mirror Peugeot 206 CC 2002.5 Owner's Manual

1Side windows demisting vents
2 Adjustable side vent
3 Passenger air bag
4 Windscreen demisting vents
5 Multifunction display
6 Central locking control*
7 Hazard warning lights switch
8 Instrument panel lightingrheostat
9 Lights and direction indica-tors stalk
10 Steering wheel height adjust-ment control
11 Steering lock 12
Windscreen wash/wipe / trip computer stalk
13 Driver's air bag
Horn
14 Radio steering column stalk
15 Headlamp height adjustment
16 Passenger air bag disarmingswitch*
17 Alarm button*
18 Dynamic stability control(ESP/ASR) button
19 Storage compartment
20 Fuse box
21 Gear lever
22 Lighter
23 Electric retractable roof control 24
Electric window switches
25 Electric mirror switches
26 Handbrake
27 Front ashtray
28 Heating / ventilation / air con- ditioning controls Rear screen and mirrors demisting
29 Audio RD3
30 Adjustable central vents
31 Glove box
32 Bonnet opening control
* According to destination. 3
YOUR AT
A GLANCE
07-10-2002

ELECTRIC WINDOWS
1. Driver's electric windowsswitch
2. Passenger's electric win- dows switch
These control the front window and the rear quarter panel win-dow on their respective sides. Manual operation  Press the switch (to open) or pull it (to close) without goingbeyond the point of resistance. The window stops as soon as the switch is released. The rear quarter panel window can only open when the frontwindow is completely open,after being inactive for onesecond.
Automatic operation ¥ Opening
The windows open automatically (with the ignition key in theRunning position, engine on).
Press the switch past the pointof resistance:
Ð a brief press opens the front window completely; thenanother brief press completelyopens the rear quarter panel
window,
Ð a long press opens the front window completely, then the
rear quarter panel window.
¥ Closing
Only the front window on the driv-er's side closes automatically(engine running or vehicle beingdriven), when the rear quarterpanel window is closed.  Briefly pull the switch past the point of resistance to com-pletely close the front windowon the driver's side.
Note: the window switches are
inoperative when the roof isbeing adjusted. ELECTRIC MIRRORS
Turn knob
3to the right or to the
left to select the corresponding
mirror. Move knob 3in all four directions
to adjust. Electrically folding mirrors With the ignition on, turn knob 3
to position A. 5
YOUR AT
A GLANCE
07-10-20028281

1212
YOUR AT A GLANCE
No. Symbol Function
1 Air distribution adjustment.
2 Air intake control.
3 Temperature adjustment.
4 Demisting the rearscreen and the mirrors.
5 Air flow adjustment.
6 Air conditioningcontrol.
HEATING/AIR CONDITIONING
07-10-2002
56
58

13
No. Symbol Function 1 Air flow adjustment.
2 Air distribution adjustment.
3 Air intake control.
4 Air conditioningcontrol.
5 Demisting the rearscreen and themirrors.
6 Switching off.
7 Temperatureadjustment.
8 Automatic comfort programme.
9 Automatic visibilityprogramme.
Note: in the cabriolet version,
system performance may be reduced.
AUTOMATIC AIR CONDITIONING
YOUR AT
A GLANCE
07-10-200260

PEUGEOT SERVICING23
- Engine oil
Level
Operations Operation descriptions 1st service
AC
Intermediate visit
- Oil filter- Fuel filter- Air filter element- Spark plugs
- Engine oil (check + top-up)- Manual gearbox oil (check + top-up)- Battery (check + top-up) if removable cap- Coolant level (check + top-up)- Front windscreen wash (check + top-up)- Brake fluid (check + top-up)- Power steering fluid (check + top-up according to specification)
- Operation of lights and indicators- Condition of glass, headlamp and light lenses and mirrors- Horn- Condition of wiper blades- Windscreen jets- Condition and tension of the ancillary drive belts- Handbrake- Condition of hydraulic circuits (hoses and covers) and check for leaks- Condition of rubber boots and gaiters- Brake pad wear o- Play in hubs, link rods, ball joints, flexible mountings- Shock absorbers: check for leaks- Rear drum brake lining wear- Condition and pressure of tyres (including spare tyre)- Emission control check according to current legislation- Pollen filter (according to specification)o- Visual check of the whole vehicle by a PEUGEOT dealer
- Courtesy vehicle

All driving conditions. oIf there are specific conditions. * According to country.
DRAIN AND REFILL
REPLACE
LEVELS
CHECK
SERVICE*
ROAD TEST
TYPE A AND C SERVICES AND THE INTERMEDIATE VISIT
07-10-2002

YOUR 206 CC IN DETAIL57
Windscreen ,side windows
and footwells. Footwells.
These settings are recommended for cold climates. Centre and side vents.
This setting is recommended for hotclimates.
3. Air flow adjustment Turn the control from position 1to position 4to give a suffi-
cient air flow for comfort. 4. Air intake control
Outside air intake.
This is the position for normal use.
Recirculation of interior air.
This position prevents the entry ofunpleasant odours and fumes from theoutside and increases the speed ofheating.
As soon as possible, place the controlin the outside air position, otherwisethere is a risk of the windows mistingup.
5. De-icing the rear screen and the mirrors
With the engine running, pressing the button de-ices therear screen and the mirrors.
It switches off automatically afterapproximately twelve minutes. Pressing the button again starts it again for twelve minutes.
It is possible to stop the de-icing opera-tion by pressing the button before thetwelve minutes have elapsed.
Note: this function is disarmed when
the roof is stored in the boot.
07-10-2002

