display OPEL ANTARA 2017.5 Manual user

184Vehicle careTyre pressures in Info-Display
The current tyre pressures can be
shown in the menu item Tyres in the
Board Computer menu. Press BC on
the Infotainment system and select
the menu item.
The tyre pressure monitoring system
automatically detects the vehicle
load. A corresponding message may appear on the Info-Display if
inconsistent tyre pressures are
detected. In some versions, the
message is displayed in abbreviated
form.
For example, the following messages can be displayed:
A graphic indicating the left rear tyre
is shown together with the current tyre
pressure; slight pressure deviation.
Reduce speed. Check tyre pressure
at next opportunity with an
appropriate gauge and correct if
necessary.
On the Colour-Info-Display, this
message will appear in yellow.A graphic indicating the front left tyre
is shown together with the current tyre
pressure; significant pressure
deviation or direct pressure loss.
Steer out of the flow of traffic as
quickly as possible without
endangering other vehicles. Stop and
check the tyres. Mount the spare
wheel if necessary 3 190.
On the Colour-Info-Display, this
message will appear in red.
Acknowledgement of warnings 3 92,
3 94.
Vehicle messages 3 99.

Vehicle care185If the tyre pressure is to be reduced or
increased, switch off the ignition. Tyre
pressures 3 182, 3 212.
General information The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved tyre repair kits can be used.
Tyre repair kit 3 187.
Operating electronic devices or being close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
The tyre pressure monitoring system
valve cores and sealing rings must be
replaced each time the tyres are
changed.
Tyre pressure sensor matching
process
Each tyre pressure sensor has a
unique identification code. The
identification code must be matched
to a new tyre/wheel position after
rotating the tyres or replacing one or
more of the tyre pressure sensors.The tyre pressure sensor matching
process should also be performed
after replacing a spare tyre with a
road tyre containing a tyre pressure
sensor. The control indicator w and
the warning message should
extinguish at the next ignition cycle.
The sensors are matched to the tyre/
wheel positions, using a TPMS
relearn tool, in the following order:
● left front tyre
● right front tyre
● right rear tyre
● left rear tyre
Consult your workshop for service or
to purchase a relearn tool.
There are two minutes to match the
first tyre/wheel position, and
five minutes overall to match all four
tyre/wheel positions. If it takes longer, the matching process stops and must
be restarted.The tyre pressure sensor matching
process is as follows:
1. Apply the electrical parking brake 3 143 ; on vehicles with automatic
transmission move the selector
lever to position P.
2. Turn the ignition on 3 125.
3. Initiate the TPMS Learn Mode by simultaneously pressing p and
q on the radio remote control,
- or -
Press INFO on the Infotainment
system until a tyre learn message appears on the Info-display.
Press and hold OK.
The horn sounds twice and the left front turn signal also illuminates
as confirmation that Learn Mode
has been enabled.
4. Start with the left front tyre. 5. Place the relearn tool against the tyre sidewall, near the valve stem.
Then press the button to activate
the tyre pressure sensor. A horn
chirp confirms that the sensor
identification code has been

200Vehicle careInterior careInterior and upholstery
Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using a soft damp cloth. If necessary use aweak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

Service and maintenance201Service and
maintenanceGeneral information ...................201
Service information ..................201
Recommended fluids, lubricants and parts .................................... 202
Recommended fluids and lubricants ................................ 202General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for the vehicle is available at
the workshop.
Service display 3 80.
European service intervals Main service
Maintenance of your vehicle is
required every 30,000 km or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Macedonia,
Malta, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
Serbia, Slovakia, Slovenia, Spain,
Sweden, Switzerland, United
Kingdom.
Service display 3 80.
International service intervals
Main service
Maintenance of your vehicle is
required every 15,000 km or 1 year,
whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 80.

202Service and maintenanceConfirmations
Confirmation of service is recorded in the Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 80.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
diesel engines. If it is unavailable,
engine oils of other listed qualities
have to be used.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 206.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 206.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.

