PORSCHE 911 GT3 2010 5.G Owners Manual

230
Practical Tips, Emergency Service
Towing Certain state statutes and local ordinances
prohibit towing with a chain, rope or even a tow
bar.
In addition, damage to your vehicle may result
from improper procedures.
Consult your authorized Porsche dealer for
details. Vehicle towing Flat bed towing is the preferred type of towing to
be used on Porsche vehicles.
Under certain circumstances, wheel lifts may be
used when the vehicle will not roll.
The vehicle must be towed with all four
wheels off the ground, otherwise damage to
the vehicle may result.
Towing hook The towing hook A is contained in the tool box in
the luggage compartment.
Caution!
Risk of damage to the vehicle.
fUse the towing hook only for an emergency to
remove the vehicle off the road. The towing
hook is to be used only to pull the vehicle onto
the flat bed, tractor or towing aparatus if the
vehicle will roll freely. Under no circumstances
is the vehicle to be secured using the towing
hook.
fNever use the towing hook to tow this or any
other vehicle.
fBear in mind the limited ground clearance of your car on uneven surfaces.Fitting towing hook
When fitting on the rear of the vehicle, the license
plate must be removed.
1. Press the lower edge of the appropriate
plastic cover into the bumper until the cover
disengages.
2. Pull cover out of the bumper and let it hang by
its thread.
3. Completely screw in the towing hook A.
10_GT3_21.book Seite 230 Donnerstag, 4. Juni 2009 12:48 12

Practical Tips, Emergency Service
231
Removing towing hook
1. Unscrew the towing hook A.
2. Insert plastic cover at the lower edge of the
opening.
3. Fold the cover up and press on its upper edge
to engage it in the bumper.
When removing on the rear of the vehicle, the
license plate must be mouted.
Pulling vehicle onto flat bed 1. Position wooden ramps at the base of the flat
bed to reduce the angle of the pull.
2. Reel in the hoist cable and check the underside
of the vehicle for any interference.
Tying down vehicle on flat bed 1. Carefully feed towing straps through the
opening in the rear wheels.
Make sure metal parts of straps do not
damage rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not
damaged.
2. Secure straps to rear of flat bed.
3. Reel in hoist cable only far enough to tension
tie-down straps.
10_GT3_21.book Seite 231 Donnerstag, 4. Juni 2009 12:48 12

232
Practical Tips, Emergency Service 4. Carefully feed towing straps through the
opening in the front wheels.
Make sure metal parts of straps do not
damage rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not
damaged.
5. Secure straps to front of flat bed.
6. Release tension on hoist cable, but do not
disconnect.
Use hoist cable as a safety cable.
10_GT3_21.book Seite 232 Donnerstag, 4. Juni 2009 12:48 12

Vehicle Identification, Technical Data
233 Vehicle Identification, Technical Data
Vehicle Identification................................... 234
Technical Data ........................................... 236
Engine Diagram at full Power ...................... 242
10_GT3_21.book Seite 233 Donnerstag, 4. Juni 2009 12:48 12

234
Vehicle Identification, Technical Data
Vehicle IdentificationWhen ordering spare parts or making inquiries,
please always quote the vehicle identification
number. Vehicle data bankThe vehicle data bank is attached to the inside of
the “Maintenance” booklet.
It contains all important data about your vehicle.
Note
This data bank cannot be re-ordered if it is lost or
damaged.
This label contains the following information:
1. Vehicle Identification No.
2. Type/Type description
3. Engine code/Transmission code
4. Paint No./Interior
5. Optional equipment
Vehicle identification number In accordance with Federal Safety Regulations,
the vehicle identification number of your car is
located at the bottom left of the windshield frame
and can be seen from the outside.
The vehicle identification number is in the luggage
compartment under the battery cover and at the
bottom left behind the windshield.
Removing the battery cover
fPlease see the chapter “BATTERY” on
Page 211.
Safety compliance stickerThe safety compliance sticker is your assurance
that your new Porsche complies with all applicable
Federal Motor Vehicle Safety Standards which
were in effect at the time the vehicle was manuf-
actured.
The sticker also shows the month and year of
production and the vehicle identification number of
your car (perforations) as well as the Gross
Vehicle Weight Rating and the Gross Axle Weight
Rating.
10_GT3_21.book Seite 234 Donnerstag, 4. Juni 2009 12:48 12

Vehicle Identification, Technical Data
235
Tire pressure plateThe tire pressure plate is attached to the left-hand
door aperture.
Engine number The engine number is stamped on the underside
of the crankcase.
10_GT3_21.book Seite 235 Donnerstag, 4. Juni 2009 12:48 12

