIRECTIONS GIVEN AND THE
DISTANCE TO THE ROAD POINTSDirections will differ, depending on the road
type.
INFO:
Distances may vary, depending on the vehicle
speed.NOTIFICATION OF AN
INTERSECTION ON AN ORDINARY
ROAD“In a quarter mile (400 meters), right (left) turn.”
“Right (left) turn ahead.”NOTIFICATION OF CONSECUTIVE
INTERSECTIONS ON AN
ORDINARY ROAD“In a quarter mile (400 meters), right (left) turn,
then left (right) turn.”
“Right (left) turn ahead, then left (right) turn.”NOTIFICATION OF AN ENTRANCE
TO A FREEWAY“In a quarter mile (400 meters) freeway entrance
on your right onto (road number and direction).”
INV1684
ABOUT VOICE GUIDANCE10-2
How do I use the voice guidance feature?


04.7.6/Z33-N


announce: “Please make a legal U-turn if
possible.”
The voice guidance in this system should be
regarded as a supplementary function. When
driving your vehicle, check the route on the
map display and follow the actual road and all
traffic regulations.

The voice guidance is activated only for
junctions with certain conditions. In some
cases you may need to turn, even if there is
no voice guidance.

The content of the voice guidance may vary,
depending on the direction of the turn and
the type of junction with other roads.

The route guidance will be activated at vari-
ous times depending on the situation.

When the vehicle is off the suggested route,
route guidance is not available. The system
will not inform you of this; please refer to the
map display and request rerouting.

At freeway junctions, the road numbers and
directions may not accurately correspond
with the voice guidance.

At freeway exits, the street names may not
accurately correspond with the voice guid-
ance.

The displayed street names may sometimes
differ from the actual names or “UNKNOWN
STREET NAME” may be displayed.Please refer to “Automatic rerouting” on page
9-2.

When the green indicator on the
Guidance Volume key is not illuminated,
the voice guidance is not available.

The voice guidance will start when the vehicle
enters the suggested route. Before entering
the route, refer to the map display for the
direction.

When the vehicle approaches a waypoint, the
voice will say, “You have arrived at waypoint 1
(2, 3, 4,...).” The guidance will switch to the
next route section. While the voice guidance
is not available, please refer to the map
display for the direction.

In some cases, the voice guidance ends
before arrival at the destination. In such
cases, drive the vehicle by referring to the
destination icon displayed on the map
screen.

When the system can judge on which side
the destination (waypoint) is located, the
voice guidance will say “on the right” after
announcing the arrival at the destination.

Voice guidance may not operate as specified
or may not operate at all due to the angle of
roads at intersection entrances and exits.
NOTES ON THE VOICE
GUIDANCE
10-4
How do I use the voice guidance feature?


04.7.6/Z33-N


INFO:

It is not possible to update the vehicle loca-
tion when the vehicle is moving.

Depending on the driving conditions, the
vehicle icon may not exactly correspond to
the actual location of the vehicle. To verify
position, refer to map books or check actual
landmarks.

If you notice that the system is displaying a
different road from the one the vehicle is
actually traveling, and the vehicle icon does
not go back to the right road after traveling
approximately 6-1/4 miles (10km), update
the vehicle location.You can set the automatic beep sound. (Acti-
vated during automatic rerouting, etc.)
1. Press the SETTING button.
The [SETTINGS] screen will be displayed.
Select the
Navigation key.2. The [NAVIGATION SETTINGS] screen will
be displayed.
Select the
Button Tone/Beep Response key.
INV1726
INV1466
INV1728
SETTINGAUTOMATIC BEEP
SOUND
11-20
How do I adjust the display?