218IndexAAccessories and vehicle modifications .......................... 157
Accessory sockets ........................77
Active head restraints .............35, 36
AdBlue .................................. 88, 131
Adjustable air vents ...................119
Airbag and belt tensioners ...........83
Airbag deactivation ................50, 83
Airbag label................................... 45 Airbag system .............................. 45
Air conditioning regular operation ................................ 121
Air conditioning system .............. 115
Air intake .................................... 120
Air vents...................................... 119
All wheel drive .....................86, 140
Antilock brake system ................ 142
Antilock brake system (ABS) .......85
Anti-theft alarm system ..........26, 91
Anti-theft locking system .............. 25
Appearance care ........................198
Apply footbrake ............................ 90
Armrest ................................... 39, 41
Armrest storage ........................... 58
Automatic anti-dazzle ..................30
Automatic dimming ......................30
Automatic headlight levelling system ...................................... 90
Automatic level control .......106, 147Automatic light control ...............106
Automatic transmission ........84, 136
Autostop ..................................... 126
AUX input ..................................... 58
B Battery .......................................... 84
Battery discharge protection ......113
Battery, jump starting.................. 194
Belt pretensioners......................... 41
Belts.............................................. 41 Bicycle rack .................................. 58
BlueInjection ............................... 131
Board-Info-Display .......................92
Bonnet ....................................... 158
Brake and clutch fluid .................202
Brake assist ............................... 144
Brake fluid .................................. 162
Brakes ............................... 142, 161
Brake system ............................... 85
Breakdown.................................. 196
Bulb replacement ....................... 165
C
Capacities .................................. 211
Card holder ................................... 56
Car Pass ...................................... 21
Catalytic converter ................84, 130
CD tray ......................................... 56
Central locking system ................22
Centre console storage ...............58

220Front passenger seat undertray...57
Front seats.................................... 36
Fuel consumption - CO 2-
Emissions ............................... 151
Fuel economy mode .............89, 122
Fuel filler cap ................................ 84
Fuel for diesel engines ..............150
Fuel gauge ................................... 79
Fuses ......................................... 171
G Gauges ......................................... 78
General information ...................152
Glovebox ..................................... 57
Graphic-Info-Display, Colour- Info-Display .............................. 94
H Halogen headlights ....................166
Hand brake ................................. 143
Hazard warning flashers ............107
Headlight flash ........................... 106
Headlight range adjustment ......106
Headlights .................. 105, 106, 165
Headlights when driving abroad 107
Headlight washer ..........................73
Head restraint adjustment .............8
Head restraints ............................ 35
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heating ........................................ 40Heating and ventilation system . 114
High beam ........................... 90, 106
Hill start assist ........................... 144
Horn ....................................... 14, 72
I
Identification plate .....................205
Ignition switch positions .............125
Immobiliser ............................ 28, 90
Indicators ...................................... 78
Information displays...................... 91
Initial drive information.................... 6
Instrument cluster ........................78
Instrument panel fuse box .........176
Instrument panel illumination .....171
Instrument panel illumination control .................................... 110
Instrument panel overview ........... 10
Instrument panel storage ..............56
Interior care ............................... 200
Interior lighting ............................ 110
Interior lights ...................... 110, 170
Interior mirrors .............................. 30
Interruption of power supply ......139
Introduction .................................... 3
ISOFIX child restraint systems ....55
J Jump starting ............................. 194K
Kerb weight........................... 70, 209
Keys ............................................. 20
Keys, locks ................................... 20
Kickdown .................................... 138
L
Lashing eyes ............................... 69
Light covers, misted.................... 109
Lighting ....................................... 105
Lighting features .........................112
Light switch ................................ 105
Load compartment ................24, 67
Load compartment cover .............67
Load compartment lighting .........111
Load compartment storage ..........67
Loading information .....................70
Low engine oil level .....................89
Low fuel ....................................... 89
M
Malfunction indicator light ............84
Manual anti-dazzle ......................30
Manual mode ............................. 138
Manual transmission .................. 139
Mirror adjustment ........................... 9
Mirrors .................................... 28, 30
Misted light covers .....................109

