Page 1 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 1 -


Nissan Altima Hybrid









© 2008 NISSAN NORTH AMERICA, INC.
All rights reserved. This document may not be
altered without the written permission of NISSAN NORTH AMERICA, I

Page 2 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 2 -

Foreword .......................................................................\
....................................................... ....................... - 3 -
About the Nissan Alti

Page 3 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 3 -
Foreword

Nissan released the Nissan Altima Hybrid in North America in January of 2007. The Nissan Altima Hybrid runs
on conventional gasoline and a traction motor. The basic vehicle systems

Page 4 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 4 -
About the Nissan Altima Hybrid

There are two power sources stored on board that are used to drive the vehicle:
•  Gasoline is stored in a fuel tank and used to supply the gasoline engine.

Page 5 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 5 -

Altima Hybrid Identification

In appearance, the Nissan Altima Hybrid is nearly identical to the conventional Nissan Altima.

VIN Location


The VIN can be located on either the front

Page 6 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 6 -
Engine Compartment


The engine compartment of the Altima Hybrid houses an aluminum alloy 2.5 liter gasoline engine, the high
voltage harnesses, fuse/fusible link box, fuse block, inverter u

Page 7 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 7 -

Exterior



•  A Hybrid logo is located on the right side of the trunk.











•  A Hybrid logo is located on each front door above the body
side molding.

Page 8 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 8 -
Hybrid System Locations and Descriptions




Component Location Description
1. Electric Air
Conditioning
Compressor  Engine compartment, front
passenger side
Electric motor driven com

Page 9 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 9 -


Battery Information

The Altima Hybrid utilizes two batteries in order to supply both high and low voltage.

Low Voltage Battery

The Altima Hybrid contains a lead-acid 12 volt DC lo

Page 10 of 27

NISSAN ALTIMA HYBRID 2009 L32A / 4.G First Responders Guide - 10 -

High Voltage Battery Specifications


High Voltage Battery Specifications
High voltage battery voltage  245 V
Number of Ni-MH battery modules in the pack 34
Ni-MH battery module voltag
