PORSCHE CAYNNE 2013 2.G Information Manual

Comfort and transport | Comfor t · 102
101 · Comfort and transport | Comfor t
As a child, you went out whatever the weather.
Nothing has changed.
Climate control.
All Cayenne models are equipped with
climate control as standard. This system
provides independent control of the
temperature and air flow volume for
driver and front passenger as well as an
automatic air recirculation function with
an air qualit y and humidit y sensor. Other
features include an active carbon filter,
which excludes dust, pollen and external
odours.
Four-zone climate control.
Four-zone climate control provides
independent air conditioning for the
rear cabin area, with separate tempera -
ture controls for left and right. The
rear climate control settings can also
be adjusted from the front seats.
Optional for the Cayenne, Cayenne
Diesel, Cayenne S, Cayenne GTS and

the Cayenne Turbo.
Comfort lighting package.
Available as an option for all Cayenne
models, this package includes dimmable
ambient lighting in the door panels and
roof console, practical LED reading
lights for the rear passengers, additional
courtesy lights on the exterior mirrors
on the driver’s and front passenger’s
side, and a second 12-volt socket in the
rear centre console.
Optional for all Cayenne models.
Privacy glass.
Available as an option, dark-tinted glass
provides privacy for the rear seat and
luggage area.
Optional for all Cayenne models.
Heated windscreen.
Ultrafine heating filaments ensure that
the windscreen does not fog up and that
any ice quickly melts away.
Optional for all Cayenne models.
Heat and noise-insulating glass.
All Cayenne models are equipped as
standard with heat-insulating tinted glass
featuring a grey top tint on the windscreen.
As an optional alternative, heat and noise-
insulating laminated
glass offers addition-
al protection against infrared radiation.
Enjoy peace and quiet, and an even more
pleasant climate, in the passenger com
-
partment.
The heat and noise-insulating glass option
also includes privacy glass at the rear.
Optional for all Cayenne models.
Four-zone climate control for rear seat area Cayenne GTS with privacy glass

Comfort and transport | Comfor t · 104
103 · Comfort and transport | Comfor t
Inconspicuous. Unobtrusive. Indispensable.
Sunscreen.
To protect the interior against direct sun -
light, an electrically operated sunscreen
for the rear side windows is available as
an option. It can also be controlled from
the driver’s seat.
Optional for all Cayenne models.
Rain sensor.
The front wiper system has t wo fixed
speeds and an automatic rain sensor
function.
Washer fluid is delivered via t wo heated
jets, ensuring uniform coverage of the
entire windscreen area. The rear wiper system is designed for
maximum visibility in all conditions.

Porsche Entry & Drive.
With Porsche Entry & Drive, you can
avoid the inconvenience of using a
conventional key.
To enter the car, simply touch the door
handle and the system automatically
checks the encrypted access code on
the key in your pocket. If the code is
accepted, the doors are unlocked and
you can step inside. To start or stop the
engine, simply turn the key in the ignition.
When you leave the car, all you have to
do is press a but ton on the outside of the door handle. Porsche Entry & Drive
then locks the car, arms the immobiliser
and locks the steering column.
Optional for all Cayenne models.

Anti-theft protection.
The Cayenne models are all equipped as
standard with an engine immobiliser and
anti-theft alarm featuring ultrasonic inter
-
ior surveillance.
The alarm circuit includes all four doors,
bonnet, tailgate, rear screen, interior,
ignition and trailer (if fit ted). The immobiliser system works by auto
-
matically communicating with the vehicle
key. If the key is approved, the engine
can be started as normal.
When the key is removed from the igni -
tion, the steering column is automatically
locked to provide additional securit y.

Preparation for Porsche Vehicle
Tracking System (PVTS).
This preparation enables future installa -
tion of the Porsche Vehicle Tracking
System (PVTS) obtainable from Porsche
Tequipment. PV TS can be used to locate
a stolen vehicle in 25 EU countries as
well as Norway, Switzerland and Russia –
irrespective of where you live.
Porsche Vehicle Tracking System (PV TS) with GPS tracking in the event of an alarm
The vehicle is not tracked continually,
only when the alarm is triggered. In the
event of vehicle theft or manipulation, or
if the loss of the vehicle is reported by
the owner, a silent alarm is automatically
triggered. The package includes a spe -
cial wiring loom, higher capacit y bat tery
(depending on vehicle specification) and
tilt sensor for the alarm system.
Optional for all Cayenne models.