04.7.6/Z33-N


3. The [BUTTON TONE/BEEP RESPONSE]
screen will be displayed.
When turning on/off the beep sound, select theOn or
Off key.
When the PUSH ENTER button is pressed, the
selected key will be illuminated.
INFO:
Press the MAP button to return to the map.You can alter the display mode.
ADJUSTING THE DISPLAY
BRIGHTNESSYou can choose the best brightness for the
display.
1. Press the SETTING button.
2. Select the
Display key.
INV1729
INV1730
SETTINGTHE DISPLAY MODE
How do I adjust the display?
11-21


04.7.6/Z33-N


3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Setting Display Duration key.
INFO:
When you finish setting the display duration
time, the display will return to the previous
display automatically.The display uses liquid crystal and should be
handled with care.
WARNING
Never disassemble the display. It has
some areas with extreme high voltage.
Touching it may result in serious per-
sonal injury.CHARACTERISTICS OF LIQUID
CRYSTAL DISPLAY
If the temperature inside the vehicle is espe-
cially low, the display will stay relatively dim or
the movement of the images may be slow.
These conditions are normal; when the tem-
perature rises, the display will function nor-
mally.

You may notice darker or brighter dots in
parts of the display; this is inherent in monitor
displays and is not a malfunction.

You may also notice a remnant of the previ-
ous display image on the screen. This after-
image is inherent in displays and is not
abnormal.INFO:
The screen may become distorted by strong
magnetic fields.
MAINTENANCE OF THE DISPLAY
CAUTION

To clean the display, never use a
rough cloth, alcohol, benzine, thin-
ner, any kind of solvent, or paper
towel with chemical cleaning agent.
They will scratch or deteriorate the
panel.

Do not splash any liquid such as
water or car fragrance on the display.
Contact with liquid will cause the
system to malfunction.
If you need to clean the display screen, use a dry
soft cloth. If additional cleaning is necessary, use
a small amount of neutral detergent with a soft
cloth. Never soak the exterior with water or
detergent.
INV1744
HOW TO HANDLE THE DISPLAY
11-28
How do I adjust the display?


04.7.6/Z33-N


Symptom Possible cause Remedy
The voice guidance is not available. Voice guidance is only available at certain intersec-
tions marked with
. In some cases, the guidance is
not available even when the vehicle should make a
turn.This condition is not abnormal.
The vehicle is off the suggested route. Go back to the suggested route or request route cal-
culation again.
Voice guidance is set OFF. Turn the voice guidance ON.
Route guidance is set OFF. Turn the route guidance ON.
The guidance content does not correspond to the
actual condition.The content of the voice guidance may vary, depend-
ing on the types of junctions at which turns are made.Follow the actual rules and regulations of the roads
upon which you are driving.
VOICE GUIDANCE
Troubleshooting guide
14-9


04.7.6/Z33-N


Symptom Possible cause Remedy
Although the system is set with the moving direction
as the preference, it does not find the route by
matching the preference.There is no route found in that direction. This condition is not abnormal.
Route is not indicated. There is no road that can be found by this system
close to the destination.Reset the destination closer to the road displayed in
orange. Especially with roads which have separate
lanes for opposite directions, be careful in setting the
destination or waypoints on it, because results may
differ depending on the lane you choose.
The starting point to the destination is too close. Set more distant destinations.
The system may not calculate a route if the current
vehicle location is too far away from the destination.Divide your trip by selecting one or two intermediate
destinations.
The route is not displayed continuously at waypoints,
for example, that are not calculated route from the
vehicle’s current position.Suggested routes may be displayed discontinuously
near waypoints as route calculation is done at each
waypoint.This condition is not abnormal.
The suggested route the vehicle has traveled is
erased.Suggested routes are stored in memory by the
blocks; if the vehicle travels past waypoint block 1,
the previous data will be erased.This condition is not abnormal.
ROUTE CALCULATION14-10
Troubleshooting guide


04.7.6/Z33-N


Symptom Possible cause Remedy
A route with many detours is suggested. If there are restrictions (such as one-way traffic) on
roads close to the starting point or destination, the
system may suggest a detoured route.Try slightly moving the starting point or destination.
The landmark description does not correspond to the
actual one.This may be caused by insufficient or incorrect data
on the DVD-ROM.Exchange the Map DVD-ROM. The new DVD-ROM
will be updated.
The suggested route does not exactly connect to the
starting point, waypoints, or destination.There is no data for route calculation closer to these
points.Set these points on the main road displayed in thick
orange. Please note that in some cases even main
roads lack the data for route calculation.
ROUTE CALCULATION
Troubleshooting guide
14-11


04.7.6/Z33-N
