light NISSAN GT-R 2020 Owners Manual

NOTICE
.If the warning light comes on
while driving there may be a
malfunction in the AWD system.
Reduce the vehicle speed and it is
recommended you have your ve-
hicle checked by a GT-R certified
NISSAN dealer as soon as possi-
ble.
. If the warning light remains on
after the above operation, it is
recommended you have your ve-
hicle checked by a GT-R certified
NISSAN dealer as soon as possi-
ble.
. The powertrain may be damaged
if you continue driving with the
warning light blinking.
. Do not spin the rear wheels while
driving. Spinning the rear wheels
may increase the temperatures
of the AWD clutch system and
damage the system. Adjust the
accelerator pedal position to stop
wheel spin.
TIGHT CORNER BRAKING PHE-
NOMENONIf the steering wheel is turned more than
half a turn when the vehicle is started
when it is cold, it may be harder to move
the vehicle forward and backward. This
phenomenon is known as the “tight
corner braking phenomenon”.
This phenomenon is unique to AWD
vehicles, and occurs due to a difference
in speeds between the front and rear
wheels while the vehicle is turning. This
does not indicate that there is a malfunc-
tion.
NOTE:
If the tight corner braking phenomenon
occurs, a slipping sound may be heard
from the tires, or a squeaking sound
may be heard from the drive system.Reducing tight corner braking
phenomenonThe tight corner braking phenomenon
can be reduced if the following three
conditions are met:
.Transmission setup switch is set to
Normal mode.
. Vehicle speed is low (less than ap-
proximately 6 MPH (10 km/h)). .
The steering wheel is turned more
than 1/2 turn.
TIRESThis vehicle is equipped with special tires.
When changing the tires, install the de-
signated special tires. Replacing tires as a
set of four with new ones is recom-
mended. However, if a tire is punctured
or damaged, it may be possible to replace
only the damaged tire. Determining
whether one tire or a complete set of
tires should be replaced is based on a
number of factors including tire wear and
condition. Contact your GT-R certified
NISSAN dealer. They can recommend if
an individual tire or a complete set should
be replaced.
NOTICE
If tires other than the designated
tires, tires with large differences in
wear or tires of different sizes are
installed, the AWD performance will
be degraded and the drive mechan-
ism may be damaged.
Starting and driving
5-43

operates to prevent one drive wheel from
slipping by transferring power to a non
slipping drive wheel. The VDC warning
light

and odorless carbon monoxide.
Carbon monoxide is dangerous. It
can cause unconsciousness or
death.
PROGRAMMING HomeLink®If you have any questions or are having
difficulty programming your HomeLink®
buttons, refer to the HomeLink® web site
at: www.homelink.com or call 1-800-355-
3515.
NOTE:
It is also recommended that a new
battery be placed in the hand-held
transmitter of the device being pro-
grammed to HomeLink® for quicker
programming and accurate transmis-
sion of the radio-frequency.
1. Position the end of your hand-heldtransmitter 1-3 in (26-76 mm) away
from the HomeLink® surface, keeping
the HomeLink® indicator light

Inspection and adjustments
after driving ............................................................... GTR-19
Inspection and adjustments
before driving .......................................................... GTR-14
Installing front license plate ............................... 9-13
Installing top tether strap .................... 1-26, 1-30
Instrument brightness control ......................... 2-12
Instrument panel ............................................................ 2-5
Intelligent Key .................................................................... 3-2
Intelligent Key battery discharge ................... 5-12
Intelligent Key battery
discharge indicator ................................................... 2-47
Intelligent Key battery replacement ............ 8-29
Intelligent Key functions ........................................... 3-9
Intelligent Key insertion indicator ................. 2-46
Intelligent Key removal indicator ................... 2-47
Intelligent Key system ................................................. 3-8
Interior light control switch ................................ 2-66
Interior lights .................................................................. 2-65
J
Jacking vehicle and removing wheels....... 8-46
Jump starting ..................................................... 6-5, 8-19
K

Seat belt maintenance .................................... 1-12
Map lights ......................................................................... 2-65
Measurement of weights ..................................... 9-16
Meters and gauges ....................................................... 2-6
Mirror Inside mirror ............................................................ 3-27
Mirrors ........................................................................... 3-27
Outside mirrors ..................................................... 3-28
Vanity mirror ........................................................... 3-29
Vanity mirror lights ............................................ 2-67
Most common factors contributing to
vehicle corrosion ............................................................. 7-9
Multi Function Display Owner’s Manual ....... 4-2
N
NCCB (NISSAN Carbon
Ceramic Brake) ........................................... GTR-6, 8-25
Replacing brake pads and brake
disc rotors ................................................................. 8-26
NISSAN Advanced Air Bag System ................ 1-40
NISSAN Vehicle Immobilizer System ............ 2-49
No key warning ............................................................ 2-44
Noises are heard while driving .................. GTR-25
Normal mode ................................................................. 5-25
O

