tow Peugeot 307 Break 2002 Owner's Manual

5YOUR 307 AT A GLANCE
STEERING WHEEL STALKS LIGHTS
Front and rear lights (ring A)Lights off. Side lights.
Dipped / main beam headlamps. Automatic switching on of lights.
Front fog lamps * and rear foglamp
Turn the ring forwards to switch
on and rearwards to switch off.
The on/off status is shown by theindicator light on the instrumentpanel.Vehicles fitted with a rear fog lamp (ring B) Rear fog lamp.
Vehicles fitted with front foglamps and a rear fog lamp(ring C) Front fog lamps (first rota-tion of the ring forwards).
Front fog lampsand rear fog lamp(second rotation ofthe ring forwards).
* According to specification
72
WINDSCREEN WIPERS Front 2 Rapid wipe (heavy rain).
1 Normal wipe (moderate rain).
AUTO Automatic wipe*.
0 Off.
Single wipe
Windscreen wash: pull the stalktowards you. Rear
Stop Intermittent wipe
Automatic wipe*In the AUTO position,
the wiper operates auto- matically and adjusts itsspeed to the intensity ofthe rainfall.
74
Windscreen

11YOUR 307 AT A GLANCE
AUTOMATIC GEARBOX "PORSCHE TIPTRONIC SYSTEM" The four speed automatic gearbox offers a choice between the comfort of
automatic integral regulation enhanced by a sport andsnow programme,
or the pleasure of manual gear changing .
Gear selection gate ➜ Move the lever in the gate to select one of the functions. Once the function is selected, the indicator light for that function illumi-
nates on the instrument panel display.
S: sport programme.

: snow programme.
P ark: for parking or for starting the engine ,
with the handbrake on or off.
R everse: to reverse; select this function with the
vehicle stationary and the engine at idle. N eutral: for starting the engine or forparking ,
with the handbrake on.Note: if function Nis engaged by mistake while the
car is moving, allow the engine to return to idling speed before engaging function Dto accelerate.
D rive: for automatic gear changing.
M anual: for manualgear changing.
To change the four gearsmanually:
➜ Push the lever to the +symbol to change up to the next gear and pull
the lever towards the - symbol to change down to the next gear.
Note: the Ssport and
snow programmes do not operate in manual
mode. Moving Off With the engine running, to move
off from position
P:
➜ It is essential to press the
brake pedal to exit position P,
➜ Select the required function(R ,D or M) then gradually
release the pressure on thebrake pedal; the vehicle will
move off immediately.
You can also move off from posi-tion N:
➜ Release the handbrake, withyour foot on the brake.
➜ Select the required function(R , D or M) then gradually
release the pressure on thebrake pedal; the vehicle will
move off immediately.
When the engine is idling with the brakes notapplied, if function R, D
or Mis selected, the
vehicle moves without the acce-lerator being pressed.
For this reason, do not
leave children unsuper- vised inside the vehi-cle, with the engine run-ning.
86

ARDUOUS CONDITIONS OF USE
¥ Continuous door-to-door use.
¥ Town use (e.g. taxi).
¥ Repeated short journeys, with the engine cold at low temperatures.
¥ A prolonged stay under the following conditions : Ð countries with temperatures often above +30 ¡C,Ð countries with temperatures often below -15 ¡C,Ð countries with a dusty atmosphere,Ð countries whose lubricants or fuels do not conform to our recommendations.
PEUGEOT SERVICING
24

Manual operation
If you wish, you can make a different
choice from that offered by the sys-
tem by changing a setting. The otherfunctions will still be controlled auto-
matically. Pressing the "AUTO" but-ton returns the system to completelyautomatic operation.
4. Air conditioningPressing this button
switches off the air conditio-
ning. The symbol "ECO" is
displayed. Automatic ope-
ration of the air conditioning is resu-med when the button is pressed
again. The symbol "A/C" is dis-played. Note: It is quite normal that the condensa- tion created by the air conditioningresults in a flow of water under the
vehicle when it is stationary. 5. Air distribution
Pressing this button severaltimes in successionenables the air flow to bedirected in turn towards:
Ð the windscreen (demisting or de- icing),
Ð the windscreen and the footwells,
Ð the footwells,
Ð the centre and side vents and the footwells,
Ð the centre and side vents.
6. Air flow
The flow of air can be increased or reducedby pressing buttons +
or Ð respectively.
7. Air intake Pressing this buttonenables the interior air tobe recirculated. Recircula-
tion, shown on the display,
enables the passenger compartmentto be insulated from exterior odoursand smoke.
Avoid prolonged recirculation of
interior air. To do this, press the but-ton again to resume intake of outside
air. 8. Switching the system off
The "OFF" button enablesthe entire system to be swit-
ched off.
9. Demisting the rear screen Pressing this buttondemists the rear screen andthe mirrors*. Demisting
switches off automatically. It is possible to stop opera-
tion of the demisting before it is swit-
ched off automatically by pressingthe button again. Note: the condensation created by
the air conditioning causes a flow of water under the vehicle when statio-nary which is perfectly normal.
* According to specification.
YOUR 307 IN DETAIL 57