YOUR 206 CC IN DETAIL59
3. Air distribution adjustment
Windscreen and side win- dows (demisting/de-icing).
To quickly de-ice or demist the wind-screen and the side windows:
Ð place the temperature and air flow controls to maximum,
Ð close the central vents,
Ð place the outside air intake control to the left, in the "Outside air" posi- tion,
Ð operate the air conditioning
Windscreen, side windowsand footwells. Footwells.
These settings are recommended for cold climates.
Central and side vents.
This setting is recommended for hotclimates.
5. Air intake control
Outside air intake.
This is the normal operating position.
Recirculation of interior air.
This position prevents the entry ofunpleasant odours or fumes from theoutside. Used simultaneously with the air con- ditioning enables both the heating andcooling performance to be improved. Used without air conditioning, recir- culation may result in misting thewindows. As soon as possible, place the control in the outside air position. Important precaution Operate the air conditioning system for 5 to 10 minutes, once or twice amonth, to keep it in perfect working
order. If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.
4. Air flow adjustment
From position 1to position 4.
Turn the knob to obtain a suf-ficient flow of air to ensureyour comfort. 6. De-misting the rear screen and
the mirrors
With the engine running, press-ing the button de-mists the rear screen and the mirrors.
It switches off automatically afterapproximately twelve minutes. Press again to resume de-misting for twelve minutes. It is possible to stop the de-misting operation by pressing the button againbefore the end of the twelve minutes. Note: this function is disarmed when
the roof is stored in the boot.
07-10-2002

YOUR 206 CC IN DETAIL61
5.
Air distribution
Successive presses of this button allow the air flow to bedirected alternately to:
Ð the windscreen (demisting or de-icing),
Ð the windscreen and the footwells,
Ð the footwells,
Ð the central and side vents and the footwells,
Ð the central and side vents.
7. Air intake Press this button to recycle
the interior air. Recirculation,
shown on the display, pre-vents the entry of unpleasant
odours and fumes from the outside.
Avoid prolonged recirculation of the
interior air. To do this, press again toreturn the system to automatic pro-cessing of the air intake.
4. Air conditioning
Press this button to stop the
air conditioning. The "ECO"symbol lights up. Press againto return to automatic opera-
tion of the air conditioning. The "A/C"symbol is displayed. 8. Switching the system off
The "OFF" button enables theentire system to be switched
off.
Temperature-related comfort is nolonger guaranteed. Pressing the "OFF", "AUTO" or "Visi-
bility" button again reactivates the
system with the values set before it
was switched off.
9. De-icing the rear window
and the mirrors
Press this button to de-ice the rear screen and the mirrors.The de-icing system switches
off automatically. It is possible
to stop the de-icing before it switches
off automatically by pressing the but-ton again. Note: this function is disarmed when
the roof is stored in the boot. Important precaution Operate the air conditioning system for 5 to 10 minutes, once or twice amonth, to keep it in perfect working
order. If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.
* According to specification.
Manual operation
If you wish you can make a different
choice from the one offered by the sys-
tem, by changing a setting. The otherfunctions will still be managed automat-
ically. Press the "AUTO" button to returnto completely automatic operation.
6. Air flowThe air flow may beincreased or reducedby pressing the buttons
+ or Ð respectively.
Note
The condensation created by the air condi- tioning causes a normal flow of water
under the vehicle when it stops. To preventcondensation on the inside of the vehicle in
cold or wet weather, you are advised toavoid using the "ECO" mode.
07-10-2002

YOUR 206 CC IN DETAIL
76
AUTOMATIC SWITCHING ON OF LIGHTS Side lights and dipped beam head- lamps switch on automatically if thelight is poor and when the windscreen
wipers operate continuously.
They switch off when the light becomes bright enough or the wind-screen wipers stop. Note:
In foggy weather or in snow, the
brightness sensor can detect sufficient
light. As a consequence, the lights will
not come on automatically. This function is active when the vehi-
cle is supplied to the customer. To dis-arm or activate the function:
Ð Start with the key in the accessories
position (1st notch),
Ð Press the end of the stalk for more than four seconds.
Note: after the ignition is switched off
and depending on the brightness, the lights remain on for 45 seconds or untilthe vehicle is locked.
The brightness sensor, coupled with
the rain sensor, is located in the centre
of the windscreen, behind the interior
mirror. It is used for automatic switch-ing on of the lights. Operating check Activation Acivation of this function is accompanied by an audible signal and the message"Automatic lighting active''
on the mul-
tifunction display. Disarming Disarming of the function is accompa- nied by an audible signal. Note: the function is temporarily dis-
armed when the driver uses the manual lighting controls. If the brightness sensor does not
function correctly, the system acti-
vates the function (the lights come
on). The driver is alerted by an audiblesignal, accompanied by the message"Automatic switching on of lightsfaulty" .
Contact a PEUGEOT dealer to have thesystem checked.
07-10-2002

07-10-2002
YOUR 206 CC IN DETAIL
82
Manual interior mirror The interior mirror has two positions:
Ð day (normal),
Ð night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower edge of
the mirror. ELECTRIC EXTERIOR MIRRORS
Turn knob
1to the right or to the left to
select the corresponding mirror. Move knob 1in all four directions to
adjust. Fold-back electric mirrors With the ignition on, turn knob 1to
position A.
The outside of the mirror on the driver's side is con-vex (area at edge definedby dotted line) in order to
eliminate the 'blind spot'. Furthermore, objects in the driver's and passenger's mirrors are in
reality closer than they appear. This must be taken into account to judge correctly the distance ofvehicles approaching from behind.