Special winter equipment .................................... 5-56
Specifications ..................................................................... 9-8
Speedometer ...................................................................... 2-7
StartingBefore starting the engine ........................... 5-13
Jump starting ............................................. 6-5, 8-19
Precautions when starting
and driving ................................................................... 5-3
Push starting .............................................................. 6-7
Starting the engine ............................................ 5-14
Steering Power steering ....................................................... 5-50
Power steering fluid .......................................... 8-14
Steering lock release
malfunction indicator ....................................... 2-46
Steering wheel ....................................................... 3-26
Steering-wheel-mounted controls ........ 5-35
Tilt/telescopic steering column ............... 3-26
Storage ............................................................................... 2-59
Summer tires ............................................................ GTR-11
Sun visors .......................................................................... 3-27
Sunglasses holder ...................................................... 2-60
Supplemental air bag warning labels ........ 1-48
Supplemental air bag warning light ............ 1-48
Supplemental restraint system ....................... 1-34
Suspension and
wheel alignment .............................. GTR-16, GTR-23
Switch
Hazard warning flasher switch .................... 6-2
Headlight and turn signal switch ........... 2-52
Headlight switch ................................................... 2-52 How to switch the modes ............................ 5-26
Ignition switch operation .............................. 5-11
Ignition switch positions ................................ 5-11
Interior light control switch ......................... 2-66
Locking with power door lock switch ..... 3-5
Push-button ignition switch ....................... 5-10
Rear window defroster switch .................. 2-52
Trunk lid release switch ................................. 3-20
Trunk open request switch ......................... 3-20
Trunk release power cancel switch ...... 3-21
VDC, transmission and suspension
setup switches ....................................................... 5-25
Wiper and washer switch .............................. 2-50
T

of the following items:
.Gear clearances
. Ultralight flywheel
. Dry sump lubrication
These noises do not indicate that there is
a malfunction.

engine for more than 20 seconds
without depressing the brake pedal.
This allows the brake pads to move
away from the rotor so the pad does
not contact the rotor.
Additionally, the brakes must be dry
before parking the vehicle after driv-
ing on wet roads or after washing the
vehicle. If the roads are wet, lightly
apply the brakes for a short distance
before parking the vehicle to dry the
brakes. After washing the vehicle, dry
the brakes by driving on a dry road for
a few miles and apply the brakes
normally based on traffic and road
conditions.
The metallic brake pads and brake
disc rotor may rust together when the
brakes are not applied:
— If the vehicle is not idled for 20seconds without the brakes ap-
plied, or if the brakes are applied
when the vehicle is shut off, the
rotor and pads can rust together,
even when the brake pads are dry.
— If the brakes are wet when the vehicle is parked and the parking
brake is applied for a long time.
— The hill start assist system can apply the brakes even if the brake
pedal is not depressed. The brake
pads and rotors can rust together if the parking procedure previously
described is not followed.
It is recommended you contact a GT-R
certified NISSAN dealer if the brake
pads and brake rotor have rusted
together.
NOTICE

NOTICE
.If the warning light comes on
while driving there may be a
malfunction in the AWD system.
Reduce the vehicle speed and it is
recommended you have your ve-
hicle checked by a GT-R certified
NISSAN dealer as soon as possi-
ble.
. If the warning light remains on
after the above operation, it is
recommended you have your ve-
hicle checked by a GT-R certified
NISSAN dealer as soon as possi-
ble.
. The powertrain may be damaged
if you continue driving with the
warning light blinking.
. Do not spin the rear wheels while
driving. Spinning the rear wheels
may increase the temperatures
of the AWD clutch system and
damage the system. Adjust the
accelerator pedal position to stop
wheel spin.
TIGHT CORNER BRAKING PHE-
NOMENONIf the steering wheel is turned more than
half a turn when the vehicle is started
when it is cold, it may be harder to move
the vehicle forward and backward. This
phenomenon is known as the “tight
corner braking phenomenon”.
This phenomenon is unique to AWD
vehicles, and occurs due to a difference
in speeds between the front and rear
wheels while the vehicle is turning. This
does not indicate that there is a malfunc-
tion.
NOTE:
If the tight corner braking phenomenon
occurs, a slipping sound may be heard
from the tires, or a squeaking sound
may be heard from the drive system.Reducing tight corner braking
phenomenonThe tight corner braking phenomenon
can be reduced if the following three
conditions are met:
.Transmission setup switch is set to
Normal mode.
. Vehicle speed is low (less than ap-
proximately 6 MPH (10 km/h)). .
The steering wheel is turned more
than 1/2 turn.
TIRESThis vehicle is equipped with special tires.
When changing the tires, install the de-
signated special tires. Replacing tires as a
set of four with new ones is recom-
mended. However, if a tire is punctured
or damaged, it may be possible to replace
only the damaged tire. Determining
whether one tire or a complete set of
tires should be replaced is based on a
number of factors including tire wear and
condition. Contact your GT-R certified
NISSAN dealer. They can recommend if
an individual tire or a complete set should
be replaced.
NOTICE
If tires other than the designated
tires, tires with large differences in
wear or tires of different sizes are
installed, the AWD performance will
be degraded and the drive mechan-
ism may be damaged.
Starting and driving
5-43

ways use run-flat tires of the specified
size on all four wheels. Mixing tire sizes or
construction may reduce vehicle handling
stability. If necessary, contact a GT-R
certified NISSAN dealer for assistance.
Frequently check the tire pressure infor-
mation on the touch screen display and
adjust pressure of each tire properly. See
the separate Multi Function Display Own-
er’s Manual.
It can be difficult to tell if a run-flat tire is
under-inflated or flat. Check the tire
pressures as described earlier in this
section. If the tire becomes under-inflated
while driving, the low tire pressure warn-
ing light will come on. If the tire becomes
flat while driving, the low tire pressure
warning light and the run-flat tire warn-
ing display will come on.
Low tire pressure:
