cruise control NISSAN JUKE 2016 F15 / 1.G Quick Reference Guide

2
3
14
5
9
16
13
1718
19
20
21
14
15
12
11
7
6
8
*See your Owner’s Manual for information.1 Vehicle Information Display*2 Headlight and Turn Signal Switch3 Low Tire Pressure Warning Light4 Instrument Brightness

Control Switch*5 Twin Trip Odometer Reset Switch* /
Trip Computer Mode Switch
Wiper and Washer Switch7 Steering Wheel Switches for
Audio* / Bluetooth
® / Siri
® Eyes Free
8 Cruise Control9 Outside Mirror Control Switch10 Paddle Shifters*11 Tilt Steering Adjustment*
12 Vehicle Dynamic Control (VDC)
OFF Switch*13 All-Wheel Drive (AWD) Switch*14 Fuel-filler Door Release15 Hood Release*16 Hazard Warning Flasher Switch*
17 Audio and Navigation System18 Integrated Control System19 Auxiliary Jack*20 USB Connection Port21 Power Outlet*
610
1905578_16a_Juke_US_pQRG_081915.indd 48/19/15 11:07 AM

NEW SYSTEM FEATURES
Around View® Monitor with Moving Object Detection (MOD) (if so equipped)...............2
SiriusXM Travel Link and SiriusXM Traffic (if so equipped) ............................... 4
Siri
® Eyes Free (if so equipped) ..................................................... 4
ESSENTIAL INFORMATION
Fuel Efficient Driving............................................................... 5
Tire Pressure Monitoring System (TPMS) ............................................. 5
Loose Fuel Cap ................................................................... 6
Fuel-filler Door .................................................................... 6
Towing Your Vehicle ............................................................... 6
USB (Universal Serial Bus) Connection Port/Aux Jack and iPod
® Interface .................. 7
Setting Display Brightness and Button Brightness ......................................7
Clock Set/Adjustment ............................................................. 7
FIRST DRIVE FEATURES
NISSAN Intelligent Key® System ....................................................9
Liftgate Release ................................................................. 10
Seat Adjustments ................................................................ 10
Heated Seats (if so equipped) ..................................................... 10
Outside Mirror Control Switch ..................................................... 11
Starting/Stopping the Engine ...................................................... 11
Headlight Control Switch .......................................................... 12
Wiper and Washer Switch ......................................................... 13
Heater and Air Conditioner (automatic) (with Integrated Control Syste\
m) (if so equipped) ....14
Drive Mode (with Integrated Control System) (if so equipped) ........................... 15
FM/AM/SiriusXM
® Satellite Radio with CD Player (if so equipped) ....................... 16
Cruise Control ................................................................... 17
SYSTEM GUIDE
Trip Computer................................................................... 18
NissanConnectSM Mobile Apps ..................................................... 18
Text Messaging .................................................................. 19
Bluetooth
® Hands-free Phone System ............................................... 20
• System Operating Tips ........................................................ 20
Bluetooth
® System without Navigation (if so equipped) .................................20
Bluetooth® System with Navigation (if so equipped) ................................... 22
Navigation System (if so equipped) ................................................. 24
TAB LE OF CONTE NTS
Please see your Owner’s Manual for important safety information and system operation limitations.
• A cellular telephone should not be used for any purpose while driving
so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured
in child restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
,
the “Heater, air conditioner, audio and phone systems (section 4)” and the “Starting and driving (section 5)”
of your Owner’s Manual.
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System
Owner’s Manual and at www.nissanusa.com.
1905578_16a_Juke_US_pQRG_081915.indd 58/19/15 11:07 AM

17
CRUISE CONTROL
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 mph (40 km/h).

The system will automatically maintain the set
speed until you tap the brake pedal, accelerate,
cancel or turn the system off.

To activate the cruise control, push the CRUISE
ON/OFF switch
1. The CRUISE indicator light
in the instrument panel will illuminate.

To set a cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
2 and release. Take your foot off
the accelerator pedal. Your vehicle will maintain the set speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch 3.
When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch 2.
Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, push the CANCEL switch 4.

To turn off cruise control, push the CRUISE ON/OFF switch 1. The CRUISE
indicator light in the instrument panel will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
43
2
1
1905578_16a_Juke_US_pQRG_081915.indd 178/19/15 11:08 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