Comfort and transport | Comfor t · 106
105 · Comfort and transport | Comfor t
Explore the world.
In every direction.
Electric slide/tilt sunroof.
The electric slide/tilt sunroof is made
from tinted single-pane safet y glass and
features a manually adjustable sunscreen
and remote closing function. It is oper -
ated using a control located on the roof
console. As with all electric windows, an
anti-jam facilit y is included – for added
safety.
Optional for all Cayenne models.
Panoramic roof system.
With a total surface area of approxi mately
1.4 square metres, the panoramic roof
system is almost four times as large as
the optional slide/tilt sunroof. It consists
of t wo glass segments. Even when closed,
it provides a unique ‘open-top’ driving
experience. The panoramic view can be
enjoyed from all seat positions in every
t ype of weather. The forward segment
can be opened or tilted upwards. An ad-
ditional sunscreen protects the interior
against direct sunlight.
Optional for all Cayenne models.
Electric slide/tilt sunroof Panoramic roof system

Comfort and transport | Driver assistance systems · 108
107 · Comfort and transport | Driver assistance systems
Seeing and being seen.
It’s all about having the right technology.
Driver assistance systems.
ParkAssist.
This parking aid uses an acoustic signal
and front /rear displays to alert the
driver of any obstacles at the front or
rear of the car. Its sensors are neatly
concealed in the front and rear aprons.
The acoustic signal is supplemented
by a visual warning in the centre console
display which provides a graphical r ep-
resentation of the vehicle’s proximit y to
obstacles.
Standard on the Cayenne Turbo.
Optional for all other Cayenne models.
Reversing camera.
The reversing camera facilitates reverse
parking and manoeuvring and also
assists with hitching a trailer. Help is
provided in the form of a high-contrast
colour image with dynamic guidelines
on the PCM screen, which show the pre -
dicted course of the vehicle based on the
current position of the steering wheel.
The ParkAssist visual proximity indicator
is also shown in the central display.
Optional for all Cayenne models.
Automatically dimming mirrors.
Another comfort-oriented feature:
automatically dimming exterior and
interior mirrors.
Standard on the Cayenne Turbo.
Optional for all other Cayenne models.
Cruise control.
Cruise control automatically regulates
the speed of your vehicle for added
driver comfort on longer journeys. It
can be used at speeds bet ween 30
and 240 km/ h and is operated using a
button on one of the control stalks.
Standard on all Cayenne models.
Reversing camera Reversing camera display in PCM

Comfort and transport | Driver assistance systems · 110
109 · Comfort and transport | Driver assistance systems
Lane Departure Warning (LDW).
Activated and deactivated via a button in
the centre console, the Lane Departure
Warning
system uses a camera to iden -
tify
both lane markings and operates
at speeds in excess of 65 km/ h. If the
vehicle is threatening to stray outside the
lane, an acoustic warning signal sounds.
If Lane Departure Warning is activated,
this is indicated in the multi-purpose
d isp lay.
Optional for all Cayenne models.
Lane Change Assist (LCA).
Lane Change Assist (LCA) monitors the
area behind the vehicle and the blind
spot using radar sensors. At speeds
bet ween 30 and 210 km/ h, the system
alerts the driver of a vehicle in the blind
spot or approaching quickly from behind
via a visual signal from the exterior mir -
rors. This enhances comfort and safet y,
particularly when driving on the motor -
way. However, LCA does not actively
intervene in the controlling of the vehicle
and can be deactivated at any time.
Optional for all Cayenne models.
Lane Departure Warning (LDW) Lane Change Assist (LCA)

Comfort and transport | Driver assistance systems · 112
111 · Comfort and transport | Driver assistance systems
Speed limit indicator.
The speed limit indicator informs the
driver about speed restrictions, restric -
tions on overtaking and when these
no longer apply, which is recorded using
a camera.
Information is shown on the colour TFT
display in the instrument cluster and
via PCM. If the driver misses a traffic
sign – e.g. due to heav y rainfall or
darkness – the speed limit stored in
the navigation module is automatically
displayed.
This leaves the driver free to focus on
the road ahead.
Optional for all Cayenne models.
Speed limit indicator
Adaptive cruise control with
Porsche Active Safe (PAS).
Optional on all Cayenne models, adaptive
cruise control regulates the speed of your
vehicle in line with that of the ve hicle in
front. To do that, the system uses a radar
sensor in the central air intake to monitor
the road up to 200 m ahead.
If you approach another vehicle that is
travelling slower than your selected
cruising speed, the system slows the
engine or gently applies the brakes.