236
Technical Data
Technical DataEngine data Ty p e M 9 7 / 7 7
Horizontally opposed engine,
liquid cooled
Number of cylinders 6
Bore 4.04 in./102.7 mm
Stroke 3.01 in./76.4 mm
Cubic capacity 231.6 cu. in./3797 cm
3
Net-horsepower 435 hp/320 kW
at crankshaft speed 7600 rpm
Net torque 317 ft. lb./430 Nm
at crankshaft speed 6250 rpm
Engine oil consumption up to 1.5 liters/1000 km
(1.6 quarts/622 miles)
Maximum permitted engine speed 8500 rpm
Engine control Stationary high-voltage distribution, sequential injection,
cylinder-selective knock-control, stereo oxygen sensor closed-loop control, diagnostic system,
4 overhead camshafts, Porsche VarioCam, hydraulic valve clearance compensation
10_GT3_21.book Seite 236 Donnerstag, 4. Juni 2009 12:48 12

Technical Data
237
Transmission
Tire Pressures for cold tires 68 °F/20 °CThese tire filling pressures apply only to the tire makes and types approved by Porsche.
fPlease see the chapter “TIRES/WHEELS” on Page 184.
fPlease see the chapter “TPM TIRE PRESSURE MONITORING” on Page 134. 1st gear 3.82
2nd gear 2.26
3rd gear 1.64
4th gear 1.29
5th gear 1.06
6th gear 0.92
Reverse 2.86
Final drive ratio 3.44
Summer tiresfront 29 psi (2.0 bar)
rear 31 psi (2.1 bar)
Snow tiresfront 29 psi (2.0 bar)
rear 35 psi (2.4 bar)
10_GT3_21.book Seite 237 Donnerstag, 4. Juni 2009 12:48 12

238
Technical Data
Tires, Rims, Tracks
Tire Rim Rim offset Track
Summer tiresfront 235/35 ZR 19 (87Y) 8.5 J x 19 H2 53 mm 58.9 in./1497 mm
911 GT3 rear 305/30 ZR 19 (102Y) XL 12 J x 19 H2 63 mm 60.0 in./1524 mm
Snow tiresfront 235/35 R 19 87V M+S 8.5 J x 19 H2 53 mm
911 GT3 rear 295/30 R 19 100V XL M+S* 11 J x 19 H2 67 mm
The load capacity coefficient (e.g. “87”) and maximum speed code letter (e.g. “Y”) are minimum requirements.
Snow chainsCan be mounted only on the rear wheels; maximum speed 30 mph (50 km/h).
Use only Porsche authorized fine-link cross-type or edge chains.
Snow chain clearance can be guaranteed only on the tire + rim combination marked*.
Tire and rim sizesExtensive tests are performed before specific tires and wheels are approved by Porsche. Your Porsche dealer has informa-
tion about approved tires and wheels and is happy to assist you.
If aftermarket tires and/or wheels are installed which are not approved by Porsche, the vehicle’s driveability, stability while
in motion and handling characteristics might be impaired. Since Porsche has no data on such combinations, Porsche cannot
stand behind the safety or durability of these aftermarket combinations.
Danger!
Installation of sizes not authorized by
Porsche may have a dangerous effect on
the driving stability and could result in
severe personal injury or death.
fBefore mounting new tires, check with your Porsche dealer about the current release status.
10_GT3_21.book Seite 238 Donnerstag, 4. Juni 2009 12:48 12

Technical Data
239
CapacitiesUse only fluids and fuels authorized by Porsche. Your authorized Porsche dealer will gladly advise you.
Your Porsche has been designed so that it is not necessary to mix any additives with oils or fuels.
EngineOil change quantity without oil filter approx. 9.25 quarts / 8.75 liters
Oil change quantity with oil filter approx. 9.5 quarts / 9 liters
Please see the chapter “ENGINE OIL” on Page 159.
Coolantapprox. 7.9 U.S. gallons / 30 liters
Manual transmission
and differential
approx. 3.5 quarts / 3.3 liters transmission oil SAE 75W-90, Mobilube PTX
Fuel tank approx. 17.7 U.S. gallons / 67 liters
Fuel qualityYour engine is designed to provide optimum performance and fuel economy using
unleaded premium fuel with an octane rating of 98 RON (93 CLC or AKI).
Porsche therefore recommends the use of these fuels in your vehicle.
Porsche also recognizes that these fuels may not always be available. Be assured that your vehicle
will operate properly on unleaded premium fuels with octane numbers of at least 95 RON (90 CLC or AKI),
since the engine’s “Electronic Octane™ knock control” will adapt the ignition timing, if necessary.
Power steeringapprox. 1.35 quarts / 1.27 liter hydraulic fluid Pentosin CHF 11 S
® or Pentosin CHF 202
®
Brake fluid0.67 quarts / 0.63 liters; use only Original Porsche brake fluid.
Windshield washerapprox. 2.6 quarts / 2,5 liters without headlight washer
approx. 6.3 quarts / 6 liters with headlight washer
