Vehicle Identification, Technical Data
371
CapacitiesUse only fluids and fuels authorized by Porsche. Your authorized Porsche dealer will be pleased to advise you.
Your Porsche has been designed so that it is not necessary to mix any additives with oils or fuels.1 Depending on equipment levelEngine oil change quantity without oil filter
approx. 8.5 quarts (8.0 liters)
Engine oil change quantity with oil filter approx. 9.0 quarts (8.5 litres)
Reference indication is the level on the oil dipstick.
Please observe the chapter “ENGINE OIL LEVEL” on Page 252.
Coolant
1)
approx. 4.8 – 5.5 U.S. gallons (18 - 21 liters)
Automatic transmission with torque converter approx. 10.6 quarts (10.0 liters)
Tr a n s f e r b o x
approx. 0.9 quarts (0.85 liter)
Front-axle differential approx. 1.1 quarts (1.0 liter)
Rear-axle differential
approx. 1.5 quarts (1.4 liters)
Locking rear differential approx. 1.7 quarts (1.6 liters)
Fuel tank
approx. 26.4 U.S. gallons (100 liters),
including approx. 3 U.S. gallons (12 liters) reserve
Fuel quality The engine is designed to provide optimum performance and fuel consumption if unleaded premi-
um fuel with 98 RON/88 MON is used.
If unleaded premium fuels with octane numbers of at least 95 RON/85 MON are used, the engine's
“Electronic Oktane™ knock control“ automatically adapts the ignition timing.
Power steering
approx. 1.6 quarts (1.5 liters) Pentosin CHF 11 S
®
Brake fluid approx. 1.0 quart (0.95 liter)
Use only Original Porsche brake fluid.Window/headlight washer system
approx. 7.9 quarts (7.5 liters)
Page 372 of 387
372
Vehicle Identification, Technical Data
Weights1)Empty weight includes 165 lbs. (75 kg) driver and baggage share.2)The maximum gross weight must not be exceeded.
Note: If additional equipment is installed, the useful load will be correspondingly less.3)Use only Original Porsche Roof Transport System. Empty weightEmpty weight (depending on equipment)per DIN 70020 5192 - 5875 lbs. (2355 - 2665 kg)per 70/156/EWG
1)
5357 - 6040 lbs. (2430 - 2740 kg)
Maximum axle load, front
2)
3285 lbs. (1490 kg)
Maximum axle load, rear
2)
3748 lbs. (1700 kg)
Maximum gross weight 6790 lbs. (3080 kg)
Trailer operation Canada/USAMaximum gross weight 6790 lbs. (3080 kg)Maximum axle load, front/rear axle
3285/3968 lbs. (1490/1800 kg)
Roof load
Maximum roof load
3)
when roof rail is fitted
3)
225 lbs (100 kg)
165lbs. (75kg)
Towing capacity/vehicle + trailer weight
Maximum towing capacity, braked (up to a max. 12% slope)
7716 lbs. (3500 kg)
Maximum towing capacity, unbraked 1654 lbs. (750 kg)
Maximum vehicle + trailer weight
14506 lbs. (6580 kg)
Maximum trailer hich load 617 lbs. (280 kg)
Page 373 of 387
Vehicle Identification, Technical Data
373
Driving PerformanceThe specifications refer to a vehicle at DIN empty weight and max. 441 lbs. load or 200 kg, without performance-inhibiting extra equipment (e.g. special tires)
Cayenne Turbo Increased performance
Cayenne TurboTo p t r a c k s p e e d
165 mph (266 km/h)
168 mph (270 km/h )
Acceleration 0 - 62 mph (100 km/h) 5.6 seconds 5.3 seconds
Maximum speed when driving with a trailer
50 mph (80 km/h)
50 mph (80 km/h)
Page 374 of 387
374
Vehicle Identification, Technical Data
DimensionsLength
188.4 in. (4786 mm)
Length with external spare wheel 197.7 in. (5021 mm)
Width
75.9 in. (1928 mm)
Height at DIN empty weight66.9 in. (1699 mm)
Height at DIN empty weight (rail)
68.5 in. (1741 mm)
Height at DIN empty weight (basic carrier of Roof Transport System) 70.4 in. (1789 mm)
Height at DIN empty weight
with rear lid open
87.4 in. (2219 mm)
Max. wading depth 22 in. (555 mm)
Tr a c k18" front 64.8 in. (1647 mm)18" rear
65.4 in. (1662 mm)
19" front 64.6 in. (1641 mm)
19" rear
65.2 in. (1656 mm)
20" front 64.6 in. (1641 mm)
20" rear
65.2 in. (1656 mm)
Wheelbase112.4 in. (2855 mm)
Overhang, front
36.5 in. (927 mm)
rear 39.5 in. (1004 mm)
Turning circle
468.5 in. (11.9 m)
Page 375 of 387
Vehicle Identification, Technical Data
375
Ground ClearanceAir suspension – normal levelRamp angle
20.4°
Overhang angle, front 29.1°
Overhang angle, rear
24.8°
Ground clearance (center of axles) 8.5 in. (217 mm)
Air suspension – low levelRamp angle 17.7°Overhang angle, front
27.3°
Overhang angle, rear 22.8°
Ground clearance (center of axles)
7.5 in. (190 mm)
Air suspension – loading level
Ramp angle
14.9°
Overhang angle, front 24°
Overhang angle, rear
20.9°
Ground clearance (center of axles) 6.2 in. (157 mm)
Air suspension – terrain levelRamp angle 22.2°Overhang angle, front
30.7°
Overhang angle, rear 25.7°
Ground clearance (center of axles)
9.6 in. (243 mm)
Page 376 of 387
376
Vehicle Identification, Technical Data
Air suspension – special terrain levelRamp angle 24.7°Overhang angle, front
32.4°
Overhang angle, rear 27.3°
Ground clearance (center of axles)
10.7 in. (273 mm)