This continues until the distance that
you have preset is maintained. If heavier
braking is required, the driver has to

actively intervene. Your vehicle will
now follow the one in front at a reduced
speed.
If the other vehicle decelerates further,
adaptive cruise control will continue to
reduce your speed – even down to a halt.
When the road ahead is free once more,
the car automatically returns to your
selected cruising speed between 30 and
210 km/ h. To pull away after an auto -
matic stop, simply use the control lever
or depress the accelerator pedal.
If selected by the driver, the integrated
Stop & Go function automatically applies
the brakes and then drives off again in
congested traf fic.
For added safet y, the system also
features integrated Porsche Active Safe
(PAS). The system visually and audibly
alerts the driver in the event of a sudden
decrease in distance and briefly tugs
on the brakes. It can also intervene in
the braking process and apply increased
braking pressure through to all- out emer -
gency braking, if required.
Optional for all Cayenne models.
Adaptive cruise control

Comfort and transport | Tra n s p o rt · 114
113 · Comfort and transport | Tra n s p o rt
The Cayenne models.
For when you need to pack in a whole lot more.
Transpor t .
The Cayenne brings a new facet to the
concept of high performance. And it ’s
extremely versatile too.
Luggage compartment.
The Cayenne models have a spacious
passenger area and, thanks to the adjust -
able rear bench, a large versatile luggage
compartment. With a total volume of
670
litres1) (VDA), it offers more than
enough space for up to six suitcases
–
depending on the size. Other standard
features include an easily accessible
meshed storage compartment on the
left and a practical load-through facilit y
when the centre section of the rear
bench is folded down. An automatic tailgate is available as an
option. A separate but ton on the driver’s
side can be used to open and close the
tailgate. For practical convenience, the
opening height can be adjusted and set
to the height of your garage.
With the rear seats folded, the loadspace
expands to as much as 1,780 litres.
2), 3)
Items can be stored out of view and pro -
tected from the sun using a retractable
cover with detachable storage cassette.
A handy ski bag is available as an option.
As well as protecting the interior of your
Cayenne, it can be used to transport
your skis to and from the car. For added
practicalit y, the ski bag is also washable. Even when the car is fully laden, the
self-levelling air suspension on the
Cayenne Turbo (optional on all other
models) maintains a constant ground
clearance at front and rear.
For greater convenience, the air sus
-
pension package includes ride-height
control, enabling the car to be lowered
below the normal ride level (Loading
Level) for easier loading of heav y items.
When moving off, the suspension
automatically reverts to the standard
ride-height setting (Normal Level).
Ski bag Loading option
1) Cayenne S Hybrid: 580 litres.2) With spor ts seats: 1,705 litres.
Cayenne S Hybrid: 1,690 litres.
3) In conjunction with comfort memory package.

Comfort and transport | Tra n s p o rt · 116
115 · Comfort and transport | Tra n s p o rt
Roof rails.
The high-quality roof rails in aluminium
blend harmoniously with the dynamic
design of the vehicle. The st yling of the
roof is further enhanced by a set of three
drip rails included in the package. The
roof rails are required for fitment of the
optional roof transport system and come
in a high-gloss black finish as part of
the monochrome black exterior package.
Only available as a factory-fit ted option.
Optional for all Cayenne models.
Roof transport system.
Even when the luggage compartment is
completely full, the Cayenne has space
for more. In conjunction with the optional
roof rails, the car can be equipped with
a set of lockable transverse roof bars for
all the usual load-carrying attachments
from Porsche. The load-bearing parts are
made from aluminium and enable a max -
imum roof load of 100 kg. Load- carrying
attachments are available from Porsche
Tequipment.
Optional for all Cayenne models.
Roof rails/drip rails with black finish incl. roof transpor t system
Roof rails/drip rails with mat t Aluminium Look finish incl. roof transpor t system

Comfort and transport | Tra n s p o rt · 118
Loadspace management system.
This facilit y enables you to partition the
luggage compartment and secure
indi-
vidual objects during transit using a rail
system with sliding telescopic bar, a

fixing belt and four variable lashing eyelets.
A reversible mat protects
against dir t
while securing luggage under braking, etc.
The package also includes a loadspace
partition net which provides additional
safet y when the car is fully laden. The
partition at taches to one of t wo easily
accessible points on the rooflining.
Optional for all Cayenne models.
Towbar systems.
For the largest of loads, you can choose
from t wo towing options: an electrically
deployable towbar system or a manually
detachable towbar. With the electric
system, the ball neck is retracted at the
push of a but ton and concealed beneath
the rear apron. Both options have a
13-pin socket and offer a maximum
braked trailer load of 3,500 kg (2,700 kg
on the Cayenne with manual gearbox)
or an un braked load of 750 kg, with a
maximum noseweight of 140 kg. Both
systems are also available for future
installation. All models have a towbar
preparation as standard.
Optional for all Cayenne models.
117 · Comfort and transport | Tra n s p o rt

Personalisation
Looking for that lit tle bit more?
Or something different?
Create a Porsche Cayenne that
reflects your own individual st yle.
