SC-1
STARTING & CHARGING SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION SC
A
B
SC
Revision: 2006 November2007 350Z
STARTING & CHARGING SYSTEM
PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
Precautions for Battery Service ................................ 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 3
BATTERY .................................................................... 4
How to Handle Battery ............................................. 4
METHODS OF PREVENTING OVER-DIS-
CHARGE ............................................................... 4
CHECKING ELECTROLYTE LEVEL .................... 5
SPECIFIC GRAVITY CHECK ............................... 5
CHARGING THE BATTERY ................................. 6
Trouble Diagnoses with Battery Service Center ....... 7
Removal and Installation .......................................... 7
REMOVAL ............................................................. 7
INSTALLATION ..................................................... 7
STARTING SYSTEM .................................................. 8
System Description .................................................. 8
M/T MODELS ........................................................ 8
A/T MODELS ........................................................ 9
Wiring Diagram — START — ................................. 10
M/T MODELS ...................................................... 10
A/T MODELS ...................................................... 12
Trouble Diagnoses with Starting/Charging System
Tester (Starting) ...................................................... 13
DIAGNOSTIC PROCEDURE 1 ........................... 14
DIAGNOSTIC PROCEDURE 2 ........................... 15MINIMUM SPECIFICATION OF CRANKING
VOLTAGE REFERENCING COOLANT TEM-
PERATURE ......................................................... 16
Removal and Installation ........................................ 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 18
Disassembly and Assembly .................................... 19
TYPE: S114-928 .................................................. 19
INSPECTION AFTER DISASSEMBLY ................ 19
CHARGING SYSTEM ............................................... 20
System Description ................................................. 20
MALFUNCTION INDICATOR .............................. 20
Wiring Diagram — CHARGE — ............................. 21
Trouble Diagnoses with Starting/Charging System
Tester (Charging) .................................................... 22
PRELIMINARY INSPECTION ............................. 23
DIAGNOSTIC PROCEDURE 1 ........................... 23
DIAGNOSTIC PROCEDURE 2 ........................... 24
DIAGNOSTIC PROCEDURE 3 ........................... 24
DIAGNOSTIC PROCEDURE 4 ........................... 24
Removal and Installation ........................................ 26
REMOVAL ........................................................... 26
ALTERNATOR PULLEY INSPECTION ............... 27
INSTALLATION ................................................... 27
Disassembly and Assembly .................................... 28
TYPE: A3TJ1991 ................................................. 28
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 29
Battery .................................................................... 29
Starter ..................................................................... 29
Alternator ................................................................ 29
Page 2 of 30
SC-2
PRECAUTIONS
Revision: 2006 November2007 350Z
PRECAUTIONS PFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS00001
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Battery ServiceNKS00002
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Page 3 of 30
PREPARATION
SC-3
C
D
E
F
G
H
I
J
L
MA
B
SC
Revision: 2006 November2007 350Z
PREPARATIONPFP:00002
Special Service ToolsNKS00004
Commercial Service ToolsNKS0054Y
Tool number
(Kent-Moore No.)
Tool nameDescription
—
(J-48087)
Battery Service CenterTests battery.
For operating instructions, refer to Technical
Service Bulletin and Battery Service Center
User Guide.
—
(J-44373 Model MCR620)
Starting/Charging System Tester
Tests starting and charging system.
For operating instructions, refer to Technical
Service Bulletin.
WKIA5280E
SEL403X
Tool nameDescription
Power toolLoosening bolts, nuts and screws
PIIB1407E
Page 4 of 30
SC-4
BATTERY
Revision: 2006 November2007 350Z
BATTERYPFP:AYBGL
How to Handle BatteryNKS00006
CAUTION:
If it becomes necessary to start the engine with a booster battery and jumper cables, use a 12-volt
booster battery.
After connecting battery cables, ensure that they are tightly clamped to battery terminals for good
contact.
METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging
a battery.
The battery surface (particularly its top) should always be kept
clean and dry.
