display Peugeot 406 Break 2002 User Guide

Display BThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or thebonnet is open and if the fuel filler cap is missing.
– the warning messages (e.g. ''battery low'') or information messages (e.g. "top up fuel tank''), displayed temporarily, can be cleared by pressing button 1or 2,
– the trip computer. Setting the parameters Press button 1for two seconds to access the settings. The information flashes
to show it is ready to be modified.Then, individual presses on button 1 allow you to scroll through the various data
in the following sequence:
– language in which the information is displayed,
– hour,
– unit of distance (kms or miles),
– unit of temperature (Celsius or Fahrenheit),
– time format (12 then 24 hour mode)
– minutes,
– year,
– month,
– day, Pressing button 2allows you to change the information selected. Maintain the
pressure for rapid scrolling.After ten seconds without moving, the display returns to the main screen and the modified data is recorded.
YOUR 406 IN DETAIL 137

Display CThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or the
bonnet is open,
– the warning messages are displayed temporarily (e.g. "top up fuel tank'') and can be cleared using the remote control,
– the trip computer (see following page),
– the satellite navigation system (see corresponding section). Setting the parameters
The remote control allows you to access the settings. Accessing the different menus is described in the section on the Satellite Navigation System.
YOUR 406 IN DETAIL
138

YOUR 406 IN DETAIL67
Adjusting the bass When "BASS" is displayed, press button For Gto vary the setting.
- "BASS -9" for a minimum bass setting,
- "BASS 0"for a normal setting,
- "BASS +9" for a maximum bass setting.
Adjusting the treble When " TREB" is displayed, press button For Gto vary the setting.
- "TREB -9" for a minimum treble setting,
- "TREB 0"for a normal setting,
- "TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low.Press button For Gto switch the function on or off.
Setting the front/rear sound distribution (Fader)When "FAD" is displayed, press button For G.
Button Fincreases the volume at the front.
Button Gincreases the volume at the rear.
Setting the right/left sound distribution (Balance)When "BAL" is displayed, press button For G.
Button Fincreases the volume on the right-hand side.
Button Gincreases the volume on the left-hand side.

YOUR 406 IN DETAIL69
Manual station search Press the "MAN"button.
Briefly press button Jor Kto increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.Pressing the "MAN"button again returns you to automatic station search.
Manual storing of stations in the memory Select the station required.Press one of the buttons "1"to "6" for more than two seconds.
The sound stops then becomes audible again, confirming that the
station has been stored in the memory. Automatic storing of FM stations in the memory (autostore)
Press button "BND/AST"for more than two seconds, to automatically store the 6 stations with the strongest
signal in FM. These stations are stored in the FMast waveband.
-If it is not possible to find 6 stations, the remaining memories are empty.
Recalling stations stored in the memory For each waveband, briefly press buttons "1"to "6" to recall the corresponding station.

YOUR 406 IN DETAIL
70
RDS Using the RDS (Radio Data System) function on FM Radio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through. Briefly press the "RDS"button to switch the function on or off.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.
Traffic information programme Press the "TA"button to switch the function on or off.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD changer).
If you wish to interrupt a message, press the "TA"button; this switches the function off.
Note: the volume of traffic information announcements is independent of the volume of normal radio listening. Youcan adjust it using the volume button. The setting will be stored and will be used when the next messages arebroadcast. Regional following mode When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode, you can keep listening to the same programme. Press the "RDS"button for more than two seconds to switch the function on or off.

