display NISSAN 350Z 2005 Z33 Navigation Manual

3. The display shows the state/province list.
Select a state/province name.4. The screen returns to the [DEST. SETTING
(City)] screen.
When the state/province is set, the display
shows the selected state/province next to the
State key.
Input the city name.
Please refer to “Setting with the
List key” on
page 5-22.
SETTING WITH THE
Phone Number
KEYSets the destination (waypoints) on the map
screen of the area and around the input phone
number.
1. Press the DEST button.
INV2410
INV2411
How do I program a destination?
5-25


04.7.6/Z33-N


6. To slightly alter the destination.
Select the
Map key to display the map
screen of the area around the specified des-
tination (waypoints).7. If necessary, operate the joystick to adjust the
location of the destination (waypoints).
Press the PUSH ENTER button.
Select the
Destination key to confirm.
To set the destination (waypoints), refer to “Mak-
ing the system guide the route with detailed
options” on page 5-32.INFO:
When a hospital is set as a destination, a
telephone number of the destination will be
displayed, if available.
INV2414
INV1537
INV2415
How do I program a destination?
5-27


04.7.6/Z33-N


SETTING WITH THE
Map
KEY
This will enable you to zoom into the map for
detail and set the desired location. This works
best when you know the location geographically,
or want to check the geographical surroundings
on the map before setting the destinations.
1. Press the DEST button.
2. Select the
Map key.
The map of the entire area will be displayed.3. Operate the joystick to choose the destina-
tion (waypoints).
INV2340
INV1540
5-28
How do I program a destination?


04.7.6/Z33-N


1. Press the DEST button.
The [DEST. SETTING] screen will be dis-
played.
Select the
Country key.2. Select the
Country key.
Each time the PUSH ENTER button is
pressed, the country selection toggles be-
tween USA and Canada.
3. Then, the selected country will be displayed
at the right of the
Country key.
SETTING WITH THE
Home
KEY (IN
EASY MODE)
Sets the home as a destination.
INFO:
In the Expert Mode, this key will not be displayed.
Turn on the highlighted green
Short Menus key
in the [SETTINGS] screen.
INV2341
INV2342
5-30
How do I program a destination?


04.7.6/Z33-N


1. Press the DEST button.
2. Select the
Home key.3. The [DEST. SETTING] screen will be dis-
played.
Select the
OK key.
To set the destination (waypoints), refer to “Mak-
ing the system guide the route with detailed
options” on page 5-32.
INFO:
If the home is not registered in the Address
Book, the [EDIT ADDRESS BOOK (Street
Address)] screen will be displayed. Please refer
to “Setting with the
Street Address key” on
page 5-7.
WARNING
To operate the navigation system or to
use the screen functions, first park the
vehicle in a safe place and set the park-
ing brake. Using the system while driv-
ing can distract the driver and may re-
sult in a serious accident.
INV2316
INV2417
HAVINGTHE SYSTEM GUIDE
YOU TO THE DESTINATIONS
How do I program a destination?
5-31


04.7.6/Z33-N


MAKING THE SYSTEM GUIDE THE
ROUTE WITH DETAILED OPTIONSBy choosing the destination from the menu, you
can choose detailed options such as waypoints
and calculation conditions and have the system
guide you from the current position to the des-
tination.Setting the destinationFirst, you will have to set the destination.
1. Select a destination using one of the meth-
ods described earlier in this chapter:— Address Book
— Previous Destination
— Street Address
— Intersection
— Point of Interest (POI)
— City
— Phone Number
— Map
— Home
2. Set the route priorities and select the
Route Calc. key to calculate the route.
INFO:

If you select the
OK key at this point, route
calculation will start without any waypoints.

Press the PREVIOUS button to display the
[EDIT ROUTE] screen.
INV1547
INV2418
5-32
How do I program a destination?


04.7.6/Z33-N


Setting the waypointsAfter you set a destination, you can set way-
points.
INFO:

When the ROUTE button is pressed on the
map and the
Edit Route key is selected, the
[EDIT ROUTE] screen will be displayed.

The maximum number of waypoints that can
be set is five (5).
Please refer to “Expert mode categories” on
page 5-2.1. Select the
key or
key on the [EDIT ROUTE] screen.
The [EDIT ROUTE] screen will be displayed.
2. Select a waypoint destination using one of
the destination selection procedures outlined
earlier in the chapter.
INV1549
INV2343
How do I program a destination?
5-33


04.7.6/Z33-N


Select the conditions with high priorities.
If you want to get to your destination in the
shortest time, select the
Shortest Time key.
Selecting the key will turn the indicator light in
the key ON, and selecting the key again will turn
the indicator light OFF.
INFO:

When you select theOK key at this point,
route calculation will start without any addi-
tional waypoints.

Press the PREVIOUS button to display the
[EDIT ROUTE] screen.
It is also possible to set a waypoint by
selecting the
Waypoint key in the [DEST.
SETTING] screen.
Setting the priorities for route
calculationAfter the setting of destinations and waypoints is
completed, set the calculation conditions such
as route type with high priorities.
1. Select the
Priorities key.
The screen for setting calculation conditions will
appear. The conditions with the indicator light
ON will have high priority.
INFO:
When the ROUTE button is pressed on the
map and theEdit Route key is selected, the
INV1551
INV1552
5-34
How do I program a destination?


04.7.6/Z33-N


[EDIT ROUTE] screen will be displayed.
2. Select the conditions with high priorities.
Select each key on the screen to turn its
respective indicator light ON or OFF.
Shortest Timekey:
The route to the destination is calculated so that
you can reach the destination in the shortest
time. In some cases, a freeway or toll road with
detours may be recommended.
NOTE:
It may not be the shortest time in all cases.Shortest Distancekey:
The route to the destination is calculated so that
it is the shortest distance.
NOTE:
It may not be the shortest distance in all
cases.Minimize Toll Roadkey:
The route to the destination is calculated with
minimum use of toll roads.Minimize FWYkey:
The route to the destination is calculated with
minimum use of freeways.Use Time Restricted Roadskey:
The route using time restricted roads is calcu-
lated.
INV1553
How do I program a destination?
5-35


04.7.6/Z33-N


When this key is selected and the
OK key is
pressed, a confirmation screen will be displayed.
When the
Yes key is pressed, route calculation
will start.
INFO:
The system considers time restricted roads as
whole-day restricted.
NOTE:
If the “Use Time Restricted Roads” is not
selected, the navigation system calculates
a route without including carpool lanes.
The auto reroute function is activated andrecalculates a route including carpool
lanes if both of the following conditions
are met:

the auto reroute function is turned ON.

you deviate from suggested road and
drive on a carpool lane.
With this auto reroute calculation, a sug-
gested route including carpool lanes will
be displayed, and the message “The route
has changed to include time restricted
roads. Please be sure to obey traffic regu-
lations.” will be displayed on the screen.
Because the suggested route provided at
this time is calculated without taking regu-
lations and limitations of time restricted
roads into consideration at all, please drive
safely and follow the actual roads and
regulations when driving.
NOTE:
When driving on a time restricted road, be
sure to obey traffic regulations.
Use Ferry Routekey:
Select this key if you prefer routes with ferry
lines.
Route calculation and guidanceAfter setting all the items required, you may
proceed to route calculation for guidance. After
the route calculation is completed, the guidance
will start automatically.
INFO:
When the ROUTE button is pressed on the
map and the
Edit Route key is selected, the
[EDIT ROUTE] screen will be displayed.
Select the
Route calc. key.
INV1554
INV1555
5-36
How do I program a destination?


04.7.6/Z33-N