The terminal connections should be clean and tight.
At every routine maintenance, check the electrolyte level.
This also applies to batteries designated as “low maintenance”
and “maintenance-free”.
When the vehicle is not going to be used over a long period of
time, disconnect the battery cable from the negative terminal.
Check the charge condition of the battery.
Periodically check the specific gravity of the electrolyte. Keep a
close check on charge condition to prevent over-discharge.
MEL040F
ELA0349D
MEL042F
Page 5 of 30
BATTERY
SC-5
C
D
E
F
G
H
I
J
L
MA
B
SC
Revision: 2006 November2007 350Z
CHECKING ELECTROLYTE LEVEL
WARNING:
Never allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touch-
ing a battery, never touch or rub your eyes until you have thoroughly washed your hands. If acid con-
tacts eyes, skin or clothing, immediately flush with water for 15 minutes and seek medical attention.
Remove the cell plug using a suitable tool.
Add distilled water up to the MAX level.
Sulphation
A battery will be completely discharged if it is left unattended
for a long time and the specific gravity will become less than
1.100. This may result in sulphation on the cell plates.
To determine if a battery has been “sulphated”, note its voltage
and current when charging it. As shown in the figure, less cur-
rent and higher voltage are observed in the initial stage of
charging sulphated batteries.
A sulphated battery may sometimes be brought back into ser-
vice by means of a long, slow charge, 12 hours or more, fol-
lowed by a battery capacity test.
SPECIFIC GRAVITY CHECK
1. Read hydrometer and thermometer indications at eye level.
2. Use the chart below to correct your hydrometer reading accord-
ing to electrolyte temperature.
Hydrometer Temperature Correction
MEL043F
PKIA2353E
MEL042FA
Battery electrolyte temperature °C (°F) Add to specific gravity reading
71 (160) 0.032
66 (150) 0.028
60 (140) 0.024
54 (130) 0.020
49 (120) 0.016
43 (110) 0.012
38 (100) 0.008
32 (90) 0.004
27 (80) 0
21 (70)−0.004
Page 6 of 30
SC-6
BATTERY
Revision: 2006 November2007 350Z
CHARGING THE BATTERY
CAUTION:
Never “quick charge” a fully discharged battery.
Keep the battery away from open flame while it is being charged.
When connecting the charger, connect the leads first, then turn on the charger. Never turn on the
charger first, as this may cause a spark.
If battery electrolyte temperature rises above 55 °C (131 °F), stop charging. Always charge battery
at a temperature below 55 °C (131 °F).
Charging Rates
Never charge at more than 50 ampere rate.
NOTE:
The ammeter reading on your battery charger will automatically decrease as the battery charges. This indi-
cates that the voltage of the battery is increasing normally as the state of charge improves. The charging amps
indicated above refer to initial charge rate.
If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be
replaced.
16 (60)−0.008
10 (50)−0.012
4 (40)−0.016
−1 (30)−0.020
−7 (20)−0.024
−12 (10)−0.028
−18 (0)−0.032
Corrected specific gravity Approximate charge condition
1.260 - 1.280 Fully charged
1.230 - 1.250 3/4 charged
1.200 - 1.220 1/2 charged
1.170 - 1.190 1/4 charged
1.140 - 1.160 Almost discharged
1.110 - 1.130 Completely discharged Battery electrolyte temperature °C (°F) Add to specific gravity reading
Amps Time
50 1 hour
25 2 hours
10 5 hours
5 10 hours
Page 7 of 30
BATTERY
SC-7
C
D
E
F
G
H
I
J
L
MA
B
SC
Revision: 2006 November2007 350Z
Trouble Diagnoses with Battery Service CenterNKS00007
For battery testing, use Battery Service Center (J-48087). For details and operating instructions, refer to Tech-
nical Service Bulletin and/or Battery Service Center User Guide.