Adjusting the bassWhen "BASS" is displayed, press button Hor Ito vary the setting.
-"BASS –9" for a minimum bass setting,
-"BASS 0" for a normal setting,
-"BASS +9" for a maximum bass setting.
Adjusting the treble When " TREB" is displayed, press button Hor Ito vary the setting.
-"TREB -9" for a minimum treble setting,
-"TREB 0"for a normal setting,
-"TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press button Hor Ito switch the function on or off.
Adjusting the front/rear sound distribution (Fader) When " FA D" is displayed, press button H or I.
Button Hincreases the volume at the front.
Button Iincreases the volume at the rear.
Adjusting the right/left sound distribution (Balance)When "BAL" is displayed, press button Hor I.
Button Hincreases the volume on the right-hand side.
Button Iincreases the volume on the left-hand side.
Automatic volume correction 'CAV'
This function enables the volume to be automatically adapted depending on the level of noise produced by the speed of the vehic le.
Press buttons Hor I to switch the function on or off.
YOUR 406 IN DETAIL 77

Manual station searchPress the "MAN" button.
Briefly press button Kor Lto increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency. The scrolling stops at the first station found as soon as the button is released.Pressing the " MAN" button again returns you to automatic station search.
Manual storing of stations in the memory Select the station required.Press one of the buttons "1" to " 6" for more than two seconds.
The sound stops then becomes audible again, confirming that the station has been stored in the memory. Automatic storing of FM stations in the memory (autostore) Press button B for more than two seconds, to automatically store the 6 stations with the strongest signal in
FM. These stations are stored in the FMast waveband.
-If it is not possible to find 6 stations, the remaining memories are empty.
Recalling stations stored in the memory For each waveband, briefly press buttons " 1" to " 6" to recall the corresponding station.
The list of the 6 stations stored in memory on the waveband is displayed each time one of the buttons " 1" to " 6" is pressed.
YOUR 406 IN DETAIL 79

RDS Using the RDS (Radio Data System) function on FMRadio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through. Briefly press the " RDS" button to switch the function on or off;
the display will show:
-"RDS" if the function is selected.
-"(RDS)" if the function is selected but not available.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.
Traffic information programme Press the "TA" button to switch the function on or off.
The display will show:
-" TA " if the function is selected,
-"(TA)" if the function is selected but not available.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD changer). If you wish to interrupt a message, press the " TA" button; this switches the function off.
Note: the volume of traffic information announcements is independent of the volume of normal radio listening. You can adjust it using the volume button. The setting will be stored and will be used when the next messages arebroadcast.
YOUR 406 IN DETAIL
80

Regional following modeWhen they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme. Press the "RDS" button for more than two seconds to switch the function on or off.
PTY function This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.).With FM selected, press the " TA" button for two seconds to switch this function on or off.
To search for a PTYprogramme:
-select the PTYfunction,
-briefly press button Kor Lto scroll down the list of the various types of pro-
grammes offered.
-when the programme of your choice is displayed, keep button Kor Lpressed for two seconds to carry out an automatic
search (after an automatic search the PTYfunction is switched off).
In PTY mode the different types of programmes can be stored in the
memory. To do this, press the preselection buttons " 1" to " 6" for more
than two seconds.
To recall the type of programme stored in the memory, briefly press the corresponding button.
EON system
This connects stations which are part of the same network. It enables the broadcast of traffic information by a station, which is part of the same network as the station to which you are listening.
This service is available when you have selected the TA traffic information programme or the PTYfunction.
YOUR 406 IN DETAIL 81

Adjusting the bassWhen "BASS" is displayed, press button Hor Ito vary the setting.
- "BASS –9" for a minimum bass setting,
- "BASS 0" for a normal setting,
- "BASS +9" for a maximum bass setting.
Adjusting the treble When "TREB" is displayed, press button Hor Ito vary the setting.
- "TREB –9" for a minimum treble setting,
- "TREB 0" for a normal setting,
- "TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press button Hor Ito switch the function on or off.
Adjusting the front/rear sound distribution (Fader) When "FAD" is displayed, press button Hor Ito vary the setting.
Button Hincreases the volume at the front.
Button Iincreases the volume at the rear.
Adjusting the right/left sound distribution (Balance) When "BAL" is displayed, press button Hor Ito vary the setting.
Button Hincreases the volume on the right-hand side.
Button Iincreases the volume on the left-hand side.
Automatic volume correction 'CAV'This function enables the volume to be automatically adapted depending on the level of noise produced by the speed of the vehicle. Press buttons Hor I to switch the function on or off.
YOUR 406 IN DETAIL 91
