key NISSAN CUBE 2013 3.G LC1 Navigation Manual

Several methods are available to set your
destination.
BASIC OPERATION
1. Press the NAV button.2. Select the appropriate destination settingmethod by touching the screen or scrolling
with the scrolling dial.
AVAILABLE SETTING ITEMS
●DESTINATION:
Set and/or save a destination.
Several methods are available to set your
destination.
“SETTING A DESTINATION”
(page 4-5)
● PREVIOUS DESTINATIONS:
Searches for a destination from the previ-
ous destinations in the destination memory. Up to 50 previous destinations will be auto-
matically stored. If the number of previous
destinations exceeds 50, the oldest one will
be removed from the list and the newest
one will be added.
To manually delete a previous destination
entry, touch the “Delete” key on the Previ-
ous Destinations list screen. Touch “Del.
All” to delete all previous destinations on the
list.
Touch the “Save” key to add a previous des-
tination to the address book.
NOTE:
It is not possible to retrieve deleted previ-
ous destination entries.
● HOME:
Your home address can be entered as a
destination.
● OPTIONS:
Changes the settings the system uses to
calculate the route.
“ROUTE CALCULATION SET-
TINGS” (page 4-4)
LNV0944
NAVIGATION SCREEN
Navigation4-3

5. Enter the name of the state or province. Thedisplay shows the touch keyboard.
“HOW TO INPUT CHARAC-
TERS” (page 2-7)
The keyboard has an intelligent spelling
setting, so it excludes non-existing
combinations. On the top right of the
screen, the number of matches is shown. 6. Touch “Street”NOTE:
It is possible to choose “City” at this step if
you want to manually enter the city name.
However, the system can automatically
narrow down the city in most cases when
you enter the street name first. Entering by
street can also be useful if you are unsure
of the city’s correct spelling. 7. The display shows a touch keyboard to en-
ter the house number of the destination. If
the house number is not known, touch
“Skip” and a default location on the street
will be used.
“HOW TO INPUT CHARACTERS”
(page 2-7)
NOTE:
If you choose “Skip”, a default location is
chosen by the system and you will have a
chance to change the position once the
map is displayed. See step 12 for more in-
structions on changing the default
location.
LNV0951LNV0950LNV0956
Navigation4-7

8. The display shows a touch keyboard to en-ter the street name. Enter the name of the
street. At any time, touch the “List” key to
display a list of possible street names based
on the letters currently entered. When the
number of matches is reduced to five or
less, the street list will be shown
automatically.
“HOW TO INPUT CHARACTERS”
(page 2-7) 9. Touch the street name on the list.
10. If the street name you choose is found in
only one city in the state, the system will au-
tomatically proceed to step 11. However, if
the street name you choose is found in mul-
tiple cities throughout the state (for
example, a common name such as Main
Street) , you will need to choose the name of
the city by touching it on the screen.
LNV0954LNV0955LNV0953
4-8Navigation

If the list of cities is too large, you may be asked
to spell the city name to narrow down the num-
ber of matches.
“HOW TO INPUT CHARACTERS”
(page 2-7)11. If the house number entered in step 7 does
not exist on the street in the chosen city or if
Skip was chosen in step 7, a screen will
be displayed asking if you want to use a de-
fault location on the street or instead view a
list with ranges of valid house numbers. If
you choose to view the list, select a range
by touching it on the screen. A default loca-
tion within that range of addresses will be
used.
NOTE:
You will have a chance to change the posi-
tion from the default location once the
map is displayed. See step 12 for more in-
structions on changing the default
location. 12. A map of the destination is displayed on the
screen. Touch “Start” to calculate the route.
The map of the destination is always displayed in
2D North Up. Once the “Start” key is touched,
the system returns to the current map settings.
NOTE:
If you did not enter an exact street address
earlier in the process, the system will have
chosen a default location, either along the
street or within a range of addresses on
that street. To move the map from that de-
fault position, touch the “Menu” key. A
message will be displayed asking if you
want to move or store the location.
LNV0952LNV0957LNV0958
Navigation4-9

Touch “Move”. A map screen will be displayed
that allows you to touch a new location for the
destination. Touch “OK” when complete.
If you touch the “Store” key after the “Menu” key
is touched, you can store the location in the ad-
dress book.
“SETTING A NEW ENTRY TO THE
ADDRESS BOOK” (page 4-10)This option allows you to set and store the des-
tination in the address book and use the stored
destinations to calculate a route.
SETTING A NEW ENTRY TO THE
ADDRESS BOOK
1. Press the NAV button.
2. Touch “Destination”.
3. Touch “Address Book”.
LNV1016LNV0959
SETTING A DESTINATION FROM THE
ADDRESS BOOK
4-10Navigation

The touch keyboard gives the option to change
the name of the selected destination.
Touch “OK”. The system confirms the entry and
adds it to the address book.●
“Current Destination”
This option allows you to store the currently
set destination in the address book when a
route is active. This option is only available
when a route is active.
Touch “Current Destination”. The touch keyboard gives the option to change
the name of the destination.
Touch “OK”. The system confirms the entry and
adds it to the address book.
LNV0963LNV0964LNV0963
4-12Navigation

●“Current Position”
This option allows you to set the current po-
sition as a destination in the address book.
Touch “Current Position”. The touch keyboard gives the option to change
the name of the destination.
Touch “OK”. The system confirms the entry and
adds it to the address book.SETTING AN ENTRY AS A DESTINA-
TION
Instead of touching “Add New Entry”, you can
touch any previously saved address (for
example, CLINIC, GRANDMA LOUISE, etc.) .
LNV0965LNV0963WNV0995
Navigation4-13

If you choose “By Name”, you can search for
places using a specific name. The touch key-
board is shown.
“HOW TO INPUT CHARACTERS”
(page 2-7)
NOTE:
● When searching “By Category”, the system
will search for up to 200 matches within 50
miles (80 km) of the current position.
● When searching “By Name”, the system will
search for up to 30 matches within 50 miles
(80 km) of the current position.
● If the destination is not found within the 50
mile (80 km) search radius, you can search for
places around a specific city name.
“SEARCHING FOR PLACES IN AN-
OTHER CITY” (page 4-18) 7. Destinations are shown based on the dis-
tance to the selected position. The arrow on
the right shows the direction of the
destination. The distance shown is a
straight line distance.
Touch the desired destination from the list.
LNV0974LNV0970
Navigation4-17

6. If necessary, enter the name of the state orprovince.
The display shows the touch keyboard.
“HOW TO INPUT CHARAC-
TERS” (page 2-7)
The keyboard has an intelligent spelling
setting, so it excludes non-existing
combinations. On the top right of the
screen, the number of matches is shown. 7. Touch “City”.
8. A touch keyboard is displayed. Enter the
name of the desired city. Press “List” at any time to display a list of remain-
ing cities. Touch the desired city.
LNV0951LNV0952LNV0953
Navigation4-19

9. Touch “By Category” or “By Name”.
10. If you choose “By Category”, you can browse destinations from a variety of cat-
egories and subcategories, including:
● Automotive
● Banking & Business
● City Center
● Emergency
● Hotel/Motel
● Leisure
● Public Places
● Restaurant
● Shopping
● Travel If you choose “By Name”, you can search for
places using a specific name. The touch key-
board is shown.
“HOW TO INPUT CHARACTERS”
(page 2-7)
NOTE:
● When searching “By Category”, the system
will search for up to 200 matches within 50
miles (80 km) of the chosen city.
● When searching “By Name”, the system will
search for up to 30 matches within 50 miles
(80 km) of the chosen city.
LNV0973LNV0974
4-20Navigation