Removal and Installation NKS00008
REMOVAL
CAUTION:
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any
interference between the window edge and the vehicle when the door is opened/closed. During normal
operation, the window slightly raises and lowers automatically to prevent any window to vehicle inter-
ference. The automatic window function will not work with the battery disconnected.
1. Remove hoodledge cover (right).
2. Disconnect both battery cables from terminals.
CAUTION:
When disconnecting, disconnect the battery cable from the
negative terminal first.
3. Remove clips of cowl top cover (right) and it raises to the up
side.
4. Remove battery fix frame mounting nuts and battery fix frame.
5. Remove relay box from bracket.
6. Remove battery.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
When connecting, connect the battery cable to positive terminal first.
PKIA1919E
SKIB1149E
Battery fix frame mounting nut
: 3.9 N·m (0.40 kg-m, 35 in-lb)
Battery cable tightening nut
: 5.4 N·m (0.55 kg-m, 48 in-lb)
Page 8 of 30
SC-8
STARTING SYSTEM
Revision: 2006 November2007 350Z
STARTING SYSTEMPFP:23300
System Description NKS00009
M/T MODELS
Power is supplied at all times:
through 40A fusible link (letter M , located in the fuse and fusible link block)
to ignition switch terminal 1,
through 10A fuse (No. 71, located in the IPDM E/R)
to CPU of IPDM E/R,
through 15A fuse (No. 78, located in the IPDM E/R)
to CPU of IPDM E/R.
With the ignition switch in the ON or START position, power is supplied:
to CPU of IPDM E/R, from battery direct
through 10A fuse (No. 89, located in the IPDM E/R) and IPDM E/R terminal 25
to clutch interlock switch terminal 1.
When the clutch pedal is depressed, power is supplied:
through clutch interlock switch terminal 2
to IPDM E/R terminal 53.
Ground is supplied:
to IPDM E/R terminals 38, 50 and 60
from grounds E17, E43 and B102 (with VDC, navigation system or telephone).
from grounds E17, E43 and F152 (without VDC, navigation system and telephone).
Then starter relay is turn ON.
With the ignition switch in the START position, IPDM E/R is energized and power is supplied:
from ignition switch terminal 5
to IPDM E/R terminal 4 and
through IPDM E/R terminal 3
to starter motor terminal 1.
The starter motor plunger closes and provides a closed circuit between the battery and starter motor. The
starter motor is grounded to the engine block. With power and ground supplied, cranking occurs and the
engine starts.
Page 9 of 30
STARTING SYSTEM
SC-9
C
D
E
F
G
H
I
J
L
MA
B
SC
Revision: 2006 November2007 350Z
A/T MODELS
Power is supplied at all times:
through 40A fusible link (letter M , located in the fuse and fusible link block)
to ignition switch terminal 1,
through 10A fuse (No. 71, located in the IPDM E/R)
to CPU of IPDM E/R,
through 15A fuse (No. 78, located in the IPDM E/R)
to CPU of IPDM E/R.
With the ignition switch in the ON or START position, power is supplied:
to CPU of IPDM E/R, from battery direct.
When the selector lever in the “P” or “N” position, power is supplied:
from A/T assembly (TCM) terminal 9
to IPDM E/R terminal 53.
Ground is supplied:
to IPDM E/R terminals 38, 50 and 60
from grounds E17, E43 and B102 (with VDC, navigation system or telephone).
from grounds E17, E43 and F152 (without VDC, navigation system and telephone).
Then starter relay is turn ON.
With the ignition switch in the START position, IPDM E/R is energized and power is supplied:
from ignition switch terminal 5
to IPDM E/R terminal 4 and
through IPDM E/R terminal 3
to starter motor terminal 1.
The starter motor plunger closes and provides a closed circuit between the battery and starter motor. The
starter motor is grounded to the engine block. With power and ground supplied, cranking occurs and the
engine starts.
Page 10 of 30
SC-10
STARTING SYSTEM
Revision: 2006 November2007 350Z
Wiring Diagram — START —NKS0000A
M/T MODELS
TKWT5715E