FRONT SEATS
1. Forwards-backwards adjustmentLift the control and slide the seat forwards or backwards.
2. Access to rear seats (3 door) Pull the handle to fold the seatback and move the seat for-wards. On repositioning, the seat returns to its initial position.
Warning: no person or object
must prevent the seat from retur- ning to its initial position; a returnto this position is necessary forthe seat to lock in place.
3. Seat back angle adjustment Push the handle towards the rear.
4. Driver's* or passenger's* seat height adjustment* Pull the handle upwardsor push it downwards as many times asnecessary to obtain the requiredposition.
YOUR 307 IN DETAIL
58
* According to specification.

THE LIGHTS STALK Front and rear lights Selection is by turning ring A.
Lights off Side lights on Dipped/main beam headlamps Automatic switching on of lights* Dipped/Main beam change Pull the stalk fully towards you. Note:
with the ignition off, if the dri-
ver's door is left open, a buzzer sounds if you have left your lights on. Front fog lamps* and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The statusis confirmed by the light on the instru-ment panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This operates with the dipped/mainbeam headlamps.
Vehicles fitted with front fog lamps* and a rear fog lamp (ring C) Front fog lamps (first rota-tion of the ring forwards).
These operate with the side lightsand the dipped beam lamps. Front and rear foglamps (2nd rotation ofthe ring forwards).
These operate with the side lightsand the dipped/main beam head-lamps. Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring backwards twice in succession. Direction indicators (flashers)
Left : downwards.
Right : upwards.
*According to specification
YOUR 307 IN DETAIL
72
In good or rainy weather, both day and night, therear fog lamp is dazzlingand is prohibited.
Do not forget to switch the foglamp off when it is no longer needed.

Operation In position 1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, thenresumes its initial speed when thevehicle starts again. When the ignition has been swit- ched off for more than a minute
with the control in the AUTO posi-tion*, it is necesary to reactivatethis function.
To do this, move the control to any position, then move it back to the
AUTO* position.
Screenwash/headlamp wash* Pull the windscreen wiper stalk towards you. The windscreen wash then the wind- screen wipers operate simultaneous-ly for two seconds, only if the dip-
ped beam or main beam head-lamps are on.
YOUR 307 IN DETAIL
74
WINDSCREEN WIPER STALK Front windscreen wipers2 Fast wipe (heavy rain).
1 Normal wipe(moderately heavy rain).
AUTO Automatic wipe*
0 Off
Single wipes (press downwards)
Automatic timed windscreen wipers* In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the intensi-ty of the rainfall.
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wipers activated" appears on the
multifunction display. Switching off
Switching off the function is accom- panied by an audible signal. In the event of malfunction, the driver is informed by an audible signal andthe message "Automatic wind-
screen wipers faulty" on the multi-
function display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate intermittent mode.
Contact a PEUGEOT dealer to have the system checked.
* According to specification

YOUR 307 IN DETAIL85
BOOT LAYOUT 1 - Rear parcel shelf To remove the shelf: Ð unhook the two strings,Ð slightly raise the shelf, then remove it.There are several options for storing the shelf:Ð either behind the front seats,Ð or behind the rear seat.
2 - Hooks
3 - Stowing rings
4 - Luggage retaining net* Hooked onto the stowing rings, this enables your luggage to be secured.
5 - Open storage trays
6 - Socket for accessories* This is a 12 volt socket (lighter type), installed on the left side of the parcel shelf.
It is supplied with the ignition off.
*According to specification

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"Handbrake on" on the
multifunction display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight comes on, accompa-nied by an audible signaland the message
"Braking
fault" , indicates that there is
a malfunction of the electronic brakeforce distribution, which can cause aloss of control of the vehicle whenbraking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoevrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 IN DETAIL
88
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pressure to be
reached more quickly, thus reducingthe stopping distance. It is triggered by the speed at which the
brake pedal is activated, the effect ofwhich is a reduction in the resistance ofthe pedal and an increase in braking
efficiency.

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"Handbrake on" on the
multifunction display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight comes on, accompa-nied by an audible signaland the message
"Braking
fault" , indicates that there is
a malfunction of the electronic brakeforce distribution, which can cause aloss of control of the vehicle whenbraking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoevrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 IN DETAIL
88
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pressure to be
reached more quickly, thus reducingthe stopping distance. It is triggered by the speed at which the
brake pedal is activated, the effect ofwhich is a reduction in the resistance ofthe pedal and an increase in braking
efficiency.