221NNew vehicle running-in ..............124
Number plate light .....................170
O
Object detection systems ...........148
Odometer ..................................... 78
Oil ............................................... 159
Oil, engine .......................... 202, 206
Oil life monitor............................... 89
Outside temperature ....................75
Overrun cut-off ........................... 126
P Parking ................................ 18, 128
Parking assist ............................ 148
Parking brake ....................... 85, 143
Parking lights ............................. 109
Particulate filter ........................... 129
Performance .............................. 208
Performing work ........................158
Pollen filter ................................. 120
Power outlets .......................... 58, 77
Power seat adjustment .................39
Power steering...................... 86, 124
Power steering fluid ....................161
Power windows ............................ 31
Preheating ................................... 87
Puncture ..................................... 190R
Radio Frequency Identification (RFID) ..................................... 216
Radio remote control ...................21
Rain sensor .................................. 73
Reading lights ............................ 111
Rear carrier system ......................58
Rear floor storage cover ..............68
Rear fog light ............................... 91
Rear fog lights ........................... 109
Rear seats ............................. 40, 41
Rear window wiper/washer .......... 74
Recommended fluids and lubricants ........................ 202, 206
Reduced engine power ................90
Refuelling ................................... 150
Remote control ............................. 21
Reversing lights .........................109
Roof .............................................. 33
Roof load ...................................... 69
Roof rack ............................... 69, 70
S Safety belts ................................... 41
Seat adjustment ....................... 6, 37
Seat belt ........................................ 8
Seat belt reminder ..................42, 83
Seat belts ..................................... 41
Seat folding .................................. 38
Seat heating ................................. 40Seat position ................................ 36
Selective catalytic reduction .......131
Selector lever ............................. 136
Service ............................... 121, 201
Service display ......................80, 89
Service information ....................201
Service vehicle soon .................... 84
Side airbag system ......................48
Sidelights .................................... 105
Side turn signal lights ................170
Spare wheel ............................... 193
Speedometer ............................... 78
Speed warning.............................. 91
Sport mode .......................... 86, 137
Starting and operating ................124
Starting off ................................... 17
Starting the engine ....................125
Steering ...................................... 124
Steering wheel adjustment ......9, 72
Steering wheel controls ...............72
Stop-start system........................ 126
Storage ......................................... 56
Storage compartments .................56
Sunglasses storage .....................57
Sunroof ........................................ 33
Sunvisor lights ........................... 112
Sun visors .................................... 33
Symbols ......................................... 4

222T
Tachometer ................................. 79
Tailgate ......................................... 24
Tail lights ................................... 169
Technical data ............................ 207
Three-point seat belt .................... 42
Tools .......................................... 179
Top-tether fastening eyes ............55
Tow bar....................................... 152
Towing ................................ 152, 196
Towing another vehicle .............197
Towing a trailer ........................... 153
Towing equipment .....................153
Towing the vehicle .....................196
Trailer coupling ........................... 152
Trailer indicator ............................ 91
Trailer stability assist .................155
Trailer towing ............................. 153
Transmission ............................... 16
Transmission display ...........80, 136
Tread depth ............................... 186
Trip computer in Board-Info- Display ................................... 100
Trip computer in Graphic-Info- Display or Colour-Info-Display 102
Trip odometer .............................. 79
Turn and lane-change signals ...108
Turn signal ................................... 83
Tyre chains ................................ 187
Tyre changing ............................. 190Tyre designations ......................181
Tyre pressure ...................... 99, 182
Tyre pressure monitoring system ......................... 88, 99, 183
Tyre pressures ........................... 212
Tyre repair kit ............................. 187
Tyres and wheel size, changing. 186
U
Ultrasonic parking assist ...... 87, 148
Underseat storage .......................57
Upholstery, cleaning ...................200
Upshift .......................................... 86
Using this manual ..........................3
V Vehicle battery ........................... 162
Vehicle checks............................ 158
Vehicle data ................................ 206
Vehicle data recording and privacy ..................................... 215
Vehicle dimensions .................... 209
Vehicle Identification Number ....204
Vehicle jack ................................ 179
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 157
Vehicle tools ............................... 179
Vehicle unlocking ........................... 6
Vehicle weight ........................... 209
Ventilation ................................... 114W
Warning chimes ........................... 99
Warning lights ............................... 78
Warning triangle .......................... 69
Washer and wiper systems .........14
Washer fluid ............................... 161
Washing the vehicle ...................198
Welcome lighting ........................112
Wheel changing .........................190
Wheel covers ............................. 187
Wheels and tyres .......................181
Windows ....................................... 31
Windscreen................................... 31
Windscreen wiper/washer ...........73
Winter tyres ............................... 181
Wiper blade replacement ..........165
X Xenon headlights .......................167
